User Manual

(;ÜQÔ2)

1178.3370.02 ─ 03

Table of Contents

Advertisement

Chapters

Table of Contents

Troubleshooting

Need help?

Need help?

Do you have a question about the FPL1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rohde & Schwarz FPL1000

Page 1 ® R&S FPL1000 Spectrum Analyzer User Manual (;ÜQÔ2) 1178.3370.02 ─ 03...
Page 2 This manual applies to the following R&S FPL1000 models with firmware version 1.10 and higher: ● ® R&S FPL1003 (1304.0004K03) - FPL1000 with maximum frequency 3 GHz In addition to the base unit, the following options are described: ● R&S FPL1000-B4, OCXO (1323.1902.02) ●...
Page 3: Table Of Contents
Basic Safety Instructions................... 10 Data Sheets and Brochures..................10 Release Notes and Open Source Acknowledgment (OSA)........10 Application Notes, Application Cards, White Papers, etc........10 3 Welcome to the R&S FPL1000............11 4 Getting Started..................12 Preparing for Use......................12 Instrument Tour......................33 Trying Out the Instrument..................
Page 4 Configuring and Performing Measurements............534 Remote Commands for Result Displays..............632 Setting Basic Spectrum RF Measurement Parameters......... 640 Managing Settings and Results................785 8.10 Configuring the R&S FPL1000................. 815 8.11 Using the Status Register..................840 8.12 Deprecated Commands.................... 853 9 Maintenance..................855 Cleaning........................
Page 5 ® Contents R&S FPL1000 10.2 Error Messages in Remote Control Mode...............858 10.3 Troubleshooting Remote Operation................859 10.4 Miscellaneous Troubleshooting Hints..............860 10.5 Collecting Information for Technical Support............862 List of Commands (Spectrum mode)..........864 Index....................880 User Manual 1178.3370.02 ─ 03...
Page 6 ® Contents R&S FPL1000 User Manual 1178.3370.02 ─ 03...
Page 7: Preface
1.1 For Your Safety The R&S FPL1000 is designated for use in industrial, administrative, and laboratory environments. Use the R&S FPL1000 only for its designated purpose. Observe the safety and usage instructions documented in the user manual, as well as operating conditions and performance limits stated in the data sheet.
Page 8 ® Preface R&S FPL1000 Conventions Used in the Documentation Convention Description Links Links that you can click are displayed in blue font. "References" References to other parts of the documentation are enclosed by quota- tion marks. 1.2.2 Conventions for Procedure Descriptions When operating the instrument, several alternative methods may be available to per- form the same task.
Page 9: Documentation Overview
Basic information on operating the R&S FPL1000 is not included. The contents of the user manuals are available as help in the R&S FPL1000. The help offers quick, context-sensitive access to the complete information for the base unit and the firmware applications.
Page 10: Instrument Security Procedures
Application Notes, Application Cards, White Papers, etc. https://gloris.rohde-schwarz.com). 2.4 Instrument Security Procedures Deals with security issues when working with the R&S FPL1000 in secure areas. It is available for download on the Internet. 2.5 Basic Safety Instructions Contains safety instructions, operating conditions and further important information.
Page 11: Welcome To The R&S Fpl1000
FPL1000 3 Welcome to the R&S FPL1000 The R&S FPL1000 is a new Rohde & Schwarz signal and spectrum analyzer devel- oped to meet demanding customer requirements. Offering low phase noise, wide analysis bandwidth and straightforward and intuitive operation, the analyzer makes measurements fast and easy.
Page 12: Getting Started
Configuring the Initial Instrument Settings.............. 32 4.1.1 Putting into Operation This section describes the basic steps to be taken when setting up the R&S FPL1000 for the first time. Risk of injury due to disregarding safety information Observe the information on appropriate operating conditions provided in the data sheet to prevent personal injury or damage to the instrument.
Page 13: Instrument
® Getting Started R&S FPL1000 Preparing for Use Risk of instrument damage due to inappropriate operating conditions An unsuitable operating site or test setup can damage the instrument and connected devices. Before switching on the instrument, observe the information on appropriate operating conditions provided in the data sheet.
Page 14: Accessory List
4.1.1.3 Placing or Mounting the Instrument The R&S FPL1000 is designed for use either on a bench top or in a rack, or as a porta- ble instrument (with optional battery operation) in a transport bag in the field. Bench Top Operation If the R&S FPL1000 is operated on a bench top, the surface should be flat.
Page 15 If you need to stack instruments, install them in a rack. Rackmounting The R&S FPL1000 can be installed in a rack using a rack adapter kit (order no. see data sheet). The installation instructions are part of the adapter kit.
Page 16: Connecting The Ac Power
With the help of the optional vest holster you can carry the R&S FPL1000 in its bag and keep your hands free. Together with the optional battery pack (see Chapter 4.1.1.7, "Con-...
Page 17: Changing The Ac Supply Fuse
Connecting an Optional DC Power Supply (R&S FPL1-B30) The R&S FPL1000 can also be equipped with an optional (internal) DC power supply (R&S FPL1-B30). If installed, the R&S FPL1000 can be operated by a DC voltage of 10.4 V to 28 V.
Page 18: Connecting An Optional Battery Pack (R&Sfpl1-B31)
R&S FPL1000 Preparing for Use DC Connection ► Connect the DC power supply on the rear panel of the R&S FPL1000 to the power source using the supplied power cable. 4.1.1.7 Connecting an Optional Battery Pack (R&S FPL1-B31) As an alternative to the fixed AC or DC power supply, the R&S FPL1000 can be oper- ated by a battery pack if the option R&S FPL1-B31 is installed.
Page 19: Switching The Instrument On And Off
Switching off the instrument 1. Press the POWER key on the front panel. The R&S FPL1000 switches to standby mode (not in battery operation). 2. For AC power operation, set the AC power switch on the rear panel to position "O".
Page 20: Checking The Supplied Options
After the R&S FPL1000 is star- ted, the operating system boots and the instrument firmware is started automatically.
Page 21 1EF96: Mal- ware Protection Windows 10 4.1.2.3 Login Windows requires that users identify themselves by entering a user name and pass- word in a login window. By default, the R&S FPL1000 provides two user accounts: User Manual 1178.3370.02 ─ 03...
Page 22 For the standard instrument account, an automatic login function is active by default. If activated, login is carried out automatically in the background when the R&S FPL1000 is started, without having to enter a password. This function is active until an adminis- trator explicitly deactivates it or changes the password.
Page 23 Deactivating the automatic login function To deactivate the automatic login function, perform the following steps: 1. Log in to the R&S FPL1000 operating system using an administrator account (see "Switching users when using the automatic login function" on page 22).
Page 24 4.1.3 Connecting USB Devices The USB interfaces of the R&S FPL1000 allow you to connect USB devices directly to the instrument. Increase the number of possible connections using USB hubs. Due to the large number of available USB devices, there is almost no limit to the expansions that are possible with the R&S FPL1000.
Page 25 Connecting a keyboard The keyboard is detected automatically when it is connected. The default input lan- guage is English – US. However, you can also connect foreign language keyboards; currently the following languages are supported for the R&S FPL1000: ● German ●...
Page 26 Preparing for Use Screen resolution and format The touchscreen of the R&S FPL1000 is calibrated for a 16:10 format. If you connect a monitor or projector using a different format (e.g. 4:3), the calibration will not be correct and the screen will not react to your touch actions properly.
Page 27 Windows operating system, or with LXI (LAN eXtension for Instruments). The R&S FPL1000 is equipped with a network interface and can be connected to an Ethernet LAN (local area network). Provided the network administrator has assigned...
Page 28 Getting Started R&S FPL1000 Preparing for Use Note: As the R&S FPL1000 uses a 1 GBit LAN, a crossover cable is not necessary (due to Auto-MDI(X) functionality). Risk of network failure Consult your network administrator before performing the following tasks: ●...
Page 29 8. Confirm the displayed message ("Yes" button) to restart the instrument. Using a DNS server to determine the IP address If a DNS server is configured on the R&S FPL1000, the server can determine the cur- rent IP address for the connection using the permanent computer name.
Page 30 ® Getting Started R&S FPL1000 Preparing for Use 4. In the "Ethernet Status" dialog box, select the "Properties" button. The items used by the LAN connection are displayed. User Manual 1178.3370.02 ─ 03...
Page 31 ® Getting Started R&S FPL1000 Preparing for Use 5. Tap the entry named "Internet Protocol Version 4 (TCP/IPv4)" to highlight it. 6. Select the "Properties" button. 7. On the "General" tab, select "Use the following DNS server addresses" and enter your own DNS addresses.
Page 32 1EF96: Malware Protection Windows 10 Note that changing firewall settings requires administrator rights. 4.1.6 Configuring the Initial Instrument Settings This section describes how to set up the R&S FPL1000 initially. For further basic instrument settings, see the R&S FPL1000 User Manual. ●...
Page 33: Instrument Tour
Instrument Tour 2. Press the "Language" softkey. 3. Select the required language. All text elements of the R&S FPL1000 user interface are displayed in the selected language. Texts in standard Windows dialog boxes are displayed in the language defined in the regional settings of the Windows operating system.
Page 34 ® Getting Started R&S FPL1000 Instrument Tour Figure 4-1: Front panel view of R&S FPL1000 1 = Power key 2 = USB (2.0) connectors 3 = System keys 4 = Touchscreen 5 = Function keys 6 = Keypad 7 = Navigation controls 8 = RF Input 50 Ω...
Page 35 ® Getting Started R&S FPL1000 Instrument Tour Figure 4-2: Touchscreen elements 1 = Toolbar with standard application functions, e.g. print, save/open file etc. 2 = Tabs for individual channel setups 3 = Softkeys for function access 4 = Channel Setup bar for firmware and measurement settings...
Page 36 ® Getting Started R&S FPL1000 Instrument Tour For details on touchscreen gestures see Chapter 4.4.4, "Touchscreen Gestures", on page 74. 4.2.1.2 Power Key The POWER key is located on the lower left corner of the front panel. It starts up and shuts down the instrument.
Page 37 ® Getting Started R&S FPL1000 Instrument Tour 4.2.1.5 Function Keys Function keys provide access to the most common measurement settings and func- tions. A detailed description of the corresponding functions is provided in the User Manual. Table 4-2: Function keys...
Page 38 ® Getting Started R&S FPL1000 Instrument Tour Function key Assigned functions RUN SINGLE Starts and stops a single new measurement (Single Sweep Mode) RUN CONT Starts and stops a continuous measurement (Continuous Sweep Mode) 4.2.1.6 Keypad The keypad is used to enter numeric parameters, including the corresponding units. It...
Page 39 RF INPUT 50 Ω 4.2.1.8 Connect a device under test (DUT) to the R&S FPL1000 to provide RF input which is then analyzed in an RF measurement. Connect the DUT to the RF INPUT on the R&S FPL1000 via a cable equipped with an appropriate connector.
Page 40 Do not overload the input. For maximum allowed values, see the data sheet. A DC input voltage of 50 V must never be exceeded. 4.2.2 Rear Panel View This figure shows the rear panel view of the R&S FPL1000. The individual elements are described in more detail in the subsequent sections. 14 15...
Page 41 For details see "GPIB Interface (IEC 625/IEEE 418 Bus Interface)" on page 168. 4.2.2.4 Ref. In / Ref. Out The Ref. In connectors are used to provide an external reference signal to the R&S FPL1000. User Manual 1178.3370.02 ─ 03...
Page 42 25. 4.2.2.7 The LAN interface can be used to connect the R&S FPL1000 to a local network for remote control, printouts or data transfer. The assignment of the RJ-45 connector sup- ports twisted-pair category 5 UTP/STP cables in a star configuration (UTP stands for unshielded twisted pair, and STP for shielded twisted pair).
Page 43 4.2.2.12 Headphones Connector The R&S FPL1000 provides demodulators for AM, FM and PM signals, which can be routed to the headphone connector. With headphones or an external loudspeaker con- nected to the 3.5 mm headphone socket the displayed signal can be identified acousti- cally.
Page 44: Trying Out The Instrument
The output supports a maximum load of 100 mA. 4.3 Trying Out the Instrument This chapter introduces the most important functions and settings of the R&S FPL1000 step by step. The complete description of the functionality and its usage is given in the R&S FPL1000 User Manual.
Page 45 50 MHz. 6. Close the dialog box. The calibration signal is now sent to the RF input of the R&S FPL1000. By default, a continuous frequency sweep is performed, so that the spectrum of the calibration signal is now displayed in the standard level versus frequency diagram.
Page 46 In addition to the standard "level versus frequency" spectrum display, the R&S FPL1000 also provides a spectrogram display of the measured data. A spectro- gram shows how the spectral density of a signal varies over time. The x-axis shows the frequency, the y-axis shows the time.
Page 47 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-6: Adding a Spectrogram to the display Drop the icon. 4. Close the SmartGrid mode by tapping the "Close" icon at the top right corner of the toolbar. 5. Close the "Overview" .
Page 48 Figure 4-7: Spectrogram of the calibration signal 4.3.3 Activating Additional Measurement Channels The R&S FPL1000 features multiple measurement channels, i.e. you can define sev- eral measurement configurations in parallel and then switch between the channel set- ups automatically to perform the measurements sequentially. We will demonstrate this feature by activating additional measurement channels for a different frequency range, a zero span measurement, and an I/Q analysis.
Page 49 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-8: Adding a new measurement channel 3. Change the frequency range for this spectrum display: In the "Frequency" dialog box, set the center frequency to 500 MHz and the span to 1 GHz.
Page 50 ® Getting Started R&S FPL1000 Trying Out the Instrument In the "Frequency" dialog box, set the center frequency to 50 MHz and tap "Zero Span" . 6. Increase the reference level so you can see the level of the calibration signal at 1 dBm.
Page 51 ® Getting Started R&S FPL1000 Trying Out the Instrument d) Drag the "Real/Imag (I/Q)" icon from the evaluation bar to the SmartGrid to replace the default "Magnitude" display. Figure 4-11: Inserting a Real/Imag diagram for I/Q analysis e) Close the SmartGrid mode.
Page 52 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-12: The "MultiView" tab 4.3.4 Performing Sequential Measurements Although only one measurement can be performed at any one time, the measurements configured in the active channel setups can be performed sequentially, that means: one after the other, automatically, either once or continuously.
Page 53 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-13: "MultiView" tab with active Sequencer Figure 4-13, the "Spectrum 2" measurement is currently active (indicated by the "channel active" icon in the tab label). 3. Stop the Sequencer by tapping the "Sequencer" softkey again.
Page 54 ® Getting Started R&S FPL1000 Trying Out the Instrument 6. Now you can move the marker by tapping and dragging it to a different position. The current position is indicated by a dotted blue line. Notice how the position and value change in the marker area of the diagram.
Page 55 ® Getting Started R&S FPL1000 Trying Out the Instrument 4.3.6 Displaying a Marker Peak List The marker peak list determines the frequencies and levels of peaks in the spectrum automatically. We will display a marker peak list for the "Spectrum 2" measurement channel.
Page 56 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-14: Marker Peak List 4.3.7 Zooming into the Display To analyze the areas around the peak levels in more detail, we will zoom into the top 3 peaks. 1. Tap the "Multiple Zoom" icon in the toolbar.
Page 57 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-16: Zoomed display around a peak 3. In Figure 4-17, the enlarged peak is represented by a very thick trace. This is due to the insufficient number of sweep points. The missing sweep points for the zoomed display are interpolated, which provides poor results.
Page 58 ® Getting Started R&S FPL1000 Trying Out the Instrument 4. Tap the "Multiple Zoom" icon in the toolbar again and define a zoom area around markers M2, M3 and M4. Figure 4-18: Multiple zoom windows 5. Tap the "Multiple Zoom" icon in the toolbar again and define a zoom area around marker M5.
Page 59 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-19: Enlarged zoom window 4.3.8 Saving Settings To restore the results of our measurements later, we will store the instrument settings to a file. To save the instrument settings to a file 1.
Page 60 ® Getting Started R&S FPL1000 Trying Out the Instrument Figure 4-20: Saving the instrument settings to a file 4. Tap the "Save" button. The file MyMultiViewSetup.dfl is stored in the default directory C:\Users\Public\Documents\Rohde-Schwarz\Analyzer\user. To load stored instrument settings You can restore the settings to the instrument at any time using the settings file.
Page 61 ® Getting Started R&S FPL1000 Trying Out the Instrument 4.3.9 Printing and Saving Results Finally, after a successful measurement, we will document our results. First we will export the numeric trace data, then we will create a screenshot of the graphical dis- play.
Page 62: Operating The Instrument
FPL1000 Operating the Instrument 4.4 Operating the Instrument This chapter provides an overview on how to work with the R&S FPL1000. Risk of touchscreen damage Inappropriate tools or excessive force can damage the touchscreen. Observe the following instructions when operating the touchscreen: ●...
Page 63 4.4.1.1 Channel Setup Bar Using the R&S FPL1000 you can handle several different measurement tasks (chan- nels) at the same time (although they can only be performed asynchronously). For each channel, a separate tab is displayed on the screen. To switch from one channel display to another, simply select the corresponding tab.
Page 64 Beneath the channel name, information on channel-specific settings for the measure- ment is displayed in the channel bar. Channel information varies depending on the active application. In the Spectrum application, the R&S FPL1000 shows the following settings: User Manual 1178.3370.02 ─ 03...
Page 65 ® Getting Started R&S FPL1000 Operating the Instrument Table 4-4: Channel settings displayed in the channel bar in the Spectrum application Ref Level Reference level RF attenuation applied to input Ref Offset Reference level offset Sweep time that has been set.
Page 66 4.4.1.2 Window Title Bar Each channel in the R&S FPL1000 display can contain several windows. Each window can display either a graph or a table as a result of the channel measurement. The win- dow title bar indicates which type of evaluation is displayed.
Page 67 ® Getting Started R&S FPL1000 Operating the Instrument SAMPLE detector AVERAGE detector RMS detector (4) Trace Mode Sweep mode: Clrw CLEAR/WRITE MAX HOLD MIN HOLD AVERAGE (Lin/Log/Pwr) View VIEW (5) Smoothing factor Smth Smoothing factor, if enabled. (See " Smoothing "...
Page 68 ® Getting Started R&S FPL1000 Operating the Instrument "FXD" Fixed reference marker "Phase Noise" Phase noise measurement "Signal Count" Signal count "TRK" Signal tracking "Noise Meas" Noise measurement "MDepth" AM modulation depth "TOI" Third order intercept measurement 4.4.1.4 Frequency and Span Information in Diagram Footer The information in the diagram footer (beneath the diagram) depends on the current application, measurement, and result display.
Page 69 ® Getting Started R&S FPL1000 Operating the Instrument Date and time The date and time settings of the instrument are displayed in the status bar. Error messages If errors or irregularities are detected, a keyword and an error message, if available, are displayed in the status bar.
Page 70: Accessing The Functionality
® Getting Started R&S FPL1000 Operating the Instrument IF OVLD Overload of the IF signal path in the A/D converter or in the digital IF. ● Increase the reference level. INPUT OVLD The signal level at the RF input connector exceeds the maximum.
Page 71 ® Getting Started R&S FPL1000 Operating the Instrument You can hide the toolbar display, e.g. when using remote control, to enlarge the display area for the measurement results ( "Setup" > "Display" > "Displayed Items" ). "Displayed Items" on page 127.
Page 72 ® Getting Started R&S FPL1000 Operating the Instrument 4.4.2.4 On-screen Keyboard The on-screen keyboard is an additional means of interacting with the instrument with- out having to connect an external keyboard. The on-screen keyboard display can be switched on and off as desired using the "On- Screen Keyboard"...
Page 73: Entering Data
® Getting Started R&S FPL1000 Operating the Instrument 4.4.3 Entering Data Data can be entered in dialog boxes using one of the following methods: ● Using the touchscreen, via the online keyboard ● Using other elements provided by the front panel, e.g. the keypad, rotary knob, or navigation keys The rotary knob acts like the ENTER key when it is pressed.
Page 74: Touchscreen Gestures
® Getting Started R&S FPL1000 Operating the Instrument Correcting an entry 1. Using the arrow keys, move the cursor to the right of the entry you want to delete. 2. Press the BACKSPACE key. The entry to the left of the cursor is deleted.
Page 75 ® Getting Started R&S FPL1000 Operating the Instrument Dragging Move your finger from one position to another on the display, keeping your finger on the display the whole time. By dragging your finger over a table or diagram you can pan the displayed area of the table or diagram to show results that were previously out of view.
Page 76 ® Getting Started R&S FPL1000 Operating the Instrument Figure 4-24: Spreading Touch gestures in diagrams change measurement settings When you change the display using touch gestures, the corresponding measurement settings are adapted. This is different to selecting an area on the screen in zoom mode, where merely the resolution of the displayed trace points is changed tempora- rily.
Page 77: Getting Help
4.4.5 Getting Help If any questions or problems concerning the R&S FPL1000 arise, an extensive online help system is provided on the instrument and can be consulted at any time. The help system is context-sensitive and provides information specifically for the current opera- tion or setting to be performed.
Page 78 ® Getting Started R&S FPL1000 Operating the Instrument a) Select the "Help pointer" icon on the toolbar. The pointer changes its shape to a "?" and an arrow. b) Select the screen element to change the focus. A topic containing information about the selected (now focused) screen element is displayed.
Page 79: Remote Control
Or: Press the ESC key. 4.4.6 Remote Control In addition to working with the R&S FPL1000 interactively, located directly at the instru- ment, it is also possible to operate and control it from a remote PC. Various methods for remote control are supported: ●...
Page 80 4.4.6.3 Connecting a PC via the GPIB Interface You can connect a PC to the R&S FPL1000 via the GPIB interface to send remote commands to control and operate the instrument. You can configure the GPIB address and the ID response string. The GPIB language is set as SCPI by default but can be changed to emulate other instruments.
Page 81: Applications, Measurement Channels, And Result Displays
5 Applications, Measurement Channels, and Result Displays The R&S FPL1000 allows you to perform all sorts of different analysis tasks on differ- ent types of signals, e.g. Analog Demodulation, I/Q analysis or basic spectrum analy- sis. Depending on the task or type of signal, a different set of measurement functions and parameters are required.
Page 82: R&S Multiview
® Applications, Measurement Channels, and Result Displays R&S FPL1000 R&S MultiView Spectrum ........................82 I/Q Analyzer ......................... 82 Analog Demod ......................82 Noise Figure .........................82 Spectrum In the Spectrum application the provided functions correspond to those of a conven- tional spectrum analyzer. The analyzer measures the frequency spectrum of the RF input signal over the selected frequency range with the selected resolution and sweep time.
Page 83: Defining Channel Setups
® Applications, Measurement Channels, and Result Displays R&S FPL1000 Defining Channel Setups 5.3 Defining Channel Setups Access: MODE The default channel setup uses the "Spectrum" application. User Manual 1178.3370.02 ─ 03...
Page 84 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Defining Channel Setups Switching between channel setups When you switch to a new channel setup, a set of parameters is passed on from the current channel setup to the new one: ●...
Page 85: Running A Sequence Of Measurements
® Applications, Measurement Channels, and Result Displays R&S FPL1000 Running a Sequence of Measurements New Channel Setup ← Defining a channel setup The application selected on this tab of the dialog box activates a new channel setup, i.e. a new tab in the display.
Page 86 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Running a Sequence of Measurements tively, a Sequencer function is provided, which changes the channel setup of the instrument as required. If activated, the measurements configured in the currently defined "Channel" s are performed one after the other in the order of the tabs.
Page 87 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Running a Sequence of Measurements Example: Sequencer procedure Assume the following active channel setup definition: Tab name Application Sweep mode Sweep count Spectrum Spectrum Cont. Sweep Spectrum 2 Spectrum Single Sweep...
Page 88 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Running a Sequence of Measurements RUN SINGLE/RUN CONT and Single Sweep/Sweep Continuous keys While the Sequencer is active, the RUN SINGLE and RUN CONT keys control the Sequencer, not individual sweeps. RUN SINGLE starts the Sequencer in single mode, while RUN CONT starts the Sequencer in continuous mode.
Page 89: Channel Setup Overview
® Applications, Measurement Channels, and Result Displays R&S FPL1000 Channel Setup Overview 5.4.3 How to Set Up the Sequencer In order to perform the configured measurements consecutively, a Sequencer function is provided. 1. Configure a channel setup for each measurement configuration as required, includ- ing the sweep mode.
Page 90: Configuring Result Displays
® Applications, Measurement Channels, and Result Displays R&S FPL1000 Configuring Result Displays Using this overview, you can easily configure an entire channel setup from input over processing to output and analysis by stepping through the dialog boxes as indicated. Chapter 7, "The Spectrum Application (RF Measurements)",...
Page 91 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Configuring Result Displays Principally, the layout of the windows on the screen is based on an underlying grid, the SmartGrid. However, the SmartGrid is dynamic and flexible, allowing for many different layout possibilities.
Page 92 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Configuring Result Displays Figure 5-1: Moving a window in SmartGrid mode The brown area indicates the possible "drop area" for the window, i.e. the area in which the window can be placed. A blue area indicates the (approximate) layout of the window as it would be if the icon were dropped at the current position.
Page 93 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Configuring Result Displays SmartGrid functions Once the evaluation icon has been dropped, icons in each window provide delete and move functions. The "Move" icon allows you to move the position of the window, possibly changing the size and position of the other displayed windows.
Page 94 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Configuring Result Displays Remote command: on page 632 / on page 636 LAYout:ADD[:WINDow]? LAYout:WINDow<n>:ADD? 5.6.1.4 How to Close a Result Window ► To close a window, activate SmartGrid mode and select the "Delete" icon for the window.
Page 95 ® Applications, Measurement Channels, and Result Displays R&S FPL1000 Configuring Result Displays 5.6.2 Changing the Size of Windows Each channel setup tab may contain several windows to evaluate the measurement results using different methods. A "splitter" allows you to change the size of neighbor- ing windows.
Page 96: Common Instrument Functions
® Common Instrument Functions R&S FPL1000 Toolbar Functions 6 Common Instrument Functions Some settings and functions are available throughout the instrument, regardless of the currently active application. These settings and functions are described here, and are not repeated for each application.
Page 97: Data Management
77 6.2 Data Management The R&S FPL1000 allows you to save and recall measurement settings. Measurement data can be exported and imported for a later analysis, the graphical result display can be stored to a file or printed. In addition, various application-specific data can be saved and/or recalled.
Page 98 Settings....110 6.2.1 Restoring the Default Instrument Configuration (Preset) When delivered, the R&S FPL1000 has a default configuration. You can restore this defined initial state at any time as a known starting point for measurements. This is often recommendable as a first step in troubleshooting when unusual measurement results arise.
Page 99 R&S FPL1000 without these options. ● Files created with newer firmware versions may not work with a previous version. ● Files created on an instrument other than the R&S FPL1000 do not work on the R&S FPL1000. User Manual 1178.3370.02 ─ 03...
Page 100 If a transducer file was in use when the save set was stored (with the save item "Cur- rent Settings" only) the R&S FPL1000 assumes that these transducer values should remain valid after every recall of that save set. Thus, even if the transducer file is changed and the original save set file is recalled later, the originally stored transducer values are recalled and applied to the measurement.
Page 101 ® Common Instrument Functions R&S FPL1000 Data Management If a channel setup with the same name as the "Channel" to be restored is already active, the name for the new channel setup is extended by a consecutive number: Quick Save / Quick Recall Settings Access: "Save"...
Page 102 Startup Recall Settings..................106 Stored Data Types The following types of data can be stored to and loaded from files via the "Save" dialog box on the R&S FPL1000: Table 6-1: Items that can be stored to files Item Description Current Settings Current instrument and measurement settings.
Page 103 ® Common Instrument Functions R&S FPL1000 Data Management Item Description All Limit Lines All limit line files. Spectrograms Spectrogram trace data (only available if spectrogram display is currently active). Storage Location and Filename The data is stored on the internal flash disk or, if selected, on a memory stick or net- work drive.
Page 104 ® Common Instrument Functions R&S FPL1000 Data Management Selecting Storage Location - Drive/ Path/ Files............104 File Name ........................104 Comment ........................105 File Type ........................105 Items: ......................... 105 Save File ........................105 Recall in New Channel / Recall in Current Channel ...........105...
Page 105: Items
® Common Instrument Functions R&S FPL1000 Data Management Comment An optional description for the data file. A maximum of 60 characters can be displayed. Remote command: on page 788 MMEMory:COMMent File Type Determines whether the global instrument settings with all "Channel" s are stored or recalled, or the current "Channel"...
Page 106 ® Common Instrument Functions R&S FPL1000 Data Management Startup Recall Settings Access: "Open" icon in the toolbar > "Startup Recall" Startup Recall ......................106 Selecting Storage Location - Drive/ Path/ Files............107 File Name ........................107 Comment ........................107 Startup Recall Activates or deactivates the startup recall function. If activated, the settings stored in the selected file are loaded each time the instrument is started or preset.
Page 107: Selecting Storage Location - Drive/ Path/ Files
® Common Instrument Functions R&S FPL1000 Data Management Selecting Storage Location - Drive/ Path/ Files Select the storage location of the file on the instrument or an external drive. The default storage location for the SEM settings files is: C:\ProgramData\Rohde-Schwarz\ZNL-FPL\sem_std.
Page 108 ® Common Instrument Functions R&S FPL1000 Data Management To save configurable instrument settings 1. Select the "Save" icon from the toolbar. 2. In the "Save" dialog box, switch to the "Save" tab. 3. In the file selection dialog box, select a filename and storage location for the set- tings file.
Page 109 In this case, you can export the measurement data to a standard format file (ASCII or XML). Some of the data stored in these formats can also be re- imported to the R&S FPL1000 for further evaluation later, for example in other applica- tions.
Page 110 ("Importing and Exporting I/Q Data"). Note: Storing large amounts of I/Q data (several Gigabytes) can exceed the available (internal) storage space on the R&S FPL1000. In this case, it can be necessary to use an external storage medium. 6.2.4 Creating Screenshots of Current Measurement Results and Set-...
Page 111 ® Common Instrument Functions R&S FPL1000 Data Management 6.2.4.1 Print and Screenshot Settings Access: PRINT For step-by-step instructions, see Chapter 6.2.4.2, "How to Store or Print Screenshots of the Display", on page 120. Remote commands for these settings are described in Chapter 8.9.4, "Storing or Print-...
Page 112 ® Common Instrument Functions R&S FPL1000 Data Management Print Screenshot ......................113 Print Multiple Windows ....................113 Comment ........................113 Print Logo ........................113 Print Page Count ......................113 Print Dialog .........................113 Print Date and Time ....................114 User Manual 1178.3370.02 ─ 03...
Page 113 ® Common Instrument Functions R&S FPL1000 Data Management Print Screenshot Selects all measurement results displayed on the screen for the current channel setup (or "MultiView" ): diagrams, traces, markers, marker lists, limit lines, etc., including the channel bar and status bar, for printout on a single page. Displayed items belonging to the software user interface (e.g.
Page 114 ® Common Instrument Functions R&S FPL1000 Data Management This setting is only available if Print Screenshot is selected. Print Date and Time Includes or removes the current date and time at the bottom of the printout. Remote command: on page 809 HCOPy:TDSTamp:STATe<device>...
Page 115 ® Common Instrument Functions R&S FPL1000 Data Management Zoom In / Zoom Out ....................115 Fit Page ........................115 Zoom 1:1 ........................115 Page Up / Page Down ....................115 Print ..........................115 Zoom In / Zoom Out Zooms into (enlarges) or zooms out of (decreases) the preview display. Note that the zoom functions affect only the preview, not the printout itself.
Page 116 ® Common Instrument Functions R&S FPL1000 Data Management Destination ......................... 116 Suppress File Name Dialog ..................117 Printer Name ......................117 Print to file ........................117 Install Printer ......................117 Destination Defines the medium to which the printout is output.
Page 117 ® Common Instrument Functions R&S FPL1000 Data Management "File" Stores the printout to a file in the selected format. The filename is queried at the time of storage, or a default name is used (see Sup- press File Name Dialog Multiple windows can only be printed to a file in PDF format.
Page 118 ® Common Instrument Functions R&S FPL1000 Data Management Page Setup Access: "Print" > "Print Config" > "Page Setup" tab Page settings are only available when printing on a printer or to a PDF file (see " Desti- nation " on page 116).
Page 119 ® Common Instrument Functions R&S FPL1000 Data Management If more than one window is printed on one page, each window is printed in equal size. Remote command: on page 808 HCOPy:PAGE:WINDow<device>:COUNt Scaling Determines the scaling of the windows in the printout if...
Page 120 To start printing or storing results to a file ► If the R&S FPL1000 has already been set up according to your current require- ments, simply press the "Print immediate" icon ( ) at the far right end of the tool- bar.
Page 121 ® Common Instrument Functions R&S FPL1000 Data Management To print a screenshot This configuration assumes a printer has already been installed. To install a new printer, use the Install Printer function (common Microsoft Windows procedure). 1. Select the "Printer" tool in the toolbar.
