COLORADO BUNK BED
Assembly Instructions
IMPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE
693mm
780mm
Minimum No. of people
recommended to assemble
this product:
Approx assembly time:
Do not throw away any of the packing or the instruction book until you have checked all the
components and fittings and the furniture is fully assembled.
In the unlikely event that this product has missing or damaged parts, please call 0870 3333 612 to
obtain spares.
2030mm
2
1
2
/
2
hours
Page 1 of 8
413-00146
Date: 09-10-2008
1035.5mm
Colorado bunk bed
Advertisement
Table of Contents
Related Manuals for DREAMS 413-00146
Summary of Contents for DREAMS 413-00146
- Page 1 COLORADO BUNK BED 413-00146 Date: 09-10-2008 Assembly Instructions IMPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE 693mm 780mm 2030mm 1035.5mm Minimum No. of people recommended to assemble this product: Approx assembly time: hours Do not throw away any of the packing or the instruction book until you have checked all the components and fittings and the furniture is fully assembled.
- Page 2 Components parts and fittings contained in the box Please sort out all parts before you begin to assemble the item. This to make sure you always use the correct part. Fittings A 29 pcs. Dowel - Ø10 x 40mm B 22 pcs. Barrel nut - M6 x 13mm C 1 pc.
- Page 3 Key diagram and tools needed. Key diagram. Tools needed. Knock the dowels "A" into Step 1 the holes indicated on the side rails "4" and the side panels "5", "6", "7" and "8". Page 3 of 8 Colorado bunk bed...
- Page 4 Assembly Press the side "12" and Step 2 "13" onto the steps "14" as indicated. Fix the sides using screws "I" into the holes indicated. Fix the side rails "4" and Step 3 the side panels "5" and "7" to the headboard "2" and the side rails "4"...
- Page 5 Assembly Step 4 Fix the headboard "3" onto the side rails "4" and the side panels "5" and "7" and the side rails "4" to the remaining headboard "1" using bolts "D" and barrel nuts "B" as shown. Tighten the bolts using the allen key "C".
- Page 6 Assembly Knock the dowels "E" into Step 6 the holes indicated on the headboards "1". Place the upper bed as shown. Secure the assembly Step 7 using screws "F" into the holes indicated. Page 6 of 8 Colorado bunk bed...
- Page 7 Assembly Fix the ladder onto the Step 8 side rails "4" using screws "H". Tighten the screws using the allen key "I" Place the side panels "6" Step 9 and "8" onto the headboard "2" and the ladder and fix them onto the ladder using screws "H".
- Page 8 Assembly Dear customer. IMPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE This product complies with BS EN 747 - 1 : 2007 & BS EN 747 - 2 : 2007 The top surface of the mattress must not be above the line marked on the frame. (Max.
