Ordering an Antenna
An antenna with matting connector can be ordered, for example, from Multi-Tech or GMBH:
MMCX Plug
The SocketModem requires an MMCX plug to connect to an antenna.
Multi-Tech Systems, Inc. SocketModem EDGE Embedded Wireless Modem Developer's Guide (S000376A)
6-Inch Antenna Cable – SMA Jack to MMCX Plug
Multi-Tech Systems, Inc.
http://www.multitech.com
Order No: 45009630
IMS Connectors Systems GMBH
http://www.imscs.com/
MMCX Connector Example (right angle type)
A small MMCX / SMA adapter can be ordered, for example, from:
Amphenol
http://www.amphenol.com/
Order No: 908-31100
Chapter 4 - SocketModem Interfaces
15