Page 122 ® Common Instrument Functions R&S FPL1000 Data Management a) Select "Print Selected Windows" to include the selected windows in the print- out, possibly on multiple pages. b) Select the result displays in the currently selected channel setup to be included in the printout.
Page 123 ® Common Instrument Functions R&S FPL1000 Data Management 6.2.4.3 Example for Storing Multiple Measurement Results to a PDF File The following example describes the procedure to store results from measurements in the Spectrum application and the I/Q Analyzer to a single PDF file.
Page 124 ® Common Instrument Functions R&S FPL1000 Data Management 13. Select "Windows Per Page" : 1 to print a single result display on each page. 14. Select the "Scaling" option "Size to fit" to maximize the result display on each page.
Page 125: General Instrument Setup
6.3.1 Reference Frequency Access: SETUP > "Reference Int/Ext" The R&S FPL1000 can use the internal reference source or an external reference source as the frequency standard for all internal oscillators. A 10 MHz crystal oscillator is used as the internal reference source. In the external reference setting, all internal oscillators of the R&S FPL1000 are synchronized to the external reference frequency.
Page 126: Display Settings
® Common Instrument Functions R&S FPL1000 General Instrument Setup 6.3.2 Display Settings 6.3.2.1 Display Settings Access: SETUP > "Display" Some general display settings are available regardless of the current application or operating mode. For information on optimizing your display for measurement results, see the application-specific result configuration descriptions.
Page 127 ® Common Instrument Functions R&S FPL1000 General Instrument Setup To reactivate the touchscreen, simply press the SETUP key on the front panel. The "Display" dialog box is opened automatically and the "Touch Screen" option is set to "On" . "Touch On"...
Page 128 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Toolbar ........................128 Status Bar ........................129 Softkey Bar .........................129 Channel Bar ....................... 129 Diagram Footer (Annotation) ..................129 Date and Time ......................129 Front Panel .........................130 Mini Front Panel ......................130 Toolbar The toolbar provides access to frequently used functions via icons at the top of the screen.
Page 129 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Status Bar The status bar beneath the diagram indicates the global instrument settings, the instru- ment status and any irregularities during measurement or display. Some of the information displayed in the status bar can be queried from the status reg- istry via remote commands, see Chapter 8.11, "Using the Status...
Page 130 The "Front Panel" display simulates the entire front panel of the device (except for the external connectors) on the screen. Thus, you can interact with the R&S FPL1000 without the keypad and keys on the front panel of the device. That is useful, for exam- ple, when working with an external monitor or operating via remote control from a com- puter.
Page 131 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Note: You can also activate the mini front panel using the key combination ALT + M (be aware of the keyboard language defined in the operating system!). That is useful when you are working from a remote PC and the front panel function is not active.
Page 132 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Theme ........................132 Screen Colors ......................132 Print Colors ........................ 132 Showing Print Colors on Display.................133 Theme The theme defines the colors and style used to display softkeys and other screen objects.
Page 133 (see the R&S FPL1000 getting started manual). Screen resolution and format The touchscreen of the R&S FPL1000 is calibrated for a 16:10 format. If you connect a monitor or projector using a different format (e.g. 4:3), the calibration will not be correct and the screen will not react to your touch actions properly.
Page 134 ® Common Instrument Functions R&S FPL1000 General Instrument Setup To select a color set 1. Press the SETUP key and select the "Display" softkey. 2. Select the "Theme + Color" tab. 3. In the "Screen Colors" area, do one of the following: ●...
Page 135 6.3.3 Language Settings Access: SETUP > "Language" The graphical user interface of the R&S FPL1000 can be displayed in various lan- guages so you can operate the instrument in your most familiar language. User Manual 1178.3370.02 ─ 03...
Page 136: Hardware Information
Hardware Information Access: SETUP > "System Configuration" > "Hardware Info" An overview of the installed hardware in your R&S FPL1000 is provided. Every listed component is described by its serial number, order number, model infor- mation, hardware code, and hardware revision.
Page 137 If an option has already expired, a message box appears for you to confirm. In this case, all instrument functions are unavailable (including remote control) until the R&S FPL1000 is rebooted. You must then use the "Install Option" function to enter the new license key.
Page 138: System Messages
Only user accounts with administrator rights are able to install options. Install Option by XML Opens a file selection dialog box to install an additional option to the R&S FPL1000 using an XML file. Enter or browse for the name of an XML file that contains the option key and select "Select"...
Page 139: Firmware Updates
System Messages. The firmware on your R&S FPL1000 may also need to be updated in order to enable additional new features or if reasons for improvement come up. Ask your sales repre- sentative or check the Rohde&Schwarz website for availability of firmware updates. A firmware update package includes at least a setup file and release notes.
Page 140 6. In the file selection dialog box select the FPLSetup*.exe file. 7. Select "Install" to start the update. 8. After the firmware update, the R&S FPL1000 reboots automatically. 9. Depending on the previous firmware version, a reconfiguration of the hardware might be required during the first startup of the firmware.
Page 141: General Configuration Settings
161). 6.3.4.5 General Configuration Settings Access: SETUP > "System Configuration" > "Config" General system settings, for example concerning the initial behaviour of the R&S FPL1000 after booting, can also be configured. Preset Mode .......................141 Out-of-range value behavior ..................141 Preset Mode The presettings can be defined in the "Config"...
Page 142 General Instrument Setup Wait for Trigger Polarity The optional AUX PORT connector of the R&S FPL1000 can provide a signal that indi- cates the instrument is ready to receive a trigger signal. (For details on the connector see the R&S FPL1000 Getting Started manual).
Page 143 It is also included in the service.zip file. 6.3.5.2 Self-test Settings and Results Access: SETUP > "Service" > "Selftest" If the R&S FPL1000 fails you can perform a self-test of the instrument to identify any defective modules. User Manual 1178.3370.02 ─ 03...
Page 144 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Once the self-test is started, all modules are checked consecutively and the test result is displayed. You can abort a running test. In case of failure a short description of the failed test, the defective module, the associ- ated value range and the corresponding test results are indicated.
Page 145 Using service functions The service functions are not necessary for normal measurement operation. Incorrect use can affect correct operation and/or data integrity of the R&S FPL1000. Therefore, only user accounts with administrator rights can use service functions and many of the functions can only be used after entering a password. These functions are described in the instrument service manual.
Page 146 Most service functions require a special password as they may disrupt normal opera- tion of the R&S FPL1000. There are different levels of service functions, depending on how restrictive their use is handled. Each service level has a different password.
Page 147 The unit cannot be changed in the amplitude settings since the R&S FPL1000 and the active transducer are regarded as one measuring instrument. Only for relative transducer factors (unit dB), the unit originally set on the instrument is maintained and can be changed.
Page 148 R&S FPL1000 General Instrument Setup When all transducers have been switched off, the R&S FPL1000 returns to the unit that was used before a transducer was activated. Configuration The R&S FPL1000 supports transducer lines with a maximum of 1001 data points.
Page 149 R&S FPL1000 General Instrument Setup Up to 8 transducer lines can be activated simultaneously in the R&S FPL1000. Many more can be stored on the instrument. Stored transducer settings When storing and recalling transducer settings, consider the information provided in "Saving and recalling transducer and limit line settings"...
Page 150 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Name ..........................150 Unit ..........................150 Compatibility .......................150 Activating / Deactivating .....................150 Comment ........................150 Included Transducer Lines in Overview (View Filter) ..........150 Adjust Ref Level ......................151 Create New Line ......................151 Edit Line ........................
Page 151 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Adjust Ref Level Activates or deactivates the automatic adjustment of the reference level to the selected transducer factor. "Auto" Activates the automatic adjustment. The original dynamic range is restored by shifting the reference level by the maximum transducer factor.
Page 152 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Name ..........................152 Comment ........................152 Unit ..........................152 X-Axis Scaling ......................153 Data Points .........................153 Insert Value ........................ 153 Delete Value .......................153 Shift x ......................... 153 Shift y ......................... 153 Save ........................... 153 Import .........................
Page 153 The frequencies of the data points may exceed the valid frequency range of the R&S FPL1000 since only the set frequency range is taken into account for mea- surements. The minimum frequency of a data point is 0 Hz, the maximum fre- quency 200 GHz.
Page 154 For details on the file format see Chapter 6.3.6.3, "Reference: Transducer Factor File Format", on page 154. The transducer factor can be imported again later by the R&S FPL1000 for use in other measurements. Remote command: on page 823 MMEMory:STORe<n>:TFACtor 6.3.6.3...
Page 155 ® Common Instrument Functions R&S FPL1000 General Instrument Setup File contents Description YAxisScaleMode;ABSOLUTE Scaling of y-axis (absolute or relative) NoOfPoints;5 Number of points the line is defined by Data section for individual data points 100000000;-50.000000 x- and y-values of each data point defining the line 500000000;-30.000000...
Page 156 ® Common Instrument Functions R&S FPL1000 General Instrument Setup 2. To deactivate a transducer line, deactivate the "Active" setting for it. After the next sweep, the originally measured values are displayed. How to edit existing transducer lines Existing transducer line configurations can be edited.
Page 157 ® Common Instrument Functions R&S FPL1000 General Instrument Setup How to configure a new transducer line 1. In the "Transducer" dialog box, select the "New" button. The "Edit Transducer" dialog box is displayed. The current line configuration is dis- played in the preview area of the dialog box. The preview is updated after each change to the configuration.
Page 158 ® Common Instrument Functions R&S FPL1000 General Instrument Setup 6.3.7 Alignment 6.3.7.1 Basics on Alignment When you put the instrument into operation for the first time or when strong tempera- ture changes occur, align the data to a reference source (see "Temperature check"...
Page 159 ® Common Instrument Functions R&S FPL1000 General Instrument Setup ter indicates a possible deviation. The current temperature of the RF frontend can be queried using a remote command (see SOURce:TEMPerature:FRONtend? on page 819). Touchscreen alignment When the device is delivered, the touchscreen is initially calibrated. However, to ensure that the touchscreen responds to the finger contact correctly, a touchscreen alignment is required.
Page 160 After the warmup operation has completed, self-alignment is star- ted automatically. Shut down Device after Self Alignment If activated, the R&S FPL1000 is automatically shut down after self-alignment is com- pleted. Note that the instrument cannot be restarted via remote control. Starting Touch Screen Alignment Starts the touchscreen alignment.
Page 161 ® Common Instrument Functions R&S FPL1000 General Instrument Setup Operating temperature Before performing this functional test, make sure that the instrument has reached its operating temperature (for details, refer to the data sheet). 1. Press the SETUP key. 2. Press the "Service" softkey.
Page 162: Network And Remote Operation
Repeat this action for the crosses in the other corners. 6.4 Network and Remote Operation In addition to working with the R&S FPL1000 interactively, located directly at the instru- ment, it is also possible to operate and control it from a remote PC. Various methods for remote control are supported: ●...
Page 163 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Table 6-3: Remote control interfaces and protocols Interface Remarks Protocols, VISA address string ● Local Area HiSLIP High-Speed LAN Instrument Protocol (IVI-6.1) A LAN connector is located on the TCPIP::host address::hislip0[::INSTR] Network rear panel of the instrument.
Page 164 R&S FPL1000 Network and Remote Operation The R&S FPL1000 supports various LAN protocols such as LXI, RSIB, raw socket or the newer HiSLIP protocol. IP address Only the IP address or a valid DNS host name is required to set up the connection.
Page 165 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation VXI-11 Protocol The VXI-11 standard is based on the ONC RPC (Open Network Computing Remote Procedure Call) protocol which in turn relies on TCP/IP as the network/transport layer. The TCP/IP network protocol and the associated network services are preconfigured.
Page 166 R&S FPL1000 Network and Remote Operation the port configured for remote-control. All R&S FPL1000 use port number 5025 for this purpose. The port is configured for communication on a command-to-command basis and for remote control from a program. LXI Web Browser Interface LAN eXtensions for Instrumentation (LXI) is an instrumentation platform for measuring instruments and test systems that is based on standard Ethernet technology.
Page 167 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation The navigation pane of the browser interface contains the following elements: ● "LXI" – "Home" opens the instrument home page. The home page displays the device information required by the LXI standard, including the VISA resource string in read-only format.
Page 168 GPIB Interface (IEC 625/IEEE 418 Bus Interface) An optional GPIB interface can be integrated on the rear panel of the instrument. By connecting a PC to the R&S FPL1000 via the GPIB connection you can send remote commands to control and operate the instrument.
Page 169 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Figure 6-1: Communication lines used by the GPIB interface User Manual 1178.3370.02 ─ 03...
Page 170: Scpi (Standard Commands For Programmable Instruments)
SCPI commands - messages - are used for remote control. Commands that are not taken from the SCPI standard follow the SCPI syntax rules. The R&S FPL1000 sup- ports the SCPI version 1999. The SCPI standard is based on standard IEEE 488.2 and aims at the standardization of device-specific commands, error handling and the status registers.
Page 171: Visa Libraries
® Common Instrument Functions R&S FPL1000 Network and Remote Operation Tables provide a fast overview of the bit assignment in the status registers. The tables are supplemented by a comprehensive description of the status registers. 6.4.1.3 VISA Libraries VISA is a standardized software interface library providing input and output functions to communicate with instruments.
Page 172: Scpi Command Structure
® Common Instrument Functions R&S FPL1000 Network and Remote Operation ● According to their definition in standards: – Common commands: their function and syntax are precisely defined in stan- dard IEEE 488.2. They are employed identically on all instruments (if imple- mented).
Page 173 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Syntax for Device-Specific Commands Not all commands used in the following examples are necessarily implemented in the instrument. For demonstration purposes only, assume the existence of the following commands for this section: ●...
Page 174 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Example: Definition: HCOPy:PAGE:DIMensions:QUADrant[<N>] Command: HCOP:PAGE:DIM:QUAD2 This command refers to the quadrant 2. Different numbering in remote control For remote control, the suffix may differ from the number of the corresponding selec- tion used in manual operation.
Page 175 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation ● Text Parameters....................176 ● Character Strings....................176 ● Block Data......................177 Numeric Values Numeric values can be entered in any form, i.e. with sign, decimal point and exponent. Values exceeding the resolution of the instrument are rounded up or down. The man- tissa may comprise up to 255 characters, the exponent must lie inside the value range -32000 to 32000.
Page 176 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation ● NAN: Not A Number (NAN) represents the value 9.91E37. NAN is only sent as a instrument response. This value is not defined. Possible causes are the division of zero by zero, the subtraction of infinite from infinite and the representation of miss- ing values.
Page 177 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Example: HCOP:ITEM:LABel "Test1" HCOP:ITEM:LABel 'Test1' Block Data Block data is a format which is suitable for the transmission of large amounts of data. For example, a command using a block data parameter has the following structure: FORMat:READings:DATA #45168xxxxxxxx The ASCII character # introduces the data block.
Page 178 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Table 6-6: Special characters Parameters A vertical stroke in parameter definitions indicates alternative possibilities in the sense of "or". The effect of the command differs, depending on which parameter is used.
Page 179 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Example: HCOP:ITEM ALL;:HCOP:IMM This command line contains two commands. Both commands are part of the HCOP command system, i.e. they have one level in common. If the successive commands belong to the same system, having one or several levels in common, the command line can be abbreviated.
Page 180: Command Sequence And Synchronization
® Common Instrument Functions R&S FPL1000 Network and Remote Operation 6.4.1.6 Command Sequence and Synchronization IEEE 488.2 defines a distinction between overlapped and sequential commands: ● A sequential command is one which finishes executing before the next command starts executing. Commands that are processed quickly are usually implemented as sequential commands.
Page 181 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Example: Overlapping command with *OPC The instrument implements INITiate[:IMMediate] as an overlapped command. Assuming that INITiate[:IMMediate] takes longer to execute than *OPC, sending the following command sequence results in initiating a sweep and, after some time, setting the OPC bit in the ESR: INIT;...
Page 182: Status Reporting System
® Common Instrument Functions R&S FPL1000 Network and Remote Operation 4. Wait for a service request. The service request indicates that the overlapped command has finished. *OPC? with a service request 1. Set bit no. 4 in the SRE: *SRE 16 to enable MAV service request.
Page 183 & Operation Complete Queue Buffer Figure 6-2: Graphical overview of the R&S FPL1000 status registers hierarchy ● STB, SRE The STatus Byte (STB) register and its associated mask register Service Request Enable (SRE) form the highest level of the status reporting system. The STB pro- vides a rough overview of the instrument status, collecting the information of the lower-level registers.
Page 184 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation ● IST, PPE The IST flag ("Individual STatus"), like the SRQ, combines the entire instrument status in a single bit. The PPE fulfills the same function for the IST flag as the SRE for the service request.
Page 185 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation ● PTRansition / NTRansition The two transition register parts define which state transition of the CONDition part (none, 0 to 1, 1 to 0 or both) is stored in the EVENt part.
Page 186 R&S FPL1000 Network and Remote Operation STATus:QUEStionable:SYNC register The STATus:QUEStionable:SYNC register is used by the R&S FPL1000 applica- tions and is described in the individual sections (manuals) for each application. ● Status Byte (STB) and Service Request Enable Register (SRE)......186 ●...
Page 187 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Bit No. Meaning MAV bit (message available) The bit is set if a message is available in the output queue which can be read. This bit can be used to enable data to be automatically read from the instrument to the controller.
Page 188 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Bit No. Meaning Device-dependent Error This bit is set if a device-dependent error occurs. An error message with a number between -300 and -399 or a positive error number, which denotes the error in greater detail, is entered into the error queue.
Page 189 "Battery LOW" This bit is set if the battery needs to be charged or a fixed power supply must be connected to the R&S FPL1000 to continue operation. "TIMe" This bit is set if a time error occurs in any of the active channels.
Page 190 STATus:QUEStionable:LMARgin Register provides more information on the error type. "SYNC" (device-specific) This bit is set if the R&S FPL1000 is not synchronized to the signal that is applied. The R&S FPL1000 is not synchronized if: ● it cannot synchronize to midamble during a measurement or premeasurement ●...
Page 191 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Bit No. Meaning ALT1 LOWer FAIL This bit is set if the limit is exceeded in the lower 1st alternate channel. ALT2 UPPer FAIL This bit is set if the limit is exceeded in the upper 2nd alternate channel.
Page 192 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Table 6-14: Meaning of the bits used in the STATus:QUEStionable:EXTended:INFO register Bit No. Meaning MESSage This bit is set if event or state has occurred that may lead to an error during further operation.
Page 193 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation STATus:QUEStionable:LIMit Register The STATus:QUEStionable:LIMit register contains information about the results of a limit check when you are working with limit lines. A separate LIMit register exists for each active channel and for each window.
Page 194 This bit is set if an overload occurs at the RF input, causing signal distortion but not yet causing damage to the device. The R&S FPL1000 displays the keyword "RF OVLD". UNDerload This bit is set if an underload occurs at the RF input.
Page 195 For details on the protection mechanism see "RF Input Protection" on page 364 or INPut: on page 669. ATTenuation:PROTection:RESet The R&S FPL1000 displays the keyword "INPUT OVLD". 4 to 14 Unused This bit is always 0. STATus:QUEStionable:TIMe Register The STATus:QUEStionable:TIMe register contains information about possible time errors that may occur during operation of the R&S FPL.
Page 196 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation troller, to which the control program can react appropriately. As evident from Fig- 6-2, an SRQ is always initiated if one or several of bits 2, 3, 4, 5 or 7 of the status byte are set and enabled in the SRE.
Page 197 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation The parallel poll method is mainly used to find out quickly which one of the instruments connected to the controller has sent a service request. To this effect, SRE and PPE must be set to the same value.
Page 198: General Programming Recommendations
® Common Instrument Functions R&S FPL1000 Network and Remote Operation Reset Values of the Status Reporting System The following table contains the different commands and events causing the status reporting system to be reset. None of the commands, except *RST and SYSTem:PRESet, influence the functional instrument settings.
Page 199 General Network Settings Access: SETUP > "Network + Remote" > "Network" tab The R&S FPL1000 can be operated in a local area network (LAN), for example to con- trol the instrument from a remote PC or use a network printer.
Page 200 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation Risk of network problems All parameters can be edited here; however, beware that changing the computer name has major effects in a network. For details, see Chapter 6.4.3, "How to Set Up a Network and Remote Control",...
Page 201 Opens the standard Windows "Network Configuration" dialog box for further configura- tion. 6.4.2.2 Remote Settings Access: SETUP > "Network + Remote" > "Remote" tab GPIB-specific settings are only available if option R&S FPL1-B10 is installed on the R&S FPL1000. User Manual 1178.3370.02 ─ 03...
Page 202 Defines the GPIB address. Values from 0 to 30 are allowed. The default address is 20. Remote command: on page 831 SYSTem:COMMunicate:GPIB[:SELF]:ADDRess Identification String Defines the identification string for the R&S FPL1000 which is provided as a response to the *IDN? query. Maximum 36 characters are allowed. Remote command: on page 832 SYSTem:IDENtify[:STRing] Reset to Factory String Restores the default identification string.
Page 203 Activates and deactivates the display of errors that occur during remote operation of the R&S FPL1000. If activated, the R&S FPL1000 displays a message box at the bot- tom of the screen that contains the type of error and the command that caused the error.
Page 204 6.4.2.3 Compatibility Settings Access: SETUP > "Network+Remote" > "Compatibility" The R&S FPL1000 can emulate the GPIB interface of other signal and spectrum ana- lyzers, e.g. in order to use existing control applications. Compatibility with former R&S signal and spectrum analyzers As a rule, the R&S FPL1000 supports most commands from previous R&S signal and...
Page 205 LXI Settings Access: SETUP > "Network + Remote" > "LXI" tab On the R&S FPL1000 the LXI Class C functionality is already installed and enabled; thus, the instrument can be accessed via any web browser (e.g. the Microsoft Internet Explorer) to perform the following tasks: ●...
Page 206 Detected LXI features, such as HiSlip (see "HiSLIP Protocol" Features" on page 165) "Computer Name of the R&S FPL1000 as defined in the operating system (see name" also "Computer Name" on page 200) "MAC address" Media Access Control address (MAC address), a unique identifier for the network card in the R&S FPL1000...
Page 207 Remote Errors Access: SETUP > "Network + Remote" > "Remote Errors " tab The error messages generated by the R&S FPL1000 during remote operation are dis- played here. The messages are displayed in the order of their occurrence; the most recent mes- sages are placed at the top of the list.
Page 208 Common Instrument Functions R&S FPL1000 Network and Remote Operation Clear Error List Deletes the error message buffer for remote operation. Note: The remote error list is automatically cleared when the R&S FPL1000 is shut down. Remote command: on page 836 SYSTem:ERRor:CLEar:REMote 6.4.2.6 Returning to Manual Mode ("Local")
Page 209 In production test and measurement, a common requirement is central monitoring of the T&M instruments for remote maintenance and remote diagnostics. Equipped with the Remote Desktop software of Windows, the R&S FPL1000 ideally meets require- ments for use in production. The computer that is used for remote operation is called "controller"...
Page 210 "How to Assign the IP Address" on page 210. Note: As the R&S FPL1000 uses a 1 GBit LAN, a crossover cable is not necessary (due to Auto-MDI(X) functionality). ► To establish a non-dedicated network connection, connect a commercial RJ-45 cable to one of the LAN ports.
Page 211 LAN. Contact your network administrator to obtain a valid IP address. Assigning the IP address on the R&S FPL1000 1. Press the SETUP key. 2. Press the "Network + Remote" softkey.
Page 212 11. Confirm the displayed message ("Yes" button) to restart the instrument. Using a DNS server to determine the IP address If a DNS server is configured on the R&S FPL1000, the server can determine the cur- rent IP address for the connection using the permanent computer name.
Page 213 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation 7. Select the "Properties" button. 8. On the "General" tab, select "Use the following DNS server addresses" and enter your own DNS addresses. For more information refer to the Windows operating system Help.
Page 214 ► Press the "Device Indicator" button on the "Instrument Home Page" to activate or deactivate the LXI status icon on the status bar of the R&S FPL1000. A green LXI status symbol indicates that a LAN connection has been established; a red symbol indicates an error, for example, that no LAN cable is connected.
Page 215 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation LAN Configuration The LAN configuration consists of three parts: ● "IP configuration" provides all mandatory LAN parameters. ● "Advanced LAN Configuration" provides LAN settings that are not declared manda- tory by the LXI standard.
Page 216 The GPIB address is maintained after a reset of the instrument settings. Setting the GPIB address 1. On the R&S FPL1000, press the SETUP key. 2. Press the "Network + Remote" softkey. 3. In the "Network + Remote" dialog box, select the "GPIB" tab.
Page 217 (= default user ID for Windows automatic login) in the network. Thus, a matching user must be created in the R&S FPL1000 and in the network, the password must be adap- ted to the network password, and the automatic login mechanism must then be deacti- vated.
Page 218 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation 5. Enter the new password in the upper text line and repeat it in the following line. 6. Press ENTER. The new password is now active. How to Activate or Deactivate the Automatic Login Mechanism...
Page 219 6.4.3.5 How to Control the R&S FPL1000 via the Web Browser Interface Via the LXI browser interface to the R&S FPL1000 one or more users can control the instrument remotely from another PC without additional installation. Most instrument controls are available via the front panel simulation. File upload and download between the instrument and the remote PC is also available.
Page 220 My Computer folder, from which you can access all other folders on the instrument. 3. To download a file from the R&S FPL1000, select the file from the displayed fold- ers and then select "Download File".
Page 221 Remote Desktop provides access to all of the applications, files, and net- work resources of the instrument. Thus, remote operation of the R&S FPL1000 is pos- sible.
Page 222 3. In the "Start" menu, select the "Control Panel" and then "System and Security". 4. In the "System" area, select "Allow remote access". 5. Define which users are to be given access to the R&S FPL1000 via Remote Desk- top.
Page 223 Only users in the Remote Desktop Users Group are allowed to connect to the R&S FPL1000 via Remote Desktop. You can add the users to this group directly when you allow remote access on the R&S FPL1000, as described in Chapter 6.4.3.7, "How...
Page 224 ® Common Instrument Functions R&S FPL1000 Network and Remote Operation c) As the level of access you want to allow the new user, select "Other", then select "Remote Desktop Users" from the dropdown list. d) Select the "Finish" button. The user is created.
Page 225 6. Open the "Local Resources" tab to enable printers, local drives and serial interfa- ces. 7. If you will need to access drives of the controller from the R&S FPL1000 (e.g. in order to store settings or to copy files from the controller to the R&S FPL1000), activate the "Disk drives"...
Page 226 Network and Remote Operation The options to configure the R&S FPL1000 screen display are displayed. 10. Under "Remote desktop size", you can set the size of the R&S FPL1000 window on the desktop of the controller. 11. Under "Colors", do not change the settings.
Page 227 R&S FPL1000 screen. To terminate Remote Desktop control The connection can be terminated by the controller or by a user at the R&S FPL1000: 1. On the controller, close the "Remote Desktop" window at any time. The connection to the R&S FPL1000 is terminated.
Page 228 Restoring the connection to the R&S FPL1000 Follow the instructions above for setting up a connection to the R&S FPL1000. If the connection is terminated and then restored, the R&S FPL1000 remains in the same state.
Page 229 Switching to manual mode is only possible via remote control then. This function is only available for the GPIB interface. 5. To enable the keys of the R&S FPL1000 again, switch the instrument to local mode (GTL - Go to Local), i.e. deactivate the REN line of the remote control interface.
Page 230: The Spectrum Application (Rf Measurements)
® The Spectrum Application (RF Measurements) R&S FPL1000 Configuration Overview 7 The Spectrum Application (RF Measure- ments) The Spectrum application provides basic RF measurements in the frequency and time domain. The common settings for these measurements are described here. ●...
Page 231 Do not confuse the "Preset Channel" button with the PRESET key, which restores the entire instrument to its default values and thus closes all channel setups on the R&S FPL1000 (except for the default channel setup)! Remote command: on page 799 SYSTem:PRESet:CHANnel[:EXEC] User Manual 1178.3370.02 ─...
Page 232: Measurements And Results
7.2 Measurements and Results Access: "Overview" > "Select Measurement" Or: MEAS In the Spectrum application, the R&S FPL1000 provides a variety of different measure- ment functions. ● Basic measurements - measure the spectrum of your signal or watch your signal in time domain ●...
Page 233 If no other measurement function is selected, or if all measurement functions are switched off, the R&S FPL1000 performs a basic frequency or time sweep. After a preset, a frequency sweep is performed.
Page 234 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: on page 644 [SENSe:]FREQuency:SPAN on page 536 INITiate<n>[:IMMediate] on page 536 INITiate<n>:CONTinuous All Functions Off Switches off all measurement functions and returns to a basic frequency sweep.
Page 235 Measuring the Level and Frequency Using Markers The level and frequency of a sinusoidal signal can be measured easily using the marker function. The R&S FPL1000 always displays its amplitude and frequency at the marker position. The frequency measurement uncertainty is determined by the refer- ence frequency of the R&S FPL1000, the resolution of the marker frequency display...
Page 236 R&S FPL1000. In other words, the highest level that occurs in the signal should be located at the top edge of the diagram ( = reference level) or immediately below it.
Page 237 The built-in signal counter allows you to measure the frequency more accurately than measuring it with the marker. The frequency sweep is stopped at the marker, and the R&S FPL1000 measures the frequency of the signal at the marker position (see also Chapter 7.9.4.1, "Precise Frequency (Signal Count) Marker",...
Page 238 Small signals can be swamped by noise and therefore cannot be measured. For sig- nals that are just above the intrinsic noise, the accuracy of the level measurement is influenced by the intrinsic noise of the R&S FPL1000. The displayed noise level of a signal analyzer depends on its noise figure, the selected RF attenuation, the selected reference level, the selected resolution and video band- width and the detector.
Page 239 467). The traces of consecutive sweeps are averaged. To perform averaging, the R&S FPL1000 automatically switches on the sample detector. The RF signal, therefore, can be more clearly distinguished from noise. Figure 7-2: RF sine wave signal with low S/N ratio with an averaged trace 6.
Page 240 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results The RF signal can be distinguished from noise more clearly. Figure 7-3: RF sine wave signal with low S/N ratio with a smaller video bandwidth 7. By reducing the resolution bandwidth by a factor of 10, the noise is reduced by 10 dB.
Page 241 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results 7.2.1.5 Measurement Examples - Measuring Signal Spectra with Multiple Signals ● Separating Signals by Selecting the Resolution Bandwidth......... 241 ● Measuring the Modulation Depth of an AM-Modulated Carrier in the Frequency Domain........................244...
Page 242 The level drop is located exactly in the center of the display only if the generator frequencies match the frequency display of the R&S FPL1000 exactly. To achieve exact matching, the frequencies of the generators and the R&S FPL1000 must be synchronized.
Page 243 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-7: Measurement of two equally-leveled RF sinusoidal signals with a resolution band- width which is larger than their frequency spacing 6. Set the resolution bandwidth to 1 kHz.
Page 244 Since the dynamic range of a signal ana- lyzer is very large, extremely small modulation depths can also be measured precisely. For this purpose, the R&S FPL1000 provides measurement routines that output the modulation depth numerically in percent directly.
Page 245 4. Select MEAS > "AM Modulation Depth" to activate the modulation depth measure- ment. The R&S FPL1000 automatically sets a marker to the carrier signal in the center of the diagram and one delta marker each to the upper and lower AM sidebands. The R&S FPL1000 calculates the AM modulation depth from the level differences of the...
Page 246 Set the "Trg/Gate Level" to 50%. The trigger level is displayed as a horizontal line across the entire measurement diagram. The R&S FPL1000 displays the 1 kHz AF signal as a static image in zero span. User Manual 1178.3370.02 ─ 03...
Page 247 Press the MKR FUNC key. b) Select "Marker Demodulation" . The R&S FPL1000 automatically switches on the AM audio demodulator. A 1 kHz tone can be heard over headset (via the PHONES connector). If neces- sary, use the volume control to turn up the volume.
Page 248 Set the "Trg Source" to "Video" . c) Set the "Trg/Gate Level" to 70%. The R&S FPL1000 shows a static image with the GSM burst at the start of the trace. The trigger level is displayed as a horizontal line labeled with the absolute level for the trigger threshold in the measurement diagram.
Page 249 Measuring the Edges of a GSM Burst with High Time Resolution Due to the high time resolution of the R&S FPL1000 at the 0 Hz display range, the edges of TDMA bursts can be measured precisely. The edges can be shifted to the display area using the trigger offset.
Page 250 By turning the rotary knob counterclockwise, reduce the trigger offset until the burst edge is displayed in the center of the display, or enter -50 µs. The R&S FPL1000 displays the rising edge of the GSM burst. Figure 7-16: Rising edge of the GSM burst displayed with high time resolution...
Page 251 Therefore, the R&S FPL1000 provides a measurement for absolute and relative power in zero span. In the following example, the measurement is performed using a GSM burst.
Page 252 9. Measure the power during the deactivation phase of the burst by switching the trig- ger slope to "Falling" (TRIG > "Trigger/ Gate Config" ). The R&S FPL1000 initiates triggering in response to the falling edge of the burst. This shifts the burst to the left-hand side of the measurement diagram. The power is measured in the deactivation phase.
