- Page 1 FDX‐M2P (FDX‐M2U) User Manual Dual DVI-D Extender Extends 2 DVI-D Signals, Audio and USB Keyboard and Mouse up to 1,400 feet over 2 Fiber Optic Cables Made in U.S.A. www.SmartAVI.com 1-800-AVI-2131...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WHAT'S IN THE BOX? INTRODUCTION FEATURES APPLICATIONS TECHNICAL SPECIFICATIONS HARDWARE INSTALLATION EDID LEARNING—ON SCREEN DISPLAY LIMITED WARRANTY STATEMENT WHAT’S IN THE BOX? PART NO. QTY DESCRIPTION FDX-TXM2P Dual DVI-D, USB Keyboard & Mouse, Audio and RS232 Multimode Fiber Extender (Transmitter) FDX-RXM2P Dual DVI-D, USB Keyboard &... -
Page 3: Introduction
The FDX-M2U allows the workstation computers to be housed in a central location, away from sensitive devices. INDUSTRIAL WORK AREAS In industrial work areas that may be too harsh for a workstation computer, the FDX-M2P can consolidate the computers into a safe location. SECURE COMPUTING be centralized When it comes to security, the FDX-M2P is an excellent deployment option. -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS VIDEO Resolution Up to 1920 x 1200 @60Hz Format DVI-D Single Link Input Interface (2) DVI-D 29-pin female Output Interface (2) DVI-D 29-pin female Maximum Pixel Clock 165 MHz Programmable Internal Table 5 volts p-p(TTL) Input Equalization Automatic Input Cable Length Up to 20 ft. -
Page 5: Hardware Installation
10. Connect the power cords and power on the FDX-TXM2P and the FDX-RXM2P. The status LEDs will flash. It will take up to 30 seconds for the FDX-M2P to learn the EDID settings from the Link 2 con- nected DVI display. Once the EDID settings are learned the LEDs will stop flashing. -
Page 6: Edid Learning—On Screen Display
EDID LEARNING—ON SCREEN DISPLAY Pressing the “Ctrl” key twice followed by the letter “o” then hitting the “Enter” key activates the On Screen Display on Link 1. Figure 6-1 “Edid Learn” learns Edid settings from the monitor connected to Link 1. The “1920X1080”... -
Page 7: Limited Warranty Statement
LIMITED WARRANTY STATEMENT A. Extent of limited warranty Smart‐AVI Technologies, Inc. warrants to the end‐user customers that the Smart‐AVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. Smart‐AVI limited warranty covers only those defects which arise as a result of normal use of the product, and do not apply to any: a. Improper or inadequate maintenance or modifications b. Operations outside product specifications c. Mechanical abuse and exposure to severe conditions If Smart‐AVI receives, during applicable warranty period, a notice of defect, Smart‐AVI will at its discretion replace or repair defective product. If Smart‐AVI is unable to replace or repair defective product covered by the Smart‐AVI warranty within reasonable period of time, Smart‐AVI shall refund the cost of the product. Smart‐AVI shall have no obligation to repair, replace or refund unit until customer returns defective product to Smart‐AVI. Any replacement product could be new or like new, provided that it has functionality at least equal to that of the product being replaced. Smart‐AVI limited warranty is valid in any country where the covered product is distributed by Smart‐AVI. B. Limitations of warranty To the extant allowed by local law, neither Smart‐AVI nor its third party suppliers make any other warranty or condition of any kind whether expressed or implied with respect to the Smart‐AVI product, and specifically disclaim implied warranties or conditions of merchantability, satisfactory quality, and fitness for a particular purpose. C. Limitations of liability ... - Page 8 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no war‐ ranty of any kind with regard to this material, including but not limited to, implied warranties of merchant‐ ability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for inci‐ dental or consequential damages in connection with the furnishing, performance or use of this material. No part of this document may be photocopied, reproduced, or translated into another language without prior written consent from SmartAVI Technologies, Inc. 20160920 ...
