  • Page 1 auto emoción...
  • Page 2 Foreword This owner's manual and the corresponding supplements should be read carefully to familiarise yourself quickly with your vehicle. Also, the regular care and maintenance and correct handling of the vehicle will contribute to the conservation of its value. For safety reasons, note the information concerning accessories, modifications and parts exchange. If selling the vehicle, give all of the onboard documentation to the new owner, because it belongs with the vehicle.
  • Page 3 Foreword...

  • Page 4: Table Of Contents

    Keys ........Seat belts .......
  • Page 5 Contents Trailer towing ......Technical Data ..... . . Driving economically and with respect for the environment .

  • Page 6: The Structure Of This Manual

    The structure of this manual The structure of this manual Before reading this manual it must be understood Caution This manual describes the vehicle equipment at the time of publication. Texts with this symbol draw your attention to a possible risk of damage to Some of the equipment described here will not be available until a later date, your vehicle.

  • Page 7: Content

    (e.g.“Air conditioning”). The entire manual is divided into five large parts which are: 1. Safety First Information on the vehicle equipment relating to passive safety such as seat belts, airbags, seats, etc. 2. Handling Instructions...

  • Page 8: Safety First

    The This chapter contains important information, advice, suggestions following list includes most of the safety equipment in your SEAT: and warnings that should be read and followed in the interest of •...
  • Page 9 ⇒ page 10. Before starting every trip – Always fasten your seat belt correctly before driving off. Instruct your passengers also to fasten their seat belts properly The driver bears the responsibility for his passengers and the ⇒...

  • Page 10: Safe Driving

    Safe driving – Always reduce your speed as appropriate for road, traffic and weather conditions. – When travelling long distances, take breaks regularly - at least every two hours. – If possible, avoid driving when tired or anxious. WARNING When driving safety is impaired during a trip, the risk of injury and acci- dents increases.

  • Page 11: Proper Sitting Position For Occupants

    ⇒ fig. and steering wheel – Move the driver's seat forwards or backwards so that you are able to press the accelerator, brake and clutch pedals to the floor with your knees still slightly angled ⇒ – Ensure that you can reach the highest point of the steering wheel.
  • Page 12 For detailed information on how to adjust the front passenger's seat, see ⇒ page 127. rest is in an upright position and the driver is wearing his or her seat belt properly. The further the backrests are tilted to the rear, the greater the risk...
  • Page 13 • If the passengers on the rear seat are not sitting properly, they could rest them on the instrument panel, out the window or on the seat. An incor- sustain severe injuries. rect sitting position exposes you to an increased risk of injury in the event •...
  • Page 14 Vehicle occupants are pressed into their seats during a rear end collision. The resulting body pressure on the backrest activates the crash-active head restraint* on the front seat, which moves rapidly forwards and upwards at the same time. This movement reduces the distance between the occupant's head and the head rest, thus reducing the risk of head injuries such as brain trauma.
  • Page 15 (e.g. by “falling” back into the seat when entering the vehicle) or if pressure is applied to a front seat head restraint from the rear. This accidental activation is, however, not dangerous as the crash-active head restraints will return to the original position immedi- Fig.
  • Page 16 • • Do not swap the centre rear head restraint with either of the outer seat never lean against the dash panel, rear head restraints. •...

  • Page 17: Pedal Area

    Safe driving Pedal area Floor mats on the driver side Only floor mats may be used which can be securely fastened Pedals in the footwell and do not impair operation of the pedals. The operation and freedom of movement of all pedals must –...
  • Page 18 Safe driving – Distribute the load evenly in the luggage compartment. WARNING (continued) • – Lay and stow heavy luggage as far forward as possible in the Never allow children to play in or around the vehicle. Close and lock luggage compartment.
  • Page 19 • To prevent pieces of luggage or other objects from flying forward, always use appropriate retaining cords which are secured to the fastening rings. • Never secure a child seat on the fastening rings.

  • Page 20: Seat Belts

    Children must be protected with an appro- priate child restraint system. WARNING • If the seat belts are worn incorrectly or not at all, the risk of severe inju-  ries increases. Seat belt warning lamp* •...
  • Page 21 Please fasten your seatbelt.  The warning lamp* does not go out until the driver seat belt is fastened while the ignition is switched on.

  • Page 22: Why Wear Seat Belts

    25 km/h to 50 km/h, for example, the kinetic energy increases by a factor of four. Because the passengers in our example are not restrained by seat belts, the entire amount of kinetic energy has to be absorbed at the point of impact ⇒...
  • Page 23 It is also important for the rear passengers to wear seat belts properly, as they could otherwise be thrown forward violently in an accident. Rear passengers who do not use seat belts endanger not only themselves but also the front ⇒...
  • Page 24 Further, properly worn seat belts improve the protection provided by airbags in the event of an accident. For this reason, wearing a seat belt is required by law in most countries.

  • Page 25: Seat Belts

    • position by a latch. Do not allow the seat belt to be damaged or jammed, or to rub on any sharp edges. • Never wear the seat belt under the arm or in any other incorrect posi- tion.
  • Page 26 • Never put the latch plate in the buckle of another seat. If you do this, the seat belt will not protect you properly and the risk of injury is increased.
  • Page 27 An incorrectly worn seat belt web can cause severe injuries in the event of an accident. • The shoulder part of the seat belt must lie on the centre of the shoulder, never across the neck. The seat belt must lie flat and snugly on the torso ⇒ page 25, fig.
  • Page 28 • WARNING For pregnant women, the lap part of the seat belt must lie as low as possible over the pelvis, never across the stomach, and always lie flat so Never unbuckle a seat belt while the vehicle is in motion. If you do, you that no pressure is exerted on the abdomen.

  • Page 29: Belt Tensioning Devices

    The seat belts for the front occupants are equipped with belt tensioning devices. Sensors will trigger the belt tensioning devices during severe head- on, lateral and rear collisions only if the seat belt is being worn. This retracts Incorrectly fastened seat belts and tightens the seat belts, reducing the forward motion of the occupants.
  • Page 30 The belt tensioning device and seat belt including its automatic retractor cannot be repaired. • Any work on the belt tensioning devices and seat belts, including the removal and refitting of system parts in conjunction with other repair work, must be performed by a qualified workshop only.

  • Page 31: Airbag System

    The airbag deploys in fractions of a second and with a high velocity. If you • If you are not wearing a seat belt or if you lean forward or to the side or have assumed an incorrect seating position at that moment, you could assume an incorrect sitting position, the risk of injury is increased sustain critical injuries.
  • Page 32 An enabled front airbag on the front passenger side is potentially a major airbags*”. danger to a child. The front passenger seat is life threatening to a child if you − The child seat must be approved by the child seat manufacturer for transport the child in a rear-facing child seat.
  • Page 33 Airbag system Warning lamp for airbag and belt tensioning device system WARNING (continued)  • If a malfunction should occur, have the system checked immediately by This warning lamp monitors the airbag and belt tensioning a qualified workshop. Otherwise there is a risk that, in the event of an acci- dent, the airbag system and belt tensioning devices may not be triggered, device system.
  • Page 34 Airbag system WARNING (continued) surface to become porous. If the airbag inflates, disintegrating plastic parts can cause substantial injuries. • Never attempt to repair, adjust, remove or install parts of the airbag system. • Any work on the airbag system or removal and installation of the airbag components for other repairs (such as repairs to the steering wheel) should be performed only by a qualified workshop.

  • Page 35: Front Airbags

    The airbag system is not a substitute for seat belts, but is an integral part of the vehicle's overall passive safety system. Please bear in mind that the airbag system can only work effectively when the occupants are wearing their seat belts correctly and have adjusted the head restraints properly.
  • Page 36 • or if the vehicle rolls. WARNING • The seat belts and airbags can only provide maximum protection if the occupants are seated correctly ⇒ page 10, “Proper sitting position for occupants”. • If a fault should occur in the airbag system, have the system checked immediately by a qualified workshop.
  • Page 37 Airbag system In order to provide the desired extra protection in an accident, the airbags may develop when the airbag deploys. This is normal and is no indication have to deploy extremely rapidly (within fractions of a second). A fine dust that there was a fire in the vehicle.

  • Page 38: Side Airbags

    • If you are not wearing a seat belt or if you lean forward or to the side or assume an incorrect sitting position, the risk of injury is increased substantially. This increased risk of injury will be further increased if you are struck by an inflating airbag.
  • Page 39 Airbag system The airbag system is not a substitute for seat belts, but is an integral part of WARNING (continued) the vehicle's overall passive safety system. Please bear in mind that the • airbag system can only work effectively when the occupants are wearing their Never drive the vehicle if the loudspeakers in the door panels have seat belts.
  • Page 40 Airbag system Function of side airbags The special design of the airbag allows the controlled escape of the propel- lant gas when an occupant puts pressure on the bag. Thus, the head and Inflated airbags can reduce the risk of head or chest injury in chest are surrounded and protected by the airbag.
  • Page 41 Any work on the side airbag system or removal and installation of the If you do not wear a seat belt, if you lean forward, or are not seated airbag components for other repairs (such as removal of the front seat) correctly while the vehicle is in motion, you are at greater risk of injury should the side airbag system be triggered in an accident.