Page 253 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-19: Measurement of the signal-to-noise ratio of a GSM burst signal in zero span 7.2.2 Basic Evaluation Methods Measurement results can be displayed and evaluated using various different methods, also at the same time.
Page 254 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: LAY:ADD? '1',RIGH, DIAG, see on page 632 LAYout:ADD[:WINDow]? Results: on page 703 TRACe<n>[:DATA] Marker Table Displays a table with the current marker values for the active markers.
Page 255 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Result Summary Result summaries provide the results of specific measurement functions in a table for numerical evaluation. The contents of the result summary vary depending on the selected measurement function. See the description of the individual measurement functions for details.
Page 256 The R&S FPL1000 software allows you to perform ACLR measurements on input con- taining multiple signals for different communication standards. A measurement stan- dard is provided that allows you to define multiple discontiguous transmit channels at specified frequencies, independent from the selected center frequency.
Page 257 ● Power of all the higher and lower channels (alternate channels 1 to 11) In the R&S FPL1000 display, only the first neighboring channel of the carrier (TX) channel is labeled "Adj" (adjacent) channel; all others are labeled "Alt" (alternate) channels.
Page 258: Sweep Time
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Alternatively, the results can be output as channel power density, i.e. in reference to the measurement bandwidth. Furthermore, the measured power values of the displayed trace can be retrieved as usual using the TRAC:DATA? commands (see on page 703).
Page 259: Frequency Span
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results If the sample detector is used, it is best to select the smallest "Sweep Time" possible for a given span and resolution bandwidth. The minimum time is obtained if the setting is coupled, that is: the time per measurement is minimal.
Page 260: Resolution Bandwidth (Rbw)
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results ● Bandwidth of one of adjacent-channels ADJ, ALT1 or ALT2, whichever is furthest away from the transmission channels "(No. of transmission channels – 1) * (transmission channel spacing + 2) * (adjacent- channel spacing + adjacent-channel bandwidth) + measurement margin"...
Page 261: Detector
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results The video bandwidth (VBW) is set as a function of the channel bandwidth (see formula above) and the smallest possible VBW with regard to the available step size is selected.
Page 262 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results than the signal bandwidth. Thus, the signal path can be overloaded although the trace is still significantly below the reference level. Selecting a predefined standard or automatically adjusting settings does not affect the reference level.
Page 263: Standard
The main measurement settings can be stored as a standard file. When such a stan- dard is loaded, the required channel and general measurement settings are automati- cally set on the R&S FPL1000. However, the settings can be changed. Predefined standards are available for standard measurements, but standard files with user- defined configurations can also be created.
Page 264: Number Of Channels: Tx , Adj
Note: User standards created on an analyzer of the R&S FSP family are compatible to the R&S FPL1000. User standards created on an R&S FPL1000, however, are not necessarily compatible to the analyzers of the R&S FSP family and may not work there.
Page 265: Reference Channel
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Reference Channel The measured power values in the adjacent channels can be displayed relative to the transmission channel. If more than one Tx channel is defined, define which one is used as a reference channel.
Page 266: Power Mode
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Power Mode The measured power values can be displayed directly for each trace ( "Clear/ Write" ), or only the maximum values over a series of measurements can be displayed ( "Max Hold"...
Page 267 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Channel Setup The "Channel Settings" tab in the "ACLR Setup" dialog box provides all the channel settings to configure the channel power or ACLR measurement. You can define the...
Page 268 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results The value entered for any ADJ or ALT channel is automatically also defined for all alternate (ALT) channels. Thus, only enter one value if all adjacent channels have the same bandwidth.
Page 269 [SENSe:]POWer:ACHannel:FILTer:ALPHa:ALTernate<ch> Channel Names In the R&S FPL1000's display, carrier channels are labeled "Tx" by default; the first neighboring channel is labeled "Adj" (adjacent) channel; all others are labeled "Alt" (alternate) channels. You can define user-specific channel names for each channel which are displayed in the result diagram and result table.
Page 270 How to Perform a Standard Channel Power Measurement Performing a channel power or ACLR measurement according to common standards is a very easy and straightforward task with the R&S FPL1000. 1. Press the MEAS key or select "Select Measurement" in the "Overview" .
Page 271 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results ● The number of transmission (Tx) and adjacent channels ● The bandwidth of each channel ● For multicarrier ACLR measurements: which Tx channel is used as a reference ●...
Page 272 User standards created on an analyzer of the R&S FSP family are compatible to the R&S FPL1000. User standards created on an R&S FPL1000, however, are not neces- sarily compatible to the analyzers of the R&S FSP family and may not work there.
Page 273 7.2.3.6 Measurement Examples The R&S FPL1000 has test routines for simple channel and adjacent channel power measurements. These routines give quick results without any complex or tedious set- ting procedures. A programming example demonstrating an ACLR measurement in a remote environ- ment is provided in Chapter 8.6.3.8, "Programming Examples for Channel Power Mea-...
Page 274 5. Set the optimal reference level and RF attenuation for the applied signal level using the "Auto Level" function. The R&S FPL1000 sets the optimum RF attenuation and the reference level for the power in the transmission channel to obtain the maximum dynamic range. The fol- lowing figure shows the result of the measurement.
Page 275 ► Leave the RF input of the R&S FPL open-circuited or terminate it with 50 Ω. Procedure: 1. Preset the R&S FPL1000. 2. Set the center frequency to 1 GHz and the span to 1 MHz. 3. To obtain maximum sensitivity, set RF attenuation to 0 dB and the reference level to -40 dBm.
Page 276 The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-21: Measurement of the R&S FPL1000's intrinsic noise power in a 1.23 MHz channel bandwidth. 7.2.3.7 Optimizing and Troubleshooting the Measurement If the results do not meet your expectations, or if you want to minimize the measure- ment duration, try the following methods to optimize the measurement: ●...
Page 277 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results 7.2.3.8 Reference: Predefined CP/ACLR Standards When using predefined standards for ACLR measurement, the test parameters for the channel and adjacent-channel measurements are configured automatically. You can select a predefined standard via the "CP / ACLR Standard" softkey in the "Ch Power"...
Page 278 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results For this measurement, the RMS detector is activated. The carrier-to-noise measurements are only available in the frequency domain (span >0). Measurement process Depending on whether the carrier is inside or outside the analyzed channel, the mea- surement process for the carrier-to-noise ratio varies: ●...
Page 279 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: You can also query the determined carrier-to-noise ratio via the remote command CALC:MARK:FUNC:POW:RES? CN or CALC:MARK:FUNC:POW:RES? CN0, see on page 538. CALCulate<n>:MARKer<m>:FUNCtion:POWer<sb>:RESult? 7.2.4.3 Carrier-to-Noise Configuration Access: "Overview" > "Select Measurement" > "C/N" / "C/N0" > "Carrier Noise Config"...
Page 280 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results ..........................280 C/N0 ........................... 280 Channel Bandwidth ....................280 Adjust Settings ......................280 Switches the measurement of the carrier/noise ratio on or off. If no marker is active, marker 1 is activated.
Page 281 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results For remote operation, see "Programming example: Measuring the carrier-to-noise ratio" on page 559. 1. Press the "C/N" , "C/N0" softkey to configure the carrier-to-noise ratio measure- ment. 2. To change the channel bandwidth to be analyzed, press the "Channel Bandwidth"...
Page 282 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results between the two markers. The distance between the two frequency markers is the occupied bandwidth which is displayed in the marker field. OBW within defined search limits - multicarrier OBW measurement in one sweep The occupied bandwidth of the signal can also be determined within defined search limits instead of for the entire signal.
Page 283 Measurements and Results Some of the measurement specifications (e.g. PDC, RCR STD-27B) require measure- ment of the occupied bandwidth using a peak detector. The detector setting of the R&S FPL1000 has to be changed accordingly then. 7.2.5.2 OBW Results As a result of the OBW measurement the occupied bandwidth ( "Occ Bw" ) is indicated in the marker results.
Page 284 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results CALC:MARK:FUNC:POW:RES? OBW, see CALCulate<n>:MARKer<m>:FUNCtion: on page 538 POWer<sb>:RESult? 7.2.5.3 OBW Configuration Access: "Overview" > "Select Measurement" > "OBW" > "OBW Config" This measurement is not available in zero span.
Page 285 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Channel Bandwidth Defines the channel bandwidth for the transmission channel in single-carrier measure- ments. This bandwidth is used to optimize the test parameters (for details see " Adjust Settings "...
Page 286 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results 7.2.5.4 How to Determine the Occupied Bandwidth The following step-by-step instructions demonstrate how to determine the occupied bandwidth. For remote operation, see Chapter 8.6.5.2, "Programming Example: OBW Measure- ment", on page 561.
Page 287 Chapter 8.6.6.10, "Example: SEM Measurement", on page 587. 1. Preset the R&S FPL1000. 2. Set the "Center Frequency" to 800 MHz. 3. Set the "Reference Level" to -10 dBm. 4. Press the MEAS key or select "Select Measurement" in the "Overview" .
Page 288 The Spectrum Emission Mask (SEM) measurement defines a measurement that moni- tors compliance with a spectral mask. The mask is defined with reference to the input signal power. The R&S FPL1000 allows for a flexible definition of all parameters in the SEM measurement. The analyzer performs measurements in predefined frequency ranges with settings that can be specified individually for each of these ranges.
Page 289 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Example: For example, in Figure 7-22, "31 < P < 39" is indicated as the used power class is defined from 31 to 39. Figure 7-22: Spectrum Emission Mask result displays...
Page 290 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results You can define in which detail the data is displayed in the result summary in the "List Evaluation" settings (see "List Evaluation (Results Configuration)" on page 313). By default, one peak per range is displayed. However, you can change the settings to dis- play only peaks that exceed a threshold ( "Margin"...
Page 291 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-24: SEM results for multiple sub blocks Retrieving results via remote control The measurement results of the spectrum emission mask test can be retrieved using the CALC:LIM:FAIL? command from a remote computer; see CALCulate<n>:...
Page 292 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results ● Start and stop frequency ● ● ● "Sweep Time" ● "Sweep Points" ● Reference level ● Attenuator settings ● Preamplifier settings ● Transducer settings ● Limit values Via the sweep list, you define the ranges and their settings. For details on settings, refer to "...
Page 293 If the total number of sweep points is not enough to satisfy the mini- mum sweep point requirements in all ranges, the R&S FPL1000 adjusts the global number of Sweep Points accordingly.
Page 294 Measurements and Results Limit Lines in SEM Measurements For the R&S FPL1000, the spectrum emission mask is defined using limit lines. Limit lines allow you to check the measured data (that is, the trace results) against specified limit values. Generally, it is possible to define limit lines for any measurement in the Spectrum application application using the LINES function.
Page 295 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Limit check type Pass/fail criteria Limit line definition "Relative with If the power exceeds both the abso- Defined by the maximum of the absolute or function f(x)" lute and the relative limits, the check...
Page 296 313). Fast SEM Measurements To improve the performance of the R&S FPL1000 for spectrum emission mask mea- surements, a "Fast SEM" mode is available. If this mode is activated, several consecu- tive ranges with identical sweep settings are combined to one sweep internally, which makes the measurement considerably faster.
Page 297 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Consequences When the "Fast SEM" mode is activated, the ranges for which these criteria apply are displayed as one single range. The sweep time is defined as the sum of the individual sweep times, initially, but can be changed.
Page 298 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Comparison to "traditional" SEM measurement The default SEM measurement is simply a special case of "Multi-SEM" - consisting of one single block. Only if the number of sub blocks in the basic SEM configuration is larger than 1, multiple sub blocks are inserted in the configuration settings and result tables.
Page 299 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-26: Behavior for overlapping masks ● For the ranges in which multiple limit lines are significant, a range-specific function determines the behavior of the limit check Limit calculation for individual ranges...
Page 300 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Different RBWs in overlapping ranges If different RBWs are defined for the overlapping ranges, the following parameters from the range with the smaller RBW are considered for both ranges: ●...
Page 301 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-27: Summarized limit line for multiple sub blocks 7.2.6.5 SEM Configuration Access: "Overview" > "Select Measurement" > "Spectrum Emission Mask" The SEM measurement is started immediately with the default settings.
Page 302 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results ● Power Classes...................... 310 ● Standard Files.......................311 ● List Evaluation (Results Configuration)..............313 Sweep List Access: "Overview" > "Select Measurement" > "Spectrum Emission Mask" > "Sweep List" For SEM measurements, the input signal is split into several frequency ranges which are swept individually and for which different limitations apply.
Page 303 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Rel Limit Start / Stop <n> ................... 305 Multi-Limit Calc <n> ....................306 Min Sweep Points ...................... 306 Insert before Range / Insert after Range ..............307 Delete Range ......................307 Symmetrical Setup .....................
Page 304 [SENSe:]ESPectrum<sb>:RANGe<range>:BANDwidth:VIDeo Sweep Time Mode Activates or deactivates the auto mode for the sweep time. Currently, only auto mode is available for the R&S FPL1000. For details on the sweep time mode, see Chapter 7.6.1.7, "How Long the Data is Mea- sured: Sweep Time ",...
Page 305 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: on page 570 [SENSe:]ESPectrum<sb>:RANGe<range>:INPut:GAIN:STATe Transducer Factor Sets a transducer for the specified range. You can only choose a transducer that fulfills the following conditions: ● The transducer overlaps or equals the span of the range.
Page 306 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results If the function is set to "Max" , you can define a relative and an absolute limit level. In this case, the maximum of the two values is used as the limit level.
Page 307 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: [SENSe:]ESPectrum<sb>:RANGe<range>:POINts:MINimum[:VALue] on page 576 Insert before Range / Insert after Range Inserts a new range to the left (before) or to the right (after) of the range in which the cursor is currently displayed.
Page 308 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Sub Block Count ......................308 Sub Block / Center Freq .....................308 Standard ........................308 Edit Sweep List ......................308 Sub Block Count Defines the number of sub blocks. By default, the familiar SEM measurement with just one single block of ranges is configured.
Page 309 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Power Reference Type ....................309 Channel Power Settings .....................309 └ Tx Bandwidth ....................309 └ RRC Filter State ...................309 └ Alpha: ......................310 Power Reference Type Defines how the reference power is calculated.
Page 310 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Alpha: ← Channel Power Settings Sets the alpha value of the RRC filter (if activated). Remote command: on page 579 [SENSe:]ESPectrum<sb>:FILTer[:RRC]:ALPHa Power Classes Access: "Overview" > "Select Measurement" > "Spectrum Emission Mask" > "Power Classes"...
Page 311 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results PMin / PMax Defines the power limits for each power class. The first range always starts at -200 dBm (-INF) and the last range always stops at 200 dBm (+INF). These fields cannot be modified.
Page 312 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results For details, see "How to Manage SEM Settings Files" on page 317. Standard files for sub blocks (Multi-SEM measurements) If more than one sub blocks are defined, the "Standard Files" tab and softkey are not available.
Page 313 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results For details on the filename and location, see "Storage Location and Filename" on page 103. Load Standard Loads the selected measurement settings file. Remote command: on page 562 [SENSe:]ESPectrum<sb>:PRESet[:STANdard]...
Page 314 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results List Evaluation State (Result Summary)..............314 Show Peaks ....................... 314 Margin ........................314 Saving the Result Summary (Evaluation List) to a File ..........314 List Evaluation State (Result Summary) Activates or deactivates the Result Summary.
Page 315 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: on page 812 MMEMory:STORe<n>:LIST on page 786 FORMat:DEXPort:DSEParator 7.2.6.6 How to Perform a Spectrum Emission Mask Measurement SEM measurements can be performed according to a specific standard or freely con- figured.
Page 316 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results 3. If the signal power level to be monitored varies and the limits vary, define power classes. For each range of levels that can be monitored in the same way, define a power class.
Page 317 SEM measurement settings can be saved to an XML file which can then be exported to another application or loaded on the R&S FPL1000 again later. Some predefined XML files are provided that contain ranges and parameters according to the selected stan- dard.
Page 318 FPL1000 Measurements and Results 2. Select the "Load" button. The settings from the selected file are restored to the R&S FPL1000 and you can repeat the SEM measurement with the stored settings. How to save a user-defined SEM settings file 1.
Page 319 A programming example demonstrating a SEM measurement in a remote environment is provided in Chapter 8.6.6.10, "Example: SEM Measurement", on page 587. Test setup: Signal generator settings (e.g. R&S FPL1000 SMW): Device Standard Center frequency Level Test model SigGen 1...
Page 320 XML file itself. In addition to saving the current settings to a file, settings files can also be created independently of the R&S FPL1000, in an external application. When creating your User Manual 1178.3370.02 ─ 03...
Page 321 Be sure to follow the structure exactly as shown below or else the R&S FPL1000 is not able to interpret the XML file and error messages are shown on the screen. It is recom- mended that you make a copy of an existing file and edit the copy of the file.
Page 322 The maximum num- ber of ranges is 30. Note that the R&S FPL1000 uses the same ranges in each power class. Therefore, the contents of the ranges of each defined power class have to be identical to the first power class.
Page 323 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results </Range> … </PowerClass> ● The "Range" element is structured as follows: – <Range Index="n"> <Name="Name"> <ChannelType>"Channel Type"</Channel Type> <WeightingFilter> <Type>"FilterType"</Type> <RollOffFactor>"Factor"</RollOffFactor> <Bandwith>"Bandwidth"</Bandwidth> </WeightingFilter> <FrequencyRange> <Start>"RangeStart"</Start> <Stop>"RangeStop"</Stop> </FrequencyRange> <Limit> <Start Unit="Unit" Value="Value"/>...
Page 324 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Child Node Attribute Value Parameter Description Mand. ShortName DL | UL Reference- Power Method TX Channel Power | TX Channel Peak Power Reference- <string> Channel Table 7-14: Attributes and child nodes of the PowerClass element...
Page 325 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Child node Attribute Value Parameter description Mand. WeightingFilter Only if Referen- cePower method is TX Channel Power and the range is the ref- erence range Type RRC | CFilter...
Page 326 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Child node Attribute Value Parameter description Mand. ReferenceLevel Value <power in dBm> " Ref Level " on page 304 Yes, if the Refer- enceLevel child node is used Unit...
Page 327 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results File contents Explanation y-Unit;dBm; List evaluation settings Margin;200; Peak List margin Reference range settings RefType; CPOWER; Reference power type TxBandwidth;3840000;;Hz Channel power settings Filter State; ON; Alpha;0.22; PeaksPerRange;1; Max. number of peaks per range to be detected Values;2;...
Page 328 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results tions of the absolute power from the limit line for each range, and the results can be checked against defined limits automatically. 7.2.7.2 Spurious Emissions Measurement Results The measured signal, including any spurious emissions, and optionally the detected peaks are displayed in the Spurious Emissions measurement diagram.
Page 329 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results ● Display a certain number of peaks per range ● Display only peaks that exceed a threshold ( "Margin" ) ● Display detected peaks as blue squares in the diagram, as well as in the peak list Furthermore, you can save the evaluation list to a file.
Page 330 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Defining ranges by remote control In Spurious Emissions measurements, there are no remote commands to insert new ranges between existing ranges directly. However, you can delete or redefine the exist- ing ranges to create the required order.
Page 331 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results The limit check is considered to be "' failed!" if any signal level outside the absolute lim- its is measured. If the limit check is activated, the limit line values for each range are displayed in the evaluation list.
Page 332: Range Start / Range Stop
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Range Start / Range Stop ..................332 Filter Type ........................332 ...........................333 ........................... 333 Sweep Time Mode ..................... 333 Sweep Time ....................... 333 Detector ........................333 Reference Level ......................333 RF Attenuation Mode ....................
Page 333: Rbw
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results For details on filter types, see Chapter 7.6.1.6, "Which Data May Pass: Filter Types", on page 394. Remote command: on page 593 [SENSe:]LIST:RANGe<range>:FILTer:TYPE Sets the RBW value for this range.
Page 334: Rf Attenuation Mode
395. Remote command: on page 596 [SENSe:]LIST:RANGe<range>:POINts[:VALue] Stop After Sweep This function is not available for the R&S FPL1000. Transducer Sets a transducer for the specified range. You can only choose a transducer that fulfills the following conditions: ●...
Page 335: Abs Limit Start / Abs Limit Stop
® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: on page 596 [SENSe:]LIST:RANGe<range>:LIMit:STATe on page 782 CALCulate<n>:LIMit<k>:FAIL? Abs Limit Start / Abs Limit Stop Sets an absolute limit value at the start or stop frequency of the range [dBm].
Page 336 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results List Evaluation State ....................336 Show Peaks ....................... 336 Margin ........................336 Details ........................336 Peaks per Range ....................... 337 Save Evaluation List ....................337 List Evaluation State Activates or deactivates the list evaluation.
Page 337 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Includes all detected peaks (up to a maximum defined by "Peaks per Range" ). Includes only one peak per range. Remote command: on page 598 CALCulate<n>:ESPectrum:PEAKsearch:DETails Peaks per Range Defines the maximum number of peaks per range that are stored in the list.
Page 338 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results a) Activate the limit check by setting "Limit Check" to "ABSOLUTE" . The limit check is always activated or deactivated for all ranges simultaneously. b) Define the limit line's start and stop values for each range of the signal. If a sig- nal level higher than the defined limit is measured, the limit check fails, which may indicate a spurious emission.
Page 339 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results The header data is made up of three columns, separated by ';', with the syntax: Parameter name; numeric value; basic unit File contents Explanation File header Type;FPL1003 Model Version;1.00;...
Page 340 7.2.8.1 About the Measurement Using the Time Domain Power measurement function, the R&S FPL1000 determines the power of the signal in zero span by summing up the power at the individual mea- surement points and dividing the result by the number of measurement points. Thus it is possible to measure the power of TDMA signals during transmission, for example, or during the muting phase.
Page 341 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Mode Description Mean Mean value from the points of the displayed trace or a segment thereof. The linear mean value of the equivalent voltages is calcula- ted. For example to measure the mean power during a GSM burst...
Page 342 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results 7.2.8.4 Time Domain Power Configuration Access: "Overview" > "Select Measurement" > "Time Domain Power" > "Time Dom Power Config" The remote commands required to perform these tasks are described in Chapter 8.6.8,...
Page 343 The measured powers are displayed in the marker results. 7.2.8.6 Measurement Example This measurement example demonstrates the time domain power calculation for a GSM burst. Test setup: Signal generator settings (e.g. R&S FPL1000 SMW): Frequency: 1.8 GHz Level: -10 dBm Modulation:...
Page 344 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results 2. Set the center frequency to 1.8 GHz. 3. Set the RBW to 100 kHz. μ s. 4. Set the sweep time to 640 5. Set the trigger source to "IF Power" .
Page 345 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results 7.2.9.1 About the Measurement With this measurement it is possible to measure the harmonics easily, for example from a VCO. In addition, the total harmonic distortion (THD) is calculated.
Page 346 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results As shown in Figure 7-29, the level of the 2 harmonic drops by 20 dB if the level of the fundamental wave is reduced by 10 dB. Figure 7-29: Extrapolation of the 1st and 2nd harmonics to the 2nd harmonic intercept at 40 dBm...
Page 347 The sweep time is, therefore, also increased con- siderably. In this case, the measurement of individual harmonics is carried out with the R&S FPL1000 set to a small span. Only the frequency range around the harmonics will then be measured with a small resolution bandwidth.
Page 348 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results In addition, a result table is displayed providing the following information: ● First harmonic frequency ● THD (total harmonic distortion), relative and absolute values ● For each detected harmonic: –...
Page 349 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results The remote commands required to perform these tasks are described in Chapter 8.6.9, "Measuring the Harmonic Distortion", on page 612. Number of Harmonics ....................349 Harmonic Sweep Time ....................349 Harmonic RBW Auto ....................
Page 350 "Adjust Settings" function to adjust the settings automatically and restart the measurement. 7.2.10 Third Order Intercept (TOI) Measurement The third order intercept point of the R&S FPL1000 can be determined if a two-tone signal with equal carrier levels is applied to the input. on page 617 CALCulate<n>:MARKer<m>:FUNCtion:TOI:RESult?
Page 351 In order to measure the third order intercept point (TOI), a two-tone signal with equal carrier levels is expected at the R&S FPL1000 input. Marker 1 and marker 2 (both nor- mal markers) are set to the maximum of the two signals. Marker 3 and marker 4 are placed on the intermodulation products.
Page 352 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-30: Intermodulation products Ps1 and Ps2 The intermodulation product at f is generated by mixing the 2nd harmonic of useful signal P and signal P Tthe intermodulation product at f...
Page 353 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Figure 7-31: Dependency of intermodulation products on level of useful signals The useful signals at the two-port output increase proportionally with the input level as long as the two-port is in the linear range. A level change of 1 dB at the input causes a level change of 1 dB at the output.
Page 354 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Intermodulation-free dynamic range The "Intermodulation-free dynamic range", i.e. the level range in which no internal intermodulation products are generated if two-tone signals are measured, is deter- mined by the third order intercept point, the phase noise and the thermal noise of the signal analyzer.
Page 355 The measurement time will be reduced, in particular if the offset of the useful signals is large. To find signals reliably when frequency span is small, it is best to synchronize the signal sources and the R&S FPL1000. 7.2.10.3...
Page 356 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command The TOI can also be queried using the remote command CALCulate<n>: on page 617. MARKer<m>:FUNCtion:TOI:RESult? 7.2.10.4 TOI Configuration Access: "Overview" > "Select Measurement" > "Third Order Intercept" > "TOI Config"...
Page 357 617 CALCulate<n>:MARKer<m>:FUNCtion:TOI:SEARchsignal ONCE 7.2.10.5 How to Determine the Third Order Intercept The precise TOI for the R&S FPL1000 in relation to the input signals is provided in the data sheet. For remote operation, see Chapter 8.6.10.2, "Programming Example: Measuring the TOI",...
Page 358 1. Press the MEAS key and select the "Third Order Intercept" measurement function from the "Select Measurement" dialog box. The R&S FPL1000 activates four markers to measure the intermodulation dis- tance. Two markers are positioned on the useful signals and two on the intermodu- lation products.
Page 359 20 dB. The noise level is, however, increased by 10 dB. Increase the RF attenuation to 20 dB to reduce intermodulation products. The R&S FPL1000's intrinsic intermodulation products disappear below the noise floor. User Manual 1178.3370.02 ─ 03...
Page 360 The markers can be adjusted manually, if necessary. The R&S FPL1000 calculates the power at the marker positions from the measured levels. The AM modulation depth is calculated as the ratio between the power values at the reference marker and at the delta markers.
Page 361 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Remote command: The AM modulation depth can also be queried using the remote command on page 619. CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:RESult? 7.2.11.3 AM Modulation Depth Configuration Access: "Overview" > "Select Measurement" > "AM Modulation Depth" > "AM Mod Depth Config"...
Page 362 ® The Spectrum Application (RF Measurements) R&S FPL1000 Measurements and Results Marker Description Maximum of the signal (= carrier level) Offset of next peak to the right of the carrier Offset of the next peak to the left of the carrier The marker positions can be edited;...
Page 363: Receiving Data Input And Providing Data Output
AM Modulation Depth. 7.3 Receiving Data Input and Providing Data Output The R&S FPL1000 can analyze signals from different input sources and provide vari- ous types of output (such as noise source control signals).
Page 364 Receiving Data Input and Providing Data Output RF Input Protection The RF input connector of the R&S FPL1000 must be protected against signal levels that exceed the ranges specified in the data sheet. Therefore, the R&S FPL1000 is equipped with an overload protection mechanism. This mechanism becomes active as soon as the power at the input mixer exceeds the specified limit.
Page 365 Figure 7-34: Power sensor support – standard test setup Using the power sensor with several applications The power sensor cannot be used from the R&S FPL1000 firmware and the R&S Power Viewer Plus (virtual power meter for displaying results of the R&S NRP power sensors) simultaneously.
Page 366 FPL1000 Receiving Data Input and Providing Data Output With the R&S FPL1000, the power sensors can be connected to the "Power Sensor" interface directly, and no further cables are required. They can then be configured as an external power sensor trigger.
Page 367: State
® The Spectrum Application (RF Measurements) R&S FPL1000 Receiving Data Input and Providing Data Output State ...........................367 Continuous Value Update ..................368 Select ......................... 368 Zeroing Power Sensor ....................368 Frequency Manual ..................... 368 Frequency Coupling ....................368 Unit/Scale ........................369 Meas Time/Average ....................
Page 368: Continuous Value Update
® The Spectrum Application (RF Measurements) R&S FPL1000 Receiving Data Input and Providing Data Output Continuous Value Update If activated, the power sensor data is updated continuously during a sweep with a long sweep time, and even after a single sweep has completed.
Page 369: Unit/Scale
® The Spectrum Application (RF Measurements) R&S FPL1000 Receiving Data Input and Providing Data Output Remote command: on page 676 [SENSe:]PMETer<p>:FREQuency:LINK Unit/Scale Selects the unit with which the measured power is to be displayed. Available units are dBm, dB, W and %.
Page 370: Average Count ( Number Of Readings )
If activated, the power sensor creates a trigger signal when a power higher than the defined "External Trigger Level" is measured. This trigger signal can be used as an external power trigger by the R&S FPL1000. This setting is only available in conjunction with a compatible power sensor.
Page 371: Trigger Holdoff
® The Spectrum Application (RF Measurements) R&S FPL1000 Receiving Data Input and Providing Data Output Trigger Holdoff ← Using the power sensor as an external trigger Defines the minimum time (in seconds) that must pass between two trigger events. Trigger events that occur during the holdoff time are ignored.
Page 372 ® The Spectrum Application (RF Measurements) R&S FPL1000 Receiving Data Input and Providing Data Output To have newly connected power sensors assigned to a tab automatically (default), select "Auto" . 5. Define the frequency of the signal whose power you want to measure.
Page 373: Output Settings
The R&S FPL1000 can provide signals to different output connectors. These connectors are only available if the R&S FPL1-B5 option is installed. For details on connectors, refer to the R&S FPL1000 Getting Started manual, "Front / Rear Panel View" chapters.
Page 374 SYSTem:SPEaker[:STATe] Noise Source Control The R&S FPL1000 provides a connector (NOISE SOURCE CONTROL) with a 28 V voltage supply for an external noise source. By switching the supply voltage for an external noise source on or off in the firmware, you can activate or deactivate the device as required.
Page 375: Frequency And Span Configuration
For sinusoidal signals, the center frequency can be defined automatically by the R&S FPL1000 as the highest frequency level in the frequency span (see " Adjusting the Center Frequency Automatically ( Auto Frequency )"...
Page 376 ® The Spectrum Application (RF Measurements) R&S FPL1000 Frequency and Span Configuration The "Center Frequency Stepsize" also defines the step size by which the value is increased or decreased when you use the rotary knob to change the center frequency;...
Page 377 ® The Spectrum Application (RF Measurements) R&S FPL1000 Frequency and Span Configuration "Auto Settings" are described in Chapter 7.8, "Adjusting Settings Automatically", on page 418. Signal Tracking is described in Chapter 7.4.3, "Keeping the Center Frequency Stable - Signal Tracking", on page 379.
Page 378 645 [SENSe:]FREQuency:STARt on page 645 [SENSe:]FREQuency:STOP Full Span Sets the span to the full frequency range of the R&S FPL1000 specified in the data sheet. This setting is useful for overview measurements. Remote command: on page 645 [SENSe:]FREQuency:SPAN:FULL Zero Span Sets the span to 0 Hz (zero span).
Page 379 ® The Spectrum Application (RF Measurements) R&S FPL1000 Frequency and Span Configuration "0.1 * Span" / Sets the step size for the center frequency to 10 % of the span / "0.1 * RBW" RBW. This is the default setting.
Page 380 ® The Spectrum Application (RF Measurements) R&S FPL1000 Frequency and Span Configuration The search bandwidth and the threshold value are shown in the diagram by red lines which are labeled as "TRK" . Signal Tracking Access: "Overview" > "Frequency" > "Signal Tracking" tab Defines the settings for signal tracking.
Page 381: Amplitude And Vertical Axis Configuration
® The Spectrum Application (RF Measurements) R&S FPL1000 Amplitude and Vertical Axis Configuration ● Select "Frequency" from the "Overview" . ● Select the FREQ key and then the "Frequency Config" softkey. ● Select the SPAN key and then the "Frequency Config" softkey.
Page 382 Reference level offset If the signal is attenuated or amplified before it is fed into the R&S FPL1000, you can define an (arithmetic) offset to the reference level so the application shows correct power results. All displayed power level results are shifted by this value, and the scal- ing of the y-axis is changed accordingly.
Page 383 Note, however, that the internal reference level (used to adjust the hardware settings to the expected signal optimally) ignores any "Reference Level Offset" . Thus, it is impor- tant to keep in mind the actual power level the R&S FPL1000 must handle, and not to rely on the displayed reference level.
Page 384 ® The Spectrum Application (RF Measurements) R&S FPL1000 Amplitude and Vertical Axis Configuration Depending on the type of measurement you must find a compromise between a low noise floor and high intermodulation levels, and protecting the instrument from high input levels. You achieve this best by letting the R&S FPL determine the optimum level automatically (see "...
