Macgill Bed
Assembly Instructions
Before you
Start, here
are some
helpful
advices.
Revision number 1/1
1. We suggest you spend a short time reading through this leaflet and then follow
the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the.
Assembly should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they remain
fully tightened.
7. Keep glue and fittings out of children s reach.
In the unlikely event that this product has missing or damaged parts, please call
03442 920000 to obtain spares
215-00945 (Solid slats)
215-00946 (Sprung slats)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DREAMS 215-00945
Summary of Contents for DREAMS 215-00945
- Page 1 215-00945 (Solid slats) Macgill Bed 215-00946 (Sprung slats) Assembly Instructions Before you 1. We suggest you spend a short time reading through this leaflet and then follow Start, here the simple step by step instructions. 2. If you follow the instructions carefully the end result should be worth the effort.
- Page 2 PARTS Fittings M6×35mmx6pcs M3×35mmx1pc M3×50mmx4pcs M6nut x6pcs NO. PART LIST (1) HEADBOARD M6 Washer x6pcs (2) FOOTBOARD (3) WOODEN FEET (4) SIDE RAILS M4Allen key × 2pcs (5) SUPPORT LEG M5Allen key × 1pc Revision number 1/1...
- Page 3 ASSEMBLY (1). Attach the Wooden Feet to the STEP 1 headboard and footboard. (2). Loosen the pre-assembled bolts on the headboard and footboard with the Allen Key(G) Note: Leave 10 mm protruding as in the diagram Revision number 1/1...
- Page 4 ASSEMBLY (1). Attach the side rails to the STEP 2 headboard and footboard. Note：Fit side panels locating the brackets behind the flat washers. Revision number 1/1...
- Page 5 ASSEMBLY MAKE CERTAIN THE BED IS STEP 3 SQUARED UP .AS SHOWN ON THE RIGHT. Once all four comers are located. make sure the bed is still square as in the sketch.then tighten all the bolts 100% using Allen key Revision number 1/1...
- Page 6 ASSEMBLY (1). Use Tapping Screw (C) to STEP 4 tighten the Side rails to Headboard and Footboard . Revision number 1/1...
- Page 7 Both slats on "step 3" and "step 4" can be assembled to the bedstead. You can make a choice between the two slats. OPTION"A": DREAMS FIXED WOOD SLATS （1） Carefully locate the slats onto the unit. Fix one end of slats, （2）Use bolt (A) ,Washer (E)
- Page 8 ASSEMBLY OPTION"B": DREAMS SPRUNG STEP 6 SLATS 1) Use the bolt to fix support leg onto the slat frame. Please note that these bolts are to be found inside the slat frame box. 2) Carefully locate the slats onto the unit.