  • Page 42: Curtain Airbags

    (airbags with gas generator) for the driver, front curtain airbag system”. passenger and passengers on the rear seats, • The airbag system is not a substitute for seat belts, but is an integral part of  in the dash panel insert ⇒ page 32. a warning lamp the vehicle's overall passive safety system.
  • Page 43 WARNING • In order for the curtain airbags to provide their maximum protection, the prescribed sitting position must always be maintained with seat belts while travelling. • Fig. 24 Deployed curtain For safety reasons, the head airbag must be disconnected in vehicles...
  • Page 44 Airbag system WARNING (continued) • There must be no other persons, animals or objects between the occu- pants of the outer seats and the deployment space of the curtain airbags so that the curtain airbag can deploy without restriction and provide the greatest possible protection.

  • Page 45: Deactivating Airbags

    Airbag system Deactivating airbags* Disabling front passenger airbag If you fit a rear-facing child seat to the front passenger seat, the front passenger front and side airbags must be disabled. Fig. 26 Warning lamp for deactivated passenger airbag in centre console When the passenger airbag is deactivated, this means that only the frontal airbag is deactivated.
  • Page 46 Risk of potentially fatal inju- ries to the child! However, if it is necessary in exceptional circumstances to transport a child in a rear-facing child seat on the front passenger seat, you must always disable the front passenger airbag.

  • Page 47: Child Safety

    We recommend that children under 12 years of age be transported on the rear seats. Children travelling on the rear seat must use a child restraint system or the seat belts provided, depending on their age, height and weight. For safety reasons, the child restraint system should be installed in the centre of the rear seat or behind the front passenger seat.
  • Page 48 Never allow a child to be transported in a vehicle without being properly As the driver, you are responsible for any children you transport in secured, or to stand up or kneel on a seat while travelling. In case of an your vehicle.

  • Page 49: Child Seats

    Child seats that have been tested and approved under the ECE R 44 standard Group 0: For babies from about 9 months old and 10 kg in weight the most bear the test mark on the seat (the letter E in a circle with the test number ⇒ fig.
  • Page 50 Children under 7 years of age weighing between 15 and 25 kg are best use in the vehicle wallet and always keep them in the vehicle. protected by group 2 child seats in conjunction with properly adjusted seat belts. WARNING...

  • Page 51: Securing Child Seats

    Securing child seats Ways to secure a child seat A child seat can be secured differently on the rear seat and on the front passenger seat. • You can secure a child seat to the rear seat or front passenger seat in the Child seats in groups 0 to 3 can be secured with a seat belt.
  • Page 52 • Never install a child seat facing backwards (or rear-facing) on the front – Pull on both sides of the child seat to ensure that it is secure. passenger seat unless the front passenger airbag has been disabled. This represents a risk of potentially fatal injuries to the child! If it is necessary in exceptional cases to transport a child on the front passenger seat, you Two “ISOFIX”...
  • Page 53 Child safety...
  • Page 54 Safety First Handling instructions Tips and Maintenance Technical Data...
  • Page 55 Fig. 31 Instrument panel...

  • Page 56: Handling Instructions

    * ......Thumb wheel for left seat heating ..... . .

  • Page 57: Instruments

    Cockpit Instruments Instrument overview The instruments display the vehicle operating status. Fig. 32 Detail of the dash panel: Instruments Time adjustment button / trip recorder reset button ⇒ page 58 Detail of the dash panel: Instruments Fuel gauge ⇒ page 57 Speedometer Multi-function display Engine coolant temperature gauge ⇒...
  • Page 58 Cockpit   Fuel gauge and reserve indicator Engine coolant temperature display This gauge shows the engine coolant temperature. Fig. 33 Details of the Fig. 34 Details of the instrument panel: Fuel instrument panel: Engine gauge coolant temperature gauge Details of the instrument panel: Fuel gauge The fuel tank has a capacity of approx.
  • Page 59 Cockpit .Stop the car and switch off the engine. Check the coolant level ⇒ page 201 ⇒ For the sake of the environment Changing up a gear early will help you to save fuel and minimise engine Even if the coolant level is correct do not continue driving. You should obtain noise.

  • Page 60: Digital Display In The Instrument Panel

    Cockpit Digital display in the instrument panel Display (without warning or information texts) The display in the instrument panel shows, amongst other things, the mileage and trip recorder as well as the selector lever position. Fig. 36 Detail of instru- ment panel: Display with Tiptronic gear selection Digital clock display ⇒...
  • Page 61 Cockpit Displayed categories Mileage display or Service Interval Display “Mileage display or Service Interval Display” The display in the instrument panel shows the mileage and Selector lever position display for the automatic gearbox. The actual trip recorder as well as the selector lever position. position of the selector lever or the gear which is engaged (for Tiptronic) are highlighted Mileage display or Service Interval Display...
  • Page 62 Cockpit An overdue service is indicated by a minus sign in front of the mileage or day information. Display with multi-function display (MFD) * The multi-function display (MFD) shows you diverse journey and consumption data. Fig. 39 Digital screen on the instrument panel: Average fuel consumption display...
  • Page 63 Cockpit the existing trip recorder memory. The memory will automatically be deleted if the journey is interrupted for more than two hours. The total journey memory 2 collects the journey data for any number of indi- vidual journeys (even if the ignition is switched off for longer than two hours) up to a total of 99 hours and 59 minutes travel time, 9999 miles distance trav- elled and 999 litres of fuel consumed.
  • Page 64 Cockpit Set speed indicator litres/100km orLitres/h - Current fuel consumption When driving at the required speed, enter the speed indicator mode and The display will show the current fuel consumption in litres/km whilst the press the button A (Reset), the display remembers the indicated speed. If the vehicle is in motion or in litres/hour when the vehicle is in a stationary posi- indicated speed is exceeded, a warning text is displayed on the screen tion with the engine running.
  • Page 65 Cockpit cated by symbols with warnings and information texts in the display. An Examples of priority 1 warning reports (red) • audible warning is given in certain cases.  Brake system symbol with the warning message STOP BRAKE FLUID INSTRUCTION MANUAL or STOP BRAKE FAULT INSTRUCTION MANUAL Warning symbols •...

  • Page 66: Instrument Panel Menus

    Cockpit Instrument panel menus Main menu The menu enables access to the different display functions. Fig. 42 Windscreen wiper lever: button A to confirm the menu point and rocker Fig. 43 Digital display on switch B to change the the instrument panel: menu Main menu Open main menu...
  • Page 67 Cockpit Main menu Function Multi-function display Change to multi-function display (MFD): “Multi-function display (MFD)” Audio The current station will be shown when the radio is switched on Navigation This menu is only available if the vehicle is fitted with a navigation system. The navigation system must be switched on.
  • Page 68 Cockpit Example of menu use All the menus on the instrument panel may be used according to the following procedure. Fig. 44 Windscreen wiper lever: button confirm the menu point Fig. 45 Digital screen on and rocker switch the instrument panel: change the menu winter tyre display The setting of a speed warning will be used as an example of how to...
  • Page 69 Cockpit 5. To activate and deactivate the speed warning 6. To leave the menu “Winter tyres” – Use the rocker switch to select the menu point On/ Off and press – In the menu select Back. the button to switch the speed warning either on or off. If the speed warning is deactivated, three dashes will be displayed ---.
  • Page 70 Cockpit Vehicle status menu Priority 2 warning messages and information texts: “Warning and information texts on the screen” automatically disappear after a certain time and are This menu shows warning or information texts. saved in the menu “Vehicle condition”. The warning and information texts may be viewed in this menu. If there are no Open Vehicle Condition menu messages, ok appears on the display.
  • Page 71 Cockpit Note For electronic and vehicle equipment one or more of these menus will be displayed. Lights and visibility menu From this menu it is it possible to alter the vehicle lighting settings. Open Lights and visibility Menu – Select the option Lights & visibility from the menu and press button on the windscreen wiper lever.

