MPLAB ICD 3 In-Circuit Debugger User's Guide
9.3

DEBUGGING DIALOGS/WINDOWS

Open the following debug dialogs and windows using the menu items mentioned in
Section 9.2 "Debugging Functions".
• Breakpoints Dialog
- Set Breakpoint Dialog
- Stopwatch Dialog
- Event Breakpoints Dialog
- Sequenced Breakpoints Dialog
- ANDed Breakpoints Dialog
9.3.1
To set up breakpoints, select Debugger>Breakpoints.
Set up different types of breakpoints in this dialog. Click on Add Breakpoint to add
breakpoints to the dialog window. Depending on your selected device, there may be
other buttons for more advanced breakpoint options.
9.3.1.1
Information about each breakpoint is visible in this window.
TABLE 9-1:
Breakpoint Type
Address
File Line #
Enabled
Once a breakpoint has been added to the window, you may right click on it to open a
menu of options:
• Delete – delete selected breakpoint
• Edit/View – open the Set Breakpoint Dialog
• Delete All – delete all listed breakpoints
• Disable All – disable all listed breakpoints
DS51766A-page 68
Breakpoints Dialog
BREAKPOINT DIALOG WINDOW
BREAKPOINT DIALOG WINDOW
Control
Type of breakpoint – program or data
Hex address of breakpoint location
File name and line number of breakpoint location
Check to enable a breakpoint
Function
