B.1.1 Prototyping Board Features
•
•
•
•
•
•
•
•
•
User's Manual
Downloaded from Elcodis.com electronic components distributor
Power Connection —A power-supply jack and a 3-pin header are provided for con-
nection to the power supply. Note that the 3-pin header is symmetrical, with both outer
pins connected to ground and the center pin connected to the raw V+ input. The cable
of the AC adapter provided with the North American version of the Development Kit
ends in a plug that connects to the power-supply jack. The header plug leading to bare
leads provided for overseas customers can be connected to the 3-pin header in either
orientation.
Users providing their own power supply should ensure that it delivers 8–24 V DC at
8 W. The voltage regulators will get warm while in use.
Regulated Power Supply
routed to a 5 V switching voltage regulator, then to a separate 3.3 V linear regulator.
The regulators provide stable power to the RCM3000 module and the Prototyping
Board.
Power LED —The power LED lights whenever power is connected to the Prototyping
Board.
—A momentary-contact, normally open switch is connected directly to the
Reset Switch
RCM3000's /RESET_IN
I/O Switches and LEDs
nected to the PG0 and PG1 pins of the master RCM3000 module and may be read as
inputs by sample applications.
Two LEDs are connected to the PG6 and PG7 pins of the master module, and may be
driven as output indicators by sample applications.
Prototyping Area —A generous prototyping area has been provided for the installation
of through-hole components. +3.3 V, +5 V, and Ground buses run around the edge of
this area. Several areas for surface-mount devices are also available. (Note that there
are SMT device pads on both top and bottom of the Prototyping Board.) Each SMT pad
is connected to a hole designed to accept a 30 AWG solid wire.
Master Module Connectors
of the first RCM3000, RCM3100, or RCM3200 module that serves as the primary or
"master module."
Slave Module Connectors
lation of a second, slave RCM3000, RCM3100, or RCM3200 module. This capability
is reserved for future use, although the schematics in this manual contain all of the
details an experienced developer will need to implement a master-slave system.
Module Extension Headers
SLAVE RabbitCore modules are duplicated at these two sets of headers. Developers
can solder wires directly into the appropriate holes, or, for more flexible development,
26-pin header strips can be soldered into place. See Figure B-4 for the header pinouts.
—The raw DC voltage provided at the POWER IN jack is
pin. Pressing the switch forces a hardware reset of the system.
—Two momentary-contact, normally open switches are con-
—A set of connectors is pre-wired to permit installation
—A second set of connectors is pre-wired to permit instal-
—The complete pin sets of both the and
MASTER