  • Page 72: Warning Lamps

    Cockpit Warning lamps Overview of the warning lamps The warning lamps indicate a number of different functions and possible faults. Fig. 46 Instrument panel with warning lamps. Some of the warning lamps listed in this section are only fitted on certain models or are optional extras Safety First Handling instructions...
  • Page 73 Cockpit Item Symbol Meaning of warning and control lamps Further information  ⇒ page 74 Fuel level / reserve  ⇒ page 74 Coolant level / coolant temperature  ⇒ page 75 Rear fog light switched on   ⇒ page 75 Turn signals in operation ...
  • Page 74 Cockpit Item Symbol Meaning of warning and control lamps Further information  ⇒ page 19 Fasten seat belts!  ⇒ page 78 Tyre pressure  ⇒ page 79 Engine fault (petrol engine) Glow plug system (diesel engine)  ⇒ page 80...
  • Page 75 Cockpit  Coolant Level* / temperature WARNING (continued) • The warning lamp lights up if the coolant temperature is too The risk of an accident increases if your vehicle breaks down. Use a high or if the coolant level is too low. warning triangle to draw the attention to your stationary vehicle so that it does not represent a danger for others.
  • Page 76 Cockpit Further information on the turn signals ⇒ page 113. First look at the coolant temperature gauge. If the needle is in the normal range, top up with coolant at the earliest opportunity ⇒  WARNING Trailer turn signals • If your vehicle is immobilised for any technical reasons, move it to a This warning lamp also flashes when the turn signals are safe distance from traffic.
  • Page 77 Cockpit  Cruise control system* If you drive faster than 6 km/h with the handbrake on, the following message will appear on the instrument panel display : HANDBRAKE ENGAGED. Also, The warning lamp comes on when the cruise control system an audible warning is given.
  • Page 78 Cockpit  Engine oil pressure Brake system fault  If the ABS warning lamp lights up together with the brake warning lamp This warning lamp indicates that the engine oil pressure is  , this indicates not only a fault in the ABS function, but also a possible fault in the brake system ⇒...
  • Page 79 Cockpit  Traction control system (TCS)* Alternator The traction control system prevents the driven wheels from This warning lamp signals a fault in the alternator. spinning when the vehicle is accelerating.  The warning lamp lights up when the ignition is switched on. It should go out when the engine has started running.
  • Page 80 Cockpit The tyre monitoring system compares the rotations and by this, the outside WARNING diameter of each wheel using the ABS sensors. If the outside diameter of one • wheel changes, this is communicated to the driver by the tyre control indi- When the tyre monitor indicator lights, reduce speed immediately and ...
  • Page 81 Cockpit  Glow plug system / Engine fault The following information is displayed in the instrument panel screen: EXHAUST GAS SEE WORKSHOP. The indicator lights up to show that the glow plugs are preheating the engine. It flashes if there is an engine fault. ...
  • Page 82 SAFE. The vehicle cannot be used in that case ⇒ page 150. able to have the rear brake pads inspected at the same time. The engine can, however, be started if the appropriate coded SEAT genuine The following information is displayed in the instrument panel screen key is used.
  • Page 83 Cockpit Note The vehicle cannot be operated properly if you do not have a genuine SEAT key.

  • Page 84: Using These Instructions

    Steering wheel controls Steering wheel controls • Using these instructions Audio version, to control the available audio functions from the steering wheel. • Audio + Telephone version, to control the available audio functions and The steering wheel includes multifunction modules which make it possible to the telephone system from the steering wheel.
  • Page 85 Steering wheel controls Short press Long press Button Radio CD Audio Radio CD Audio CD mp3 CD mp3 Volume up Continue volume up Volume down Continue volume down Station search Station search Following track Fast forward Higher frequency Higher frequency Station search Station search Lower...
  • Page 86 Steering wheel controls Steering wheel Audio + Telephone version controls Fig. 50 Controls on the Fig. 51 Controls on the steering wheel steering wheel Short press Long press Button Radio CD Audio Radio CD Audio CD mp3 CD mp3 Volume up Continue volume up Volume down Continue volume down...
  • Page 87 Steering wheel controls Cyclic source control No specified function FM - AM - CD - CDC - FM... Voice recognition activation No specified function Press to speak Make a call Direct access to the phone book No specified function Accept a call Terminate call Refuse call No specified function...

  • Page 88: Radio Navigation System

    Steering wheel controls Radio navigation system Steering wheel audio version controls Fig. 52 Controls on the Fig. 53 Controls on the steering wheel steering wheel Short press Long press Button Radio Radio Raise the source volume and the navigation message Raise the source volume and the navigation message continuously Lower the source volume and the navigation message Lower the source volume and the navigation message continuously...
  • Page 89 Steering wheel controls Station search Station search Previous track Fast Rewind Lower frequency Lower frequency Cyclic change of source Repeat the last Navigation instruction Radio - CD / CDC - Radio - ... When in Navigation mode the system leaves the navigation screen Only if the Navigation function is activated Silence No specified function...
  • Page 90 Steering wheel controls Short press Long press Button Radio Radio Raise the source volume and the navigation message Raise the source volume and the navigation message continuously Lower the source volume and the navigation message Lower the source volume and the navigation message continuously Station search Station search Following track...

  • Page 91: Steering Wheel Lighting Controls

    Steering wheel controls Steering wheel lighting controls Push simultaneously... ⇒ fig. 57 Audio Audio + Telephone ⇒ fig. 56 Fig. 56 Steering wheel Audio + Telephone version controls Fig. 57 Steering wheel audio version controls The lighting is turned on using the simultaneous pressing of the following keys:...

  • Page 92: Central Locking

    Opening and closing Opening and closing Central locking Safety system “Safe” This is an anti-theft device consisting of a double lock for the Description door locks and a deactivation function for the boot in order to make forced entry more difficult. The central locking system enables you to lock and unlock all the doors and the tailgate from one point.
  • Page 93 Opening and closing When the “Safe” system is deactivated, the doors are locked using the simple WARNING locking system, meaning that they may be opened from the interior but not from the exterior. No one should remain in the vehicle if the “Safe” deadlock mechanism has been activated.
  • Page 94 Opening and closing will be activated. The indicator will be turned off as will be the alarm for those Unlocking vehicles fitted with one. The driver's door automatically unlocks when the key is removed from the ignition. Unlocking the boot See ⇒...
  • Page 95 Opening and closing Emergency manual locking Unlocking the manually (emergency) locked driver's door Insert the key in the door lock cylinder and rotate anti-clockwise for the left This permits mechanical locking of the doors in case of hand side doors and clockwise for the right hand side doors. central locking system failure.
  • Page 96 Opening and closing • Central locking button The driver's door cannot be locked if it is open. This prevents you from locking yourself out of the vehicle. • The vehicle can be locked and unlocked from the inside using Repeated operation of the central locking will deactivate the central the central locking button.
  • Page 97 Opening and closing Childproof locks This function is independent of the electronic opening and locking systems of the vehicle. It only affects the rear doors. It is only The childproof lock prevents the rear doors being opened possible to activate it and deactivate it manually, as described from the inside.

  • Page 98: Keys

    Opening and closing Keys If you sell the vehicle, please give the plastic key tab to the new owner. Duplicate keys Key set If you need a replacement key, take your key tab to an Authorised Service Centre. The set of keys includes a remote control, a key without a remote control and a key tab with the number of the key.

  • Page 99: Radio Frequency Remote Control

    Opening and closing Radio frequency remote control Locking and unlocking the vehicle The remote control key can be used to lock and unlock the vehicle from a distance. Fig. 64 Range of the remote control ⇒ fig. 63 Using the button (arrow) on the control, the key shaft is released.
  • Page 100 Opening and closing  Press the button twice to unlock all doors. Changing the battery WARNING • Incorrect use of the key can result in critical injuries. • Never leave children or disabled persons in the vehicle; in case of emer- gency they may not be able to leave the vehicle or look after themselves.

  • Page 101: Anti-Theft Alarm System

    Opening and closing Synchronising the remote control key Up to eight remote control keys can be used. Synchronising the remote control key – Use both keys that have been delivered with the vehicle Anti-theft alarm system* ⇒ page 97, fig. 62, the key fitted with the remote control the normal key Description of anti-theft alarm system*...
  • Page 102 Opening and closing Opening the doors mechanically (emergency opening) Interior monitoring system* If the remote control function fails, you will have to use the key to unlock the car. This is done as follows: • ⇒ page 99, fig. 65 Unfold the key by pressing the button shown by the (arrow).

  • Page 103: Tailgate

    Opening and closing WARNING For those vehicles in which a separate sunblind is fitted in the passenger compartment, the alarm will not function correctly due to interference with the sensor. Tailgate Fig. 68 Detail of the tail- gate inner trim: recessed Opening and locking handle for closing the tail- gate...
  • Page 104 Opening and closing Emergency opening WARNING • This allows the vehicle to be opened if the central locking Always close the tailgate properly. Risk of accident or injury. • does not operate (for example if the battery is flat). The tailgate must not be opened when the reverse or rear fog lights are lit.

  • Page 105: Windows

    Opening and closing Windows Buttons in the driver door Button for window in front left door Button for window in front right door Opening or closing the windows electrically Buttons for rear windows* The front and rear electric windows can be operated using the Safety switch for deactivating the electric window buttons in the rear controls in the driver's door.
  • Page 106 Opening and closing – Use the key to lock the vehicle from outside and hold the key in WARNING (continued) the lock position for at least one second. The one-touch function • is now ready for operation. If necessary, use the safety switch to disable the rear electric windows. Make sure that they have been disabled.

  • Page 107: Sliding/Tilting Roof

    Opening and closing The one-touch function and roll-back function will not work if there is a Sliding/tilting roof* malfunction in the electric windows. Contact an Authorised Service Centre. Opening and closing the sliding/tilting roof WARNING • The sliding/tilting sunroof is opened and closed using the Incorrect use of the electric windows can result in injury.
  • Page 108 Opening and closing Tilting the sliding/tilting sunroof Convenience closing* – Turn the rotary button to position Using the door lock Always close the sliding/tilting roof fully if you park the vehicle or leave it – Hold the key in the door lock of the driver's door in the locking unattended ⇒...
  • Page 109 Opening and closing Roll-back function of the sliding/tilting roof* The sliding/tilting roof has a roll-back function which prevents larger objects getting trapped when the roof is closed. The roll-back function does not prevent fingers getting pinched against the roof opening. The sliding/tilting sunroof stops and opens again immediately if it is obstructed when closing.