Page 385: Reference Level
Define an offset if the signal is attenuated or amplified before it is fed into the R&S FPL1000 so the application shows correct power results. All displayed power level results are shifted by this value.
Page 386: Setting The Reference Level Automatically ( Auto Level )
"Reference Level Offset" . Thus, it is important to keep in mind the actual power level the R&S FPL1000 must handle. Do not rely on the displayed reference level (internal reference level = displayed reference level - offset).
Page 387: Impedance
® The Spectrum Application (RF Measurements) R&S FPL1000 Amplitude and Vertical Axis Configuration In "Manual" mode, you can set the RF attenuation in 5 dB steps down to 0 dB (with option R&S FPL1-B22: in 1 dB steps). Other entries are rounded to the next integer value.
Page 388 ® The Spectrum Application (RF Measurements) R&S FPL1000 Amplitude and Vertical Axis Configuration Range .........................388 Ref Level Position ...................... 388 Auto Scale Once ......................388 Scaling ........................389 Range Defines the displayed y-axis range in dB. The default value is 100 dB.
Page 389 ® The Spectrum Application (RF Measurements) R&S FPL1000 Amplitude and Vertical Axis Configuration Scaling Defines the scaling method for the y-axis. For more information see Chapter 7.5.1.3, "Scaling", on page 384. "Logarithmic" Logarithmic scaling (only available for logarithmic units - dB..., and A, V, Watt) "Linear with...
Page 390: Bandwidth, Filter And Sweep Configuration
® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration 7.6 Bandwidth, Filter and Sweep Configuration The basic bandwidth, filter and sweep settings that apply to most measurements are described here. These parameters define how the data is measured: how much data is collected internally and which filters are used.
Page 391 60 dB bandwidth to the 3 dB bandwidth (= shape factor). For the R&S FPL1000, the shape factor for bandwidths is < 5, i.e. the 60 dB bandwidth of the 30 kHz filter is <150 kHz.
Page 392 ® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration RMS/Average detector and VBW If an RMS or average detector is used, the video bandwidth in the hardware is bypassed. Thus, duplicate trace averaging with small VBWs and RMS or average detector no longer occurs.
Page 393 RBWs. Which sweep mode is appropriate for the current measurement depends on the span, RBW, VBW and "Sweep Time" settings. The R&S FPL1000 automatically selects the appropriate sweep type. For RBWs lower than 100 kHz and for gated measurements, an FFT is performed, otherwise a sweep is performed.
Page 394 Gaussian filters provide a good compromise between steep edges and a short settling time. This filter is suitable for most measurement tasks and is used by default. The available Gaussian (3 dB) filters are listed in the R&S FPL1000 data sheet. Channel filters Channel filters are fairly steep but require a long settling time;...
Page 395 ® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration 7.6.1.8 How Much Data is Measured: Sweep Points and Sweep Count By default, 1001 data points are determined in a single sweep. During the next sweep, 1001 new data points are collected, and so on. The number of sweep points defines how much of the entire span is covered by a single data point.
Page 396 ® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration Figure 7-36: Bandwidth dialog box for RF measurements Figure 7-37: Sweep dialog box for spectrogram display User Manual 1178.3370.02 ─ 03...
Page 397: Rbw
® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration ...........................397 ........................... 397 Sweep Time ....................... 398 Span/RBW ......................... 398 RBW/VBW ........................398 Filter Type ........................399 Default Coupling ......................399 Sweep/Average Count ....................399 Sweep Points......................400 Optimization .......................
Page 398: Sweep Time
RBW", on page 392. "Auto[100]" "Resolution Bandwidth" = "Span/100" This coupling ratio is the default setting of the R&S FPL1000. "Manual" The coupling ratio is defined manually. The span/resolution bandwidth ratio can be set in the range from 1 to 10000.
Page 399: Filter Type
® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration "Pulse[0.1]" "Video Bandwidth" = 10 x "Resolution Bandwidth" "Video Bandwidth" = "10 MHz" (= max. VBW) Recommended for pulse signals "Noise[10]" "Video Bandwidth" = "Resolution Bandwidth/10" Recommended for noise measurements "Manual"...
Page 400: Sweep Points
For spectrogram displays, the sweep count determines how many sweeps are com- bined in one frame in the spectrogram; that is: how many sweeps the R&S FPL1000 performs to plot one trace in the spectrogram result display. For more details, see "Time Frames"...
Page 401: Sweep Type
654 [SENSe:]SWEep:OPTimize Sweep Type The R&S FPL1000 automatically sets the optimal sweep type for the current measure- ment (sweep or FFT). The sweep type cannot be defined manually. Single Sweep / Run Single After triggering, starts the number of sweeps set in "Sweep Count". The measurement stops after the defined number of sweeps has been performed.
Page 402: Continue Single Sweep
® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration Furthermore, the RUN CONT key controls the Sequencer, not individual sweeps. RUN CONT starts the Sequencer in continuous mode. For details on the Sequencer, see Chapter 5.4.1, "The Sequencer Concept",...
Page 403: Frame Count
(see the following table). The indicated filter bandwidth is the 3 dB bandwidth. For RRC filters, the fixed roll-off factor (a) is also indicated. The available Gaussian 3 dB sweep filters are listed in the R&S FPL1000 data sheet. Table 7-19: Filter types...
Page 404 ® The Spectrum Application (RF Measurements) R&S FPL1000 Bandwidth, Filter and Sweep Configuration Filter Bandwidth Filter Type Application 6 kHz CFILter 6 kHz, a=0.2 APCO 8.5 kHz CFILter ETS300 113 (12.5 kHz channels) 9 kHz CFILter AM Radio 10 kHz CFILter 12.5 kHz...
Page 405: Trigger And Gate Configuration
® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration Filter Bandwidth Filter Type Application 4.096 MHz, a=0.22 W-CDMA NTT DOCoMo 5 MHz CFILter CFILter CFILter CFILter 7.7 Trigger and Gate Configuration Triggering means to capture the interesting part of the signal. Choosing the right trigger type and configuring all trigger settings correctly allows you to detect various incidents in your signals.
Page 406 An offset can be defined to delay the measurement after the trigger event, or to include data before the actual trigger event in time domain measurements (pre-trigger offset). Pre-trigger offsets are possible because the R&S FPL1000 captures data continuously in the time domain, even before the trigger occurs.
Page 407 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration Example: In the following example, the second possible trigger event is ignored as the signal does not exceed the hysteresis (threshold) before it reaches the trigger level again on the rising edge.
Page 408 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration Drop-out times for falling edge triggers If a trigger is set to a falling edge ( "Slope" = "Falling" , see " Slope " on page 413) the measurement is to start when the power level falls below a certain level.
Page 409 Trigger Settings Access: "Overview" > "Trigger/Gate" External triggers from one of the TRIGGER INPUT / OUTPUT connectors on the R&S FPL1000 are configured in a separate tab of the dialog box. For step-by-step instructions on configuring triggered measurements, see Chap- ter 7.7.1.4, "How to Configure a Triggered...
Page 410 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration The trigger and gate settings are applied to the measurement when the dialog box is closed. Note: The zero span settings refer only to the preview diagram. The main diagram remains unchanged.
Page 411 665 TRIGger[:SEQuence]:SOURce IF Power ← Trigger Source The R&S FPL1000 starts capturing data as soon as the trigger level is exceeded around the third intermediate frequency. For frequency sweeps, the third IF represents the start frequency. The trigger band- width at the third IF depends on the RBW and sweep type.
Page 412 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration Remote command: on page 664 TRIGger[:SEQuence]:LEVel:IFPower on page 665 TRIGger[:SEQuence]:LEVel:IQPower on page 664 TRIGger[:SEQuence]:LEVel[:EXTernal<port>] Repetition Interval Defines the repetition interval for a time trigger. The shortest interval is 2 ms.
Page 413 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration For more information, see "Trigger Holdoff" on page 408. Remote command: on page 663 TRIGger[:SEQuence]:IFPower:HOLDoff Slope For all trigger sources except time, you can define whether triggering occurs when the signal rises to the trigger level or falls down to it.
Page 414 To define an external trigger: 1. Connect an external device that will provide the trigger signal to one of the TRIG- GER INPUT / OUTPUT connectors on the R&S FPL1000 (for details see the R&S FPL1000 "Getting Started" manual). 2. In the "Trigger And Gate" dialog box, define the "Trigger Source" = "External" .
Page 415 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration Additionally, a delay time can be defined so that the first few measurement points after the gate opening are ignored. Figure 7-42: Effects of Gate mode, Gate delay and Gate length...
Page 416 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trigger and Gate Configuration Example: By using a gate in sweep mode and stopping the measurement while the gate signal is inactive, the spectrum for pulsed RF carriers can be displayed without the superposi- tion of frequency components generated during switching.
Page 417 After the gate signal has been detected, the gate remains open until the signal disappears. Note: If you perform gated measurements in combination with the IF Power trigger, the R&S FPL1000 ignores the holding time for fre- quency sweep, FFT sweep, zero span and I/Q mode measurements. Remote command:...
Page 418: Adjusting Settings Automatically
® The Spectrum Application (RF Measurements) R&S FPL1000 Adjusting Settings Automatically Gate Length Defines how long the gate is open when it is triggered. The gate length can only be set in the edge-triggered gate mode. In the level-triggered mode the gate length depends on the level of the gate signal.
Page 419 FPL1000 Adjusting Settings Automatically Some settings can be adjusted by the R&S FPL1000 automatically according to the current measurement settings. In order to do so, a measurement is performed. The duration of this measurement can be defined automatically or manually.
Page 420 ® The Spectrum Application (RF Measurements) R&S FPL1000 Adjusting Settings Automatically ● Auto Level Remote command: on page 646 [SENSe:]ADJust:ALL Adjusting the Center Frequency Automatically ( Auto Frequency ) The R&S FPL adjusts the center frequency automatically. The optimum center frequency is the frequency with the highest S/N ratio in the fre- quency span.
Page 421: Marker Usage
Markers are used to mark points on traces, to read out measurement results and to select a display section quickly. R&S FPL1000 provides 16 markers per display win- dow. In the Spectrum application, the same markers are displayed in all windows.
Page 422 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage ● Alternatively, change the position of the selected marker using the rotary knob. By default, the marker is moved from one pixel to the next. If you need to position the marker more precisely, change the step size to move from one sweep point to the next (General Marker Setting).
Page 423 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage ● Marker Types......................423 ● Activating Markers....................423 ● Marker Results...................... 423 7.9.1.1 Marker Types All markers can be used either as normal markers or delta markers. A normal marker indicates the absolute signal value at the defined position in the diagram. A delta marker indicates the value of the marker relative to the specified reference marker (by default marker 1).
Page 424 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Marker information in diagram area By default, the results of the last two markers or delta markers that were activated are displayed in the diagram area. The following information is displayed there: ●...
Page 425: Selected Marker
® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage 7.9.2.1 Individual Marker Setup Up to 17 markers or delta markers can be activated for each window simultaneously. Initial marker setup is performed using the "Marker" dialog box. The markers are distributed among 3 tabs for a better overview. By default, the first marker is defined as a normal marker, whereas all others are defined as delta markers with reference to the first marker.
Page 426: Marker Position X-Value
® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Remote command: on page 713 CALCulate<n>:MARKer<m>[:STATe] on page 711 CALCulate<n>:DELTamarker<m>[:STATe] Marker Position X-value Defines the position (x-value) of the marker in the diagram. For normal markers, the absolute position is indicated. For delta markers, the position relative to the reference marker is provided.
Page 427: Linking To Another Marker
® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Linking to Another Marker Links the current marker to the marker selected from the list of active markers. If the x- axis value of the initial marker is changed, the linked marker follows to the same posi- tion on the x-axis.
Page 428: All Marker Off
® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage All Marker Off Deactivates all markers in one step. Remote command: on page 712 CALCulate<n>:MARKer<m>:AOFF 7.9.2.2 General Marker Settings Some general marker settings allow you to influence the marker behavior for all mark- ers.
Page 429 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Marker Info Turns the marker information displayed in the diagram on and off. Remote command: on page 715 DISPlay:MINFo[:STATe] Marker Stepsize Defines the size of the steps that the marker position is moved using the rotary knob.
Page 430 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage 7.9.3 Marker Search Settings and Positioning Functions Access: "Overview" > "Analysis" > "Marker" > "Search" or: MKR TO Several functions are available to set the marker to a specific position very quickly and easily, or to use the current marker position to define another characteristic value.
Page 431 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Auto Max Peak Search / Auto Min Peak Search ............431 Search Limits ......................432 └ Search Limits ( Left / Right )................. 432 └ Search Threshold ..................432 └ Use Zoom Limits ..................
Page 432 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Remote command: on page 719 CALCulate<n>:MARKer<m>:MAXimum:AUTO on page 721 CALCulate<n>:MARKer<m>:MINimum:AUTO Search Limits The search results can be restricted by limiting the search area or adding search con- ditions. Search Limits ( Left / Right ) ← Search Limits If activated, limit lines are defined and displayed for the search.
Page 433 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Search Mode for Next Peak in X-Direction ..............433 Search Mode for Next Peak in Y-Direction ..............433 Marker Search Type ....................434 Marker Search Area ....................434 Exclude LO .........................434 Peak Excursion ......................
Page 434 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage "Up" Determines the next maximum/minimum above the current peak (in more recent frames). "Absolute" Determines the next maximum/minimum above or below the current peak (in all frames). "Down" Determines the next maximum/minimum below the current peak (in older frames).
Page 435 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage "On" The minimum frequency included in the peak search range is ≥ 5 × resolution bandwidth (RBW). Due to the interference by the first local oscillator to the first inter- mediate frequency at the input mixer, the LO is represented as a sig- nal at 0 Hz.
Page 436 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Use Zoom Limits ← Search Limits If activated, the peak search is restricted to the active zoom area defined for a single zoom. Remote command: on page 718 CALCulate<n>:MARKer<m>:X:SLIMits:ZOOM[:STATe] Deactivating All Search Limits ← Search Limits Deactivates the search range limits.
Page 437 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Search Minimum Sets the selected marker/delta marker to the minimum of the trace. If no marker is active, marker 1 is activated. For spectrogram displays, define which frame the minimum is to be searched in.
Page 438 Frequency resolution is further restricted by the RBW and sweep time settings. To determine the frequency of a signal point accurately without changing the sweep settings, the R&S FPL1000 is equipped with a signal counter. The signal counter sets User Manual 1178.3370.02 ─ 03...
Page 439 Signal counting can be performed explicitly at the current marker position ( "Signal Count" marker function), or implicitly by the R&S FPL1000 for certain functions. Signal counting is only possible while the instrument is not sweeping. Thus, to perform a signal count for a marker, the sweep is stopped at the marker position.
Page 440 ● Trace averaging: In the default setting, the R&S FPL1000 uses the sample detector for the noise function. With the sample detector, you can set the trace to "Average" mode to sta- bilize the measured values. When the RMS detector is used, trace averaging pro- duces noise levels that are too low and cannot be corrected.
Page 441 For span > 0, the measured values are averaged versus time (after a sweep). The R&S FPL1000 noise figure can be calculated from the measured power density level. It is calculated by deducting the set RF attenuation (RF Att) from the displayed noise level and adding 174 to the result.
Page 442 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Marker State Activates or deactivates the marker in the diagram. Remote command: on page 713 CALCulate<n>:MARKer<m>[:STATe] on page 711 CALCulate<n>:DELTamarker<m>[:STATe] Marker Type Toggles the marker type. The type for marker 1 is always "Normal" , the type for delta marker 1 is always "Delta"...
Page 443 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Phase noise is unintentional modulation of a carrier; it creates frequencies next to the carrier frequency. A phase noise measurement consists of noise density measure- ments at defined offsets from the carrier; the results are given in relation to the carrier level (dBc).
Page 444 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Remote commands: on page 747 CALCulate<n>:MARKer<m>:FUNCtion:PNOise[:STATe] on page 746 CALCulate<n>:MARKer<m>:FUNCtion:PNOise:RESult? Phase Noise Measurement State ................444 Defining Reference Point ................... 445 Switching All Phase Noise Measurements Off ............445 Phase Noise Measurement State Activates or deactivates phase noise measurement for the reference point in the dia- gram.
Page 445 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage If activated, the delta markers display the phase noise measured at defined offsets from the reference position. Remote command: on page 746 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise[:STATe] on page 745 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:RESult? Defining Reference Point Instead of using marker 1 as the reference marker, a fixed reference marker can be defined for phase noise measurement.
Page 446 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Figure 7-45: n dB down marker function The following marker function results are displayed: Table 7-20: n dB down marker function results Label Description Current position and level of marker 1...
Page 447 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage on page 752 CALCulate<n>:MARKer<m>:FUNCtion:NDBDown:RESult? n dB down Marker State .....................447 n dB down Delta Value ....................447 n dB down Marker State Activates or deactivates the special n dB down marker function.
Page 448 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage You can move the position of the fixed reference marker graphically by dragging the display lines, or numerically by entering values for the marker position and level. Remote commands: on page 739 CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed[:STATe]...
Page 449 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Band power markers are only available for standard frequency measurements (not zero span) in the Spectrum application. For the I/Q Analyzer application, band power markers are only available for Spectrum displays.
Page 450 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Remote commands: on page 748 CALCulate<n>:MARKer<m>:FUNCtion:BPOWer[:STATe] on page 748 CALCulate<n>:MARKer<m>:FUNCtion:BPOWer:RESult? Band Power Measurement State ................450 Span ...........................450 Power Mode ....................... 451 Switching All Band Power Measurements Off ............451 Band Power Measurement State Activates or deactivates band power measurement for the marker in the diagram.
Page 451 Or: MKR > "Select Marker Function" > "Marker Demodulation" > "Marker Demod Con- fig" The R&S FPL1000 provides demodulators for AM, FM and PM signals. The demodula- tion marker function sends the demodulated data at the current marker frequency to the audio output.
Page 452 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Optionally, a minimum level ( "Squelch Level" ) can be defined so that the signal is only demodulated when it exceeds the set level. This is useful during continuous demodula- tion to avoid listening to noise.
Page 453 Access: "Overview" > "Analysis" > "Marker Functions" > "Marker Peak List" Or: MKR > "Select Marker Function" > "Marker Peak List" A common measurement task is to determine peak values, i.e. maximum or minimum signal levels. The R&S FPL1000 provides various peak search functions and applica- tions: ●...
Page 454 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage When is a peak a peak? - Peak excursion During a peak search, for example when a marker peak table is displayed, noise val- ues may be detected as a peak if the signal is very flat or does not contain many peaks.
Page 455 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Marker peak list The marker peak list determines the frequencies and levels of peaks in the spectrum. It is updated automatically after each sweep. How many peaks are displayed can be defined, as well as the sort order.
Page 456 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage Remote command: on page 742 CALCulate<n>:MARKer<m>:FUNCtion:FPEaks:STATe Sort Mode Defines whether the peak list is sorted according to the x-values or y-values. In either case the values are sorted in ascending order.
Page 457 ® The Spectrum Application (RF Measurements) R&S FPL1000 Marker Usage 7.9.5 How to Work With Markers The following step-by-step instructions demonstrate in detail how to work with markers. ● How to Analyze a Signal Point in Detail..............457 ● How to Use a Fixed Reference Marker..............
Page 458 2. Set the center frequency to 128 MHz. 3. Set the span to 100 kHz. The R&S FPL1000 displays the reference signal with a span of 100 kHz and reso- lution bandwidth of 1 kHz. 4. Switch on the marker by pressing the MKR key.
Page 459: Trace Configuration
® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration The position of the marker becomes the reference point. The reference point level is indicated by a horizontal line, the reference point frequency with a vertical line. At the same time, the delta marker 2 is switched on.
Page 460 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration 7.10.1 Standard Traces 7.10.1.1 Basics on Setting up Traces Some background knowledge on traces is provided here for a better understanding of the required configuration settings. ● Mapping Samples to sweep Points with the Trace Detector.........460...
Page 461 (not available for SEM) Calculates the root mean square of all samples contained in a sweep point. To this effect, R&S FPL1000 uses the linear voltage after envelope detection. The sampled linear values are squared, summed and the sum is divided by the number of samples (= root mean square).
Page 462 You can define the trace detector to be used for the individual traces manually, or the R&S FPL1000 can select the appropriate detector automatically. The detectors of the R&S FPL1000 are implemented as pure digital devices. All detec- tors work in parallel in the background, which means that the measurement speed is independent of the detector combination used for different traces.
Page 463 Max Hold The maximum value is determined over several measurements and displayed. The R&S FPL1000 saves the sweep result in the trace memory only if the new value is greater than the previous one. This mode is especially useful with modulated or pulsed signals. The signal spectrum is filled up upon each sweep until all signal components are detected in a kind of envelope.
Page 464 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration  Trace MeasValue  Trace Figure 7-48: Equation 1 Due to the weighting between the current trace and the average trace, past val- ues have practically no influence on the displayed trace after about ten sweeps.
Page 465 This low average value is usually corrected in noise power measurements by a 2.5 dB factor. Therefore the R&S FPL1000 offers the selection of linear averaging. The trace data is linearized before averaging, then averaged and logarithmized again for display on the screen.
Page 466 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration You can turn trace smoothing on and off for all traces individually and compare, for example, the raw and the smooth trace. Linear smoothing is based on the following algorithm: ...
Page 467 "Max Hold" The maximum value is determined over several sweeps and dis- played. The R&S FPL1000 saves each trace point in the trace mem- ory only if the new value is greater than the previous one. The "Detector" is automatically set to "PositivePeak" .
Page 468 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration For details see "Mapping Samples to sweep Points with the Trace Detector" on page 460. "Auto" Selects the optimum detector for the selected trace and filter mode. This is the default setting.
Page 469 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration "Linear" The power level values are converted into linear units prior to averag- ing. After the averaging, the data is converted back into its original unit. "Logarithmic" For logarithmic scaling, the values are averaged in dBm. For linear scaling, the behavior is the same as with linear averaging.
Page 470 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Function Trace Settings Set Trace Mode Trace 1: Max Hold Max | ClrWrite | Min Auto Detector (Positive Peak) Trace 2: Clear Write Auto Detector (Auto Peak) Trace 3: Min Hold...
Page 471 693 TRACe<n>:COPY 7.10.2 Spectrograms 7.10.2.1 Working with Spectrograms In addition to the standard "level versus frequency" or "level versus time" traces, the R&S FPL1000 also provides a spectrogram display of the measured data. User Manual 1178.3370.02 ─ 03...
Page 472 In this example, you see the spectrogram for the calibration signal of the R&S FPL1000, compared to the standard spectrum display. Since the signal does not change over time, the color of the frequency levels does not change over time, i.e. ver- tically.
Page 473 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Figure 7-51: Screen layout of the spectrogram result display 1 = Spectrum result display 2 = Spectrogram result display 3 = Marker list 4 = Marker 5 = Delta marker...
Page 474 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Frames are sorted in chronological order, beginning with the most recently recorded frame at the top of the diagram (frame number 0). With the next sweep, the previous frame is moved further down in the diagram, until the maximum number of captured frames is reached.
Page 475 How the colors are distributed within the value range, i.e where the focus of the vis- ualization lies (shape of the color curve) The individual colors are assigned to the power levels automatically by the R&S FPL1000. The Color Scheme ●...
Page 476 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Uses a color range from black over green to light turquoise with shades of green in between. Dark colors indicate low levels, light colors indicate high ones. ● Grayscale Shows the results in shades of gray. Dark gray indicates low levels, light gray indi- cates high ones.
Page 477 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Example: In the color map based on the linear color curve, the range from -100 dBm to -60 dBm is covered by blue and a few shades of green only. The range from -60 dBm to -20 dBm is covered by red, yellow and a few shades of green.
Page 478 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Figure 7-53: Spectrogram with non-linear color curve (shape = -0.5) Markers in the Spectrogram Markers and delta markers are shaped like diamonds in the spectrogram. They are only displayed in the spectrogram if the marker position is inside the visible area of the spectrogram.
Page 479 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration 7.10.2.2 Spectrogram Settings Access: TRACE > "Spectrogram Config" The individual settings available for spectrogram display are described here. For set- tings on color mapping, see "Color Map Settings" on page 481.
Page 480 Sets the number of frames that the R&S FPL1000 stores in its memory. The maximum number of frames depends on the Sweep Points. If the memory is full, the R&S FPL1000 deletes the oldest frames stored in the memory and replaces them with the new data. Remote command: on page 695 CALCulate<n>:SPECtrogram:HDEPth...
Page 481 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Furthermore, the RUN CONT key controls the Sequencer, not individual sweeps. RUN CONT starts the Sequencer in continuous mode. For details on the Sequencer, see Chapter 5.4.1, "The Sequencer Concept", on page 85.
Page 482 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Figure 7-54: Color Mapping dialog box = Color map: shows the current color distribution = Preview pane: shows a preview of the spectrogram with any changes that you make to the color...
Page 483 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration Set to Default Sets the color mapping to the default settings. Remote command: on page 698 DISPlay[:WINDow<n>]:SPECtrogram:COLor:DEFault Close Saves the changes and closes the dialog box. 7.10.2.3 How to Display and Configure a Spectrogram The following tasks are described here: ●...
Page 484 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration To set a marker in the spectrogram 1. While a spectrogram is displayed, select the MARKER key. 2. Select a "Marker" softkey. 3. Enter the frequency or time (x-value) of the marker or delta marker.
Page 485 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration To select a color scheme You can select which colors are assigned to the measured values. ► In the "Color Mapping" dialog box, select the option for the color scheme to be used.
Page 486 The color map starts at -110 dBm and ends at -10 dBm (that is: a range of 100 dB). In order to suppress the noise, you only want the color map to start at -90 dBm. Thus, you enter 10% in the "Start" field. The R&S FPL1000 shifts the start point 10% to the right, to -90 dBm.
Page 487 ® The Spectrum Application (RF Measurements) R&S FPL1000 Trace Configuration ● 0 defines a linear distribution ● A positive value (>0 to 1) focuses the higher values 7.10.3 Trace Math Access: TRACE > "Trace Math" If you have several traces with different modes, for example an average trace and a maximum trace, it may be of interest to compare the results of both traces.
Page 488: Display And Limit Lines
® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Trace Math Off Deactivates any previously selected trace math functions. Remote command: CALC:MATH:STAT OFF, see on page 702 CALCulate<n>:MATH:STATe Trace Math Position Defines the zero point on the y-axis of the resulting trace in % of the diagram height.
Page 489 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Access: "Overview" > "Analysis" > "Lines" For remote operation, see Chapter 8.8.9, "Configuring Display and Limit Lines", on page 767. ● Display Lines......................489 ● Limit Lines......................491 7.11.1 Display Lines 7.11.1.1...
Page 490 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Vertical Line 1 / Vertical Line 2 ...................490 Horizontal Line 1 / Horizontal Line 2 ................490 Vertical Line 1 / Vertical Line 2 Activates a vertical display line (V1 or V2) in the diagram at the specified point of the x- axis, depending on the scale of the axis.
Page 491 (GO/NOGO test). The R&S FPL1000 supports limit lines with a maximum of 200 data points. Eight of the limit lines stored in the instrument can be activated simultaneously. The number of limit lines stored in the instrument is only limited by the capacity of the storage device used.
Page 492 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines 200 GHz. For the time range representation, negative times may also be entered. The allowed range is -1000 s to +1000 s. Figure 7-55: Example for an upper limit line Limits and Margins Limit lines define strict values that must not be exceeded by the measured signal.
Page 493 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Offsets and Shifting A configured limit line can easily be moved vertically or horizontally. Two different methods to do so are available: ● An offset moves the entire line in the diagram without editing the configured values or positions of the individual data points.
Page 494 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Figure 7-56: Margin violation for limit check Figure 7-57: Limit violation for limit check User Manual 1178.3370.02 ─ 03...
Page 495 Limit Line Settings and Functions Access: "Overview" > "Analysis" > "Lines" or: LINES > "Line Config" Up to 8 limit lines can be displayed simultaneously in the R&S FPL1000. Many more can be stored on the instrument. Stored limit line settings When storing and recalling limit line settings, consider the information provided in "Sav-...
Page 496 FPL1000 Display and Limit Lines For the limit line overview, the R&S FPL1000 searches for all stored limit lines with the file extension .LIN in the limits subfolder of the main installation folder. The over- view allows you to determine which limit lines are available and can be used for the current measurement.
Page 497 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Unit The unit in which the y-values of the data points of the limit line are defined. Compatibility Indicates whether the limit line definition is compatible with the current measurement settings.
Page 498 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines This setting does not have any effect on limit lines that are defined by absolute values for the x-axis. Remote command: on page 771 CALCulate<n>:LIMit<k>:CONTrol:OFFSet Y-Offset Shifts a limit line that has relative values for the y-axis (levels or linear units such as volt) vertically.
Page 499 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Name ..........................499 Comment ........................499 Threshold ........................499 Margin ........................500 X-Axis .........................500 Y-Axis .........................500 Data Points .........................500 Insert Value ........................ 501 Delete Value .......................501 Shift x ......................... 501 Shift y .........................
Page 500 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines Remote command: on page 775 CALCulate<n>:LIMit<k>:LOWer:THReshold on page 778 CALCulate<n>:LIMit<k>:UPPer:THReshold Margin Defines a margin for the limit line. The default setting is 0 dB (i.e. no margin). For details on margins see "Limits and Margins"...
Page 501 For details on the file format see Chapter 7.11.2.4, "Reference: Limit Line File Format", on page 506. The limit line can be imported again later by the R&S FPL1000 for use in other mea- surements. Remote command: on page 781 MMEMory:STORe<n>:LIMit...
Page 502 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines 7.11.2.3 How to Define Limit Lines Access: "Overview" > "Analysis" > "Lines" > "Limit Lines" or: LINES > "Line Config" > "Limit Lines" Limit lines for spurious and SEM measurements...
Page 503 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines How to edit existing limit lines Existing limit line configurations can be edited. 1. In the "Line Config" dialog box, select the limit line. 2. Select the "Edit" button.
Page 504 ® The Spectrum Application (RF Measurements) R&S FPL1000 Display and Limit Lines ● Absolute or relative limits ● Upper or lower limit line 5. Define the data points: minimum 2, maximum 200: a) Select "Insert Value" . b) Define the x-value ( "Position" ) and y-value ( "Value" ) of the first data point.
Page 505 How to import a limit line Limit line configurations that are stored in an ASCII file and contain a minimum of required data can be imported to the R&S FPL1000. For details on the required file format see Chapter 7.11.2.4, "Reference: Limit Line File Format",...
Page 506 Limit line data can be exported to a file in ASCII (CSV) format for further evaluation in other applications. Limit lines stored in the specified ASCII (CSV) format can also be imported to the R&S FPL1000 for other measurements (see "How to import a limit line"...
Page 507: Zoomed Displays
® The Spectrum Application (RF Measurements) R&S FPL1000 Zoomed Displays 7.12 Zoomed Displays You can zoom into the diagram to visualize the measurement results in greater detail. Using the touchscreen or a mouse pointer you can easily define the area to be enlarged.
Page 508 ® The Spectrum Application (RF Measurements) R&S FPL1000 Zoomed Displays Figure 7-58: Single zoom Figure 7-59: Multiple zoom Using the zoom area to restrict a peak search The selected zoom area can be used to restrict the search range for a peak search, but only in single zoom mode (see "...
Page 509 ® The Spectrum Application (RF Measurements) R&S FPL1000 Zoomed Displays 7.12.2 Zoom Functions Access: "Zoom" icons in toolbar Single Zoom ....................... 509 Multi-Zoom ......................... 509 Restore Original Display .................... 509 Single Zoom A single zoom replaces the current diagram by a new diagram which displays an enlarged extract of the trace.
Page 510 ® The Spectrum Application (RF Measurements) R&S FPL1000 Zoomed Displays 7.12.3 How to Zoom Into a Diagram The remote commands required to zoom into a display are described in Chapter 8.8.6, "Zooming into the Display", on page 685. The following tasks are described here: ●...
Page 511: Importing And Exporting Measurement Results For Evaluation
7.13 Importing and Exporting Measurement Results for Evaluation The R&S FPL1000 provides various evaluation methods for the results of the per- formed measurements. However, you may want to evaluate the data with further, external applications. In this case, you can export the measurement data to a standard format file (ASCII or XML).
Page 512 The Spectrum Application (RF Measurements) R&S FPL1000 Importing and Exporting Measurement Results for Evaluation imported to the R&S FPL1000 for further evaluation later, for example in other applica- tions. The following data types can be exported (depending on the application): ●...
Page 513 ® The Spectrum Application (RF Measurements) R&S FPL1000 Importing and Exporting Measurement Results for Evaluation Export all Traces and all Table Results ..............513 Include Instrument & Measurement Settings ............. 513 Trace to Export ......................513 Decimal Separator ..................... 514 Export all Traces and all Table Results Selects all displayed traces and result tables (e.g.
