- Page 1 ® R&S Spectrum Analyzer Getting Started (=LØ92) 1328740902 Version 05...
- Page 2 Trade names are trademarks of the owners. ® 1328.7409.02 | Version 05 | R&S Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol and without ® the model designation, e.g. R&S FPC1000 is indicated as R&S FPC.
-
Page 3: Safety And Regulatory Information
® Safety and regulatory information R&S Safety Instructions Safety and regulatory information The product documentation helps you use the product safely and efficiently. Fol- low the instructions provided here and in the following chapters. Intended use The product is intended for the development, production and verification of elec- tronic components and devices in industrial, administrative, and laboratory envi- ronments. - Page 4 ® Safety and regulatory information R&S Safety Instructions Never open the casing of the product. Only service personnel authorized by Rohde & Schwarz are allowed to repair the product. If any part of the product is damaged or broken, stop using the product. Contact Rohde & Schwarz customer service at http://www.customersupport.rohde-schwarz.com.
- Page 5 ® Safety and regulatory information R&S Safety Instructions Connecting to power The product is an overvoltage category II product. Connect the product to a fixed installation used to supply energy-consuming equipment such as household appliances and similar loads. Keep in mind that electrically powered products have risks, such as electric shock, fire, personal injury or even death.
- Page 6 ® Safety and regulatory information R&S Warning messages in the documentation Meaning of safety labels Safety labels on the product warn against potential hazards. Potential hazard Read the product documentation to avoid personal injury or product damage. Electrical hazard Indicates live parts. Risk of electric shock, fire, personal injury or even death. Hot surface Do not touch.
-
Page 7: Regulatory Information
® Safety and regulatory information R&S Korea certification class A NOTICE Potential risks of damage. Could result in damage to the supported product or to other property. Regulatory information Instruments with a serial number < 200000 have an internal Wi-Fi module. You can access the regulatory information for this module in the firmware of the R&S FPC. -
Page 8: Documentation Overview
® Documentation overview R&S Documentation overview This section provides an overview of the R&S FPC user documentation. You can find it on the product page at: www.rohde-schwarz.com/manual/fpc Getting started manual Introduces the R&S FPC and describes how to set up and start working with the product. - Page 9 ® Documentation overview R&S Basic safety instructions Contains safety instructions, operating conditions and further important informa- tion. The printed document is included in the delivery. Data sheet and brochure The data sheet contains the technical specifications of the R&S FPC. It also lists the options and their order numbers as well as optional accessories.
-
Page 10: Preparing For Use
® Preparing for use R&S Unpacking and checking the instrument Preparing for use Here, you can find basic information about setting up the product for the first time. ● Lifting and carrying..................10 ● Unpacking and checking the instrument............10 ● Choosing the operating site................11 ●... - Page 11 ® Preparing for use R&S Setting up the R&S FPC Choosing the operating site Specific operating conditions ensure proper operation and avoid damage to the product and connected devices. For information on environmental conditions such as ambient temperature and humidity, see the data sheet. See also "Choosing the operating site"...
- Page 12 ® Preparing for use R&S Setting up the R&S FPC 3.4.1 Placing the R&S FPC on a bench top To place the product on a bench top 1. Place the product on a stable, flat and level surface. Ensure that the surface can support the weight of the product.
- Page 13 ® Preparing for use R&S Considerations for test setup To unmount the R&S FPC from a rack 1. Loosen the screws at the rack brackets. 2. Remove the R&S FPC from the rack. 3. If placing the R&S FPC on a bench top again, unmount the adapter kit from the R&S FPC.
-
Page 14: Connecting Ac Power
® Preparing for use R&S Turning the R&S FPC on and off Connecting AC power The AC power connector on the rear panel of the R&S FPC allows you to connect it to the primary power supply. Included in the delivery of the R&S FPC are several common power plug types. 1. - Page 15 ® Preparing for use R&S Turning the R&S FPC on and off ● "Power" key is highlighted orange: R&S FPC is in standby mode (main AC power switch is in position "I"). ● "Power" key is highlighted green: R&S FPC is running and ready for oper- ation.
-
Page 16: Instrument Tour
® Instrument tour R&S Front panel Instrument tour The R&S FPC has various connectors on the front and rear panel. Front panel Figure 4-1: Front panel of the R&S FPC USB ports (type A) Headphone jack Softkeys Signal source output Function keys and alphanumeric keypad RF Input Power switch... - Page 17 ® Instrument tour R&S Front panel The "Signal Source" output allows you to generate a signal that can be fed into the DUT or other external accessories like frequency dividers or amplifiers. You can connect the DUT or accessories with a cable that has a male N connector. Headphone jack The female headphone jack allows you to connect headphones (or external speakers) with a miniature jack plug.
-
Page 18: Rear Panel
® Instrument tour R&S Rear panel The frequency range of the RF input is specified in the datasheet. The attenuation range is between 0 dB and 40 dB. Rear panel Figure 4-2: Rear panel of the R&S FPC Trigger input / external reference USB port (type B) Power supply Power supply... - Page 19 ® Instrument tour R&S Rear panel When you are using the connector as a trigger input, you can trigger measure- ments with an external trigger. For more information about triggered measure- ments, refer to the user manual. Alternatively, you can use the connector to connect a 10 MHz reference signal to synchronize the frequency with the external reference.