  • Page 110: Lights And Visibility

    Lights and visibility Lights and visibility Lights Switching on the fog lights*   – Turn the control from position to the first stop. The  lights control symbol will light up.  Switching lights on and off Switching on the rear fog lights (vehicles with front fog lights) ...
  • Page 111 Lights and visibility • If the coming home* feature is activated, the acoustic signal for the When the switch is in this position, as soon as visibility conditions are dipped beam headlights will not sound, it will sound if the position lights are reduced, the lights are automatically activated.
  • Page 112 Lights and visibility Coming home / leaving home function* Leaving home function* The function is activated when the vehicle is unlocked using the remote After dark the area around the car is lit up with the aid of the control. In the dark, the leaving home function will light the dipped beam coming home / leaving home function.
  • Page 113 Lights and visibility  Instrument and switch lighting Hazard warning lights When the headlights are switched on, the brightness of the instruments and The hazard warning lights are used to draw the attention of switch lighting can be regulated to suit your requirements by turning the ⇒...
  • Page 114 Lights and visibility 7. Always take the vehicle key with you when you leave the vehicle Indicator and main beam headlight lever The turn signal and main beam lever also operates the You should switch on the hazard warning lights to warn other road users, for parking lights and the headlight flasher.
  • Page 115 Lights and visibility  Switching main beam on and off damaged, the indicator does not light up. You should have the bulb replaced.  – Turn the light switch to position • The main beam headlights can only be switched on if the dipped beam ⇒...

  • Page 116: Interior Lights

    Lights and visibility Interior lights Note If not all the vehicle doors are closed, the interior lights will be switched off Front interior light after approx. 10 minutes, providing the key has been removed and the cour- tesy light position selected. This prevents the battery discharging. Front reading lights Fig.

  • Page 117: Visibility

    Lights and visibility  Rear interior and reading lights* Interior lights or both reading lights switched on Turn the control to position Note If not all the vehicle doors are closed, the interior lights will be switched off after approx. 10 minutes, providing the key has been removed and the cour- tesy light position selected.

  • Page 118: Windscreen Wipers

    Lights and visibility ⇒ fig. 83 The make-up mirrors in the sun visors have covers. When you open the cover The windscreen wiper lever has the following positions: a light* in the roof turns on. Switching off the wipers The lamp* in the roof lining will go out when the vanity mirror cover is pushed –...
  • Page 119 Lights and visibility • Optional heated windscreen in the wiper blade* area The windscreen will be wiped again after approximately five seconds once the “automatic wipe/wash system” has been operated while the vehicle is in In some countries and with some versions, there is the possibility of heating transit.
  • Page 120 Lights and visibility Rain sensor* Switching on the rain sensor ⇒ fig. – Move the windscreen wiper lever into position The rain sensor controls the frequency of the windscreen wiper intervals, depending on the amount of rain. – Move the control to the left or right to set the sensitivity of the rain sensor.
  • Page 121 Lights and visibility  Rear window wiper Switching on the windscreen wiper and washer system ⇒ page 120, fig. – Press the lever fully forwards to position The windscreen wiper lever operates the windscreen wiper The wash function will start immediately and the wiper will start and the wash and wipe system for the rear window.

  • Page 122: Mirrors

    Lights and visibility Headlight washer system* Automatic anti-dazzle interior mirror* The headlight washers clean the headlights. The automatic anti-dazzle function can be switched on and off as desired. The headlight washers are activated automatically when the windscreen washer is used and the windscreen wiper lever is pulled towards the steering wheel for at least 1.5 seconds –...
  • Page 123 Lights and visibility 2. Turn the rotary knob to position the mirror so that you have a Note good view to the rear of the vehicle • The automatic anti-dazzle function will only work properly if the sun 3. Turn knob to position R (right exterior mirror) blind* for the rear window is retracted and there are no other objects preventing light from reaching the interior mirror.
  • Page 124 Lights and visibility WARNING • The rear view convex or aspheric mirror increase the field of vision however the objects appear smaller and further away in the mirrors. If you use these mirrors to estimate the distance to vehicles behind you when changing lane, you could make a mistake.

  • Page 125: The Importance Of Correct Seat Adjustment

    Always keep your feet in the footwell when the vehicle is moving; never Proper seat adjustment optimises the level of protection rest them on the dash panel, out of the window or on the seat. This also offered by seat belts and airbags.

  • Page 126: Head Restraints

    Seats and stowage Head restraints Correct adjustment of head restraints Properly adjusted head restraints are an important part of occupant protection and can reduce the risk of injuries in most accident situations. Fig. 90 Viewed from side: Properly adjusted head restraints and proper belt adjustment –...
  • Page 127 Seats and stowage Removing or adjusting head restraints – To lower the head restraint, press the button and push head restraint downwards. The head restraints can be adjusted by moving them up and – Make sure that the head restraint engages securely in one of its down.

  • Page 128: Electric Front Seats

    ⇒ fig. 92 The control elements in are mirrored for the front right- tilted far to the rear. The maximum protection of the seat belt can be hand seat. achieved only when the backrests are in an upright position and the driver and front passenger have properly adjusted their seat belts.

  • Page 129: Rear Seat Bench

    – Fold down the backrest . The rear head restraints may have to be The seat heating only works when the ignition is switched on. The left thumb removed before folding the seat forwards if the front seats have wheel controls the left seat and the right thumb wheel the right seat.

  • Page 130: Stowage Compartments

    Seats and stowage Folding up the seat back Stowage compartments Stowage compartment on the front passenger side Fig. 95 Folding up the rear seat back Fig. 96 Passenger side: – Fold the backrest back and push the backrest firmly into the lock.
  • Page 131 Stowage compartment under the left hand side front seat* Stowage compartment with the CD charger* There is a stowage locker with a cover under the front left The CD* loader is located under the front right hand seat. hand side seat. To access the loader –...

  • Page 132: Ashtrays*, Cigarette Lighter* And Electrical Sockets

    Seats and stowage WARNING (continued) WARNING • • Ensure that no objects can fall from the centre console or other stowage Never place hot drinks in the bottle holder. During normal or sudden areas into the driver footwell while the vehicle is moving. In the event of a driving manoeuvres, sudden braking or an accident, the hot drink could be sudden braking manoeuvre, you will not be able to use the brake, clutch or spilled.
  • Page 133 Seats and stowage – To close, lower the cover. – Pull out the cigarette lighter and light the cigarette on the glowing coil. Emptying the ashtray – Extract the ashtray and empty. WARNING • Improper use of the cigarette lighter can lead to serious injuries or start WARNING a fire.
  • Page 134 Seats and stowage Electrical sockets Electrical accessories may be connected to the 12 volt socket in the front ⇒ fig. 101 ⇒ fig. 102 centre console or to that of the rear centre console Electrical equipment can be connected to any of the 12 volt the passenger compartment and to the socket in the luggage compartment*.

  • Page 135: First-Aid Kit, Warning Triangle, Fire Extinguisher

    Seats and stowage First-aid kit, warning triangle, fire The fire extinguisher* is fastened to the luggage compartment carpet with velcro. extinguisher Note • Warning triangle The first-aid kit and the fire extinguisher are not part of the vehicle's standard equipment. •...
  • Page 136 Seats and stowage – Secure luggage in the luggage compartment with suitable straps Luggage compartment cover on the fastening rings. WARNING • Loose luggage and other loose items in the vehicle can cause serious injuries. • Loose objects in the luggage compartment can suddenly move and change the way the vehicle handles.
  • Page 137 Please observe the following points if you intend to carry loads on the roof: • For safety reasons, only luggage racks and accessories supplied by offi- cial SEAT Service should be used. • It is imperative to precisely follow the fitting instructions included for the...

  • Page 138: Air Conditioning

    Air conditioning Air conditioning Heating Controls and equipment Fig. 105 On the dash panel: Heater controls ⇒ fig. 105 – Using the controls you can set the output, which is needed to defrost the windows quickly, is only available when the engine has reached its operating temperature. temperature, air distribution and the air flow.
  • Page 139 Air conditioning With low ambient temperatures, the air recirculation increases the effective- ness of the heating system by heating the air inside the passenger compart- ment rather than the ambient air. Air distribution Control for setting the flow of air in the required direction. ...

  • Page 140: Climate Control

    Air conditioning Climate control* Control switches Fig. 106 On the dash panel: Climate controls The air conditioning system only works when the engine is running Button  – Rear window heating. The heating will be switched off auto- matically approximately 20 minutes after switching on. It can also be and the blower is switched on.
  • Page 141 Air conditioning Note Please observe the general notes ⇒ page 146. Heating and cooling the interior Fig. 107 On the dash panel: Climate controls Heating of the vehicle interior Cooling the passenger compartment ⇒ fig. 107 ⇒ page 139, – Turn the temperature selector clockwise to select –...
  • Page 142 Air conditioning – Use the air distribution control to guide the flow of air in the comfort for the vehicle occupants and prevents misting of the windows when the ambient air humidity is high.   required direction: (to the windscreen), (to the upper body), ...

