CORDOVA KING BED
Assembly Instruction
Minimum No.of people
recommended to assemble
this product
Approx assembly time
Before you
start,here
is some
helpful advice
1.
We suggest you spend a short time reading through this leaflet and
then follow the simple step by step instructions.
2.
If you follow the instructions carefully the end result should be worth
the effort.
3.
Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4.
To ensure an easier assembly, we strongly advise that all fittings are
only finger tightened during initial assembly. Only upon completion of
the. Assembly should all fixing points be fully tightened.
5.
We recommend a periodic check on all fixing points to make sure they
remain fully tightened.
6.
Keep glue and fittings out of children's reach.
7.
In the unlikely event that this product has missing or damaged parts,
please call 08442 920000 to obtain spares
Page 1 of 6
225-00135 (Solid slats)
225-00136 (Sprung slats)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DREAMS 225-00135
Summary of Contents for DREAMS 225-00135
- Page 1 225-00135 (Solid slats) CORDOVA KING BED 225-00136 (Sprung slats) Assembly Instruction Minimum No.of people recommended to assemble this product Approx assembly time Before you We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
- Page 2 PARTS Fittings Ø10 x 40mm x 8pcs. 1(1 piece) M8 x 65mm x 8pcs. 3(2 pieces) Ø35 x 8pcs. M8 x 8pcs. Spanner x 1pc. 2(1 piece) Allen key 4mm x 2pcs. M6 x 38mm x 4pcs. M6 x 22mm x 4pcs. Ø4 x 40mm x 6pcs.
- Page 3 Assembly Insert cam bolts "B" into the headboard "1" by hand. 46mm Insert cam bolts "B" into the footboard "2" by hand. 46mm Page 3 of 6...
- Page 4 Insert dowels "A" into the side rails "3". 3 x2 Fix the side rails "3" to the headboard "1" and footboard "2". Insert cam locks "C" and nuts "D" to side rails "3",and tighten with a spanner "E". Page 4 of 6...
- Page 5 "K" and washer "L",tighten with a screwdriver. total of six screws and washers. Option 2: Dreams sprung slat frame Open the metal slat frame outwards. Attach center leg "M" and support legs "N" to the frame and secure using bolts "P",tighten using allen...
- Page 6 Turn the metal slat frame falling upward and carefully lower the slat frame into the bed. Ensure that the frame sits on the guides located on the side rails "3". Position the slat frame so that the holes in the frame align with those in the side rails "3".Secure the frame to the side rails...
