Technical data

GR 300
GR 500
GR 700
GR 900
•
Panel depth inclusive a holder is 70mm
•
The panel may be mounted on the grounds of the flammability class C, D.
Instructions for cleaning the panel
Always clean the whole surface of the glass - never clean just small parts of it. Cleaning must be performed while the glass is wet! It is
recommended that the following glass cleaning agents which contain alcohol be used:
Clin – window cleaner spray (with alcohol), manufactured by Henkel
Vitro – an industrial window and mirror cleaner (2-butoxyethanol) made by Amstutz produkte AG
After the application of cleaning agent, use a soft, clean, non-fraying cotton cloth. Do not apply any great pressure when carrying out the
cleaning itself, as this could cause scratches or smudges to appear on the surface of the glass. Wipe the glass in this way until the cleaning
agent dries up evenly. The more even the wet surface is, the lower the risk of smudging. Never use great pressure to wipe the glass dry! If
smudges appear on the glass anyway, please repeat the procedure.
All products containing hydrofluoric acids or fluoride derivatives are prohibited as they may damage the coating and
surface of the glass.
Highly acidic or alkaline products are prohibited, and so are abrasive products.
The glass panel must be protected against aggressive substances such as lime, soda, cement, etc., and must not come into contact with any
kind of paint or varnish.
9
Dimensions (mm)
TYP
(LxWxD)
700x500x12
900x600x12
1100x600x12
1200x800x12
Weight Power Current
(kg) (W)
14 300
21 500
26 700
38 900
Voltage Protection
(A) (V) AC class
1,3
2,2
230 V II
3
3,9
Protection
IP 44