  • Page 143: 2C-Climatronic

    Air conditioning ⇒ page 141, fig. 108  Air recirculation mode prevents strong odours in For reasons of safety, air recirculation is not possible when the control for air  the outside air from entering the vehicle interior, for example when passing distribution is set to the windscreen setting through a tunnel or in queuing traffic.
  • Page 144 Air conditioning Blower control ⇒ page 144 The air conditioning system only works when the engine is running – Switches the 2C-Climatronic on and off ⇒ page 144 and the blower is switched on. Button Button AUTO – Automatic temperature, ventilation and air distribution ⇒...
  • Page 145 Air conditioning – Turn the temperature selectors to set the desired temperatures Climatronic maintains a constant temperature level automatically. The temperature of the air supplied to the interior, the blower speed and the air for the left and right sides of the interior. We recommend 22°C distribution are regulated automatically.
  • Page 146 Air conditioning Temperature Air recirculation mode There are separate temperature selectors for the left and right sides of the Air recirculation mode prevents fumes or unpleasant smells vehicle interior. The selected temperature is displayed above the selector. It from entering the vehicle. is possible to select interior temperatures from +16°C (61°F) to +29.5°C (86°F).

  • Page 147: General Notes

    Air conditioning • General notes The air conditioning system operates most effectively with the windows and the sliding/tilting roof* closed. However, if the sun has heated up the vehicle, the air inside can be cooled more quickly by opening the windows for The pollution filter a short period.

  • Page 148: Steering

    The height and reach of the steering wheel can be freely adjusted to suit the driver. Fig. 112 Proper sitting position for driver – Adjust the driver seat to the correct position. ⇒ fig. 111 – Push the lever under the steering column down ⇒...

  • Page 149: Safety

    Driving Safety WARNING (continued) • Adjust the driver seat or steering wheel so that there is a distance of at ⇒ page 147, Electronic stabilisation programme (ESP)* least 25 cm between the steering wheel and your breast bone fig. 112. If you fail to observe the minimum distance, the airbag will not ESP helps make driving safer in certain situations.

  • Page 150: Ignition Lock

    Driving • when rocking the vehicle backwards and forwards to free it from mud, for Ignition lock example. You should press the button to switch the ESP back on when you no longer Position of the ignition key need wheel spin. The TCS and EDL are also switched off if the ESP is switched off.

  • Page 151: Starting And Stopping The Engine

    • Never remove the ignition key from the ignition until the vehicle is The engine can only be started using a genuine SEAT key with the correct completely stopped! Otherwise, the steering may lock immediately and code.
  • Page 152 10 seconds and try again after about half a minute. If the engine still does not The engine can only be started using a genuine SEAT key with start, the fuel pump fuse should be checked ⇒ page 224, “Fuses”.
  • Page 153 Driving Glow plug system for the diesel engine For the sake of the environment To avoid unnecessary load on the battery, do not use any other major elec- Do not warm-up the engine by running the engine with the vehicle stationary. trical equipment while the glow plugs are pre-heating.

  • Page 154: Manual Gearbox

    Driving Caution If the engine has been driven hard for a long period, the engine could over- heat when it is switched off. Risk of engine damage. For this reason, you should idle the engine for approx. 2 minutes before you switch it off. Manual gearbox Fig.

  • Page 155: Automatic Gearbox

    Driving Neutral position (lever locked). This position is similar to the neutral Note position for manual gearboxes). • Do not rest your hand on the gear lever when driving. The pressure of your Drive position (economic driving program). hand could cause premature wear on the selector forks in the gearbox. Sports driving position.
  • Page 156 Driving Selecting the sport program Releasing the selector lever lock – Move the lever to position S. – Start the vehicle. – Press and release the brake pedal, at the same time press the If you have selected the normal driving programme D, you will drive in a more button on the knob.
  • Page 157 Driving Driving with an automatic gearbox* Short stop – Hold the vehicle stationary with the brake pressed down (for The drive and reverse gears are automatically engaged. example at traffic lights). The selector lever does not need to be put into the positions P or N for this. –...
  • Page 158 Driving braking is insufficient and vehicle accelerates. So that the engine speed does Caution not become excessive, the gearbox changes to the next highest gear. Depress • the brake pedal and move the selector lever to the Tiptronic gate to return to Never use the automatic gearbox to hold the vehicle stationary on a hill, 3rd gear.

  • Page 159: Handbrake

    Driving – Press the gear lever forwards (+) to select a higher gear. Releasing the handbrake – Pull the lever up slightly and press the locking knob in the direc- – Press the gear lever back (-) to select a lower gear. ⇒...

  • Page 160: Acoustic Parking Aid System

    Driving Parking WARNING (continued) • The handbrake should always be firmly applied when the Never park where the hot exhaust system could ignite inflammable vehicle is parked. materials, such as dry grass, low bushes, spilt fuel etc. • Never allow vehicle occupants to remain in the vehicle when it is Always note the following points when parking the vehicle: locked.
  • Page 161 Driving Activation WARNING The system is activated by engagement of the reverse gear. A brief acoustic • signal confirms the activation and correct function of the system. The sensors have blind spots in which obstacles may not be detected. • Always look out for small children and animals because the system will Reversing not always detect them.

  • Page 162: Cruise Control System (Ccs)

    Driving Cruise control system (CCS)* Switching the cruise control system on and off Description The cruise control system is able to maintain the set speed in the range from approx. 30 km/h to 180 km/h. Once the speed setting has been saved, you may take your foot off the accel- erator.
  • Page 163 Driving Setting speed* Adjusting set speed* The speed can be altered without touching the accelerator or the brake. Fig. 124 Turn signal and main beam lever: switch and rocker switch for CCS Fig. 125 Turn signal and main beam lever: switch –...
  • Page 164 Driving • When you increase speed with the accelerator and then release the pedal, the if the clutch pedal is depressed, • system will automatically restore the set speed. This will not be the case, if the vehicle is accelerated to over 180 km/h, •...
  • Page 165 Driving...

  • Page 166: Tips And Maintenance

    Intelligent technology Tips and Maintenance Intelligent technology Brakes The brake assist system intervenes here, if you press the brake pedal very quickly, the brake assist system registers an emergency situation. It then very quickly builds up the full brake pressure so that the ABS can be activated Brake servo more quickly and efficiently, thus reducing the braking distance.

  • Page 167: Anti-Lock Brake System And Traction Control M-Abs (Abs And Tcs)

    Intelligent technology Anti-lock brake system and traction control WARNING (continued) M-ABS (ABS and TCS) • The effectiveness of ABS is also determined by the tyres fitted ⇒ page 209. • If the running gear or brakes are modified, the effectiveness of the ABS Anti-lock brake system (ABS) could be severely limited.

  • Page 168: Electronic Stabilisation Program (Esp)

    Intelligent technology The TCS should be switched on again afterwards as soon as possible. Electronic Stabilising Program (ESP)* ESP reduces the danger of skidding by braking the wheels individually. WARNING The system uses the steering wheel angle and road speed to calculate the •...
  • Page 169 Intelligent technology Anti-lock brake system (ABS) WARNING (continued) • Always adapt your driving style to suit road conditions and the traffic The anti-lock brake system prevents the wheels locking during braking ⇒ page 166. situation. Do not let the extra safety afforded by EDL tempt you into taking any risks when driving, this can cause accidents.

  • Page 170: Driving And The Environment

    Driving and the environment Driving and the environment Running-in Running in tyres and brake pads New tyres should be run-in carefully in the first 500 km. New Running in a new engine brake pads should be run-in carefully in the first 200 km. The engine needs to be run-in over the first 1,500 km.

  • Page 171: Catalytic Converter

    Driving and the environment Authorised Service Centre more frequently than recommended in the Service WARNING (continued) Schedule. • Non-standard or damaged front spoilers could restrict the airflow to the If you drive with wet brakes, for example after driving through water, after brakes and cause them to overheat.

  • Page 172: Driving Abroad

    The catalytic converter reaches very high temperatures! Risk of fire. • SEAT importers and distributors will gladly provide information about the Never park where the catalytic converter could come into contact with technical preparation of your vehicle in addition to necessary maintenance dry grass or inflammable materials under the vehicle.
  • Page 173 Driving and the environment Covering headlights for driving on the left On the left hand side headlight, if you are changing from driving on the left- ⇒ fig. hand side to the right-hand side 128. Covering headlights for driving on the right Fig.

  • Page 174: Trailer Towing

    Driving and the environment On the right headlight, if you are changing from driving on the left-hand side weight of the vehicle and trailer combination must be reduced by 10% for to the right-hand side. every further 1,000m (or part thereof). The gross combination weight is the actual weight of the laden vehicle plus the actual weight of the laden trailer.
  • Page 175 Driving and the environment Driving tips Note • Driving with a trailer always requires extra care. Towing a trailer places additional demands on the vehicle. We recom- mend additional services between the normal inspection intervals if the Weight distribution vehicle is used frequently for towing a trailer. •...

  • Page 176: Driving Economically And With Respect For The Environment

    Driving and the environment Driving economically and with respect for the Regular servicing environment By taking your car to an Authorised Service Centre for regular servicing you can establish a basis for good fuel economy before you start driving. A well- serviced engine gives you the benefit of improved fuel efficiency as well as General notes maximum reliability and an enhanced resale value.
  • Page 177 Driving and the environment Directly after a cold start, the engine uses about 50-70 litres of fuel per 100 km. This figure then drops to 20-30 litres per 100 km after about one kilometre. The engine only reaches its working temperature after about four kilometres, when fuel consumption will return to a normal level.

  • Page 178: Cleaning And Caring For Your Vehicle

    Cleaning and caring for your vehicle Cleaning and caring for your vehicle General notes WARNING (continued) your vehicle. The use of certain products may produce noxious vapours; Regular washing and care help maintain the value of your these should be used in well ventilated areas. vehicle.

