- Page 1 Compressor Controller MAM – 200 OPERATION MANUAL Revision 1.0 04.08.2017...
- Page 2 Notice Please read all the operation manual before operating the set and keep this manual for further reference. Installation of MAM—8** compressor controller can be performed only by professional technicians. RC snubber must be connected to the two terminals of coil (such as AC contactor, valve, etc),which are controlled by relay output.
-
Page 3: Table Of Contents
Contents Basic Operations ................................. 4 Button Explanation ..............................4 Status Display and Operations ..........................6 Operating Parmeter and Menu ..........................7 Calendar .................................. 7 Custom parameter ..............................8 2 Controller Function and Technical Parameter ......................13 3 Model and Specification ............................. 14 4 Alarm Function ................................ -
Page 4: Basic Operations
Basic Operations 1.1 Button Explanation Start button When compressor is at stop status, press this button to start the compressor When compressor is set as main (No. 1) in block mode, press this button to start the compressor and activate block mode function at the same time Stop button ... - Page 5 Move down button / Decreasing button When viewing the menu, press this button to move downward the cursor When modifying data, press this button to decrease the data at current position Move up button / Increasing button When viewing the menu, press this button to move upward the cursor ...
-
Page 6: Status Display And Operations
1.2 Status Display and Operations The Display screen will show as below after powered on: After 5 seconds the menu will switch as below: Press to enter into selection menu: RUN PARAMETER CALENDAR CUSTOMER PARAMETER FACTORY PRAMETER 04.08.2017 Operation Manual MAM - 200 V1.0... -
Page 7: Operating Parmeter And Menu
1.3 Operating Parmeter and Menu Press to move the cursor to “RUN PARAMETER”, then press to switch to secondary menu: HOST、FAN CURRENT TOTAL RUN TIME CURRENT RUN TIME MAINTENANCE PARAMETER Move the cursor to “HOST, FAN CURR”, press to switch to secondary menu: CUR(A)：R HOST：... -
Page 8: Custom Parameter
1.5 Custom parameter 1.5.1 Customer Parameter View and Modification CUSTOMER PARAMETER and FACTORY PARAMETER are not allowed to be modified in running and stop delay status. When modifying Customer parameter please refer to run parameter modification method. The modification process of LOADING P is showing as an example below: Press to move the cursor to “CUSTOMER PARAMETER”, then press to switch to secondary... - Page 9 In this menu the first data bit of password blinking, press to modify the first bit of password. Press move the cursor to the next data bit, modify the second data bit of password in accordeance with the above. Modify the the third and fourth data of password in sequence, press to confirm the input data and the menu will switch to the following menu after verification.
- Page 10 1.5.2 Customer Parameter Table and Function First Second Preset Value Functions Submenu Submenu 1. In AUTO LOADING status, compressor will load if pressure is below this set data LOADING P 0,65 MPa 2. In STANDBY mode, compressor will start if the pressure below this set data 1.
- Page 11 Alone/ BLOCK ON/OFF Order When master pressure is between BLOCK LOAD P and BLOCK UNLD P, TURN TIME 99 Hours master determines slave to work alternatively after working over this set time BLOCK NUMBER 0016 Number of air compressors in block net In BLOCK mode, one compressor will start or load when master AIR P is BLOCK LOAD P *.**MPa...
- Page 12 1.5.3 Factory Parameter The view and modification of factory parameter requires a factory password, The modification step is same as customer parameter modification. Main function is as below: Menu Initial Value Functions After the starting delay time, when the motor current is greater than 1.2 times of the set HOST RATED CURRENT value and less than 4 times of the set value, the unit will jump as per overload feature.
-
Page 13: Controller Function And Technical Parameter
1.6 Operating Authorization and Password Controller provides multiple passwords and access management. According to different levels of passwords, controller provides different levels of operating authorization. Details are as following: Customer Password: factory set ____________ Permissions: Allows to modify all Customer Parameter Factory Password: fixed ____________ Permissions: Allows user to modify all Parameter 2 Controller Function and Technical Parameter... -
Page 14: Model And Specification
3 Model and Specification Main controller model description MAM - KY02 S (40) (B) (T) T：RS—485 communication B：Transformer; K：Pressure Switch Matched Host Maximum nominal working current S：Screw type Air compressor 02 type air compressor controller（LCD） Products Series Power consumption table for corresponding motor Parameter Adopted Host Current Range... - Page 15 Electrical basic wiring installation Attention: the magnetic coil must be connected to the surging absorber when wiring 04.08.2017 Operation Manual MAM - 200 V1.0...
-
Page 16: Alarm Function
4 Alarm Function 4.1 Monitor text 4.1.1 Air Filter Alarm 1. Use switching signal to detect alarm The monitor displays AIR FILTER BLOCK by checking air filter differential pressure switch 2. Set AIR filter max. time The monitor displays AIR LIFE END when the run time of air filter exhausts 4.1.2 Oil Filter Alarm 1. -
Page 17: Controller Protection
5 Controller Protection 5.1 Motor Protection MAM-200 compressor controller provides short circuit, block, overload, lack phase and unbalance protection on motor. Electronic Failure Display Reasons Failure Short circuit Display “MOTOR / FAN OVERLOAD” Short circuit or wrong current set Current block Display “MOTOR / FAN BLOCK”... -
Page 18: Troubleshooting
6 Troubleshooting Failure stop caused by the external parts of controllers may be removed by checking this fault or history fault, method is shown as below. Press to move the cursor to “RUN PARAMETER”, then press to switch to secondary menu MOTORS CURRENT TOTAL RUN TIME: CURRENT RUN TIME... - Page 19 User can reset the error according to the following information: Failure Causes Measurement to take AIR T HIGH Bad vent condition, Oil lacking etc. Check the vent condition and lubricant amount etc. AIR T SENSOR FAULT Cable off or PT1OO damaged Checking the wiring and PT100 The pressure too high or the pressure AIR P HIGH...
-
Page 20: Sequence Mode Control And Network
7 Sequence Mode Control and Network 7.1 Sequence Mode Control MAM-860 controller can operate with other MAM series compressor (with communication function). 16 pcs compressors are allowed in the net at most. The cable connection for block mode is as below…. Master 1 Slave 16 Slave 2... -
Page 21: Sequence Mode Setting
7.2 Sequence Mode Setting 7.2.1 Set as Master Press to move the cursor to “USER PARAMETER”, then press to switch to the menu below: P, T SET TIMER SET OPERATION MODE SEQ PARA. SET Move the cursor to the “OPERATION MODE”, then press to switch to the menu below. -
Page 22: Set As Slave
7.2.2. Set as Slave When MAM controller serves as slave, it is only necessary to set COM MODE as SEQ. Set COM ADD from 2 – 16 with sequence according to the quantity of compressors, and SEQ STATE as SLAVE. 7.3 Start, Stop Sequence Control: Make sure sequence cables connect correctly and the parameter of compressors in net set correctly. -
Page 23: Network
7.5 Network MAM-860 controller supports MODBUS RTU protocol and can serve as slave when connect with other equipment and supports 03, 06, 16 MODBUS command. Communication baud rate: 9600BPS 1 start bit 8 data bits 1 stop bit ... -
Page 24: Copyright
8 Copyright This manual is protected by copyright and intended solely for internal use. This manual must not be made available to third parties, duplicated in any manner or form – whether in whole or in part – and the content must not be used and/or communicated, except for internal purposes, without the written consent of the manufacturer.