Page 514 ® The Spectrum Application (RF Measurements) R&S FPL1000 Importing and Exporting Measurement Results for Evaluation Decimal Separator Defines the decimal separator for floating-point numerals for the data export/import files. Evaluation programs require different separators in different languages. Remote command: on page 786 FORMat:DEXPort:DSEParator 7.13.2 How to Export Trace Data and Numerical Results...
Page 515 ® The Spectrum Application (RF Measurements) R&S FPL1000 Importing and Exporting Measurement Results for Evaluation 5. Select the "Marker Peak List" softkey to display the "Marker Peak List" dialog box again. 6. If necessary, change the decimal separator to be used for the ASCII export file.
Page 516 FPL1000 Importing and Exporting Measurement Results for Evaluation Table 7-25: ASCII file format for trace export in the Spectrum application File contents Description Header data Type;R&S FPL1000; Instrument model Version;1.00; Firmware version Date;01.Oct 2006; Date of data set storage Mode;ANALYZER;...
Page 517 Name of next window Data section for individual trace Trace 1;; First trace Table 7-26: ASCII file format for spectrogram trace export File contents Description Header Type;R&S FPL1000; Instrument model Version;5.00; Firmware version Date;01.Oct 2006; Date of data set storage Mode;ANALYZER;SPECTROGRAM Operating mode Center Freq;55000;Hz...
Page 518: Optimizing Measurements
® The Spectrum Application (RF Measurements) R&S FPL1000 Optimizing Measurements File contents Description Level Range;100;dB Display range in y direction. Unit: dB with x-axis LOG, % with x- axis LIN Rf Att;20;dB Input attenuation RBW;100000;Hz Resolution bandwidth VBW;30000;Hz Video bandwidth SWT;0.005;s...
Page 519 ® The Spectrum Application (RF Measurements) R&S FPL1000 Optimizing Measurements ● Increase the RBW to minimize the measurement time; however, consider the requirements of the standard if you need to measure according to standard! ● Reduce the sweep time and thus the amount of data to be captured and calcula- ted;...
Page 520: Remote Commands
Compatibility with former R&S signal and spectrum analyzers As a rule, the R&S FPL1000 supports most commands from previous R&S signal and spectrum analyzers such as the FSQ, FSP, FSU, or FSV. However, the default values, in particular the number of sweep points or particular bandwidths, may vary.
Page 521: Common Suffixes
® Remote Commands R&S FPL1000 Common Commands A command which does not automatically finish executing before the next com- mand starts executing (overlapping command) is indicated as an Asynchronous command. ● Reset values (*RST) Default parameter values that are used directly after resetting the instrument (*RST command) are indicated as *RST values, if available.
Page 522 ® Remote Commands R&S FPL1000 Common Commands ..........................524 *SRE ...........................524 *STB? ..........................525 *TRG ........................... 525 *TST? ..........................525 *WAI *CAL? Calibration query Initiates a calibration of the instrument and subsequently queries the calibration status. Responses > 0 indicate errors.
Page 523 ® Remote Commands R&S FPL1000 Common Commands *IDN? Identification Returns the instrument identification. Usage: Query only *IST? Individual status query Returns the contents of the IST flag in decimal form. The IST flag is the status bit which is sent during a parallel poll.
Page 524 ® Remote Commands R&S FPL1000 Common Commands Sets parallel poll enable register to the indicated value. The query returns the contents of the parallel poll enable register in decimal form. Parameters: <Value> Range: 0 to 255 *PSC <Action> Power on status clear Determines whether the contents of the ENABle registers are preserved or reset when the instrument is switched on.
Page 525: Commands For Remote Instrument Operation
(see also command synchronization and *OPC). Usage: Event 8.4 Commands for Remote Instrument Operation The following commands are required to shutdown or reboot the R&S FPL1000 from a remote PC......................525 SYSTem:CLOGging ......................526 SYSTem:REBoot ......................526...
Page 526: Selecting The Operating Mode And Application
® Remote Commands R&S FPL1000 Selecting the Operating Mode and Application Parameters: <State> ON | 1 Writes all remote commands that have been sent to a file. The destination is C: \ProgramData\Rohde-Schwarz\ZNL-FPL\ScpiLogging\ScpiLog.txt OFF | 0 *RST: Manual operation: "I/O Logging"...
Page 527 ® Remote Commands R&S FPL1000 Selecting the Operating Mode and Application Parameters: <State> ON | OFF | 1 | 0 ON | 1 The MultiView tab is displayed. OFF | 0 The most recently displayed channel setup is displayed. *RST: INSTrument:CREate:DUPLicate This command duplicates the currently selected channel setup, i.e creates a new chan-...
Page 528 ® Remote Commands R&S FPL1000 Selecting the Operating Mode and Application <ChannelType> Channel type of the new channel setup. For a list of available channel setup types see INSTrument: on page 528. LIST? <ChannelName2> String containing the name of the new channel setup.
Page 529 ® Remote Commands R&S FPL1000 Selecting the Operating Mode and Application Table 8-2: Available channel setup types and default channel setup names Application <ChannelType> Parameter Default Channel Setup Name*) Spectrum SANALYZER Spectrum Analog Demodulation ADEM Analog Demod I/Q Analyzer IQ Analyzer...
Page 530 ® Remote Commands R&S FPL1000 Selecting the Operating Mode and Application Manual operation: " Spectrum " on page 82 " I/Q Analyzer " on page 82 " Analog Demod " on page 82 " Noise Figure " on page 82 "Defining a channel setup"...
Page 531 Remote Commands R&S FPL1000 Selecting the Operating Mode and Application INITiate<n>:SEQuencer:MODE <Mode> This command selects the way the R&S FPL1000 application performs measurements sequentially. Before this command can be executed, the Sequencer must be activated (see on page 531). SYSTem:SEQuencer Note: In order to synchronize to the end of a sequential measurement using *OPC, *OPC? or *WAI you must use SINGle Sequence mode.
Page 532 ® Remote Commands R&S FPL1000 Selecting the Operating Mode and Application Parameters: <State> ON | OFF | 0 | 1 ON | 1 The Sequencer is activated and a sequential measurement is started immediately. OFF | 0 The Sequencer is deactivated. Any running sequential measure- ments are stopped.
Page 533 ® Remote Commands R&S FPL1000 Selecting the Operating Mode and Application SENSe:ESPectrum:PRESet:STANdard 'WCDMA\3GPP\DL\3GPP_DL.xml' //Set sweep count in Spectrum channel SENS:SWEEP:COUNT 5 //----------Creating a second measurement channel ---------------- //Create second IQ channel INSTrument:CREate:NEW IQ,'IQ 2' //Set sweep count SENS:SWEEP:COUNT 2 //Change trace modes...
Page 534: Configuring And Performing Measurements
® Remote Commands R&S FPL1000 Configuring and Performing Measurements INITiate:SEQuencer:MODE SINGle //Sweep all channels once, taking the sweep count in each channel into account INITiate:SEQuencer:IMMediate;*OPC? //Set marker to maximum in IQ1 and query result CALCulate:MARKer:MAXimum CALC:MARK:Y? //Switch to second IQ channel and retrieve results INST:SEL 'IQ 2';*WAI...
Page 535 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Remote commands exclusive for performing measurements: .......................... 535 ABORt ....................535 INITiate<n>:CONMeas ....................536 INITiate<n>:CONTinuous ....................536 INITiate<n>[:IMMediate] ................537 [SENSe:]SWEep:COUNt:CURRent? ABORt This command aborts the measurement in the current channel setup and resets the trigger system.
Page 536 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Example: INIT:CONT OFF Switches to single sweep mode. DISP:WIND:TRAC:MODE AVER Switches on trace averaging. SWE:COUN 20 Setting the sweep counter to 20 sweeps. INIT;*WAI Starts the measurement and waits for the end of the 20 sweeps.
Page 537 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Example: INIT:CONT OFF Switches to single sweep mode. DISP:WIND:TRAC:MODE AVER Switches on trace averaging. SWE:COUN 20 Sets the sweep counter to 20 sweeps. INIT;*WAI Starts the measurement and waits for the end of the 20 sweeps.
Page 538 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Mode> WRITe The power is calculated from the current trace. MAXHold The power is calculated from the current trace and compared with the previous power value using a maximum algorithm.
Page 539 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Query parameters: <Measurement> ACPower | MCACpower ACLR measurements (also known as adjacent channel power or multicarrier adjacent channel measurements). Returns the power for every active transmission and adjacent channel. The order is: •...
Page 540 The R&S FPL1000 performs the measurement on the trace selected with [SENSe:]POWer:TRACe. OBANdwidth | OBWidth Occupied bandwidth measurement. The R&S FPL1000 performs the measurement on the trace that marker 1 is positioned on. Carrier-to-noise ratio measurement. Carrier-to-noise ratio measurement referenced to 1 Hz band-...
Page 541 This automatic routine makes sure that the that the signal power level does not over- load the R&S FPL1000 or limit the dynamic range by too small a S/N ratio. To determine the best reference level, the R&S FPL1000 aborts current measurements and performs a series of test sweeps.
Page 542 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <TraceNumber> Range: 1 to 6 *RST: Example: POW:TRAC 2 Assigns the measurement to trace 2. Manual operation: " Selected Trace " on page 265 8.6.3 Measuring the Channel Power and ACLR All remote control commands specific to channel power or ACLR measurements are described here.
Page 543 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Standard> For more information see Chapter 7.2.3.8, "Reference: Prede- fined CP/ACLR Standards", on page 277. If you want to load a customized configuration, the parameter is a string containing the file name.
Page 544 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Standard> String containing the file name. The file format is xml. Manual operation: " User Standards " on page 263 8.6.3.2 Configuring the Channels The following commands configure channels for channel power and ACLR measure- ments.
Page 545 FPL1000 Configuring and Performing Measurements If you set the channel bandwidth for the first alternate channel, the R&S FPL1000 sets the bandwidth of the other alternate channels to the same value, but not the other way round. The command works hierarchically: to set a bandwidth of the 3rd and 4th chan- nel, you have to set the bandwidth of the 3rd channel first.
Page 546 This command defines the distance from transmission channel to alternate channels. If you set the channel spacing for the first alternate channel, the R&S FPL1000 adjusts the spacing of alternate channels of a lower order, but not the other way round. The...
Page 547 FPL1000 Configuring and Performing Measurements If you set the channel spacing for a transmission channel, the R&S FPL1000 sets the spacing of the lower transmission channels to the same value, but not the other way round. The command works hierarchically: to set a distance between the 2nd and 3rd and 3rd and 4th channel, you have to set the spacing between the 2nd and 3rd chan- nel first.
Page 548 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]POWer:ACHannel:FILTer:ALPHa[:ALL] <Value> This command defines the alpha value for the weighting filter for all channels. Parameters: <Value> <numeric value> *RST: 0.22 Example: POW:ACH:FILT:ALPH:ALL 0.35 [SENSe:]POWer:ACHannel:FILTer:ALPHa:ALTernate<ch> <Alpha> This command defines the roll-off factor for the alternate channel weighting filter.
Page 549 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]POWer:ACHannel:FILTer[:STATe][:ALL] <State> This command turns the weighting filters for all channels on and off. Parameters: <State> ON | OFF | 1 | 0 *RST: [SENSe:]POWer:ACHannel:FILTer[:STATe]:ALTernate<ch> <State> This command turns the weighting filter for an alternate channel on and off.
Page 550 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Manual operation: "Setting a fixed reference for Channel Power measure- ments ( Set CP Reference )" on page 266 [SENSe:]POWer:ACHannel:REFerence:TXCHannel:AUTO <RefChannel> This command selects the reference channel for relative measurements. You need at least one channel for the command to work.
Page 551 CALCulate<n>:LIMit<k>:ACPower:ACHannel:ABSolute <LowerLimit>, <UpperLimit> This command defines the absolute limit of the adjacent channels. If you have defined an absolute limit as well as a relative limit, the R&S FPL1000 uses the lower value for the limit check. Suffix: <n>, <k>...
Page 552 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <LowerLimit> The limit of the lower adjacent channel. Range: 0 dB to 100 dB *RST: 0 dB Default unit: dB <UpperLimit> The limit of the upper adjacent channel. Range: 0 dB to 100 dB...
Page 553 CALCulate<n>:LIMit<k>:ACPower:ALTernate<ch>:ABSolute <LowerLimit>, <UpperLimit> This command defines the absolute limit of the alternate channels. If you have defined an absolute limit as well as a relative limit, the R&S FPL1000 uses the lower value for the limit check. Suffix: <n>, <k>...
Page 554 This command defines the relative limit of the alternate channels. The reference value for the relative limit is the measured channel power. If you have defined an absolute limit as well as a relative limit, the R&S FPL1000 uses the lower value for the limit check.
Page 555 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Example: INIT:IMM;*WAI; CALC:LIM:ACP:ACH:RES? PASSED,PASSED Usage: Query only CALCulate<n>:LIMit<k>:ACPower:ALTernate<ch>[:RELative]:STATe This command turns the relative limit check for the alternate channels on and off. You have to activate the general ACLR limit check before using this command with CALCulate<n>:LIMit<k>:ACPower[:STATe].
Page 556 "Channel power level and density ( Power Unit )" on page 265 [SENSe:]POWer:ACHannel:MODE <Mode> This command selects the way the R&S FPL1000 displays the power of adjacent chan- nels. You need at least one adjacent channel for the command to work.
Page 557 Note that this example is primarily meant to demonstrate the remote control commands, it does not necessarily reflect a useful measurement task. For most com- mon measurement standards, the R&S FPL1000 performs the measurement optimally with the predefined settings, without further configuration.
Page 558 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements //Select relative display of the channel power. POW:ACH:MODE REL //Define transmission channel 1 as the reference channel. POW:ACH:REF:TXCH:MAN 1 //-----------Saving the settings as a user standard-------------- //Save the user standard with the name "my_aclr_standard".
Page 559 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements //Initiate a new measurement and waits until the sweep has finished. INIT;*WAI //---------------Limit Check-------------------- //Query the results of the limit check for the adjacent channels. CALC:LIM:ACP:ACH:RES? //Query the results of the limit check for the first alternate channels.
Page 560 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements //Initiates a new measurement and waits until the sweep has finished. //---------------Retrieving Results------------- CALC:MARK:FUNC:POW:RES? CN //Returns the carrier-to-noise ratio. 8.6.5 Measuring the Occupied Bandwidth All remote control commands specific to occupied bandwidth measurements are described here.
Page 561 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Percentage> Range: 10 PCT to 99.9 PCT *RST: 99 PCT Example: POW:BAND 95PCT Manual operation: " % Power Bandwidth " on page 284 8.6.5.2 Programming Example: OBW Measurement This programming example demonstrates the measurement example described in Chapter 7.2.5.5, "Measurement...
Page 562 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements See also Chapter 8.6.2, "Configuring Power Measurements", on page 537. ● Managing Measurement Configurations............... 562 ● Controlling the Measurement................563 ● Configuring a Multi-SEM Measurement..............564 ● Configuring a Sweep List..................565 ●...
Page 563 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Standard> String containing the file name. If you have stored the file in a subdirectory of the directory men- tioned above, you have to include the relative path to the file.
Page 564 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements INITiate<n>:ESPectrum This command initiates a Spectrum Emission Mask measurement. Suffix: <n> irrelevant Usage: Event [SENSe:]SWEep:MODE <Mode> This command selects the spurious emission and spectrum emission mask measure- ments. You can select other measurements with ●...
Page 565 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Suffix: <sb> 1 | 2 | 3 Sub block in a Multi-SEM measurement Parameters: <Frequency> Frequency within the currently defined global span (see on page 644 and [SENSe:]FREQuency:SPAN [SENSe: on page 642).
Page 566 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements .......... 570 [SENSe:]ESPectrum<sb>:RANGe<range>:INPut:GAIN:STATe ............. 570 [SENSe:]ESPectrum<sb>:RANGe<range>:INSert ......570 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:ABSolute:STARt ......571 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:ABSolute:STOP ......572 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt ....572 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt:ABS ..573 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt:FUNCtion ......573 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STOP ....574 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STOP:ABS ..575 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STOP:FUNCtion ........575 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:STATe .........576...
Page 567 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <RBW> Resolution bandwidth. Refer to the data sheet for available resolution bandwidths. *RST: 30.0 kHz Default unit: Hz Manual operation: " RBW " on page 303 [SENSe:]ESPectrum<sb>:RANGe<range>:BANDwidth:VIDeo <VBW> This command defines the video bandwidth for a SEM range.
Page 568 Make sure to set an appropriate span. If you set a span that is ● smaller than the span the SEM sweep list covers, the R&S FPL1000 will not mea- sure the ranges that are outside the span - results may be invalid.
Page 569 FPL1000 Configuring and Performing Measurements ● smaller than the span the SEM sweep list covers, the R&S FPL1000 will not mea- sure the ranges that are outside the span - results may be invalid. ● greater than the span the SEM sweep list covers, the R&S FPL1000 will adjust the...
Page 570 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements <range> 1..30 Selects the measurement range. Parameters: <State> ON | OFF | 0 | 1 *RST: Example: ESP:RANG2:INP:ATT:AUTO OFF Deactivates the RF attenuation auto mode for range 2. Manual operation: " RF Att Mode "...
Page 571 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Unlike manual operation, you can define an absolute limit anytime and regardless of the limit check mode. Suffix: <sb> 1 | 2 | 3 <range> 1..30 Selects the measurement range. <PClass>...
Page 572 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt <Limit> This command defines a relative limit for a SEM range. Unlike manual operation, you can define a relative limit regardless of the limit check mode. Suffix: <sb> 1 | 2 | 3 <range>...
Page 573 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Example: SENSe:ESPectrum:RANGe:LIMit:RELative:STARt: ABSolute -10 For a detailed example see Chapter 8.6.6.10, "Example: SEM Measurement", on page 587. Manual operation: " Rel Limit Start / Stop <n> " on page 305 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt: FUNCtion <Function>...
Page 574 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Suffix: <sb> 1 | 2 | 3 <range> 1..30 Selects the SEM range. <PClass> 1..4 Power class for which the limit is defined. Parameters: <Level> Relative limit at the stop frequency of a SEM range.
Page 575 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STOP: FUNCtion <Function> This command enables the use of a function when defining the relative limit for a SEM range. Suffix: <sb> 1 | 2 | 3 <range> 1..30 Selects the SEM range.
Page 576 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <State> ABSolute | RELative | AND | OR ABSolute Checks only the absolute limits defined. RELative Checks only the relative limits. Relative limits are defined as rel- ative to the measured power in the reference range.
Page 577 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Function> NONE (reference ranges only:) the limit of the reference range is used; Reference ranges always use the function "NONE". sum of the two limit lines (calculated for linear powers) is used...
Page 578 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]ESPectrum<sb>:RANGe<range>:SWEep:TIME:AUTO <State> This command turns automatic selection of the sweep time for a SEM range on and off. In case of high speed measurements, the sweep time has to be identical for all ranges.
Page 579 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]ESPectrum<sb>:BWID <Bandwidth> This command defines the channel bandwidth of the reference range. The bandwidth is available if the power reference is the channel power. Suffix: <sb> 1 | 2 | 3...
Page 580 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Return values: <RefRange> Number of the current reference range. Range: 1 to 30 Usage: Query only [SENSe:]ESPectrum<sb>:RTYPe <Type> This command defines the type of the power reference. Suffix: <sb> 1 | 2 | 3...
Page 581 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Setting parameters: <Max1> Defines the value range for power class 1 as -200 to <Max1>. Only available for CALC:LIM:ESP:PCL:COUNT >=2 If only 2 power classes are defined, the value range for power class 2 is defined as <Max1>...
Page 582 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Mode> AUTO The power class (and thus the limit line) is assigned dynamically according to the currently measured channel power. MANUAL One of the specified power classes is selected manually for the entire measurement.
Page 583 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements <sb> 1 | 2 | 3 Parameters: <NoPowerClasses> 1 to 4 *RST: Example: CALC:LIM:ESP:PCL:COUN 2 Two power classes can be defined. Manual operation: " Adding or Removing a Power Class "...
Page 584 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <State> ABSolute Evaluates only limit lines with absolute power values RELative Evaluates only limit lines with relative power values Evaluates limit lines with relative and absolute power values. A negative result is returned if both limits fail.
Page 585 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements ● The lower limit of a power class must always be the same as the upper limit of the previous power class. ● The power class must already exist (see CALCulate<n>:LIMit<k>: on page 582).
Page 586 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Example: CALC:ESP:PSE:AUTO OFF Deactivates the list evaluation. Manual operation: " List Evaluation State (Result Summary)" on page 314 " List Evaluation State " on page 336 CALCulate<n>:ESPectrum:PSEarch[:IMMediate] CALCulate<n>:ESPectrum:PEAKsearch[:IMMediate] This command initiates a list evaluation.
Page 587 For most common measurement stand- ards, the R&S FPL1000 performs the measurement optimally with the predefined set- tings, without further configuration.
Page 588 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements //------------ Defining the Reference Range----------------- //Query the current reference range. ESP:RRAN? //Select the channel power as the power reference. ESP:RTYP CPOW //Define a channel bandwidth of 4 MHz for the power reference.
Page 589 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements //Define a resolution bandwidth of 1 MHz for range 2. ESP:RANG2:BAND:RES 1000000 //Select an RRC filter for range 2. ESP:RANG2:FILT:TYPE RRC //Define a video bandwidth of 5 MHz for range 2.
Page 590 Programming Example: Spurious Emissions Measurement......... 600 8.6.7.1 Initializing the Measurement Note that with the R&S FPL1000, the spurious measurement must be initialized before you can start configuring the sweep list or list evaluation....................591 INITiate<n>:SPURious User Manual 1178.3370.02 ─ 03...
Page 591 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements INITiate<n>:SPURious This command initiates a Spurious Emission measurement. Suffix: <n> irrelevant Usage: Event 8.6.7.2 Configuring a Sweep List The following commands configure the sweep list for spurious emission measure- ments. The sweep list cannot be configured using remote commands during an on-going sweep operation.
Page 592 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Suffix: <range> 1..30 Selects the measurement range. Parameters: <RBW> Resolution bandwidth. Refer to the data sheet for available resolution bandwidths. Default unit: Hz Manual operation: " RBW " on page 333 [SENSe:]LIST:RANGe<range>:BANDwidth:VIDeo <VBW>...
Page 593 - results may be invalid. ● greater than the span the sweep list covers, the R&S FPL1000 will adjust the start frequency of the first range and the stop frequency of the last range to the span For more information see Chapter 7.2.7, "Spurious Emissions...
Page 594 - results may be invalid. ● greater than the span the sweep list covers, the R&S FPL1000 will adjust the start frequency of the first range and the stop frequency of the last range to the span For more information seeChapter 7.2.7, "Spurious Emissions...
Page 595 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]LIST:RANGe<range>:INPut:ATTenuation:AUTO <State> This command turns automatic selection of the input attenuation for a spurious emis- sion measurement range on and off. Suffix: <range> 1..30 Selects the measurement range. Parameters: <State> ON | OFF | 0 | 1...
Page 596 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]LIST:RANGe<range>:LIMit:STATe This command turns the limit check for all spurious emission measurement ranges on and off (<range> is irrelevant). Parameters: <State> ON | OFF | 1 | 0 *RST: Manual operation: "...
Page 597 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <RefLevel> Reference level. Refer to the data sheet for the reference level range. *RST: 0 dBm Manual operation: " Reference Level " on page 333 [SENSe:]LIST:RANGe<range>:SWEep:TIME <SweepTime> This command defines the sweep time for a spurious emission measurement range.
Page 598 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <Transducer> String containing the transducer file name, including the path information. Manual operation: " Transducer " on page 334 8.6.7.3 Configuring the List Evaluation The following commands configure the list evaluation.
Page 599 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <State> ON | OFF | 1 | 0 ON | 1 Includes all detected peaks (up to a maximum defined by on page 600). CALCulate<n>:PEAKsearch:SUBRanges OFF | 0 Includes only one peak per range.
Page 600 CALCulate<n>:PSEarch:SUBRanges <NumberPeaks> CALCulate<n>:PEAKsearch:SUBRanges <NumberPeaks> This command defines the number of peaks included in the peak list. After this number of peaks has been found, the R&S FPL1000 stops the peak search and continues the search in the next measurement range. Suffix: <n>...
Page 601 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements SWE:MODE LIST //Activates spurious emissions measurement INIT:CONT OFF //Selects single sweep mode. //Spurious measurement has to be in single sweep mode to be configured //and no sweep operation may be running! // If required, a sweep stop can be ensured by INIT:IMM;*WAI...
Page 602 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements // Frequency Span 0 MHz to 20 Ghz SENSe1:CORRection:TRANsducer:DATA 0e6,5, 20e9,3 SENS:LIST:RANG1:TRAN 'Test' //Includes a transducer called 'Test' for range 1. LIST:RANG1:LIM:STAR 10 LIST:RANG1:LIM:STOP 10 //Defines an absolute limit of 10 dBm at the start and stop frequencies of range 1.
Page 603 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements ● CALCulate<n>:MARKer<m>:X:SLIMits[:STATe] Remote commands exclusive to time domain power measurements ........... 603 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:AOFF ..........603 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:AVERage ..........604 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:PHOLd ..........604 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary[:STATe] ........604 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MEAN[:STATe] ........605 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:PPEak[:STATe] ........605 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:RMS[:STATe] .......605 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:SDEViation[:STATe]...
Page 604 This command turns time domain power measurements on and off. This measurement in only available in zero span. When you turn the measurement on, the R&S FPL1000 activates a marker and posi- tions it on the peak power level in the marker search range.
Page 605 " Results " on page 342 CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:PPEak[:STATe] <State> This command turns the evaluation to determine the positive peak time domain power on and off. The R&S FPL1000 performs the measurement on the trace marker 1 is positioned on. Suffix: <n> Window <m>...
Page 606 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <State> ON | OFF | 1 | 0 *RST: 8.6.8.2 Performing a Time Domain Power Measurement The following commands are required to perform a Time Domain Power measurement: on page 536, see Chapter 8.6.1, "Performing Measure-...
Page 607 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements See also on page 536. INITiate<n>:CONTinuous Suffix: <n> Window <m> Marker Return values: <MeanPower> Mean power of the signal during the measurement time. Usage: Query only CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MEAN:RESult? This command queries the mean time domain power.
Page 608 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:PPEak:PHOLd:RESult? This command queries the maximum positive peak time domain power. The query is only possible if the peak hold function has been activated previously using CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:PHOLd. To get a valid result, you have to perform a complete measurement with synchroniza- tion to the end of the measurement before reading out the result.
Page 609 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Suffix: <n> Window <m> Marker Return values: <RMSPower> RMS power of the signal during the measurement time. Usage: Query only CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:RMS:PHOLd:RESult? This command queries the maximum RMS of the time domain power. The query is only possible if the peak hold function has been activated previously using CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:PHOLd.
Page 610 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Measuring the Standard Deviation CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:SDEViation:AVERage:RESult? This command queries the average standard deviation of the time domain power. The query is only possible if averaging has been activated previously using on page 603.
Page 611 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Suffix: <n> Window <m> Marker Return values: <StandardDeviation> Standard deviation of the signal during the measurement time. Usage: Query only 8.6.8.4 Programming Example: Time Domain Power This programming example demonstrates the measurement example described in Chapter 7.2.8.6, "Measurement...
Page 612 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements //--------------Performing the Measurement------------------------ INIT;*WAI //Initiates the measurement and waits until the measurement is finished. //-------------Retrieving the Results-------------------------------- CALC:MARK:FUNC:SUMM:MEAN:RES? CALC:MARK:FUNC:SUMM:PPE:RES? CALC:MARK:FUNC:SUMM:RMS:RES? //Queries the mean, peak and RMS time domain power. 8.6.9 Measuring the Harmonic Distortion All remote control commands specific to harmonic distortion measurements are descri- bed here.
Page 613 ON | 1 a multiple *RST: Manual operation: " Harmonic RBW Auto " on page 349 CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:NHARmonics <NoHarmonics> This command selects the number of harmonics that the R&S FPL1000 looks for. Suffix: <n> Window <m> Marker Parameters: <NoHarmonics> Range:...
Page 614 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:PRESet This command initiates a measurement to determine the ideal configuration for the har- monic distortion measurement. The method depends on the span. ● Frequency domain (span > 0) Frequency and level of the first harmonic are determined and used for the mea- surement list.
Page 615 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Usage: Query only CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:LIST? This command queries the position of the harmonics. To get a valid result, you have to perform a complete measurement with synchroniza- tion to the end of the measurement before reading out the result. This is only possible for single sweep mode.
Page 616 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements //Queries the position of the harmonics. CALC:MARK:FUNC:HARM:DIST? TOT //Queries the total harmonic distortion. 8.6.10 Measuring the Third Order Intercept Point ● Determining the TOI....................616 ● Programming Example: Measuring the TOI............617 8.6.10.1 Determining the TOI All remote control commands specific to TOI measurements are described here.
Page 617 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements CALCulate<n>:MARKer<m>:FUNCtion:TOI:SEARchsignal ONCE This command initiates a search for signals in the current trace to determine the third intercept point. Suffix: <n>, <m> irrelevant Parameters: ONCE Example: CALC:MARK:FUNC:TOI:SEAR ONCE Executes the search for 2 signals and their intermodulation prod- uct at the currently available trace.
Page 618 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements CALC:MARK:FUNC:TOI ON //Activate TOI measurement. //--------------Performing the Measurement----- INIT:CONT OFF //Selects single sweep mode. CALC:MARK:FUNC:TOI:SEAR ONCE //Initiates a search for signals in the current trace. //---------------Retrieving Results------------- CALC:MARK:FUNC:TOI:RES? //Returns the TOI.
Page 619 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements Parameters: <State> ON | OFF | 1 | 0 *RST: CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:SEARchsignal ONCE This command initiates a search for the signals required for the AM depth measure- ment. Note that the command does not perform a new measurement, but looks for the sig- nals on the current trace.
Page 620 200 frequencies. The measurement itself is a time domain measurement. Note that if you set a span greater than 0, the R&S FPL1000 aborts the list evaluation. In case of a triggered measurement, a separate trigger event is required for each fre- quency to initiate that measurement.
Page 621 If you use a command that controls those functions, the R&S FPL1000 aborts the list evaluation. The R&S FPL1000 also aborts the list evaluation if you end the remote session. The commands can be used in two different ways.
Page 622 The list can contain up to 200 entries (frequencies). You can define a different instru- ment setup for each frequency that is in the list. If you synchronize the measurement with *OPC, the R&S FPL1000 produces a service request when all frequencies have been measured and the number of individual mea- surements has been performed.
Page 623 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements [SENSe:]LIST:POWer:SET <PeakPower>, <RMSPower>, <AVGPower>, <TriggerSource>, <TriggerSlope>, <TriggerOffset>, <GateLength> This command defines global List Evaluation parameters. These parameters are valid for every frequency you want to measure. The state of the first three parameters (<PeakPower>, <RMSPower> and <AVG- Power>) define the number of results for each frequency in the list.
Page 624 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements 8.6.12.2 Example: Performing List Evaluation The following example shows a list evaluation with the following configuration. Freq Filter Meas Trigger [MHz] Level Attenu- Attenu- Time Level [dBm] ation ation [dB] [dB] 935.2...
Page 625 If you use a command that controls those functions, the R&S FPL1000 aborts the Pulse Power measurement. The R&S FPL1000 also aborts the Pulse Power measurement if you end the remote session. The commands can be used in two different ways.
Page 626 <TimeOffset>,<MeasTime>,<PulsePeriod>,<#OfPulses> This command configures power measurements on pulses in the time domain. To evaluate the pulse power, the R&S FPL1000 uses the data captured during a previ- ous measurement. The data recorded during the set measurement time is combined to a measured value for each pulse according to the detector specified and the indicated number of results is output as a list.
Page 627 <TriggerSource>, <TriggerLevel>, <TriggerOffset>, <Detector>, <#OfPulses> This command configures and initiates the pulse power measurement. The R&S FPL1000 caches all measurement parameters that you can set with this command. If you use the command repeatedly, the R&S FPL1000 only changes those settings that you have actually changed before initiating the measurement.
Page 628 Defines a trigger level. The trigger level is available for the video trigger. In that case, the level is a percentage of the diagram height. In case of an external trigger, the R&S FPL1000 uses a fix TTL level. Range:...
Page 629 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements *OPC //Configures and initiates a measurement on 20 pulses with synchronization to the end. //Analyzer produces a service request //On service request: MPOW:RES? //Returns the results of the measurements (20 power levels).
Page 630 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements BAND:VID 500kHz //Decouples the VBW from the RBW and decreases it to smooth the trace. //--------------Configuring the Sweep-------------------------- SENS:SWE:COUN 10 //Defines 10 sweeps to be performed in each measurement. SENS:SWE:POIN 500 //During each sweep, 500 trace points will be measured.
Page 631 ® Remote Commands R&S FPL1000 Configuring and Performing Measurements SWE:EGAT ON SWE:EGAT:TYPE EDGE SWE:EGAT:LENG 5ms //Defines gating. Values are measured for 5 ms after triggering. OUTP:TRIG2:DIR OUTP OUTP:TRIG2:OTYP UDEF OUTP:TRIG2:LEV HIGH OUTP:TRIG2:PULS:LENG 100us OUTP:TRIG2:PULS:IMM //Configures a high trigger signal with a pulse length of 100 us to be output at //the front TRIGGER INPUT/OUTPUT connector once.