  • Page 179: Care Of The Vehicle Exterior

    Cleaning and caring for your vehicle Care of the vehicle exterior – Clean the wheels, sill panels etc. last using a different sponge or glove. Automatic car washes – Rinse the vehicle thoroughly with water. – Dry the surface of the vehicle gently using a chamois leather. The paint is so durable that the car can normally be washed without problems in an automatic car wash.
  • Page 180 Cleaning and caring for your vehicle luggage compartment, or bonnet. This could cause them to freeze. Otherwise WARNING there is a risk of malfunction. • Never wash tyres with a concentrated jet or cylindrical jet (“rotating nozzle”). Even at large spraying distances and short cleaning times, visible For the sake of the environment and invisible damage can occur to the tyres.
  • Page 181 Cleaning and caring for your vehicle Polishing the paintwork Cleaning windows and exterior mirrors Polishing brings back gloss to the paintwork. Cleaning the windows – Moisten the windows with commercially available, alcohol based Polishing is only necessary if the paint has lost its shine, and the gloss cannot glass cleaner.
  • Page 182 Cleaning and caring for your vehicle • The heating element for the rear window is located on the inner side of the Door lock cylinders window. To prevent damage, do not put stickers over the heating elements on The door lock cylinders can freeze up in winter. the inside of the window.
  • Page 183 Cleaning and caring for your vehicle WARNING WARNING • • Never wash tyres with a cylindrical jet. Even at large spraying distances Never wash tyres with a cylindrical jet. Even at large spraying distances and short cleaning times, visible and invisible damage can occur to the and short cleaning times, visible and invisible damage can occur to the tyres.

  • Page 184: Care Of The Vehicle Interior

    Cleaning and caring for your vehicle Cleaning the engine compartment WARNING (continued) • Take special care when cleaning the engine compartment. Moisture, ice and salt on the brakes may affect braking efficiency. Risk of accident. If possible, avoid sudden braking immediately after washing Anti-corrosion treatment the vehicle.
  • Page 185 SEAT does everything possible to preserve the special qualities of leather, as a natural product. Because of the natural properties of the specially selected Cloth seat covers and fabric trim on the doors, headlining etc. can be cleaned hides employed, the finished leather has a certain sensitivity to grease and with a special interior cleanser or with dry foam and a soft brush.
  • Page 186 Keep the seat belts clean and check all seat belts regularly. Cleaning seat belts – Carefully pull the dirty seat belt right out and leave it out. – Clean the dirty seat belts with a gentle soap solution. – Allow the seat belt fabric to dry.

  • Page 187: Accessories, Parts Replacement And Modifications

    Authorised Service accident. Centre. Your SEAT dealer will be happy to provide you with the latest information about the use, legal requirements and recommendations from the manufac- Modifications turer regarding accessories and parts.

  • Page 188: Roof Aerial

    • radios. transmitting power in excess of 10 watts. SEAT has approved your vehicle for use with mobile telephones and two-way radios providing the following conditions are observed: Note • Please observe the operating instructions of your mobile telephone / two-way The external aerial must be correctly installed, •...

  • Page 189: Fitting A Rear Towing Bracket

    Accessories, parts replacement and modifications Fitting a rear towing bracket* It is possible to fit a towing bracket to the rear of the vehicle. Fig. 132 Attachment points for towing bracket...
  • Page 190 Accessories, parts replacement and modifications If a towing bracket is to be fitted after the vehicle is purchased, this must be Caution completed according to the instructions of the towing bracket manufacturer. If the electrical socket is incorrectly installed, this could cause damage to the The attachment points for the towing bracket are underneath the vehicle.

  • Page 191: Checking And Refilling Levels

    Checking and refilling levels Checking and refilling levels Refuelling The tank flap is at the rear of the vehicle on the right. If the automatic filler nozzle is operated correctly, it will switch itself off as The fuel tank cap opens automatically with the central soon as the tank is “full”.

  • Page 192: Petrol

    Checking and refilling levels Petrol WARNING (continued) − Never fill the spare fuel canister inside the vehicle or on it. An elec- Petrol types trostatic charge could build up during filling, causing the fuel fumes to ignite. There is a danger of explosion. Always place the canister on the The correct petrol types are listed on a sticker inside the fuel ground to fill it.

  • Page 193: Diesel

    Checking and refilling levels containing additives. These additives will help to prevent corrosion, keep the If the datasheet of your vehicle mentions the number PR 2G0 (optional equip- fuel system clean and prevent deposits from building up in the engine. ment) this means that the vehicle is prepared by the manufacturer for the use of biodiesel.

  • Page 194: Working In The Engine Compartment

    However, if the fuel has waxed to such an extent that the engine will not start batteries, are being constantly developed. SEAT provides a constant flow of at temperatures of under -24°C, simply place the vehicle in a warm room for information to the Authorised Service Centres concerning modifications.
  • Page 195 Checking and refilling levels WARNING (continued) WARNING • If any work has to be performed when the engine is started or with the All work on the engine or in the engine compartment, e.g. checking and engine running, there is an additional, potentially fatal, safety risk from the refilling fluids, involves the danger of injury and scalding as well as the risk rotating parts, such as the drive belts, alternator, radiator fan, etc., and of accident or fire.
  • Page 196 Checking and refilling levels For the sake of the environment Service fluids leaks are harmful to the environment. For this reason you should make regular checks on the ground underneath your vehicle. If you find spots of oil or other fluids, have your vehicle inspected in a qualified workshop.

  • Page 197: Engine Oil

    Checking and refilling levels Engine oil WARNING (continued) • Wait until no more steam, smoke or coolant is emitted from the bonnet, Engine oil specifications then carefully open the bonnet. • When working in the engine compartment, always observe the safety The engine used must conform with exact specifications.
  • Page 198 Checking and refilling levels Oil properties Viscosity The viscosity class of the oil is selected according to the diagram. When the ambient temperature falls outside the limits of the scale for a short period, an oil change is not required. Fig.
  • Page 199 Checking and refilling levels Mono-grade oil Checking the engine oil level Single grade oils are generally not suitable for all year round use, due to The engine oil dipstick indicates the level of the oil. ranges of viscosity These oils are only useful in a climate that is constantly very cold or very warm.
  • Page 200 Checking and refilling levels ⇒ page 198,  – Pull the dipstick out again and check the oil level Topping up engine oil fig. 137. Top up gradually with small quantities of oil. – Replace the dipstick, pushing it in as far as it will go. The position of the dipstick is shown in the corresponding engine compart- ment diagram ⇒...
  • Page 201 Checking and refilling levels Engine oil specification ⇒ page 196. WARNING (continued) • Before opening the bonnet, read and observe the warnings WARNING ⇒ page 193, “Safety instructions on working in the engine compartment”. • Oil is highly inflammable! Ensure that no oil comes into contact with hot Wait for the engine to cool down.

  • Page 202: Coolant

    Checking and refilling levels Coolant Caution • Other additives may give considerably inferior corrosion protection. The Coolant specifications resulting corrosion in the cooling system can lead to a loss of coolant, causing serious damage to the engine. • Coolant is a mixture of water and at least 40% coolant addi- The coolant additive G 12+ (purple) can be mixed with the additive G 12 tive.
  • Page 203 Checking and refilling levels Opening the coolant expansion tank The coolant additive G 12+ (dyed purple) may be mixed with G 12 (dyed red) and also with G 11. – Switch off the engine and allow it to cool. – To prevent scalding, cover the cap on the expansion tank with a WARNING thick cloth and carefully unscrew the cap ⇒...

  • Page 204: Washer Fluid And Windscreen Wiper Blades

    Checking and refilling levels Washer fluid and windscreen wiper blades WARNING Any work carried out in the engine compartment or on the engine must be  Topping up washer fluid carried out cautiously. • When working in the engine compartment, always observe the safety The water for cleaning the windscreen should always be warnings ⇒...
  • Page 205 Checking and refilling levels Changing the front windscreen wiper blades – Move the blade towards the arm in the opposite direction of the ⇒ fig. arrow , until it clicks into place 141. If the windscreen wiper blades are in perfect condition, you –...
  • Page 206 Checking and refilling levels Changing the rear wiper blade If this is not sufficient, refer to a qualified workshop. A good rear wiper blade is essential for clear rear vision. WARNING Damaged wiper blades should be replaced immediately. Do not drive unless you have good visibility through all windows! •...

  • Page 207: Brake Fluid

    It important that you use only use brake fluid compliant with the US standard black and yellow cap. FMVSS 116 DOT 4. We recommend the use of Genuine SEAT brake fluid. The brake fluid level drops slightly when the vehicle is being used as the brake pads are automatically adjusted as they wear.

  • Page 208: Battery

    Checking and refilling levels Battery WARNING (continued) • Before opening the bonnet to check the brake fluid level, read and observe the warnings ⇒ page 193. Warnings on handling the battery • Brake fluid should be stored in the closed original container in a safe place out of reach of children.
  • Page 209 Checking and refilling levels • If the vehicle is left standing in cold conditions for a long period, protect WARNING (continued) the battery from frost. If it “freezes” it will be damaged. charge. Never short the battery terminals. High-energy sparks can cause injury.

