Detect, display and store all the electrical signal of five parameters,
namely amplitude, frequency, shape, pulse width, and array.

1.3 Product function

Provides specialized automotive oscilloscope function and supports ignition
waveform analysis.

1.4 Technical parameters

Scopebox: 4 channels, highest sampling frequency 200MHZ, max storage
depth 64MSa, 8-bit resolution.