Page 632: Remote Commands For Result Displays
® Remote Commands R&S FPL1000 Remote Commands for Result Displays TRAC:DATA? TRACE4 //Returns one power and one frequency value per sweep point for each trace. 8.7 Remote Commands for Result Displays ● Working with Windows in the Display..............632 ●...
Page 633 ® Remote Commands R&S FPL1000 Remote Commands for Result Displays <WindowType> text value Type of result display (evaluation method) you want to add. See the table below for available parameter values. Return values: <NewWindowName> When adding a new window, the command returns its name (by default the same as its number) as a result.
Page 634 ® Remote Commands R&S FPL1000 Remote Commands for Result Displays Query parameters: <WindowName> String containing the name of a window. Return values: <WindowIndex> Index number of the window. LAY:WIND:IDEN? '2' Example: Queries the index of the result display named '2'.
Page 635 ® Remote Commands R&S FPL1000 Remote Commands for Result Displays LAYout:REPLace[:WINDow] <WindowName>,<WindowType> This command replaces the window type (for example from "Diagram" to "Result Sum- mary") of an already existing window in the active channel setup while keeping its posi- tion, index and window name.
Page 636 ® Remote Commands R&S FPL1000 Remote Commands for Result Displays <Index2> The index of a window on the other side of the splitter. <Position> New vertical or horizontal position of the splitter as a fraction of the screen area (without channel and status bar and softkey menu).
Page 637 ® Remote Commands R&S FPL1000 Remote Commands for Result Displays Example: LAY:WIND1:ADD? LEFT,MTAB Result: Adds a new window named '2' with a marker table to the left of window 1. Usage: Query only LAYout:WINDow<n>:IDENtify? This command queries the name of a particular display window (indicated by the <n>...
Page 638 ® Remote Commands R&S FPL1000 Remote Commands for Result Displays Suffix: <n> Window Setting parameters: <WindowType> Type of measurement window you want to replace another one with. on page 632 for a list of availa- LAYout:ADD[:WINDow]? ble window types. Example: LAY:WIND2:REPL MTAB Replaces the result display in window 2 with a marker table.
Page 639 ® Remote Commands R&S FPL1000 Remote Commands for Result Displays //Add a Marker Peak List window to the right of the Spectrogram window LAY:WIND2:ADD? RIGH,PEAK //Result: window number: '4' //--------------- Changing the size of individual windows ------------- //Move the splitter between the Frequency Sweep window and the Marker Table //window to enlarge the spectrum display to 60% of the entire width.
Page 640: Setting Basic Spectrum Rf Measurement Parameters
® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters //-------------- Preparing the configuration from example 1 ----------- *RST LAY:ADD? '1',BEL,SGR LAY:ADD? '1',RIGH,MTAB LAY:WIND2:ADD? RIGH,PEAK LAY:CAT? //Result : '1',1,'2',2,'3',3,'4',4 //Remove Spectrogram LAY:WIND2:REM //Remove Marker Table window LAY:REM '3' //Replace Marker Peak List window by Marker Table...
Page 641 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters ● Configuring the Trace Display and Retrieving Trace Data........687 ● Working with Markers....................708 ● Configuring Display and Limit Lines..............767 8.8.1 Defining the Frequency and Span The commands required to configure the frequency and span settings in a remote envi- ronment are described here.
Page 642 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:MARKer<m>:FUNCtion:CSTep This command matches the center frequency step size to the current marker fre- quency. The command turns delta markers into normal markers. Suffix: <n> Window <m> Marker Usage: Event DISPlay[:WINDow<n>]:TRACe:X:SPACing <ScalingType>...
Page 643 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters [SENSe:]FREQuency:CENTer:STEP <StepSize> This command defines the center frequency step size. You can increase or decrease the center frequency quickly in fixed steps using the SENS:FREQ UP AND SENS:FREQ DOWN commands, see [SENSe:]FREQuency: on page 642.
Page 644 " Frequency Offset " on page 379 [SENSe:]FREQuency:SPAN <Span> This command defines the frequency span. If you set a span of 0 Hz in the Spectrum application, the R&S FPL1000 starts a mea- surement in the time domain. Parameters: <Span>...
Page 645 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Zero Span " on page 233 " Span " on page 377 " Zero Span " on page 378 " Last Span " on page 378 [SENSe:]FREQuency:SPAN:FULL This command restores the full span.
Page 646 All )" on page 419 [SENSe:]ADJust:CONFigure[:LEVel]:DURation <Duration> In order to determine the ideal reference level, the R&S FPL1000 performs a measure- ment on the current input data. This command defines the length of the measurement is set to MANual. [SENSe:]ADJust:CONFigure[:LEVel]:DURation:MODE Parameters: <Duration>...
Page 647 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Resetting the Automatic Measurement Time ( Meastime Auto )" on page 420 " Changing the Automatic Measurement Time ( Meastime Manual )" on page 420 [SENSe:]ADJust:CONFigure:HYSTeresis:LOWer <Threshold>...
Page 648 This ensures that the settings of the RF attenuation and the reference level are optimally adjusted to the signal level without overloading the R&S FPL1000 or limiting the dynamic range by an S/N ratio that is too small.
Page 649 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n>, <m> irrelevant Parameters: <State> ON | OFF | 1 | 0 *RST: Manual operation: " Signal Tracking " on page 380 CALCulate<n>:MARKer<m>:FUNCtion:STRack:BANDwidth <Bandwidth> This command defines the bandwidth around the center frequency that is included in the signal tracking process.
Page 650 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Signal Tracking " on page 380 8.8.2 Configuring Bandwidth and Sweep Settings The commands required to configure the bandwidth, sweep and filter settings in a remote environment are described here. The tasks for manual operation are described Chapter 7.6, "Bandwidth, Filter and Sweep...
Page 651 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters [SENSe:]BWIDth[:RESolution]:AUTO <State> [SENSe:]BANDwidth[:RESolution]:AUTO <State> This command couples and decouples the resolution bandwidth to the span. Parameters: <State> ON | OFF | 0 | 1 *RST: Example: BAND:AUTO OFF Switches off the coupling of the resolution bandwidth to the span.
Page 652 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters [SENSe:]BWIDth:VIDeo <Bandwidth> [SENSe:]BANDwidth:VIDeo <Bandwidth> This command defines the video bandwidth. The command decouples the video bandwidth from the resolution bandwidths. Parameters: <Bandwidth> refer to data sheet *RST: AUTO is set to ON...
Page 653 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Mode> LINear The video filter is applied in front of the logarithmic amplifier. In linear mode, measurements with a logarithmic level scale result in flatter falling edges compared to logarithmic mode. The...
Page 654 Setting Basic Spectrum RF Measurement Parameters Parameters: <SweepCount> When you set a sweep count of 0 or 1, the R&S FPL1000 per- forms one single sweep in single sweep mode. In continuous sweep mode, if the sweep count is set to 0, a moving average over 10 sweeps is performed.
Page 655 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Table 8-3: Optimization parameters in FFT mode Optimization mode Description DYNamic Optimizes the dynamic range by using the narrowest possible partial span (depend- ing on the RBW). The autorange function for the internal IF gain calculation is activated to obtain the best control range for the A/D converter.
Page 656 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters [SENSe:]SWEep:TIME <Time> This command defines the sweep time. In the Spectrum application, the command decouples the sweep time from the span and resolution and video bandwidths. Note that this command queries only the time required to capture the data, not to process it.
Page 657 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters ● Amplitude Settings....................657 ● Configuring the Attenuation...................658 ● Configuring a Preamplifier..................659 ● Scaling the Y-Axis....................660 8.8.3.1 Amplitude Settings The tasks for manual configuration are described in Chapter 7.5.2, "Amplitude Set- tings",...
Page 658 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Unit> DBM | V | A | W | DBPW | WATT | DBUV | DBMV | VOLT | DBUA | AMPere *RST: Example: UNIT:POW DBM Sets the power unit to dBm.
Page 659 INPut:ATTenuation:AUTO <State> This command couples or decouples the attenuation to the reference level. Thus, when the reference level is changed, the R&S FPL1000 determines the signal level for opti- mal internal data processing and sets the required attenuation accordingly. Parameters: <State>...
Page 660 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters INPut:GAIN:STATe <State> This command turns the internal preamplifier on and off. It requires the optional pream- plifier hardware. The input signal is amplified by 20 dB if the preamplifier option is activated.
Page 661 Sets the grid spacing to 10 units (e.g. dB) per division DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RPOSition <Position> This command defines the vertical position of the reference level on the display grid (for all traces). The R&S FPL1000 adjusts the scaling of the y-axis accordingly. Suffix: <n> Window...
Page 662 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters <t> irrelevant Parameters: <Position> 0 PCT corresponds to the lower display border, 100% corre- sponds to the upper display border. *RST: 100 PCT = frequency display; 50 PCT = time dis-...
Page 663 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters 8.8.4.1 Configuring the Triggering Conditions The following commands are required to configure a triggered measurement....................663 TRIGger[:SEQuence]:DTIMe ................663 TRIGger[:SEQuence]:HOLDoff[:TIME] ................663 TRIGger[:SEQuence]:IFPower:HOLDoff ..............664 TRIGger[:SEQuence]:IFPower:HYSTeresis ..............664 TRIGger[:SEQuence]:LEVel[:EXTernal<port>] ................664 TRIGger[:SEQuence]:LEVel:IFPower ................
Page 664 Note that this command can be used for any trigger source, not just IF Power (despite the legacy keyword). Note: If you perform gated measurements in combination with the IF Power trigger, the R&S FPL1000 ignores the holding time for frequency sweep, FFT sweep, zero span and I/Q data measurements. Parameters: <Period>...
Page 665 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <TriggerLevel> For details on available trigger levels and trigger bandwidths see the data sheet. *RST: -10 dBm Example: TRIG:LEV:IFP -30DBM Manual operation: " Trigger Level " on page 411 TRIGger[:SEQuence]:LEVel:IQPower <TriggerLevel>...
Page 666 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters For troubleshooting tips see "Incompleted sequential commands - blocked remote channels" on page 859. Parameters: <Source> IMMediate Free Run EXTernal Trigger signal from the TRIGGER INPUT connector. IFPower Second intermediate frequency...
Page 667 This command defines the delay time between the gate signal and the continuation of the measurement. Note: If you perform gated measurements in combination with the IF Power trigger, the R&S FPL1000 ignores the holding time for frequency sweep, FFT sweep, zero span and I/Q mode measurements. Parameters: <DelayTime>...
Page 668 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <GateLength> Range: 125 ns to 30 s *RST: 400μs Example: SWE:EGAT:LENG 10ms Manual operation: " Gate Length " on page 418 [SENSe:]SWEep:EGATe:POLarity <Polarity> This command selects the polarity of an external gate signal.
Page 669 After the gate signal has been detected, the gate remains open until the signal disappears. Note: If you perform gated measurements in combination with the IF Power trigger, the R&S FPL1000 ignores the holding time for frequency sweep, FFT sweep, zero span and I/Q mode mea- surements.
Page 670 INPut:UPORt:STATe <State> This command toggles the control lines of the user ports for the AUX PORT connector. This 9-pole SUB-D male connector is located on the rear panel of the R&S FPL1000. See the R&S FPL1000 Getting Started manual for details.
Page 671 *RST: Example: SYST:COMM:RDEV:PMET:CONF:AUTO OFF Manual operation: " Select " on page 368 SYSTem:COMMunicate:RDEVice:PMETer:COUNt? This command queries the number of power sensors currently connected to the R&S FPL1000. Parameters: <NumberSensors> Number of connected power sensors. Example: SYST:COMM:RDEV:PMET:COUN? Usage: Query only Manual operation: "...
Page 672 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters SYSTem:COMMunicate:RDEVice:PMETer<p>:DEFine <Placeholder>, <Type>, <Interface>, <SerialNo> This command assigns the power sensor with the specified serial number to the selected power sensor index (configuration). The query returns the power sensor type and serial number of the sensor assigned to the specified index.
Page 673 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters ................678 [SENSe:]PMETer<p>:UPDate[:STATe] ..................678 UNIT<n>:PMETer<p>:POWer ................679 UNIT<n>:PMETer<p>:POWer:RATio CALibration:PMETer<p>:ZERO:AUTO ONCE This command zeroes the power sensor. Note that you have to disconnect the signals from the power sensor input before you start to zero the power sensor.
Page 674 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters <p> 1...4 Power sensor index Parameters: ONCE CALC:PMET2:REL:AUTO ONCE Example: Takes the current measurement value as reference value for rel- ative measurements for power sensor 2. Usage: Event Manual operation: "Setting the Reference Level from the Measurement Meas -...
Page 675 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <p> 1...4 Power sensor index Usage: Query only [SENSe:]PMETer<p>:DCYCle[:STATe] <State> This command turns the duty cycle correction on and off. Suffix: <p> 1...4 Power sensor index Parameters: <State>...
Page 676 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Frequency> The available value range is specified in the data sheet of the power sensor in use. *RST: 50 MHz Example: PMET2:FREQ 1GHZ Sets the frequency of the power sensor to 1 GHz.
Page 677 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters [SENSe:]PMETer<p>:MTIMe:AVERage:COUNt <NumberReadings> This command sets the number of power readings included in the averaging process of power sensor measurements. Extended averaging yields more stable results for power sensor measurements, espe- cially for measurements on signals with a low power, because it minimizes the effects of noise.
Page 678 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <State> ON | 1 Includes the reference level offset in the results. OFF | 0 Ignores the reference level offset. *RST: Example: PMET2:ROFF OFF Takes no offset into account for the measured power.
Page 679 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n> irrelevant <p> 1...4 Power sensor index Parameters: <Unit> DBM | WATT | W *RST: Example: UNIT:PMET:POW DBM Manual operation: " Unit/Scale " on page 369 UNIT<n>:PMETer<p>:POWer:RATio <Unit>...
Page 680 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: PMET2:TRIG:DTIMe 0.001 [SENSe:]PMETer<p>:TRIGger:HOLDoff <Holdoff> This command defines the trigger holdoff for external power triggers. Suffix: <p> 1...4 Power sensor index Parameters: <Holdoff> Time period that has to pass between the trigger event and the start of the measurement, in case another trigger event occurs.
Page 681 Switches the external power trigger on Manual operation: " Using the power sensor as an external trigger " on page 370 8.8.5.3 Configuring the Outputs The following commands are required to provide output from the R&S FPL1000. User Manual 1178.3370.02 ─ 03...
Page 682 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Output functions require the option R&S FPL1-B5 to be installed on the R&S FPL1000..................682 DIAGnostic:SERVice:NSOurce ..................... 682 OUTPut:IF[:SOURce] ....................683 OUTPut:IF:IFFRequency ....................683 OUTPut:UPORt:STATe ....................683 OUTPut:UPORt[:VALue] ................684 OUTPut:UPORt:WTRigger:POLarity .....................684...
Page 683 374 OUTPut:UPORt:STATe <State> This command toggles the control lines of the user ports for the AUX PORT connector. This 9-pole SUB-D male connector is located on the rear panel of the R&S FPL1000. Parameters: <State> ON | 1...
Page 684 A high signal (= 5 V) indicates the instrument is ready to receive a trigger. Example: OUTP:UPOR:WTR:POL HIGH The R&S FPL1000 waits for a 5-V-signal at the AUX PORT con- nector before accepting a trigger signal. SYSTem:SPEaker[:STATe] <State> This command switches the built-in loudspeaker on or off for demodulated signals.
Page 685 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Volume> Percentage of the maximum possible volume. Range: 0 to 1 *RST: Example: SYST:SPE:VOL 0 Switches the loudspeaker to mute. Manual operation: "Data Output" on page 374 "Audio Output Volume"...
Page 686 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters DISPlay[:WINDow<n>]:ZOOM[:STATe] <State> This command turns the zoom on and off. Suffix: <n> Window Parameters: <State> ON | OFF | 1 | 0 *RST: Example: DISP:ZOOM ON Activates the zoom mode.
Page 687 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Multi-Zoom " on page 509 DISPlay[:WINDow<n>]:ZOOM:MULTiple<zoom>[:STATe] <State> This command turns the multiple zoom on and off. Suffix: <n> Window <zoom> 1...4 Selects the zoom window. If you turn off one of the zoom windows, all subsequent zoom windows move up one position.
Page 688 Count" determines the number of averaging procedures. MAXHold The maximum value is determined over several sweeps and dis- played. The R&S FPL1000 saves the sweep result in the trace memory only if the new value is greater than the previous one. MINHold The minimum value is determined from several measurements and displayed.
Page 689 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: INIT:CONT OFF Switching to single sweep mode. SWE:COUN 16 Sets the number of measurements to 16. DISP:TRAC3:MODE WRIT Selects clear/write mode for trace 3. INIT;*WAI Starts the measurement and waits for the end of the measure- ment.
Page 690 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Trace 1 / Trace 2 / Trace 3 / Trace 4 / Trace 5 / Trace 6 " on page 467 " Trace 1 / Trace 2 / Trace 3 / Trace 4 (Softkeys)"...
Page 691 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters In case of continuous sweep mode, the application calculates the moving average over the average count. In case of single sweep mode, the application stops the measurement and calculates the average after the average count has been reached.
Page 692 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Average Mode " on page 468 [SENSe:][WINDow<n>:]DETector<t>[:FUNCtion] <Detector> Defines the trace detector to be used for trace analysis. For details see "Mapping Samples to sweep Points with the Trace Detector"...
Page 693 In addition to the standard "level versus frequency" or "level versus time" spectrum traces, the R&S FPL1000 also provides a spectrogram display of the measured data. A spectrogram shows how the spectral density of a signal varies over time. The x-axis shows the frequency, the y-axis shows the time.
Page 694 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters ..................696 CALCulate<n>:SGRam[:STATe] ................696 CALCulate<n>:SPECtrogram[:STATe] ................696 CALCulate<n>:SGRam:TSTamp:DATA? ..............696 CALCulate<n>:SPECtrogram:TSTamp:DATA? ................ 697 CALCulate<n>:SGRam:TSTamp[:STATe] ..............697 CALCulate<n>:SPECtrogram:TSTamp[:STATe] CALCulate<n>:SGRam:CLEar[:IMMediate] CALCulate<n>:SPECtrogram:CLEar[:IMMediate] This command resets the spectrogram and clears the history buffer.
Page 695 CALC:SGR:FRAM:SEL -25 Selects frame number -25. Manual operation: "Select Frame" on page 402 CALCulate<n>:SGRam:HDEPth <History> CALCulate<n>:SPECtrogram:HDEPth <History> This command defines the number of frames to be stored in the R&S FPL1000 mem- ory. Suffix: <n> irrelevant User Manual 1178.3370.02 ─ 03...
Page 696 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <History> The maximum number of frames depends on the number of sweep points. Range: 781 to 20000 Increment: 1 *RST: 3000 Example: CALC:SGR:SPEC 1500 Sets the history depth to 1500.
Page 697 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters The return values consist of four values for each frame. If the Spectrogram is empty, the command returns '0,0,0,0'. The times are given as delta values, which simplifies evaluating relative results; however, you can also calculate the absolute date and time as displayed on the screen.
Page 698 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <State> ON | OFF | 1 | 0 *RST: Example: CALC:SGR:TST ON Activates the time stamp. Manual operation: " Time Stamp " on page 480 Configuring the Color Map ..............
Page 699 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters DISPlay[:WINDow<n>]:SGRam:COLor:SHAPe <Shape> DISPlay[:WINDow<n>]:SPECtrogram:COLor:SHAPe <Shape> This command defines the shape and focus of the color curve for the spectrogram result display. Suffix: <n> Window Parameters: <Shape> Shape of the color curve.
Page 700 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <ColorScheme> Uses a color range from blue to red. Blue colors indicate low lev- els, red colors indicate high ones. COLD Uses a color range from red to blue. Red colors indicate low lev- els, blue colors indicate high ones.
Page 701 CALC:MATH:EXPR:DEF (TRACE1-TRACE3) Subtracts trace 3 from trace 1. Manual operation: " Trace Math Function " on page 487 CALCulate<n>:MATH:MODE <Mode> This command selects the way the R&S FPL1000 calculates trace mathematics. Suffix: <n> Window Parameters: <Mode> For more information on the way each mode works see...
Page 702 This command selects the data format that is used for transmission of trace data from the R&S FPL1000 to the controlling computer. Note that the command has no effect for data that you send to the R&S FPL1000. The R&S FPL1000 automatically recognizes the data it receives, regardless of the format.
Page 703 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Format> ASCii ASCii format, separated by commas. This format is almost always suitable, regardless of the actual data format. However, the data is not as compact as other for- mats may be.
Page 704 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: TRAC TRACE1,+A$ Transfers trace data ('+A$') to trace 1. Example: TRAC? TRACE3 Queries the data of trace 3. Manual operation: " Diagram " on page 253 " List Evaluation State (Result Summary)"...
Page 705 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Query parameters: <Trace> TRACE1 | TRACE2 | TRACE3 | TRACE4 | TRACE5 | TRACE6 <OffsSwPoint> The offset in sweep points related to the start of the measure- ment at which data retrieval is to start.
Page 706 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Number of digits (= 4 in the example) of the following number of data bytes 1024 Number of following data bytes (= 1024 in the example) <Value> 4-byte floating point value Reading out data in binary format is quicker than in ASCII format.
Page 707 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters DISP:WIND:SGR:COL:SHAP 0.8 //Defines a color map for a range that comprises 40% of the measurement range, //excluding 30% at each end. The colors are not scaled linearly; the light gray //colors are stretched to distinguish low values better.
Page 708 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALC:MARK2:X? CALC:MARK2:Y? CALC:MARK2:SGR:FRAM? //Queries the frequency (x), level (y) and frame values of marker 2. CALC:DELT1:X? CALC:DELT1:Y? CALC:DELT1:SGR:FRAM? //Queries the frequency (x), level (y) and frame values of deltamarker 1.
Page 709 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters ● Signal Count Marker..................... 754 ● Marker Demodulation....................756 ● Programming Examples for Using Markers and Marker Functions.......758 8.8.8.1 Setting Up Individual Markers The following commands define the position of markers in the diagram.
Page 710 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <State> ON | OFF | 1 | 0 *RST: Example: CALC:DELT2:LINK ON Manual operation: " Linking to Another Marker " on page 427 CALCulate<n>:DELTamarker<m>:LINK:TO:MARKer<m> <State> This command links delta marker <m1> to any active normal marker <m2>.
Page 711 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:DELTamarker<m>:MREF <Reference> This command selects a reference marker for a delta marker other than marker 1. The reference may be another marker or the fixed reference. Suffix: <n> Window <m>...
Page 712 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Trace> Trace number the marker is assigned to. Example: CALC:DELT2:TRAC 2 Positions delta marker 2 on trace 2. CALCulate<n>:DELTamarker<m>:X <Position> This command moves a delta marker to a particular coordinate on the x-axis.
Page 713 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters If you change the horizontal position of marker <m2>, marker <m1> changes its hori- zontal position to the same value. Suffix: <n> Window <m> Marker Parameters: <State> ON | OFF | 1 | 0...
Page 714 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: CALC:MARK3:TRAC 2 Assigns marker 3 to trace 2. Manual operation: " Assigning the Marker to a Trace " on page 427 CALCulate<n>:MARKer<m>:X <Position> This command moves a marker to a particular coordinate on the x-axis.
Page 715 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <DisplayMode> ON | 1 Turns on the marker table. OFF | 0 Turns off the marker table. AUTO Turns on the marker table if 3 or more markers are active.
Page 716 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters 8.8.8.3 Configuring and Performing a Marker Search The following commands control the marker search................716 CALCulate<n>:MARKer<m>:LOEXclude .................716 CALCulate<n>:MARKer<m>:PEXCursion ..............717 CALCulate<n>:MARKer<m>:X:SLIMits[:STATe] ..............717 CALCulate<n>:MARKer<m>:X:SLIMits:LEFT ..............717 CALCulate<n>:MARKer<m>:X:SLIMits:RIGHt ............. 718 CALCulate<n>:MARKer<m>:X:SLIMits:ZOOM[:STATe] ....................718 CALCulate<n>:THReshold...
Page 717 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Peak Excursion " on page 431 CALCulate<n>:MARKer<m>:X:SLIMits[:STATe] <State> This command turns marker search limits on and off for all markers in all windows. If you perform a measurement in the time domain, this command limits the range of the trace to be analyzed.
Page 718 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters If you perform a measurement in the time domain, this command limits the range of the trace to be analyzed. Suffix: <n>, <m> irrelevant Parameters: <Limit> The value range depends on the frequency range or sweep time.
Page 719 ..............722 CALCulate<n>:MARKer<m>:MINimum[:PEAK] ..............722 CALCulate<n>:MARKer<m>:MINimum:RIGHt CALCulate<n>:MARKer<m>:MAXimum:AUTO <State> This command turns an automatic marker peak search for a trace maximum on and off. The R&S FPL1000 performs the peak search after each sweep. Suffix: <n> Window <m> Marker User Manual 1178.3370.02 ─ 03...
Page 720 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <State> ON | OFF | 1 | 0 *RST: Example: CALC:MARK:MAX:AUTO ON Activates the automatic peak search function for marker 1 at the end of each particular sweep.
Page 721 Manual operation: " Search Next Peak " on page 436 CALCulate<n>:MARKer<m>:MINimum:AUTO <State> This command turns an automatic marker peak search for a trace minimum on and off. The R&S FPL1000 performs the peak search after each sweep. Suffix: <n> Window <m>...
Page 722 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters In the spectrogram, the command moves a marker horizontally to the minimum level in the currently selected frame. The vertical marker position remains the same. Suffix: <n> Window <m>...
Page 723 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n> Window <m> Marker Usage: Event Manual operation: " Search Next Minimum " on page 437 Positioning Delta Markers The following commands position delta markers on the trace.
Page 724 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:DELTamarker<m>:MAXimum[:PEAK] This command moves a delta marker to the highest level. In the spectrogram, the command moves a marker horizontally to the maximum level in the currently selected frame. The vertical marker position remains the same.
Page 725 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:DELTamarker<m>:MINimum:NEXT This command moves a marker to the next higher minimum value. In the spectrogram, the command moves a marker horizontally to the minimum level in the currently selected frame. The vertical marker position remains the same.
Page 726 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters You can use the marker values to position the center frequency or reference level directly using the following commands: ● on page 641 CALCulate<n>:MARKer<m>:FUNCtion:CENTer ● on page 657 CALCulate<n>:MARKer<m>:FUNCtion:REFerence Useful commands for retrieving results described elsewhere: ●...
Page 727 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Marker 1 / Marker 2 / Marker 3 / Marker 4 " on page 357 " Marker 1 / Marker 2 / Marker 3 " on page 361 CALCulate<n>:DELTamarker<m>:Y?
Page 728 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters See also on page 536. INITiate<n>:CONTinuous Suffix: <n> Window <m> Marker Return values: <Result> Result at the marker position. The unit is variable and depends on the one you have currently set.
Page 729 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Remote commands exclusive to spectrogram markers ..............729 CALCulate<n>:MARKer<m>:SGRam:FRAMe ............729 CALCulate<n>:MARKer<m>:SPECtrogram:FRAMe ..............730 CALCulate<n>:MARKer<m>:SGRam:SARea ............730 CALCulate<n>:MARKer<m>:SPECtrogram:SARea ..........730 CALCulate<n>:MARKer<m>:SGRam:XY:MAXimum[:PEAK] ........730 CALCulate<n>:MARKer<m>:SPECtrogram:XY:MAXimum[:PEAK] ..........730 CALCulate<n>:MARKer<m>:SGRam:XY:MINimum[:PEAK] ........730 CALCulate<n>:MARKer<m>:SPECtrogram:XY:MINimum[:PEAK] ..........730 CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:ABOVe ........
Page 730 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:MARKer<m>:SGRam:SARea <SearchArea> CALCulate<n>:MARKer<m>:SPECtrogram:SARea <SearchArea> This command defines the marker search area for all spectrogram markers in the channel setup. Suffix: <n>, <m> irrelevant Parameters: <SearchArea> VISible Performs a search within the visible frames.
Page 731 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n> Window <m> Marker Usage: Event Manual operation: " Search Mode for Next Peak in Y-Direction " on page 433 CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:BELow CALCulate<n>:MARKer<m>:SPECtrogram:Y:MAXimum:BELow This command moves a marker vertically to the next lower peak level for the current frequency.
Page 732 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n> Window <m> Marker Usage: Event CALCulate<n>:MARKer<m>:SGRam:Y:MINimum:ABOVe CALCulate<n>:MARKer<m>:SPECtrogram:Y:MINimum:ABOVe This command moves a marker vertically to the next higher minimum level for the cur- rent frequency. The search includes only frames above the current marker position. It does not change the horizontal position of the marker.
Page 733 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Usage: Event Manual operation: " Search Mode for Next Peak in Y-Direction " on page 433 CALCulate<n>:MARKer<m>:SGRam:Y:MINimum[:PEAK] CALCulate<n>:MARKer<m>:SPECtrogram:Y:MINimum[:PEAK] This command moves a marker vertically to the minimum level for the current fre- quency.
Page 734 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters ......... 736 CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:BELow .........736 CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MAXimum:BELow ...........736 CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:NEXT ........736 CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MAXimum:NEXT .........736 CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum[:PEAK] ........ 736 CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MAXimum[:PEAK] ..........737 CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:ABOVe ......... 737 CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MINimum:ABOVe .......... 737 CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:BELow ........737 CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MINimum:BELow ..........737 CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:NEXT ........737 CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MINimum:NEXT...
Page 735 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <SearchArea> VISible Performs a search within the visible frames. Note that the command does not work if the spectrogram is not visible for any reason (e.g. if the display update is off).
Page 736 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:BELow CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MAXimum:BELow This command moves a marker vertically to the next higher level for the current fre- quency. The search includes only frames below the current marker position. It does not change the horizontal position of the marker.
Page 737 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:ABOVe CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MINimum:ABOVe This command moves a delta marker vertically to the next minimum level for the cur- rent frequency. The search includes only frames above the current marker position. It does not change the horizontal position of the marker.
Page 738 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum[:PEAK] CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MINimum[:PEAK] This command moves a delta marker vertically to the minimum level for the current fre- quency. The search includes all frames. It does not change the horizontal position of the marker.
Page 739 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <RefPoint> Numeric value that defines the horizontal position of the refer- ence. For frequency domain measurements, it is a frequency in Hz. For time domain measurements, it is a point in time in s.
Page 740 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters If necessary, the command activates a marker and positions it on the peak power. Subsequently, you can change the coordinates of the fixed reference independent of the marker. The fixed reference is independent of the trace and is applied to all active delta markers.
Page 741 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n> Window <m> Marker Parameters: <State> ON | OFF | 0 | 1 *RST: Example: CALC:MARK:FUNC:FPE:ANN:LAB:STAT OFF Removes the peak labels from the diagram Manual operation: " Display Marker Numbers "...
Page 742 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:MARKer<m>:FUNCtion:FPEaks:LIST:SIZE <MaxNoPeaks> This command defines the maximum number of peaks that the R&S FPL1000 looks for during a peak search. Suffix: <n> Window <m> Marker Parameters: <MaxNoPeaks> Maximum number of peaks to be determined.
Page 743 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: CALC:MARK:FUNC:FPE:STAT ON Activates marker peak search Manual operation: " Peak List State " on page 455 CALCulate<n>:MARKer<m>:FUNCtion:FPEaks:X? This command queries the position of the peaks on the x-axis.
Page 744 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n> Window <m> Marker Return values: <NoiseLevel> Current noise level. The unit is the one currently active. Example: INIT:CONT OFF Switches to single sweep mode. CALC:MARK2 ON Switches on marker 2.
Page 745 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Remote commands exclusive to phase noise markers ..........745 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:AUTO ........... 745 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:RESult? ........... 746 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise[:STATe] ........... 746 CALCulate<n>:MARKer<m>:FUNCtion:PNOise:RESult? ........... 747 CALCulate<n>:MARKer<m>:FUNCtion:PNOise[:STATe] CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:AUTO <State> This command turns an automatic peak search for the fixed reference marker at the end of a sweep on and off.
Page 746 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise[:STATe] <State> This command turns the phase noise measurement at the delta marker position on and off. The reference marker for phase noise measurements is either a normal marker or a fixed reference.
Page 747 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:MARKer<m>:FUNCtion:PNOise[:STATe] <State> This command turns the phase noise measurement at the marker position on and off in the Analog Demodulation application. Suffix: <n> Window <m> Marker Parameters: <State> ON | OFF | 1 | 0...
Page 748 <n> Window <m> Marker Parameters: <Span> Frequency. The maximum span depends on the marker position and R&S FPL1000 model. *RST: 5% of current span Default unit: Hz Example: CALC:MARK:FUNC:BPOW:SPAN 2MHz Measures the band power over 2 MHz around the marker.
