MAXinBOX SHUTTER 4CH / 8CH

2.4 SCENE TEMPORISATION

The scene temporisation allows imposing delays over the scenes of the shutter
channels. These delays, defined in parameters, are applied on the execution of one or
more scenes that may have been configured.
Please bear in mind that, as multiple delayed scenes can be configured for each
shutter channel, in case of receiving an order to execute one of them when a previous
temporisation is still pending in that channel, the channel will interrupt such
temporisation and will only execute the delay and the action of the new scene.

ETS PARAMETERISATION

Prior to setting the scene temporisation, it is necessary to have one or more scenes
configured in some of the channels. When entering the Configuration window under
Scene Temporization, all configured scenes will be listed, together with a few
checkboxes to select which of them need to be temporised, as shown in Figure 4.
Figure 4. Scene Temporization
Enabling a certain scene number n brings a new tab with such name to the menu on
the left, from which it is possible to configure the temporisation of that scene for each of
the channels where it has been configured.
Figure 5. Configuration of Scene Temporization
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
12
