Page 1: User Manual
Vertrieb von CAMBOARD Electronics K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: TP-576 HDMI/CAT 5 Line Driver P/N: 2900-000760 Rev 4 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... - Page 2 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
-
Page 3: Table Of Contents
Kramer Protocol 2000 Figures Figure 1: TP-576 HDMI/CAT 5 Line Driver Figure 2: Connecting the TP-576 HDMI/CAT 5 Line Driver Figure 3: TP-576 RS-232 Signals Figure 4: TP-576 IR Control – Example I Figure 5: TP-576 IR Control – Example II Figure 6: TP-576 IR Control –... -
Page 4: Introduction
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer TP-576 HDMI/CAT 5 Line Driver, which is ideal for the following typical applications: ... -
Page 5: Getting Started
This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. You must use shielded twisted pair (STP) cabling with the TP-576, (refer to Section 3.1 for further details). -
Page 6: Safety Instructions
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
CAMBOARD Electronics Overview The TP-576 is a twisted pair line driver for HDMI, bidirectional RS-232 and infrared signals. The TP-576 receives an HDMI signal either from a local HDMI source or from a transmitter (for example, the Kramer TP-573) via the LINE IN RJ-45 connector. -
Page 8: Using Twisted Pair Cable
LEDs indicating the selected input and active output LED indicators The TP-576 is 12V DC fed and is housed in a MegaTOOLS® enclosure where two units can be rack mounted side-by-side in a 1U rack space with the optional RK-T2B rack adapter. -
Page 9: Defining The Tp-576 Hdmi/Cat 5 Line Driver
RS-232 9-pin D-sub Connector Connects to a PC or other controller REMOTE IR 3.5mm Mini Jack Connects to an infrared receiver/emitter Compatible with a Kramer transmitter and via a Kramer external remote IR receiver: C-A35M/IRR or C-A35M/IRE or C A35M/2IRE 12V DC... -
Page 10: Connecting The Tp-576
2. The CAT 5 or CAT 6 cable from the TP-573 to the INPUT 2 RJ-45 twisted pair connector (to power the TP-576 as well as the TP-573 and TP-574). 3. An IR sensor or emitter to the REMOTE IR 3.5mm mini jack connector (see Section 4.2). - Page 11 Alternatively, you can connect an RS-232 controllable device to the RS-232 port of the TP-573 and a PC to the RS-232 port of the TP-574. 4. The CAT 5 or CAT 6 cable from the TP-576 to the LINE IN RJ-45 twisted pair connector.
-
Page 12: Figure 2: Connecting The Tp-576 Hdmi/Cat 5 Line Driver
Vertrieb von CAMBOARD Electronics Figure 2: Connecting the TP-576 HDMI/CAT 5 Line Driver TP-576 - Connecting the TP-576 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... -
Page 13: Connecting To The Tp-576 Via Rs-232
To connect to the TP-576 via RS-232, connect the RS-232 9-pin D-sub rear panel port on the TP-576 unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub port on your PC. -
Page 14: Operating The Tp-576
TP-574. For example, a PC connected to the RS-232 port on the TP-573 can control an RS-232 controllable device on the TP-574. You can connect a PC to the RS-232 port on the TP-576 via a straight connection (see Section 5.1) to control the TP-576 only. -
Page 15: Controlling Via Infrared
Point the LCD display remote controller either to the IR sensor of the TP-573 or the IR receiver window of the TP-576 to control the LCD display. Point the Kramer remote controller to IR receiver window of the TP-576 to control the TP-576. -
Page 16: Figure 5: Tp-576 Ir Control - Example Ii
TP-576. Once an IR emitter is connected to the IR REMOTE 3.5mm mini jack connector, IR control on the TP-576 becomes local. Point the Kramer remote controller to the IR receiver window of the TP-576 to control the TP-576. TP-576 - Operating the TP-576 www.camboard.de... -
Page 17: Figure 6: Tp-576 Ir Control - Example Iii
Vertrieb von CAMBOARD Electronics Figure 6: TP-576 IR Control – Example III TP-576 - Operating the TP-576 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... -
Page 18: Wiring The Tp Line In / Line Out Rj-45 Connectors
Figure 7: TP PINOUT EIA /TIA 568B Wire Color Orange / White Orange Green / White Blue Blue / White Green Brown / White Brown TP-576 - Operating the TP-576 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... -
Page 19: Acquiring The Edid
Once acquired, the EDID is saved in non-volatile memory and further acquisition is not necessary. Initially, the TP-576 operates with the factory default EDID. This lets you connect the power before connecting one of the acceptors or sources. -
Page 20: Disabling/Enabling Deep Color Support
2. Connect the output or outputs from which you want to acquire the EDID. 3. Connect the power while pressing the INPUT SELECT button. 4. Perform steps 3 and 4 in Section 5.4. TP-576 - Operating the TP-576 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... -
Page 21: Default Edid
1280 x 1024p at 75Hz - VESA 1280 x 1024p at 60Hz - VESA STD 1600 x 1200p at 60Hz - VESA STD 1152 x 864p at 75Hz - VESA STD TP-576 - Default EDID www.camboard.de Tel. 07131 911201 ce-info@camboard.de... -
Page 22: Technical Specifications
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95"), W, D, WEIGHT: 0.3kg (0.67lbs) approx. ACCESSORIES: 12V DC 2.1A power supply, bracket installation kit RK-3T 19” rack mount, Kramer remote external receiver, OPTIONS: C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE Specifications are subject to change without notice at http://www.kramerelectronics.com TP-576 - Technical Specifications www.camboard.de... -
Page 23: Default Communication Parameters
Default Communication Parameters RS-232 Protocol 2000 Baud Rate 9600 Data Bits Stop Bits Parity None Command Format Example (Output 1 to Input 1) 0x01, 0x81, 0x81, 0x81 TP-576 - Default Communication Parameters www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203... -
Page 24: Kramer Protocol 2000
For a single machine controlled using the serial port, always set M4…M0 = 1, and make sure that the machine itself is configured as MACHINE NUMBER = 1. Note: All values in the table are decimal, unless otherwise stated. TP-576 - Kramer Protocol 2000 www.camboard.de Tel. 07131 911201 ce-info@camboard.de... - Page 25 “video” commands have universal meaning. For example, instruction 1 (SWITCH VIDEO) will cause all units (including data, etc.) to switch. Similarly, if a machine is in “FOLLOW” mode, it will perform any “video” instruction. TP-576 - Kramer Protocol 2000 www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
- Page 26 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
- Page 27 Vertrieb von CAMBOARD Electronics For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com...
