DREAMS VALENCIA Assembly Instructions

Single bed (guest unit)

VALENCIA SINGLE BED (GUEST UNIT)

Assembly Instructions

Caution when unpacking the

guest unit. The legs are spring

loaded and if opened without due

care can cause injury.

NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that

the bed will be used in.

Before you

Start, here

is some

helpful advice

1. We suggest you spend a short time reading through this leaflet and then

follow the simple step by step instructions.

2. If you follow the instructions carefully the end result should be worth the effort.

3. Do not discard any of the packaging until you have checked that you

have all the parts and the pack of fittings.

4. Assemble this product on a carpet.

5. To ensure an easier assembly, we strongly advise that all fittings are only

finger tightened during initial assembly. Only upon completion of the assembly

should all fixing points be fully tightened.

6. We recommend a periodic check on all fixing points to make sure they remain

fully tightened.

7. Keep glue and fittings out of children's reach.

In the unlikely event that this product has missing or damaged parts, please call

0870 3333 612

to obtain spares

1 of 5

Table of Contents

Need help?

Do you have a question about the VALENCIA and is the answer not in the manual?

Page 1 VALENCIA SINGLE BED (GUEST UNIT) Assembly Instructions Caution when unpacking the guest unit. The legs are spring loaded and if opened without due care can cause injury. NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that the bed will be used in.
Page 2 Component parts and fittings contained in the box PARTS Fittings Connector 4pcs 1 piece Connecting bolt 4pcs 2 pieces M6 x35mm 6pcs 1 piece Spanner 1 piece M8 Nut 4pcs 8 Spring Washer 4pcs JCN Nut 6pcs 4MM Allen key 1pc 10x40 Dowel 8pcs 2 of 5...
Page 3 ASSEMBLY Screw the connecting bolt “B” into the STEP 1 headboard “1”and footboard “2”. 1) Knock the dowels “I” into the holes STEP 2 indicated on the side rail “3”. 2) Carefully fit the side rail to the head&foodboard . Use connectors “A”, spring washer “F”...
Page 4 ASSEMBLY STEP 3 To store the Guest bed under the single bed, first ensure that the legs are retracted, before sliding the Guest bed under the single bed. (see inset) 4 of 5...
Page 5 ASSEMBLY NOTE: Slats not supplied shown for STEP 4 reference only. Both slats on “step4-5” can be assembled to the bedstead.you can to make a choice beteen the two slats. 1) Carefully locate the slats frame onto the bed. 2) Use bolt “C” and Jcn nut “G” to fix the slats frame onto the bed.