Page 749 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: CALC:MARK4:FUNC:BPOW:STAT ON Activates or turns marker 4 into a band power marker. Manual operation: " Band Power Measurement State " on page 450 " Switching All Band Power Measurements Off "...
Page 750 Suffix: <n> Window <m> Marker Parameters: <Span> Frequency. The maximum span depends on the marker position and R&S FPL1000 model. *RST: 5% of current span Default unit: Hz Manual operation: " Span " on page 450 CALCulate<n>:DELTamarker<m>:FUNCtion:BPOWer[:STATe] <State> This command turns delta markers for band power measurements on and off.
Page 751 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:MARKer<m>:FUNCtion:NDBDown <Distance> This command defines the distance of the n dB down markers to the reference marker. Suffix: <n> Window <m> Marker Parameters: <Distance> Distance of the temporary markers to the reference marker in For a positive offset, the markers T1 and T2 are placed below the active reference point.
Page 752 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: INIT:CONT OFF Switches to single sweep mode. CALC:MARK:FUNC:NDBD ON Switches on the n dB down function. INIT;*WAI Starts a sweep and waits for the end. CALC:MARK:FUNC:NDBD:FREQ? This command would return, for example, 100000000,...
Page 753 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: INIT:CONT OFF Switches to single sweep mode. CALC:MARK:FUNC:NDBD ON Switches on the n dB down function. INIT;*WAI Starts a sweep and waits for the end. CALC:MARK:FUNC:NDBD:RES? Outputs the measured value.
Page 754 This command turns the frequency counter at the marker position on and off. The frequency counter works for one marker only. If you perform a frequency count with another marker, the R&S FPL1000 deactivates the frequency count of the first marker.
Page 755 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Signal Count Marker State " on page 439 CALCulate<n>:MARKer<m>:COUNt:FREQuency? This command queries the frequency at the marker position. To get a valid result, you have to perform a complete measurement with synchroniza- tion to the end of the measurement before reading out the result.
Page 756 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters 8.8.8.14 Marker Demodulation The following commands control the demodulation of AM and FM signals at the marker position. Useful commands for marker demodulation described elsewhere: ● on page 684 SYSTem:SPEaker[:STATe] ●...
Page 757 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: CALC:MARK:FUNC:DEM:HOLD 3s Manual operation: " Marker Stop Time " on page 452 CALCulate<n>:MARKer<m>:FUNCtion:DEModulation:SELect <DemodMode> This command selects the demodulation mode at the marker position. Suffix: <n> Window <m>...
Page 758 [SENSe:]DEMod:SQUelch[:STATe] <State> This command turns selective demodulation at the marker position on and off. For selective demodulation, the R&S FPL1000 turns on a video trigger whose level correponds to the squelch level. Therefore it turns other triggers or gates off.
Page 759 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters DISP:MTAB ON //Marker information is always displayed in a separate table. CALC:MARK:X:SSIZ STAN //The marker moves from one pixel to the next instead of sweep points in manual op.
Page 760 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALC:DELT6:Y? //Retrieves the marker levels of each active normal and delta marker. CALC:DELT5:X:REL? CALC:DELT6:X:REL? //Retrieves the frequency difference between the delta marker and marker 1. //--------------Deactivating all markers ---------------------...
Page 761 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Basic Frequency Sweep Measurement for Marker Function Examples Since markers can only be placed on an existing trace, the following example provides a simple frequency sweep measurement to be used as a basis for the subsequent marker function scripts.
Page 762 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters on page 761 has been performed and thus does not begin by presetting the instru- ment. In this example, the peak search is restricted to the frequency range of 50 MHz to 150 MHz.
Page 763 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters ples" on page 761 has been performed and thus does not begin by presetting the instrument. //------------- Configuring the phase noise marker ------------------- DET SAMP //Switches to Sample detector...
Page 764 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALC:MARK1:FUNC:BPOW:STAT ON //Activates the band power measurement for the band around marker 1 CALC:MARK1:FUNC:BPOW:SPAN 30MHz //Sets the bandwidth to be measured to 30 MHz CALC:MARK1:FUNC:BPOW:MODE DENS //Sets the result to be a density (power per Hz bandwidth)
Page 765 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters //Returns the bandwidth at the specified power offset. CALC:MARK:FUNC:NDBD:FREQ? //Returns the frequencies of the temporary markers at the power offsets CALC:MARK:FUNC:NDBD:QFAC? //Returns the quality factor of the resulting bandwidth...
Page 766 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Basic Frequency Sweep", on page 629 has been performed and thus does not begin by presetting the instrument. //------------- Configuring the marker demodulation ------------------- CALC:MARK1 ON //Activates marker1 CALC:MARK1:FUNC:DEM:SEL FM...
Page 767 Parameters: <Position> The value range is variable. You can use any unit you want, the R&S FPL1000 then converts the unit to the currently selected unit. If you omit a unit, the R&S FPL1000 uses the currently selected unit. *RST:...
Page 768 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: CALC:DLIN2:STAT ON Turns on display line 2. CALCulate<n>:FLINe<k> <Frequency> This command defines the position of a frequency line. Suffix: <n> Window <k> Limit line Parameters: <Frequency> Note that you can not set a frequency line to a position that is outside the current span.
Page 769 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: CALC:TLIN 10ms Sets the first time line to 10 ms. Manual operation: " Vertical Line 1 / Vertical Line 2 " on page 490 CALCulate<n>:TLINe<k>:STATe <State> This command turns a time line on and off Suffix: <n>...
Page 770 Note that the number of horizontal values has to be the same as the number of vertical values set with CALCulate<n>: LIMit<k>:LOWer[:DATA] CALCulate<n>:LIMit<k>: UPPer[:DATA]. If not, the R&S FPL1000 either adds missing values or ignores surplus values. The unit is Hz or s. *RST: Manual operation: "...
Page 771 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Type> FREQuency | TIME FREQuency For limit lines that apply to a range of frequencies. TIME For limit lines that apply to a period of time. *RST: FREQuency...
Page 772 Note that the number of vertical values has to be the same as the number of horizontal values set with CALCulate<n>: LIMit<k>:CONTrol[:DATA]. If not, the R&S FPL1000 either adds missing values or ignores surplus values. The unit depends on CALCulate<n>:LIMit<k>:UNIT on page 775.
Page 773 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Data Points " on page 500 CALCulate<n>:LIMit<k>:LOWer:MARGin <Margin> This command defines an area around a lower limit line where limit check violations are still tolerated. Suffix: <n>...
Page 774 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Parameters: <Offset> Numeric value. *RST: Default unit: dB Manual operation: " Y-Offset " on page 498 CALCulate<n>:LIMit<k>:LOWer:SHIFt <Distance> This command moves a complete lower limit line vertically. Compared to defining an offset, this command actually changes the limit line definition points by the value you define.
Page 775 Manual operation: " Visibility " on page 497 CALCulate<n>:LIMit<k>:LOWer:THReshold <Threshold> This command defines a threshold for relative limit lines. The R&S FPL1000 uses the threshold for the limit check, if the limit line violates the threshold. Suffix: <n> irrelevant <k>...
Page 776 Note that the number of vertical values has to be the same as the number of horizontal values set with CALCulate<n>: LIMit<k>:CONTrol[:DATA]. If not, the R&S FPL1000 either adds missing values or ignores surplus values. The unit depends on CALCulate<n>:LIMit<k>:UNIT on page 775.
Page 777 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Suffix: <n> Window <k> Limit line Parameters: <Mode> ABSolute Limit line is defined by absolute physical values. The unit is variable. RELative Limit line is defined by relative values related to the reference level (dB).
Page 778 " Visibility " on page 497 CALCulate<n>:LIMit<k>:UPPer:THReshold <Limit> This command defines an absolute limit for limit lines with a relative scale. The R&S FPL1000 uses the threshold for the limit check, if the limit line violates the threshold. Suffix: <n>...
Page 779 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Managing Limit Lines Useful commands for managing limit lines described in the R&S FPL1000 User Man- ual: ● MMEM:SEL[:ITEM]:LIN:ALL ● MMEM:STOR:TYPE Remote commands exclusive to managing limit lines: ..................779 CALCulate<n>:LIMit<k>:ACTive?
Page 780 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Manual operation: " Copy Line " on page 498 CALCulate<n>:LIMit<k>:DELete This command deletes a limit line. Suffix: <n> Window <k> Limit line Usage: Event Manual operation: " Delete Line "...
Page 781 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters Example: CALC:LIM3:TRAC2:CHEC ON Switches on the limit check for limit line 3 on trace 2. Manual operation: " Traces to be Checked " on page 497 MMEMory:LOAD<n>:LIMit <FileName> Loads the limit line from the selected file in .CSV format.
Page 782 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters CALCulate<n>:LIMit<k>:FAIL? This command queries the result of a limit check in the specified window. Note that for SEM measurements, the limit line suffix <k> is irrelevant, as only one spe- cific SEM limit line is checked for the currently relevant power class.
Page 783 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters //Selects an absolute vertical scale for limit line 1. CALC:LIM1:UNIT DBM //Selects the unit dBm for limit line 1. CALC:LIM1:UPP -10,-5,0,-5,-10 //Defines 5 definition points for limit line 1.
Page 784 ® Remote Commands R&S FPL1000 Setting Basic Spectrum RF Measurement Parameters //--------------Preparing the instrument --------------------- *RST //Resets the instrument INIT:CONT OFF //Selects single sweep mode. //--------------Configuring the measurement ------------- FREQ:CENT 100MHz //Defines the center frequency FREQ:SPAN 200MHz //Sets the span to 100 MHz on either side of the center frequency.
Page 785: Managing Settings And Results
® Remote Commands R&S FPL1000 Managing Settings and Results //-------------- Retrieving limit check results---------------------------- CALC:LIM1:FAIL? //Queries the result of the upper limit line check CALC:LIM3:FAIL? //Queries the result of the lower limit line check 8.9 Managing Settings and Results The commands required to store and load instrument settings and import and export measurement results in a remote environment are described here.
Page 786: Remote Command: Mmemory:catalog
® Remote Commands R&S FPL1000 Managing Settings and Results See also: ● on page 702 FORMat[:DATA] ..................786 FORMat:DEXPort:DSEParator ...................... 786 MMEMory:CATalog? .................... 787 MMEMory:CATalog:LONG? ....................788 MMEMory:CDIRectory ......................788 MMEMory:COMMent ......................788 MMEMory:COPY ......................788 MMEMory:DATA ......................789 MMEMory:DELete ....................789 MMEMory:MDIRectory ......................
Page 787 ® Remote Commands R&S FPL1000 Managing Settings and Results Query parameters: <Path> String containing the path and directory If you leave out the path, the command returns the contents of the directory selected with MMEMory:CDIRectory. The path may be relative or absolute. Using wildcards ('*') is possible to query a certain type of files only.
Page 788 ® Remote Commands R&S FPL1000 Managing Settings and Results <FileInfo> <NameFileN>,<SuffixFileN>,<SizeFileN> Describes the individual file. <NameFileN> Name of the file. <SuffixFileN> Type of the file. Possible suffixes are: ASCii, BINary, DIRectory, STAT <SizeFileN> Size of the file in bytes. Usage: Query only MMEMory:CDIRectory <Directory>...
Page 789 ® Remote Commands R&S FPL1000 Managing Settings and Results When you query the contents of a file, you can save them in a file on the remote con- trol computer. The command is useful for reading stored settings files or trace data from the instru-...
Page 790 ® Remote Commands R&S FPL1000 Managing Settings and Results The command also renames the file if you define a new name in the target directory. If you do not include a path for <NewFileName>, the command just renames the file.
Page 791 ® Remote Commands R&S FPL1000 Managing Settings and Results Usage: Event MMEMory:NETWork:MAP <Drive>, <HostName> [, <UserName>, <Password>][, <Reconnect>] This command maps a drive to a server or server directory of the network. Note that you have to allow sharing for a server or folder in Microsoft networks first.
Page 792 ® Remote Commands R&S FPL1000 Managing Settings and Results Parameters: <State> You do not have to use the parameter. If you do not include the parameter, the command returns a list of all drives in use. This is the same behavior as if you were using the parameter OFF.
Page 793 ® Remote Commands R&S FPL1000 Managing Settings and Results MMEMory:SELect:CHANnel[:ITEM]:ALL MMEMory:SELect[:ITEM]:ALL This command includes all items when storing or loading a configuration file. The items are: ● Hardware configuration: MMEMory:SELect[:ITEM]:HWSettings ● Limit lines: MMEMory:SELect[:ITEM]:LINes:ALL ● Spectrogram data: MMEMory:SELect[:ITEM]:SGRam ● Trace data: MMEMory:SELect[:ITEM]:TRACe[:ACTive] ●...
Page 794 ® Remote Commands R&S FPL1000 Managing Settings and Results Manual operation: " Items: " on page 105 MMEMory:SELect:CHANnel[:ITEM]:LINes:ALL <State> MMEMory:SELect[:ITEM]:LINes:ALL <State> This command includes or excludes all limit lines (active and inactive) when storing or loading a configuration file. Parameters: <State>...
Page 795 ® Remote Commands R&S FPL1000 Managing Settings and Results MMEMory:SELect:CHANnel[:ITEM]:TRACe[:ACTive] <State> MMEMory:SELect[:ITEM]:TRACe[:ACTive] <State> This command includes or excludes trace data when storing or loading a configuration file. Parameters: <State> ON | OFF | 1 | 0 *RST: 0, i.e. no traces are stored...
Page 796 MMEMory:LOAD:AUTO 1, 'Factory' | <FileName> This command restores an instrument configuration and defines that configuration as the default state. The default state is restored after a preset (*RST) or after you turn on the R&S FPL1000. Parameters: 'Factory' | 'Factory' <FileName>...
Page 797 The string may or may not include the file's extension. Example: MMEM:SEL:ALL //Save all items (User Settings, All Traces, All Limit Lines) from the R&S FPL1000. MMEM:LOAD:STAT 1,'C: \Users\Public\Documents\Rohde-Schwarz\Analyzer\user\TEST01' //Reloads all items In the "Recall" dialog, select only "User Settings" and "All Limit Lines".
Page 798 ® Remote Commands R&S FPL1000 Managing Settings and Results <FileName> String containing the path and name of the target file. The file extension is .dfl. Example: MMEM:STOR:STAT 1,'Save' Saves the current instrument settings in the file Save.dfl. Usage: Event Manual operation: "...
Page 799 ® Remote Commands R&S FPL1000 Managing Settings and Results SYSTem:PRESet This command presets the R&S FPL1000. Example: SYST:PRES Usage: Event SYSTem:PRESet:CHANnel[:EXEC] This command restores the default instrument settings in the current channel setup. Use INST:SEL to select the channel setup.
Page 800 ® Remote Commands R&S FPL1000 Managing Settings and Results ................806 HCOPy:PAGE:MARGin<device>:UNIT ................807 HCOPy:PAGE:ORIentation<device> ............807 HCOPy:PAGE:WINDow<device>:CHANnel:STATe ................. 808 HCOPy:PAGE:WINDow<device>:COUNt ................. 808 HCOPy:PAGE:WINDow<device>:SCALe ................808 HCOPy:PAGE:WINDow<device>:STATe ................. 809 HCOPy:TDSTamp:STATe<device> ............809 SYSTem:COMMunicate:PRINter:ENUMerate:FIRSt? ............810 SYSTem:COMMunicate:PRINter:ENUMerate[:NEXT]? .............810 SYSTem:COMMunicate:PRINter:SELect<device> DISPlay:LOGO <State> Activates/deactivates the printout of the Rohde & Schwarz company logo at the top of each page.
Page 801 ® Remote Commands R&S FPL1000 Managing Settings and Results Parameters: <ContType> WINDows | HCOPy WINDows Includes only the selected windows in the printout. All currently active windows for the current channel setup (or "MultiView") are available for selection. How many windows are printed on a...
Page 802 ® Remote Commands R&S FPL1000 Managing Settings and Results <colors> 1...4 Current colors with a white background and a black grid. Optimized colors. Current screen colors (setting for hardcopies). Example: HCOP:CMAP:DEF2 Selects the optimized color set for the color settings of a printout or a hardcopy.
Page 803 ® Remote Commands R&S FPL1000 Managing Settings and Results HCOPy:DESTination<device> <Destination> This command selects the destination of a print job. Suffix: <device> 1 | 2 Irrelevant. Parameters: <Destination> 'MMEM' Sends the hardcopy to a file. You can select the file name with MMEMory:NAME.
Page 804 ® Remote Commands R&S FPL1000 Managing Settings and Results Parameters: <Format> Graphics Device Interface Default format for output to a printer configured under Windows. Must be selected for output to the printer interface. Can be used for output to a file. The printer driver configured under Windows is used to generate a printer-specific file format.
Page 805 ® Remote Commands R&S FPL1000 Managing Settings and Results HCOPy:PAGE:COUNt:STATe <State> This command includes or excludes the page number for printouts consisting of multi- ple pages (HCOP:CONT WIND). Parameters: <State> 1 | 0 | ON | OFF 1 | ON The page number is printed.
Page 806 ® Remote Commands R&S FPL1000 Managing Settings and Results HCOPy:PAGE:MARGin<device>:RIGHt <Margin> This command defines the margin at the right side of the printout page on which no elements are printed. The margins are defined according to HCOPy:PAGE: on page 806.
Page 807 ® Remote Commands R&S FPL1000 Managing Settings and Results Example: HCOP:PAGE:MARG2:BOTT 2 Manual operation: " Margins " on page 119 HCOPy:PAGE:ORIentation<device> <Orientation> The command selects the page orientation of the printout. The command is only available if the output device is a printer or a PDF file.
Page 808 ® Remote Commands R&S FPL1000 Managing Settings and Results HCOPy:PAGE:WINDow<device>:COUNt <WinPerPage> This command defines how many windows are displayed on a single page of the print- out for HCOP:CONT WIND. Suffix: <device> 1 | 2 Irrelevant. Parameters: <WinPerPage> integer *RST:...
Page 809 ® Remote Commands R&S FPL1000 Managing Settings and Results Suffix: <device> 1 | 2 Irrelevant. Parameters: <ChannelName> String containing the name of the channel setup. For a list of available channel setup types use INSTrument: on page 528. LIST? <WindowName>...
Page 810 Usage: Query only Manual operation: " Printer Name " on page 117 SYSTem:COMMunicate:PRINter:SELect<device> <PrinterName> This command selects the printer that processes jobs sent by the R&S FPL1000. to select another output destination. HCOPy:DESTination<device> Suffix: <device> 1 | 2 Irrelevant.
Page 811 ® Remote Commands R&S FPL1000 Managing Settings and Results Useful commands for storing results described elsewhere: ● on page 702 FORMat[:DATA] Remote commands exclusive to storing results: ....................811 FORMat:DEXPort:HEADer ..................... 811 FORMat:DEXPort:TRACes .................... 812 MMEMory:STORe<n>:LIST ...................812 MMEMory:STORe<n>:PEAK ..................812 MMEMory:STORe<n>:SGRam ................812 MMEMory:STORe<n>:SPECtrogram...
Page 812 ® Remote Commands R&S FPL1000 Managing Settings and Results MMEMory:STORe<n>:LIST <FileName> This command exports the SEM and spurious emission list evaluation to a file. The file format is *.dat. Suffix: <n> Window Parameters: <FileName> String containing the path and name of the target file.
Page 813 ® Remote Commands R&S FPL1000 Managing Settings and Results Manual operation: " Export Trace to ASCII File " on page 110 MMEMory:STORe<n>:SPURious <FileName> This command exports the marker peak list available for spurious emission measure- ments to a file. Suffix: <n>...
Page 814 ® Remote Commands R&S FPL1000 Managing Settings and Results 8.9.6.1 Storing Data MMEM:MSIS 'C:' //Selects drive C: as the default storage device. //-----Connecting a network drive-------- MMEM:NETW:USED? //Returns a list of all drives in use in the network. MMEM:NETW:UNUS? //Returns a list of free drive names in the network.
Page 815: Configuring The R&S Fpl1000
//to a new channel. The new channel is named 'Spectrum2' to avoid a naming conflict //with the existing 'Spectrum' channel. INST:REN 'Spectrum2','Spectrum3' //Renames the loaded channel to 'Spectrum3'. 8.10 Configuring the R&S FPL1000 The remote commands required to set up the R&S FPL1000 are described here. ● Configuring the Reference Frequency..............816 ●...
Page 816 Sets the frequency to 13 MHz. SOUR:EXT:ROSC:EXT:FREQ 13MHZ [SENSe:]ROSCillator:SOURce <Source> This command selects the reference oscillator. If you want to select the external reference, it must be connected to the R&S FPL1000. Parameters: <Source> INTernal The internal reference is used (10 MHz)
Page 817 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 8.10.2 Calibration and Checks The following commands control calibration and checks on the R&S FPL1000......................817 CALibration[:ALL]? .......................817 CALibration:RESult? ............818 DIAGnostic:SERVice:INPut:PULSed:CFRequency ..............818 DIAGnostic:SERVice:INPut:RF[:SPECtrum] ................818 DIAGnostic:SERVice:INPut[:SELect] ................819 DIAGnostic:SERVice:STESt:RESult? ................. 819...
Page 818 <Frequency> Possible frequencies of the calibration signal are fix. If you define a frequency that is not available, the R&S FPL1000 uses the next available frequency. Example: a frequency of 20 MHz is rounded up to the next available frequency (25 MHz).
Page 819 Usage: Query only SOURce:TEMPerature:FRONtend? This command queries the current frontend temperature of the R&S FPL1000. During self-alignment, the instrument's (frontend) temperature is also measured (as soon as the instrument has warmed up completely). This temperature is used as a ref- erence for a continuous temperature check during operation.
Page 820 " Adjust Ref Level " on page 151 [SENSe:]CORRection:TRANsducer:CATalog? This command queries all transducer factors stored on the R&S FPL1000. After general data for the transducer storage directory, data for the individual files is lis- ted. The result is a comma-separated list of values with the following syntax: <UsedMem>,<FreeMem>,<FileSize>,<FileName>[,<FileSize>,<FileName>]...
Page 821 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Before you can use the command, you have to select and turn on a transducer. Parameters: <Comment> *RST: (empty comment) Manual operation: " Comment " on page 152 [SENSe:]CORRection:TRANsducer:DATA <Frequency>,<Level>[,<Frequency>,<Level>] This command configures transducer factors for specific trace points. A set of trans- ducer factors defines an interpolated transducer line and can be stored on the instru- ment.
Page 822 [SENSe:]CORRection:TRANsducer:SELect <Name> This command selects a transducer factor. Parameters: <Name> String containing the name of the transducer factor. If the name does not exist yet, the R&S FPL1000 creates a transducer factor by that name. Example: CORR:TRAN:SEL 'FACTOR1' Manual operation: "...
Page 823 Stores the transducer factor named "Transducer1" in the file TEST.CSV. Manual operation: " Export " on page 154 8.10.4 Customizing the Screen Layout The remote commands required to set up the display of the R&S FPL1000 are descri- bed here. ● General Display Settings and Items..............824 ●...
Page 824 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 8.10.4.1 General Display Settings and Items The following commands add, remove or customize general display and screen ele- ments. Useful commands for general display settings described elsewhere ● on page 714 DISPlay[:WINDow<n>]:MTABle...
Page 825 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Parameters: <State> ON | OFF | 0 | 1 *RST: Example: DISP:ANN:FREQ OFF Manual operation: " Diagram Footer (Annotation) " on page 129 DISPlay:SBAR[:STATe] <State> This command turns the status bar on and off.
Page 826 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Parameters: <State> ON | 1 Touch screen is active for entire screen OFF | 0 Touch screen is inactivate for entire screen FRAMe Touch screen is inactivate for the diagram area of the screen, but active for softkeys, toolbars and menus.
Page 827 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Parameters: <State> ON | OFF | 0 | 1 *RST: Manual operation: " Front Panel " on page 130 " Mini Front Panel " on page 130 8.10.4.2 Colors and Themes...
Page 828 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Suffix: <item> Selects the item for which the color scheme is to be defined. Parameters: <hue> tint Range: 0 to 1 <sat> saturation Range: 0 to 1 <lum> brightness Range: 0 to 1 Example: DISP:CMAP2:HSL 0.3,0.8,1.0...
Page 829 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 8.10.4.3 CMAP Suffix Assignment Several commands to change the color settings of individual items of the display or printout are available. Which item is to be configured is defined using a <CMAP> suffix.
Page 830 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Suffix Description CMAP30 Limit and Margin Check – Text CMAP31 Limit and Margin Check – \"Margin\" CMAP32 *) Table Overall – Title Text CMAP33 *) Table Overall – Title Background CMAP34 *) Table Overall –...
Page 831 ....................833 SYSTem:LXI:LANReset .....................834 SYSTem:LXI:MDEScription ....................834 SYSTem:LXI:PASSword ................... 834 SYSTem:REVision:FACTory SYSTem:COMMunicate:GPIB[:SELF]:ADDRess <Address> This command sets the GPIB address of the R&S FPL1000. Parameters: <Address> Range: 0 to 30 *RST: (no influence on this parameter, factory default 20) Example: SYST:COMM:GPIB:ADDR 18 Manual operation: "GPIB Address"...
Page 832 This command the error display during remote operation on and off. If activated, the R&S FPL1000 displays a message box at the bottom of the screen that contains the most recent type of error and the command that caused the error.
Page 833 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Parameters: <State> LLO (local lockout) GTL (go to local) *RST: Example: SYST:KLOK ON Activates LLO (remote control) Manual operation: "Local" on page 208 SYSTem:LANGuage <Language> This function is used to emulate previous R&S signal and spectrum analyzers.
Page 834 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 Manual operation: "LAN Reset" on page 206 SYSTem:LXI:MDEScription <Description> This command defines the LXI instrument description. Parameters: <Description> String containing the instrument description. Manual operation: "LXI Manufacturer Description" on page 206 SYSTem:LXI:PASSword <Password>...
Page 835 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 DIAGnostic:INFO:CCOunt? <Relay> This command queries how many switching cycles the individual relays have per- formed since they were installed. Query parameters: <Relay> ACDC Mechanical Attenuation Coupling ATT5 Mechanical Attenuation 05 DB...
Page 836 This command deletes all contents of the "System Messages" table. Example: SYST:ERR:CLE:ALL Usage: Event SYSTem:ERRor:CLEar:REMote This command deletes all contents of the "Remote Errors" table. Note: The remote error list is automatically cleared when the R&S FPL1000 is shut down. Example: SYST:ERR:CLE:REM Usage: Event Manual operation: "Display Remote Errors"...
Page 837 Queries fatal errors in the 'Spectrum2' application. If none have occurred, the result is: " ". Usage: Query only SYSTem:ERRor:LIST? [<MessType>] This command queries the error messages that occur during R&S FPL1000 operation. Query parameters: <MessType> SMSG (default) Queries the system messages which occurred during manual operation.
Page 838 ® Remote Commands R&S FPL1000 Configuring the R&S FPL1000 <RemoteErrors> <Error_no> | <Description> | <Command> | <Date> | <Time> Comma-separated list of errors from the "Remote Errors" table, where: <Error_no>: device-specific error code <Description>: brief description of the error <Command>: remote command causing the error <Date>|<Time>: date and time the error occurred...
Page 839 SYST:FORM:IDEN LEG Adapts the return value of *IDN? to the R&S FSP/FSU/FSQ fam- ily. SYSTem:PRESet:COMPatible <OpMode> This command defines the operating mode that is activated when you switch on the R&S FPL1000 or press the PRESET key. Parameters: <OpMode> SANalyzer (Default:) Defines Signal and Spectrum Analyzer operating mode as the presetting.
Page 840: Using The Status Register
® Remote Commands R&S FPL1000 Using the Status Register Usage: Query only DIAGnostic:SERVice:SFUNction:RESults:DELete This command deletes the results of the most recent service function you have used. Usage: Event Manual operation: " Clear Results " on page 146 DIAGnostic:SERVice:SFUNction:RESults:SAVE <FileName>...
Page 841 ® Remote Commands R&S FPL1000 Using the Status Register ● "STATus:OPERation Register" on page 188 ● "STATus:QUEStionable:ACPLimit Register" on page 190 ● "STATus:QUEStionable:EXTended Register" on page 191 ● "STATus:QUEStionable:FREQuency Register" on page 192 ● "STATus:QUEStionable:LIMit Register" on page 193 ●...
Page 842 ® Remote Commands R&S FPL1000 Using the Status Register 8.11.2 Reading Out the CONDition Part For more information on the condition part see "Structure of a SCPI Status Register" on page 184. STATus:OPERation:CONDition? STATus:QUEStionable:CONDition? STATus:QUEStionable:ACPLimit:CONDition? <ChannelName> STATus:QUEStionable:EXTended:CONDition? <ChannelName> STATus:QUEStionable:EXTended:INFO:CONDition? <ChannelName>...
Page 843 ® Remote Commands R&S FPL1000 Using the Status Register Query parameters: <ChannelName> String containing the name of the channel. The parameter is optional. If you omit it, the command works for the currently active channel. Usage: Query only 8.11.4 Controlling the ENABle Part For more information on the enable part see "Structure of a SCPI Status Register"...
Page 844 ® Remote Commands R&S FPL1000 Using the Status Register STATus:QUEStionable:LIMit<n>:NTRansition <SumBit>,<ChannelName> STATus:QUEStionable:LMARgin<n>:NTRansition <SumBit>,<ChannelName> STATus:QUEStionable:POWer:NTRansition <SumBit>,<ChannelName> STATus:QUEStionable:TIME:NTRansition <SumBit>,<ChannelName> These commands control the Negative TRansition part of a register. Setting a bit causes a 1 to 0 transition in the corresponding bit of the associated regis- ter.
Page 845 ® Remote Commands R&S FPL1000 Using the Status Register 8.11.7 Service Request The service request routine requires an extended initialization of the instrument in which the relevant bits of the transition and enable registers are set. In addition the ser- vice request event must be enabled in the VISA session.
Page 846 ® Remote Commands R&S FPL1000 Using the Status Register 'For example on TCP use TCPIP0::192.168.1.2::inst0::INSTR mbSession = CType(ResourceManager.GetLocalManager().Open("FSW"), _ MessageBasedSession) mbSession.TerminationCharacterEnabled = True mbSession.Write("*CLS") 'Reset status reporting system mbSession.Write("*SRE 168") 'Enable service request for 'STAT:OPER, STAT:QUES and ESR register mbSession.Write("*ESE 60") 'Set event enable bit for 'command, execution, device-dependent and query error mbSession.Write("STAT:OPER:ENAB 32767")
Page 847 ® Remote Commands R&S FPL1000 Using the Status Register Console.ReadKey() End Sub 8.11.7.2 Waiting for the Arrival of a Service Request There are basically two methods of waiting for the arrival of a service request: Blocking (user inputs not possible):...
Page 848 ® Remote Commands R&S FPL1000 Using the Status Register The method necessitates a waiting loop that checks the status of the SRQ line at regu- lar intervals and returns control to the operating system during the time the expected event has not yet occurred. In this way, the system can respond to user inputs (mouse clicks, key entries) during the waiting time.
Page 849 ® Remote Commands R&S FPL1000 Using the Status Register Public Sub Hold(delayTime As Single) Start = Timer 'Save timer count on calling the 'function Do While Timer < Start + delayTime/1000 'Check timer count DoEvents 'Return control to operating 'system to enable control of...
Page 850 ® Remote Commands R&S FPL1000 Using the Status Register If (mySTB And 8) > 0 Then Call Questionablestatus() If (mySTB And 128) > 0 Then Call Operationstatus() If (mySTB And 32) > 0 Then Call Esrread() End If Catch exp As Exception Console.WriteLine(exp.Message)
Page 851 ® Remote Commands R&S FPL1000 Using the Status Register Dim parts As String() = result.Split(",") If parts(0) = 0 Then hasErr = False Console.WriteLine(result) Else Console.WriteLine(result) End If Loop While hasErr End Sub 8.11.7.7 Evaluation of SCPI Status Registers REM ------ Subroutine for evaluating Questionable Status Register ---------...
Page 852 ® Remote Commands R&S FPL1000 Using the Status Register Console.WriteLine(exp.Message) End Try End Sub 8.11.7.8 Evaluation of Event Status Register REM ------ Subroutine for evaluating the Event Status Register ------------ Public SUB Esrread() Esr$ = SPACE$(20) 'Preallocate blanks to text 'variable CALL InstrWrite (analyzer, "*ESR?") 'Read ESR...
Page 853: Deprecated Commands
® Remote Commands R&S FPL1000 Deprecated Commands End Try End Sub 8.12 Deprecated Commands The following commands are provided for compatibility to other signal analyzers only. For new remote control programs use the specified alternative commands..................853 CALCulate<n>:LIMit<k>:TRACe ..................853 DISPlay[:WINDow<n>]:STATe...
Page 854 ® Remote Commands R&S FPL1000 Deprecated Commands DISPlay[:WINDow<n>]:TYPE <WindowType> This command selects the results displayed in a measurement window. Note that this command is maintained for compatibility reasons only. Use the LAYout commands for new remote control programs (see Chapter 8.7.1, "Working with Win- dows in the Display",...
