DREAMS HAMPSTEAD BED Assembly Instruction Manual

Double solid/sprung slats
Hide thumbs

Advertisement

Quick Links

Download this manual
HAMPSTEAD BED
Assembly Instruction
Minimum No.of people
recommended to assemble
this product
Approx assembly time
Before you
start,here
is some
helpful advice
27814400
DOUBLE 231-00029 (Solid slats)
1.
We suggest you spend a short time reading through this leaflet and
then follow the simple step by step instructions.
2.
If you follow the instructions carefully the end result should be worth
the effort.
3.
Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4.
To ensure an easier assembly, we strongly advise that all fittings are
only finger tightened during initial assembly. Only upon completion of
the. Assembly should all fixing points be fully tightened.
5.
We recommend a periodic check on all fixing points to make sure they
remain fully tightened.
6.
Keep glue and fittings out of children's reach.
7.
In the unlikely event that this product has missing or damaged parts,
please call 0844 292 0000 to obtain spares
Page 1 of 12
231-00030 (Sprung slats)

Advertisement

loading
Need help?

Need help?

Do you have a question about the HAMPSTEAD BED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DREAMS HAMPSTEAD BED

Summary of Contents for DREAMS HAMPSTEAD BED

  • Page 1 DOUBLE 231-00029 (Solid slats) HAMPSTEAD BED 231-00030 (Sprung slats) Assembly Instruction Minimum No.of people recommended to assemble this product Approx assembly time Before you We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.

  • Page 2: Check List

    Part Artical number Quantity Measure Dimention (mm) Quantity CHECK LIST number 32433944 1554x1210x110 32434044 1524x418x80 32434144 1920x395x104 32434244 1920x395x104 32432344 340x310x17 32432444 340x310x17 32432544 416x340x17 32432644 416x340x37 32434344 1354x310x19 32432844 500x260x17 32432944 500x260x17 32434444 1315x260x17 32434544 1325x481x8 324332 481x50x17 324346 1907x70x25 324334 316x70x25...
  • Page 3 Fittings Ø10 x 40mm x 10pcs. M8 x 65mm x 2pcs. Ø35 x 2pcs. M8 x 2pcs. Spanner x 1pc. Allen key 4mm x 2pcs. M6 x 38mm x 6pcs. M6 x 22mm x 4pcs. Ø3.5 x 30mm x 16pcs. M6 x 25mm x 24pcs.
  • Page 4 Assembly Insert cam bolts "B" into the footboard "2" by hand. 46mm Insert dowels "A" into the side rails "3" and "4". Attach wooden blocks "Q" to side rails "3" and "4", insert screws "I" into wooden blocks "Q", tighten with a screwdriver.
  • Page 5 Fix the side rails "3" and "4" to the headboard "1" and footboard "2". For the footboard, use washers "C" and nuts "D" to secure side rails "3" and "4". Tighten using spanner "E". Insert screws "I" into wooden blocks "Q", tighten with a screwdriver.
  • Page 6 Install castors "K" to panel "8", tighten with screws "L". Footboard Drawer Attach side panels "10" and "11" to back panel "12" using bolts "J". Tighten using allen key "F". 27814400 Page 6 of 12...
  • Page 7 Slide in panel "13" along the groove into the drawer frame. Locate supports "14" into back panel "12". Attach front panel "9" and secure to side panels "10" and "11" using bolts "J". Tighten using allen key "F". 27814400 Page 7 of 12...
  • Page 8 Secure supports "14" to front panel "9" and back panel "12" using screws "I". Install castors "K" to body of drawer, tighten with screws "L". 27814400 Page 8 of 12...
  • Page 9 Attach central support "15" to support feet "16". Using bolts "G", tighten using allen key "F". Locate central support "15" in between the headboard "1" and footboard "2". 27814400 Page 9 of 12...
  • Page 10 Please carefully follow the correct assembly instructions for the slat system that you have purchased. Option 1: Dreams solid slats Place the fixed wood slats onto the slat holders on side rails "3" and "4". Fix the slats at both ends and the middle using screws "I"...
  • Page 11 Option 2: Dreams sprung slat frame Open the metal slat frame outwards. Turn the metal slat frame falling upward and carefully lower the slat frame into the bed. Ensure that the frame sits on the guides located on the side rails "3" and "4".
  • Page 12 Place the bedside tables and footboard drawer into the body of bed. Rotate the block of side rails "3" and "4", in order to stop the bedside tables. Need to lift the footboard "2", in order to put the footboard drawer.
