2.2 PRODUCT OVERVIEW

SCOUT DIAGRAM
1. Rotor blades
2. Feet
3. Power Switch
4. Rotor Guards
Battery Hatch/Flap
5.
Camera
6.
REMOTE CONTROL DIAGRAM
Antenna
1.
2. Directional Lock
3. Left Thumb Stick
4. Throttle Trimming
5. YawTrimming
6. Flip Button
Power Switch
7.
Right Thumb Stick
8.
9. Back / Forward Pitch Trimming
10. Left/Right Roll Trimming
11. Speed Mode Button
12. Light On/Off
13. Video Button
14. Photo Button
_8
Capture the skies.™
1
3
2
1
2
3
4
5
6
5
* Micro SD Card not included
4
6
7
8
9
10
11
12
13
14