Page 855: Maintenance
9 Maintenance The R&S FPL1000 does not require regular maintenance. Maintenance is essentially restricted to cleaning the R&S FPL1000. It is, however, recommended that you check the nominal data from time to time. The data sheet specifies the storage temperature range for the R&S FPL1000. Protect the instrument against dust if it is to be stored for a long period.
Page 856 ® Maintenance R&S FPL1000 Cleaning c) If necessary, remove any excess moisture with a dry, soft cloth. User Manual 1178.3370.02 ─ 03...
Page 857: Troubleshooting
® Troubleshooting R&S FPL1000 Error Information 10 Troubleshooting If the results do not meet your expectations, the following sections may contain helpful hints and information. ● Error Information....................857 ● Error Messages in Remote Control Mode.............858 ● Troubleshooting Remote Operation..............859 ●...
Page 858: Error Messages In Remote Control Mode
In remote control mode error messages are entered in the error/event queue of the sta- tus reporting system and can be queried with the command SYSTem:ERRor?. The answer format of R&S FPL1000 to the command is as follows: <error code>, "<error text with queue query>; <remote control command concerned>"...
Page 859: Troubleshooting Remote Operation
R&S FPL1000 is blocked for further commands. In this case, you must interrupt processing on the remote channel in order to abort the measurement.
Page 860: Miscellaneous Troubleshooting Hints
Power levels for low frequency signals not correct By default, the R&S FPL1000 uses AC coupling for RF input. For very low frequencies, the input signal may be distorted with this setting. In this case, use DC coupling instead. To change the setting, select INPUT/OUPUT > "Input Source Config" > "Radio Frequency"...
Page 861 654 [SENSe:]SWEep:DURation? Multiple user access to one instrument Using the R&S FPL1000's LXI browser interface, several users can access and oper- ate the same instrument simultaneously. This is useful for troubleshooting or training purposes. Type the instrument's host name or IP address in the address field of the browser on your PC, for example "http://10.113.10.203".
Page 862: Collecting Information For Technical Support
In addition, our customer support centers are there to assist you in solving any prob- lems that you may encounter with your R&S FPL1000. We will find solutions more quickly and efficiently if you provide us with the information listed below.
Page 863 ® Troubleshooting R&S FPL1000 Collecting Information for Technical Support The file is stored as C:\ProgramData\Rohde-Schwarz\ZNL-FPL\user\ <inst_model>_<serial-no>_<date_and_time>.zip For example C:\ProgramData\Rohde-Schwarz\ZNL-FPL\user\ FPL1003__20160803_145113.zip Collect the error information and attach it to an email in which you describe the problem. Send the email to the customer support address for your region as listed on the Internet (http://www.customersupport.rohde-schwarz.com).
Page 864: List Of Commands (Spectrum Mode)
® List of Commands (Spectrum mode) R&S FPL1000 List of Commands (Spectrum mode) [SENSe:][WINDow<n>:]DETector<t>[:FUNCtion]..................692 [SENSe:][WINDow<n>:]DETector<t>[:FUNCtion]:AUTO................692 [SENSe:]ADJust:ALL............................. 646 [SENSe:]ADJust:CONFigure:HYSTeresis:LOWer..................647 [SENSe:]ADJust:CONFigure:HYSTeresis:UPPer..................647 [SENSe:]ADJust:CONFigure:TRIGger......................647 [SENSe:]ADJust:CONFigure[:LEVel]:DURation.................... 646 [SENSe:]ADJust:CONFigure[:LEVel]:DURation:MODE................646 [SENSe:]ADJust:FREQuency........................648 [SENSe:]ADJust:LEVel..........................648 [SENSe:]AVERage<n>:COUNt........................690 [SENSe:]AVERage<n>:TYPE........................691 [SENSe:]AVERage<n>[:STATe<t>].......................691 [SENSe:]BANDwidth:VIDeo...........................652 [SENSe:]BANDwidth:VIDeo:AUTO........................652 [SENSe:]BANDwidth:VIDeo:RATio........................652 [SENSe:]BANDwidth:VIDeo:TYPE........................ 652 [SENSe:]BANDwidth[:RESolution].........................650 [SENSe:]BANDwidth[:RESolution]:AUTO......................651 [SENSe:]BANDwidth[:RESolution]:RATio......................651 [SENSe:]BANDwidth[:RESolution]:TYPE...................... 651 [SENSe:]BWIDth:VIDeo..........................652...
Page 865 ® List of Commands (Spectrum mode) R&S FPL1000 [SENSe:]ESPectrum<sb>:RANGe<range>:BANDwidth:RESolution.............566 [SENSe:]ESPectrum<sb>:RANGe<range>:BANDwidth:VIDeo..............567 [SENSe:]ESPectrum<sb>:RANGe<range>:COUNt?..................567 [SENSe:]ESPectrum<sb>:RANGe<range>:DELete..................567 [SENSe:]ESPectrum<sb>:RANGe<range>:FILTer:TYPE................568 [SENSe:]ESPectrum<sb>:RANGe<range>:INPut:ATTenuation..............569 [SENSe:]ESPectrum<sb>:RANGe<range>:INPut:ATTenuation:AUTO............569 [SENSe:]ESPectrum<sb>:RANGe<range>:INPut:GAIN:STATe..............570 [SENSe:]ESPectrum<sb>:RANGe<range>:INSert..................570 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:ABSolute:STARt..........570 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:ABSolute:STOP..........571 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt..........572 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt:ABS........572 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STARt:FUNCtion.......573 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STOP..........573 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STOP:ABS........574 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:RELative:STOP:FUNCtion........575 [SENSe:]ESPectrum<sb>:RANGe<range>:LIMit<PClass>:STATe...............575 [SENSe:]ESPectrum<sb>:RANGe<range>:MLCalc..................576 [SENSe:]ESPectrum<sb>:RANGe<range>:POINts:MINimum[:VALue]............576 [SENSe:]ESPectrum<sb>:RANGe<range>:RLEVel..................577 [SENSe:]ESPectrum<sb>:RANGe<range>:SWEep:TIME................
Page 866 ® List of Commands (Spectrum mode) R&S FPL1000 [SENSe:]LIST:RANGe<range>:DETector......................593 [SENSe:]LIST:RANGe<range>:FILTer:TYPE....................593 [SENSe:]LIST:RANGe<range>:INPut:ATTenuation..................594 [SENSe:]LIST:RANGe<range>:INPut:ATTenuation:AUTO................595 [SENSe:]LIST:RANGe<range>:INPut:GAIN:STATe..................595 [SENSe:]LIST:RANGe<range>:INPut:GAIN[:VALue]..................595 [SENSe:]LIST:RANGe<range>:LIMit:STARt....................595 [SENSe:]LIST:RANGe<range>:LIMit:STATe....................596 [SENSe:]LIST:RANGe<range>:LIMit:STOP....................596 [SENSe:]LIST:RANGe<range>:POINts[:VALue]................... 596 [SENSe:]LIST:RANGe<range>:RLEVel......................596 [SENSe:]LIST:RANGe<range>:SWEep:TIME....................597 [SENSe:]LIST:RANGe<range>:SWEep:TIME:AUTO..................597 [SENSe:]LIST:RANGe<range>:TRANsducer....................597 [SENSe:]LIST:RANGe<range>[:FREQuency]:STARt..................593 [SENSe:]LIST:RANGe<range>[:FREQuency]:STOP..................594 [SENSe:]MPOWer:FTYPe..........................626 [SENSe:]MPOWer:RESult:MIN?........................628 [SENSe:]MPOWer:RESult[:LIST]?.........................627 [SENSe:]MPOWer[:SEQuence]........................627 [SENSe:]PMETer<p>:DCYCle:VALue......................675...
Page 867 ® List of Commands (Spectrum mode) R&S FPL1000 [SENSe:]POWer:ACHannel:FILTer[:STATe][:ALL]..................549 [SENSe:]POWer:ACHannel:MODE....................... 556 [SENSe:]POWer:ACHannel:NAME:ACHannel....................545 [SENSe:]POWer:ACHannel:NAME:ALTernate<ch>..................545 [SENSe:]POWer:ACHannel:NAME:CHANnel<ch>..................546 [SENSe:]POWer:ACHannel:PRESet......................541 [SENSe:]POWer:ACHannel:PRESet:RLEVel....................541 [SENSe:]POWer:ACHannel:REFerence:AUTO ONCE................. 549 [SENSe:]POWer:ACHannel:REFerence:TXCHannel:AUTO................. 550 [SENSe:]POWer:ACHannel:REFerence:TXCHannel:MANual..............550 [SENSe:]POWer:ACHannel:SPACing:ALTernate<ch>..................546 [SENSe:]POWer:ACHannel:SPACing:CHANnel<ch>................... 546 [SENSe:]POWer:ACHannel:SPACing[:ACHannel]..................546 [SENSe:]POWer:ACHannel:TXCHannel:COUNt...................547 [SENSe:]POWer:BANDwidth......................... 560 [SENSe:]POWer:BWIDth..........................560 [SENSe:]POWer:TRACe..........................541 [SENSe:]ROSCillator:SOURce........................816 [SENSe:]ROSCillator:SOURce:EAUTo?....................... 816 [SENSe:]SWEep:COUNt..........................
Page 868 ® List of Commands (Spectrum mode) R&S FPL1000 *WAI................................525 ABORt................................535 CALCulate<n>:DELTamarker<m>:AOFF...................... 709 CALCulate<n>:DELTamarker<m>:FUNCtion:BPOWer:MODE..............749 CALCulate<n>:DELTamarker<m>:FUNCtion:BPOWer:RESult?..............749 CALCulate<n>:DELTamarker<m>:FUNCtion:BPOWer:SPAN..............750 CALCulate<n>:DELTamarker<m>:FUNCtion:BPOWer[:STATe]..............750 CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:MAXimum[:PEAK]...........738 CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:X..............738 CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:Y..............739 CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed:RPOint:Y:OFFSet............739 CALCulate<n>:DELTamarker<m>:FUNCtion:FIXed[:STATe]............... 739 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:AUTO................745 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise:RESult?..............745 CALCulate<n>:DELTamarker<m>:FUNCtion:PNOise[:STATe]..............746 CALCulate<n>:DELTamarker<m>:LINK......................709 CALCulate<n>:DELTamarker<m>:LINK:TO:MARKer<m>................710 CALCulate<n>:DELTamarker<m>:MAXimum:LEFT..................723 CALCulate<n>:DELTamarker<m>:MAXimum:NEXT..................723 CALCulate<n>:DELTamarker<m>:MAXimum:RIGHt..................724 CALCulate<n>:DELTamarker<m>:MAXimum[:PEAK]...................724 CALCulate<n>:DELTamarker<m>:MINimum:LEFT..................724...
Page 869 ® List of Commands (Spectrum mode) R&S FPL1000 CALCulate<n>:DELTamarker<m>:SPECtrogram:Y:MINimum[:PEAK]............738 CALCulate<n>:DELTamarker<m>:TRACe....................711 CALCulate<n>:DELTamarker<m>:X......................712 CALCulate<n>:DELTamarker<m>:X:RELative?....................726 CALCulate<n>:DELTamarker<m>:Y?......................727 CALCulate<n>:DELTamarker<m>[:STATe]....................711 CALCulate<n>:DLINe<k>..........................767 CALCulate<n>:DLINe<k>:STATe........................767 CALCulate<n>:ESPectrum:PEAKsearch:AUTO....................585 CALCulate<n>:ESPectrum:PEAKsearch:DETails..................598 CALCulate<n>:ESPectrum:PEAKsearch:MARGin..................586 CALCulate<n>:ESPectrum:PEAKsearch:PSHow..................586 CALCulate<n>:ESPectrum:PEAKsearch[:IMMediate]................... 586 CALCulate<n>:ESPectrum:PSEarch:AUTO....................585 CALCulate<n>:ESPectrum:PSEarch:MARGin....................586 CALCulate<n>:ESPectrum:PSEarch:PSHow....................586 CALCulate<n>:ESPectrum:PSEarch[:IMMediate]..................586 CALCulate<n>:FLINe<k>..........................768 CALCulate<n>:FLINe<k>:STATe........................768 CALCulate<n>:LIMit<k>:ACPower:ACHannel:ABSolute................
Page 870 ® List of Commands (Spectrum mode) R&S FPL1000 CALCulate<n>:LIMit<k>:FAIL?........................782 CALCulate<n>:LIMit<k>:LOWer:MARGin......................773 CALCulate<n>:LIMit<k>:LOWer:MODE......................773 CALCulate<n>:LIMit<k>:LOWer:OFFSet.......................773 CALCulate<n>:LIMit<k>:LOWer:SHIFt......................774 CALCulate<n>:LIMit<k>:LOWer:SPACing.....................774 CALCulate<n>:LIMit<k>:LOWer:STATe......................774 CALCulate<n>:LIMit<k>:LOWer:THReshold....................775 CALCulate<n>:LIMit<k>:LOWer[:DATA]......................772 CALCulate<n>:LIMit<k>:NAME........................775 CALCulate<n>:LIMit<k>:STATe........................780 CALCulate<n>:LIMit<k>:TRACe........................853 CALCulate<n>:LIMit<k>:TRACe<t>:CHECk....................780 CALCulate<n>:LIMit<k>:UNIT........................775 CALCulate<n>:LIMit<k>:UPPer:MARGin...................... 776 CALCulate<n>:LIMit<k>:UPPer:MODE......................776 CALCulate<n>:LIMit<k>:UPPer:OFFSet....................... 777 CALCulate<n>:LIMit<k>:UPPer:SHIFt......................777 CALCulate<n>:LIMit<k>:UPPer:SPACing..................... 778 CALCulate<n>:LIMit<k>:UPPer:STATe......................778 CALCulate<n>:LIMit<k>:UPPer:THReshold....................778 CALCulate<n>:LIMit<k>:UPPer[:DATA]......................
Page 871 ® List of Commands (Spectrum mode) R&S FPL1000 CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:RESult?................619 CALCulate<n>:MARKer<m>:FUNCtion:MDEPth:SEARchsignal ONCE............619 CALCulate<n>:MARKer<m>:FUNCtion:MDEPth[:STATe]................618 CALCulate<n>:MARKer<m>:FUNCtion:MSUMmary..................626 CALCulate<n>:MARKer<m>:FUNCtion:NDBDown..................751 CALCulate<n>:MARKer<m>:FUNCtion:NDBDown:FREQuency?..............751 CALCulate<n>:MARKer<m>:FUNCtion:NDBDown:QFACtor?..............752 CALCulate<n>:MARKer<m>:FUNCtion:NDBDown:RESult?.................752 CALCulate<n>:MARKer<m>:FUNCtion:NDBDown:STATe................753 CALCulate<n>:MARKer<m>:FUNCtion:NDBDown:TIME?................753 CALCulate<n>:MARKer<m>:FUNCtion:NOISe:RESult?................743 CALCulate<n>:MARKer<m>:FUNCtion:NOISe[:STATe]................744 CALCulate<n>:MARKer<m>:FUNCtion:PNOise:RESult?................746 CALCulate<n>:MARKer<m>:FUNCtion:PNOise[:STATe]................747 CALCulate<n>:MARKer<m>:FUNCtion:POWer:MODE................537 CALCulate<n>:MARKer<m>:FUNCtion:POWer:PRESet................542 CALCulate<n>:MARKer<m>:FUNCtion:POWer:RESult:PHZ................556 CALCulate<n>:MARKer<m>:FUNCtion:POWer:SELect................540 CALCulate<n>:MARKer<m>:FUNCtion:POWer:STANdard:CATalog?............543 CALCulate<n>:MARKer<m>:FUNCtion:POWer:STANdard:DELete.............
Page 872 ® List of Commands (Spectrum mode) R&S FPL1000 CALCulate<n>:MARKer<m>:FUNCtion:TOI[:STATe]..................616 CALCulate<n>:MARKer<m>:LINK:TO:MARKer<m>..................712 CALCulate<n>:MARKer<m>:LOEXclude...................... 716 CALCulate<n>:MARKer<m>:MAXimum:AUTO..................... 719 CALCulate<n>:MARKer<m>:MAXimum:LEFT....................720 CALCulate<n>:MARKer<m>:MAXimum:NEXT..................... 720 CALCulate<n>:MARKer<m>:MAXimum:RIGHt..................... 721 CALCulate<n>:MARKer<m>:MAXimum[:PEAK]................... 720 CALCulate<n>:MARKer<m>:MINimum:AUTO....................721 CALCulate<n>:MARKer<m>:MINimum:LEFT....................721 CALCulate<n>:MARKer<m>:MINimum:NEXT....................722 CALCulate<n>:MARKer<m>:MINimum:RIGHt....................722 CALCulate<n>:MARKer<m>:MINimum[:PEAK].....................722 CALCulate<n>:MARKer<m>:PEXCursion..................... 716 CALCulate<n>:MARKer<m>:SGRam:FRAMe....................729 CALCulate<n>:MARKer<m>:SGRam:SARea....................730 CALCulate<n>:MARKer<m>:SGRam:XY:MAXimum[:PEAK]................730 CALCulate<n>:MARKer<m>:SGRam:XY:MINimum[:PEAK]................. 730 CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:ABOVe................730 CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:BELow................731 CALCulate<n>:MARKer<m>:SGRam:Y:MAXimum:NEXT................
Page 873 ® List of Commands (Spectrum mode) R&S FPL1000 CALCulate<n>:MATH[:EXPRession][:DEFine]....................700 CALCulate<n>:PEAKsearch:AUTO.......................598 CALCulate<n>:PEAKsearch:MARGin......................599 CALCulate<n>:PEAKsearch:PSHow......................599 CALCulate<n>:PEAKsearch:SUBRanges..................... 600 CALCulate<n>:PMETer<p>:RELative:STATe....................674 CALCulate<n>:PMETer<p>:RELative[:MAGNitude]..................673 CALCulate<n>:PMETer<p>:RELative[:MAGNitude]:AUTO ONCE............... 673 CALCulate<n>:PSEarch:AUTO........................598 CALCulate<n>:PSEarch:DETails........................598 CALCulate<n>:PSEarch:MARGin........................599 CALCulate<n>:PSEarch:PSHow........................599 CALCulate<n>:PSEarch:SUBRanges......................600 CALCulate<n>:SGRam:CLEar[:IMMediate]....................694 CALCulate<n>:SGRam:CONTinuous......................694 CALCulate<n>:SGRam:FRAMe:COUNt......................694 CALCulate<n>:SGRam:FRAMe:SELect......................695 CALCulate<n>:SGRam:HDEPth........................695 CALCulate<n>:SGRam:LAYout........................696 CALCulate<n>:SGRam:TSTamp:DATA?...................... 696 CALCulate<n>:SGRam:TSTamp[:STATe].....................697 CALCulate<n>:SGRam[:STATe]........................696 CALCulate<n>:SPECtrogram:CLEar[:IMMediate]..................
Page 874 ® List of Commands (Spectrum mode) R&S FPL1000 DIAGnostic:SERVice:SINFo?........................840 DIAGnostic:SERVice:STESt:RESult?......................819 DIAGnostic:SERVice:VERSinfo?........................836 DISPlay:ANNotation:CBAR..........................824 DISPlay:ANNotation:FREQuency........................824 DISPlay:ATAB..............................526 DISPlay:BLIGhting............................824 DISPlay:CMAP<item>:DEFault<colors>......................827 DISPlay:CMAP<item>:HSL..........................827 DISPlay:CMAP<item>:PDEFined........................828 DISPlay:LOGO...............................800 DISPlay:MINFo[:STATe]..........................715 DISPlay:SBAR[:STATe]..........................825 DISPlay:SKEYs[:STATe]..........................825 DISPlay:TBAR[:STATe]..........................825 DISPlay:THEMe:CATalog?..........................828 DISPlay:THEMe:SELect..........................828 DISPlay:TOUChscreen[:STATe]........................825 DISPlay[:WINDow]:TIME..........................826 DISPlay[:WINDow]:TIME:FORMat.........................826 DISPlay[:WINDow<n>]:MTABle........................714 DISPlay[:WINDow<n>]:SGRam:COLor:DEFault................... 698 DISPlay[:WINDow<n>]:SGRam:COLor:LOWer.....................698 DISPlay[:WINDow<n>]:SGRam:COLor:SHAPe....................
Page 875 ® List of Commands (Spectrum mode) R&S FPL1000 DISPlay[:WINDow<n>]:ZOOM[:STATe]......................686 FETCh:PMETer<p>?............................. 674 FORMat:DEXPort:DSEParator........................786 FORMat:DEXPort:HEADer..........................811 FORMat:DEXPort:TRACes..........................811 FORMat[:DATA].............................702 HCOPy:ABORt...............................800 HCOPy:CMAP<item>:DEFault<colors>......................801 HCOPy:CMAP<item>:HSL..........................802 HCOPy:CMAP<item>:PDEFined........................802 HCOPy:CONTent............................800 HCOPy:DESTination<device>........................803 HCOPy:DEVice:COLor..........................803 HCOPy:DEVice:LANGuage<device>......................803 HCOPy:ITEM:ALL............................854 HCOPy:ITEM:WINDow:TEXT........................804 HCOPy:PAGE:COUNt:STATe........................805 HCOPy:PAGE:MARGin<device>:BOTTom....................805 HCOPy:PAGE:MARGin<device>:LEFT......................805 HCOPy:PAGE:MARGin<device>:RIGHt......................806 HCOPy:PAGE:MARGin<device>:TOP......................806 HCOPy:PAGE:MARGin<device>:UNIT......................806 HCOPy:PAGE:ORIentation<device>......................807...
Page 876 ® List of Commands (Spectrum mode) R&S FPL1000 INSTrument:DELete............................528 INSTrument:LIST?............................528 INSTrument:REName............................ 529 INSTrument[:SELect].............................529 LAYout:ADD[:WINDow]?..........................632 LAYout:CATalog[:WINDow]?.........................633 LAYout:IDENtify[:WINDow]?..........................633 LAYout:MOVE[:WINDow]..........................634 LAYout:REMove[:WINDow]........................... 634 LAYout:REPLace[:WINDow]..........................635 LAYout:SPLitter............................. 635 LAYout:WINDow<n>:ADD?........................... 636 LAYout:WINDow<n>:IDENtify?........................637 LAYout:WINDow<n>:REMove........................637 LAYout:WINDow<n>:REPLace........................637 MMEMory:CATalog:LONG?.......................... 787 MMEMory:CATalog?............................786 MMEMory:CDIRectory........................... 788 MMEMory:CLEar:ALL............................ 795 MMEMory:CLEar:STATe..........................796 MMEMory:COMMent............................. 788 MMEMory:COPY............................
Page 877 ® List of Commands (Spectrum mode) R&S FPL1000 MMEMory:SELect[:ITEM]:NONE........................794 MMEMory:SELect[:ITEM]:SGRam.........................794 MMEMory:SELect[:ITEM]:SPECtrogram....................... 794 MMEMory:SELect[:ITEM]:TRACe[:ACTive]....................795 MMEMory:SELect[:ITEM]:TRANsducer:ALL....................795 MMEMory:STORe<n>:LIMit...........................781 MMEMory:STORe<n>:LIST...........................812 MMEMory:STORe<n>:PEAK.........................812 MMEMory:STORe<n>:SGRam........................812 MMEMory:STORe<n>:SPECtrogram......................812 MMEMory:STORe<n>:SPURious........................813 MMEMory:STORe<n>:STATe........................797 MMEMory:STORe<n>:STATe:NEXT......................798 MMEMory:STORe<n>:TFACtor........................823 MMEMory:STORe<n>:TRACe........................813 MMEMory:STORe<n>:TYPE......................... 798 OUTPut:IF:IFFRequency..........................683 OUTPut:IF[:SOURce].............................682 OUTPut:UPORt:STATe..........................683 OUTPut:UPORt:WTRigger:POLarity......................684 OUTPut:UPORt[:VALue]..........................683 READ:PMETer<p>?............................674 SOURce:EXTernal:ROSCillator:EXTernal:FREQuency................816 SOURce:TEMPerature:FRONtend?......................
Page 878 ® List of Commands (Spectrum mode) R&S FPL1000 STATus:QUEStionable:FREQuency:PTRansition..................844 STATus:QUEStionable:FREQuency[:EVENt]?....................842 STATus:QUEStionable:LIMit<n>:CONDition?....................842 STATus:QUEStionable:LIMit<n>:ENABle......................843 STATus:QUEStionable:LIMit<n>:NTRansition....................844 STATus:QUEStionable:LIMit<n>:PTRansition....................844 STATus:QUEStionable:LIMit<n>[:EVENt]?....................842 STATus:QUEStionable:LMARgin<n>:CONDition?..................842 STATus:QUEStionable:LMARgin<n>:ENABle....................843 STATus:QUEStionable:LMARgin<n>:NTRansition..................844 STATus:QUEStionable:LMARgin<n>:PTRansition..................844 STATus:QUEStionable:LMARgin<n>[:EVENt]?.................... 842 STATus:QUEStionable:NTRansition......................843 STATus:QUEStionable:POWer:CONDition?....................842 STATus:QUEStionable:POWer:ENABle......................843 STATus:QUEStionable:POWer:NTRansition....................844 STATus:QUEStionable:POWer:PTRansition....................844 STATus:QUEStionable:POWer[:EVENt]?......................842 STATus:QUEStionable:PTRansition......................844 STATus:QUEStionable:TIME:CONDition?....................842 STATus:QUEStionable:TIME:ENABle......................843 STATus:QUEStionable:TIME:NTRansition....................844...
Page 879 ® List of Commands (Spectrum mode) R&S FPL1000 SYSTem:LXI:INFO?............................833 SYSTem:LXI:LANReset..........................833 SYSTem:LXI:MDEScription........................... 834 SYSTem:LXI:PASSword..........................834 SYSTem:PRESet............................799 SYSTem:PRESet:CHANnel[:EXEC]......................799 SYSTem:PRESet:COMPatible........................839 SYSTem:REBoot............................526 SYSTem:REVision:FACTory......................... 834 SYSTem:SEQuencer.............................531 SYSTem:SHUTdown............................. 526 SYSTem:SPEaker:VOLume.......................... 684 SYSTem:SPEaker[:STATe]........................... 684 TRACe<n>:COPY............................693 TRACe<n>[:DATA]............................703 TRACe<n>[:DATA]:MEMory?........................704 TRACe<n>[:DATA]:X?...........................705 TRIGger[:SEQuence]:DTIMe......................... 663 TRIGger[:SEQuence]:HOLDoff[:TIME]......................663 TRIGger[:SEQuence]:IFPower:HOLDoff....................... 663 TRIGger[:SEQuence]:IFPower:HYSTeresis....................
Page 880: Index
® Index R&S FPL1000 Index Symbols Analog Demodulation Application ..............82 *OPC ................181 Annotations *OPC? ................181 Hiding/restoring ............129 *RST ................199 AP (trace information) ............66 *WAI ................181 Application cards ............... 10 "% Power Bandwidth" Application notes ............... 10 Softkey ..............
Page 881 ® Index R&S FPL1000 Channel bandwidth C/N ................280 Band power markers CP/ACLR ..............267 Programming example ..........763 "Channel Bandwidth" Band power measurement OBW ................. 285 Activating/Deactivating ..........450 Softkey ..............285 Deactivating .............. 451 Channel bar Power mode .............. 451 Changing names ............
Page 882 ® Index R&S FPL1000 Color scheme Continue single sweep Spectrogram ............. 475, 482 Softkey .............. 234, 402 Colors Continuous Sequencer Configuring ............... 133 Softkey ................ 88 Display ..............131 Continuous sweep Editing ............... 131 Softkey ............234, 401, 480 Editing (remote) ............827 Conventions Print ................
Page 883 ® Index R&S FPL1000 Trace averaging ............261 Diagram footer ..............68 Trace Selection ............265 Hiding/restoring ............129 Troubleshooting ............276 Diagrams User-defined standards ........263, 272 Evaluation method ............ 253 VBW ................260 Dialog boxes Weighting filters ............269 Slider ................
Page 884 ® Index R&S FPL1000 Errors IF OVLD ..........70, 194, 385, 857 INPUT OVLD ..........70, 194, 857 Falling LOUNL ..............858 Slope (Power sensor) ..........371 Fast SEM ................ 296 Messages, device-specific ........858 NO REF .............. 70, 858 Consequences ............
Page 885 Smoothing ..............468 Trigger level (remote) ..........665 GTL ................. 170 Identification Remote ..............523 String, R&S FPL1000 ..........202 String, resetting (R&S FPL1000) ......202 Hardcopy IEC/IEEE bus see Screenshots ............61 see GPIB ..............163 User Manual 1178.3370.02 ─ 03...
Page 886 ® Index R&S FPL1000 IF frequency Output ............... 374 Output (remote) ............682 IF Out Frequency ............374 DOWN ................ 39 LEFT ................39 IF output ................374 Remote ..............682 Power ................36 RIGHT ................. 39 IF OVLD Error ..............70, 857 UP ................
Page 887 ® Index R&S FPL1000 Margins ..............492 Ping ................215 Name ................ 499 Remote control ........... 79, 166 OBW ............285, 432, 435 Reset (LCI) ............... 206 Offsets ..............493 see user Manual ............79 Peak search ..........285, 432, 435 Settings ..............
Page 888 ® Index R&S FPL1000 Querying position (remote) ........727 Instrument responses ..........172 Remote control ............708 Interface ..............171 Search (remote control) ..........716 MI (trace information) ............66 Setting center frequency ........... 437 MIN ..................175 Setting reference level ..........437 MINH (trace information) ...........
Page 889 ® Index R&S FPL1000 Negative Peak detector ........... 460 Results ..............283 Network Search limits ..........282, 284, 286 Automatic login ............218 Occupied Bandwidth Changing user passwords ........217 see OBW ..............281 Configuration (dialog box) ......... 201 OCXO ................125 Configuring ............
Page 890 ® Index R&S FPL1000 Passwords Standard deviation (time domain) ......340 Changing ..............217 Time domain ............. 340 Service functions ............146 Power classes Peak excursion ........431, 435, 454, 456 Adding/Removing (SEM) .......... 311 Peak list ................455 Ranges (SEM) ............311 Configuring ...............
Page 891 ® Index R&S FPL1000 Printer Inserting (Spurious Emissions) ......... 335 Selecting ..............117 Reference (SEM) ..........292, 308 Printers Remote control (Spurious Emissions) ...... 330 Installing ..............117 Rules (SEM) ............. 292 Printing Rules (Spurious Emissions) ........329 Colors ............131, 132, 133 SEM ................
Page 892 ® Index R&S FPL1000 Introduction - see user Manual ........79 Noise floor ..............383 LXI settings ............... 205 SEM range ..............304 Protocols ..............162 Spurious Emissions range ........334 Sequential commands ..........859 RF input Remote Desktop ............. 209, 221 Overload protection (remote) ........
Page 893 ® Index R&S FPL1000 Search limits Ranges ..............291 Deactivating ..........285, 432, 436 RBW ................. 303 OBW ..............282, 284 Reference level ............304 "Search Limits" Reference power ............309 Activating ..........285, 432, 435 Reference range ............308 Search Mode Reference range (remote control) ......
Page 894 ® Index R&S FPL1000 Restoring files ............313 Soft front panels Saving ............... 102, 107 Using ................. 135 Storage location ........104, 107, 312 softkey Storing ..............98, 100 Trace Mode (remote control) ......603, 604 Settings files Softkey bar Deleting ..............
Page 895 ® Index R&S FPL1000 Res BW Auto (remote) ..........651 Removing ..............483 Res BW Manual ............397 Scaling ..............474 Save ................103 Selecting frames ..........402, 480 Save File ..............105 Settings ..............479 Search Config ........... 430, 432 Sweep count .............
Page 896 ® Index R&S FPL1000 Provided files (SEM) ..........320 Support ................862 Restoring files (SEM) ..........313 Information ............142, 143 Settings files (SEM) ..........311 Information (remote) ..........839 Star (yellow) Suppressing see Invalid data icon ........... 64 File name dialog ............117...
Page 897 ® Index R&S FPL1000 Sweep time Time frames Harmonics ..............349 Configuring ............... 402 Spurious Emissions range ........333 Continuing ..............402 "Sweep Time" ..............394 Navigating ............402, 475 Auto (Softkey) ............398 per sweep ..............403 CP/ACLR ............258, 266 Selecting ............
Page 898 ® Index R&S FPL1000 Mode (remote) ............688 Trigger level ..............411 Saving ............... 102 External trigger (remote) ........... 664 Settings ..............460 I/Q Power (remote) ........... 665 Settings (remote control) .......... 687 IF Power (remote) ............. 664 Settings, predefined ..........469 Trigger source ............
Page 899 ® Index R&S FPL1000 Version information ............136 Vertical Line 1/2 Softkeys ..............490 Y-axis Vertical stroke ..............177 Limit lines ..............500 Optimizing display ............. 389 Video Trigger source ............411 Scaling .............. 384, 389 Settings ..............387 Video bandwidth ..............397 Auto (Softkey) ............

Save PDF