  • Page 210: Wheels

    The battery has been developed to suit the conditions of their location and has special safety features. Storing tyres Genuine SEAT batteries fulfil the maintenance, performance and safety spec- – Mark tyres when you remove them to indicate the direction of ifications of your vehicle.
  • Page 211 Checking and refilling levels New tyres Checking tyre pressure New tyres have to be run in ⇒ page 169. The correct tyre pressure can be seen on the sticker on the The tread depth of new tyres may vary, according to the type and make of tyre inside of the tank flap.
  • Page 212 Checking and refilling levels Tyre service life Wear indicators The original tyres on your vehicle have 1.6 mm high “tread wear The service life of tyres is dependent on tyre pressure, driving indicators”⇒ fig. 144 running across the tread. Depending on the make, style and fitting.
  • Page 213 We recommend that you use only use wheels and tyres which have been tyres or both rear tyres together). A knowledge of tyre designations makes it approved by SEAT for your model. Failure to do so could impair vehicle handling. Risk of accident.
  • Page 214 The prescribed torque for wheel bolts for steel and alloy wheels is 120 Nm. wheels or tyres which have not been approved by SEAT for use with your model may invalidate the vehicle's type approval for use on public roads.
  • Page 215 Checking and refilling levels Information on approved winter tyre sizes can be found in the vehicle's regis- Snow chains tration documents. Use only radial winter tyres. All tyre sizes listed in the vehicle documentation also apply to winter tyres. Snow chains may be fitted only to the front wheels, and only to certain tyre sizes ⇒...

  • Page 216: If And When

    If and when If and when Tools, tyre repair kit and spare wheel WARNING • Do not use the hexagonal socket in the screwdriver handle to tighten Vehicle Tools the wheel bolts. It is impossible to tighten the bolts with the torque neces- sary, risk of accident.
  • Page 217 If and when Compact temporary spare wheel Snow chains For technical reasons, snow chains must not be used on the compact tempo- The compact temporary spare wheel is only intended for rary spare wheel. temporary use over short distances. If you should have a puncture on one of the front wheels when using snow chains, fit the compact temporary spare in place of one of the rear wheels.

  • Page 218: Wheel Change

    If and when WARNING Note • Seek professional assistance if the repair of a tyre puncture is not Put the hazard warning lights on and place the warning triangle in position. possible with the sealing compound. This is for your own safety and also warns other road users. Caution Wheel change If you have to change the wheel on a gradient, block the wheel opposite the...
  • Page 219 If and when After changing a wheel Wheel trims After changing the wheel there are still tasks to complete. The wheel trims must be removed to gain access to the wheel bolts. – Put the tools and jack back in the luggage compartment. –...
  • Page 220 If and when Wheel covers* Loosening the wheel bolts The entire wheel cover must be removed for access to the The wheel bolts must be loosened before raising the vehicle. wheel bolts. Removing – Remove the wheel cover using the spanner and the hook*. –...
  • Page 221 If and when WARNING Loosen the wheel bolts only about one turn before raising the vehicle with the jack, loosening the wheel bolts more than one turn can result in an acci- dent. Note • Do not use the hexagonal socket in the screwdriver handle to loosen or tighten the wheel bolts.
  • Page 222 If and when a large and stable base, if necessary. On a hard, slippery surface (such as Removing a wheel tiles) use a rubber mat or similar to prevent the jack from slipping. – Unscrew the bolts using the hexagonal tool in the handle of the screwdriver (vehicle tool) and place them on a clean surface ⇒...

  • Page 223: Tyre Repair Kit (Tyre-Mobility-System)

    If and when Theft inhibiting wheel bolts Tyres with directional tread pattern A special adapter is required to turn the theft inhibiting wheel Tyres with directional tread pattern must be fitted so that they bolts. rotate in the correct direction. A directional tread pattern can be identified by arrows on the sidewall that point in the direction of rotation.
  • Page 224 If and when Notes for the proper use of the air compressor are included in an additional – Engage the first gear, of put the selector lever to position P. instruction leaflet. – All passengers should leave the vehicle. They should wait in a safe area (for instance behind the roadside crash barrier).

  • Page 225: Fuses

    If and when Inflating the tyre Fuses – Remove the air compressor and hose from the container. Changing a fuse – Screw the retaining nut onto the valve. If a fuse has blown it must be replaced. – Plug the compressor cable into a 12 volt socket. –...
  • Page 226 If and when Fuse cover underneath the steering wheel Colour coding of fuses – Switch off the ignition and the component concerned. Colour Amperes – Identify the fuse for the failed component ⇒ page 226. light brown – Take the plastic clip from inside the fuse cover, fit it onto the blue blown fuse and pull the fuse out.
  • Page 227 If and when Fuses on left side of dash panel Fuses Number Electrical equipment Amperes Petrol and diesel engine control ABS/ESP control Airbag control Heating controls, pressure sensor, heated seats, ESP switch, reverse gear Left and right hand side headlight motor, dimmer, GDL control Gateway, automatic gearbox lever Windscreen relay, heated rear-view mirrors, VDA telephone Trailer control...
  • Page 228 If and when Number Electrical equipment Amperes Heater Door control Cigarette lighter Wiring control 12 V current sockets FSI advance control, petrol relay, EKP 1.6 Vacant Flow gauge, engine Pre-wired Vacuum pump Door control Sunroof Convenience controls Alarm sensor, horn Headlight washer system Seats Engine...
  • Page 229 If and when Number Electrical equipment Amperes Heating jets, heating controls, air, climate Lambda probe Lambda probe Light switch Some of the electrical items listed in the table are only fitted on certain Please note that the above list, while correct at the time of printing, is subject models or are optional extras.
  • Page 230 If and when Number Electrical equipment Amperes Vacant Gateway Petrol injection module power supply Diesel injection module power supply Coil T71 / 20 FSI engine Pump relay ADS pump Horn Vacant Cleaning Vacant Lambda probe Brake pedal, speed sensor 1.6 litre engine, principal relay (relay 100) T 71 diesel EGR 2.0 D2L High pressure fuel pump ARF, gear change valve...
  • Page 231 If and when Number Electrical equipment Amperes Electric windows (front and rear) Electric windows (front) Position in engine compartment: side box Fuses Number Electrical equipment Amperes Alternator < 140 W Alternator > 140 W Power steering PTC's (Supplementary electrical heating using air) Electric ventilator <...

  • Page 232: Lamp Change

    If and when Lamp change Fog lights Fog lights - H3 Rear fixed light General notes Stop/Position - P21W Indicator - P21W Before changing any lamp first turn off the equipment concerned. Do not touch the lamp glass. Fingerprints vaporise in the heat, causing a Rear mobile light unit reduction in the lamp life and condensation on the mirror surface, thus Foglight (left hand side) - P21W...
  • Page 233 If and when Main headlight lamps Turn signal lamps Fig. 155 Main headlight Fig. 156 Turn signal lamps lamps Turn signals – Raise the bonnet. Dipped headlights ⇒ fig. 156 – Rotate the lamp holder to the left and pull. Main beam headlights Side lights –...
  • Page 234 If and when ⇒ fig. 157 Dipped beam lights – Remove the loops in the direction of the arrow and remove the cover. ⇒ fig. 158 – Remove the connector from the lamp. ⇒ fig. 158 – Disengage the retainer spring pressing inwards and to the right.
  • Page 235 If and when ⇒ fig. 160 Main beam lights – Remove the connector from the lamp. ⇒ fig. 160 – Press the spring inwards and to the right. – Extract the lamp and fit the replacement so that it sits correctly into the rebate on the reflector.
  • Page 236 If and when ⇒ fig. 162 Side lights – Extract the lamp holder outwards. – Replace the bulb by pulling this out and inserting the replace- ment. – Installation is done in the reverse order. Rear lights • On the bodywork Indicator, position and brake light •...
  • Page 237 If and when Indicator, position and brake lights on the bodywork Position, fog and rear lights on the tailgate Fig. 163 Indicator posi- tion and brake light on the Fig. 164 Lights on the bodywork tailgate – Press the side piece towards the exterior and take out the lamp holder.
  • Page 238 If and when ⇒ page 236, – Remove the cover by pulling on it. See the arrow – Insert the lampholder in the indicator guide until it clicks into fig. 164. place. – Pull out the lampholder by pressing on the attachment side –...
  • Page 239 If and when Luggage compartment lights – Press the lamp sideways and remove it from its housing ⇒ fig. 168. – Installation is done in the reverse order. Fig. 167 Luggage compartment light Fig. 168 Luggage compartment light – Extract the tulip shaped fitting by pressing on the lower edge of ⇒...
  • Page 240 If and when Registration light – Remove the lamp, moving it in the direction of the arrow and ⇒ fig. outwards 170. – Installation is done in the reverse order. Fig. 169 Registration plate light Fig. 170 Registration plate light ⇒...

  • Page 241: Jump-Starting

    If and when Sunroof light – Remove the lamp, moving it in the direction of the arrow and ⇒ fig. outwards 172. – Installation is done in the reverse order. Jump-starting Jump leads The jump lead must have a sufficient wire cross section. If the engine fails to start because of a discharged battery, the battery can be Fig.
  • Page 242 If and when How to jump start 4. Connect the other end of the black jump lead to a solid metal component which is bolted on to the engine block, or onto the engine block itself of the vehicle with the flat battery. Do not connect it to a point near the battery ⇒...
  • Page 243 If and when WARNING • Please note the safety warnings referring to working in the engine compartment ⇒ page 193, “Working in the engine compartment”. • The battery providing assistance must have the same voltage as the flat battery (12V) and approximately the same capacity (see imprint on battery).

  • Page 244: Towing And Tow-Starting

    If and when Towing and tow-starting Towing rings Tow-starting* The use of jump leads is preferable to tow-starting. We recommend that you do not tow-start your vehicle. Jump-starting is preferable ⇒ page 240. However, if your vehicle has to be tow-started –...
  • Page 245 If and when Notes for the driver of the towing vehicle A tow-rope should be slightly elastic to reduce the loading on both vehicles. It is advisable to use a tow-rope made of synthetic fibre or similarly elastic – Drive slowly at first until the tow-rope is taut. Then accelerate material.
  • Page 246 If and when • Switch on the hazard warning lights of both vehicles. However, observe any regulations to the contrary. • For technical reasons, vehicles with an automatic gearbox must not be tow-started. • If damage to your vehicle means that there is no lubricant in the gearbox, you must raise the drive wheels while the vehicle is being towed.
  • Page 247 If and when...

  • Page 248: Technical Data

    General notes on the technical data Technical Data General notes on the technical data What you should be aware of General notes All data in the official vehicle documents take precedence over this data. All data in these documents are valid for the basic model as offered in Spain. The figures may vary for different models, for special vehicles and for other The vehicle data card included in the inspection and maintenance schedule countries, depending upon the optional extras and the version.
  • Page 249 General notes on the technical data Vehicle identification data Vehicle identification number The vehicle identification number (chassis number) can be read from outside the vehicle through a viewer in the windscreen. This is located on the left- hand side of the vehicle in the lower area of the windscreen. It is also located on the right hand side of the engine compartment.

  • Page 250: How Are The Figures Measured

    General notes on the technical data How are the figures measured? Fuel consumption Fuel consumption and emission values are determined according to Euro- measuring cycles are carried out on a rolling road test bed. The test criteria pean Commission Directive 99/100/EC. They take the actual kerb weight are as follows: (weight class) into consideration.

  • Page 251: Towing A Trailer

    General notes on the technical data Weights Drawbar load The maximum permitted weight exerted by the trailer drawbar on the ball joint of the towing bracket must not exceed 75 kg. Kerb weight refers to the basic model with a fuel tank filled to 90% capacity and without optional extras.
  • Page 252 General notes on the technical data Snow chains Snow chains may be fitted only to the front wheels. Consult the chapter “wheels” of this manual. Wheel bolts After the wheels have been changed, the tightening torque of the wheel bolts should be checked as soon as possible with a torque wrench ⇒...

  • Page 253: Technical Data

    Technical Data Technical Data Checking fluid levels Overview Further explanations, instructions and restrictions on the technical data are contained as of ⇒ page 247. From time to time, the levels of the different fluids in the vehicle must be checked. Never mix up the fluids, to do so may cause serious damage to the engine.

  • Page 254: Petrol Engine 1.6L 75 Kw (102 Bhp)

    Technical Data Petrol engine 1.6l 75 kW (102 bhp) General engine data Power output in kW (bhp) 75 (102)/ 5600 Maximum torque in Nm at rpm 148/ 3800 No. of cylinders, capacity 4/ 1595 in cm 10,5 ± 0,5 Compression Fuel Premium unleaded 95 RON or Regular unleaded 91 RON Slight power loss...

  • Page 255: Petrol Engine 2.0L 110 Kw (150 Bhp)

    Technical Data Weights Gross vehicle weight in kg 1783 Weight in working order (with driver) in kg 1280/ 1395 Gross axle weight, front in kg Gross axle weight, rear in kg Permitted roof load in kg Trailer weights With no brakes, gradients up to 12% With brakes, gradients up to 12% 1200 Engine oil capacity...
  • Page 256 Technical Data Performance figures Maximum speed in km/h Acceleration from 0-80 km/h in sec. Acceleration from 0-100 km/h in sec. Consumption (litres/100 km)/ CO (g/km) Urban cycle 11,1/266 11,3/271 Extra urban cycle 6,1/146 6,4/151 Combined 7,9/190 8,2/197 Weights Gross vehicle weight in kg 1830 Weight in working order (with driver)

  • Page 257: Petrol Engine 2.0L 110 Kw (150 Bhp). Automatic

    Technical Data Petrol engine 2.0l 110 kW (150 bhp). Automatic Engine oil capacity Engine oil capacity with oil filter change 5.3 litres General engine data General engine data Power output in kW (bhp) 110 (150)/ 6000 Maximum torque in Nm at rpm 200/ 3500 No.

  • Page 258: Diesel Engine 1.9L Tdi 77 Kw (105 Bhp)

    Technical Data Weights Gross vehicle weight in kg 1870 Weight in working order (with driver) in kg 1375 /1482 Gross axle weight, front in kg 1024 Gross axle weight, rear in kg Permitted roof load in kg Trailer weights With no brakes, gradients up to 12% With brakes, gradients up to 12% 1400 Engine oil capacity...
  • Page 259 Technical Data Performance figures Performance figures Maximum speed in km/h Acceleration from 0-80 km/h in sec. Acceleration from 0-100 km/h in sec. 11,3 Consumption (litres/100 km)/ CO (g/km) Urban cycle Extra urban cycle Combined Weights Gross vehicle weight in kg 1868 Weight in working order (with driver) in kg...

  • Page 260: Diesel Engine 2.0L 103 Kw (140 Bhp) 16V

    Technical Data Diesel engine 2.0l 103 kW (140 bhp) 16V General engine data Power output in kW (bhp) 103 (140)/ 4000 Maximum torque in Nm at rpm 320/ 1750 - 2500 No. of cylinders, capacity 4/ 1968 in cm 18,5 ± 0,5 Compression Fuel Min 49 CZ...

  • Page 261: Diesel Engine 2.0L 103 Kw (140 Bhp) 16 V. Automatic

    Technical Data Weights Gross vehicle weight in kg 1885 Weight in working order (with driver) in kg 1390/ 1497 Gross axle weight, front in kg 1042 Gross axle weight, rear in kg Permitted roof load in kg Trailer weights With no brakes, gradients up to 12% With brakes, gradients up to 12% 1400 Engine oil capacity...
  • Page 262 Technical Data Performance figures Maximum speed in km/h Acceleration from 0-80 km/h in sec. Acceleration from 0-100 km/h in sec. Consumption (litres/100 km)/ CO (g/km) Data not available at the time of going to print Urban cycle Extra urban cycle Combined Weights Gross vehicle weight...

  • Page 263: Diesel Engine 2.0L 100 Kw (136 Bhp) 16V

    Technical Data Diesel engine 2.0l 100 kW (136 bhp) 16V General engine data General engine data Power output in kW (bhp) 100 (136)/ 4000 Maximum torque in Nm at rpm 320/ 1750 - 2500 No. of cylinders, capacity 4/ 1968 in cm 18,5 ±...

  • Page 264: Diesel Engine 2.0L 100 Kw (136 Bhp) 16 V. Automatic

    Technical Data Weights Gross vehicle weight in kg 1885 Weight in working order (with driver) in kg 1390/ 1497 Gross axle weight, front in kg 1042 Gross axle weight, rear in kg Permitted roof load in kg Trailer weights With no brakes, gradients up to 12% With brakes, gradients up to 12% 1400 Engine oil capacity...
  • Page 265 Technical Data Performance figures Maximum speed in km/h Acceleration from 0-80 km/h in sec. Acceleration from 0-100 km/h in sec. Consumption (litres/100 km)/ CO (g/km) Data not available at the time of going to print Urban cycle Extra urban cycle Combined Weights Gross vehicle weight...

  • Page 266: Dimensions And Capacities

    Technical Data Dimensions and capacities Dimensions Dimensions Length, width 4,315 mm/ 1,768 mm Height at kerb weight 1,459 mm Front and rear projection 949 mm/ 788mm Wheelbase 2,578 mm Turning circle 10.7 m Front Rear 1,525 mm 1,509 mm Track width 1,533mm 1,517 mm This data will change depending on the type of wheel rim...
  • Page 267 Technical Data...

  • Page 268: Index

    Warning lamp ......32 Adjusting the seat belt height ....27 Anti-theft alarm system .
  • Page 269 Cockpit ....... . . 55 Child seat ....... 48...
  • Page 270 Emergency opening seat ....... 31 Doors ......101 Driving safety .
  • Page 271 Avoiding pollution ....191 Head restraints Front seat adjustment Adjusting ..... . . 125, 126 ESP .
  • Page 272 Index Indicator lights Multi-function display ..... 61 Indication lamp ..... . . 75 Lamp changes Information texts in the display .
  • Page 273 Roof aerial* ......187 Seat belts ....... 19 Radio wave remote control .
  • Page 274 Stowage compartment To fold down the seat back ....128 Function ......39 Front passenger side .
  • Page 275 Car care products ....177 Why wear seat belts? ....19, 21 Vehicle tools Why wear seatbelts? .
  • Page 276 SEAT S.A. is permanently concerned about continuous development of its types and models. For this reason we ask you to understand, that at any given time, changes regarding shape, equipment and technique may take place on the car delivered. For this reason no right at all may derive based on the data, drawings and descriptions in this current handbook.
  • Page 277 auto emoción...

Table of Contents

Save PDF
