- Page 1 THERMO PRODUCTS USER MANUAL FIANDRA IDRO MADE ITALY design & production 004276688 - Rev 005...
- Page 2 ENGLISH...
-
Page 3: Table Of Contents
Fumes eXHaust sYstem............................................9 HyDrauLIc SyStEM ...................................... 10 installation and saFetY devices ......................................10 aNtI-coNDENSatIoN DEVIcE (MaNDatory) ............................11 fIaNDra IDro DEtaILS ....................................12 on/oFF ..................................................12 fEaturES........................................13 cHEckS aND MEaSurES for coMMISSIoNING ............................13 tHe pellet load motor does not Function: ..................................13 bulb tHermostats - rearm ..........................................13... - Page 4 ATTENZIONE TASSATIVO PrImA dI mOVImENTArE lA STufA TOglIErE lE mAIOlIchE INdIcATE PEr EVITArE dANNI. ATTENTION - cOmPulSOrY BEfOrE mOVINg ThE STOVE, kINdlY TAkE ThE cErAmIcS Off IN OrdEr TO AVOId ANY dAmAgES ATTENTION - OBlIgATOIrE AVANT dE BOugEr lE POêlE , fAIrE ATTENTION à lEVEr lES cérAmIquES INdIquéES POur éVITEr dES dégâTS VOrSIchT - OBlIgATOrISch BEVOr SIE dEN OfEN BEwEgEN , BITTE uNBEdINgT dIE BEZEIchNETE kErAmIk...
-
Page 5: English
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner or user, or if transferred to another place. -
Page 6: Routine Maintenance
Š DO NOT LEAVE THE PACKAGING ELEMENTS WITHIN REACH OF CHILDREN OR UNASSISTED DISABLED PERSONS. Š THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL FUNCTIONING OF THE PRODUCT. Š WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH, ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID Š... -
Page 7: Installation
InstallatIon general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. the installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);... - Page 8 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...
-
Page 9: Hermetic Installation
Hermetic installation Fiandra Idro is a completely sealed product with respect to the installation environment, which makes it ideal for passive houses, as it does not take air from inside the homes. combustion air To respect the air-tight seal of the stove, the combustion air connection pipe must be directly connected to the outside using specific sealed fittings and pipes. -
Page 10: Hydraulic System
Standards in force, national, regional and municipal, as well as these instructions. For Italy, installation must be carried out by professionally qualified staff (Ministerial Decree dated 22.01.08 n°37). Extraflame S.p.A. declines all responsibility for damage to objects and/or persons caused by the system. TYPE OF SYSTEM Š... -
Page 11: Anti-Condensation Device (Mandatory)
DISTANCES OF SAFETY DEVICES ACCORDINg TO THE STANDARD The temperature safety sensors must be in place on the machine at a distance no greater than 30 cm from the flow connection. Whenever the generators lack a device, those missing can be installed on the generator flow pipe, within a distance no greater than 1 m from the machine. COMMISSIONINg CHECkS Before connecting the boiler: a) wash all system piping thoroughly in order to remove any residues which might compromise the correct functioning of certain system... -
Page 12: Fiandra Idro Details
FIANDRA IDRO DetAIls Room air outlet Heat exchanger scrapers Door handle Heat exchanger scrapers Access to the ash Pellet hopper drawer pressurised closure Room air outlet Radio/emergency card Fumes exhaust On/OFF Fuse Power supply 230v Combustive air input HyDRAulIc INstAllAtION... -
Page 13: Features
FeAtuRes Water content of the thermo-product heat exchanger (l) volume of expansion vessel integrated into thermo-product (l) 3 bar safety valve integrated into the thermo-product Minimum and maximum pressure switch integrated into the thermo-product Pump integrated into the thermo-product Pump max. head (m) Envision any inTEgraTivE Expansion vEssEl on ThE Basis of ThE sysTEm WaTEr conTEnT. -
Page 14: Stove Positioning
stOve pOsItIONINg For correct product functioning, it is recommended to position it in a way that it is perfectly level, with the aid of a spirit level. NOte FOR cORRect OpeRAtION Pellet hopper lid The following indications must be respected for correct pellet stove operation: During stove operation, the pellet hopper lid and the door must always be closed. -
Page 15: Pellets And Feeding
Pellets and feeding Pellets are made by subjecting wood shavings i.e. the rejects of pure wood (without paint) sawmill, carpenter products and products from other activities connected to working and transforming wood, to very high pressures. This type of fuel is fully ecological as no glues are used to hold it together. In fact, the compactness of the pellets is guaranteed over time by a natural substance that is found in wood: wood coal. -
Page 16: Radio/Emergency Card
Radio/emeRgency caRd The stove is fitted with an emergency radio card located at the side, allowing the basic operation of the stove in the event the LCD handheld remote is damaged or malfunctions. Not in use The functions that can be managed from the emergency card are: Power supply presence Power decrease LED off: stove off... -
Page 17: Lcd Handheld Remote
lcd handheld remOte cOnFIGUratIOn HAndHeld codIng procedUre: 1. disconnect the power supply to the stove. 2. press the keys at the same time until the UnIT selection screen appears. 3. Using the keys, select the new UnIT. 4. power the stove. confirm the selected unit within 10 seconds (all leds flash on the radio/emergency card) by pressing the oK key on the handheld. -
Page 18: Handheld Features
handheld FeatUreS The handheld is fitted with an lcd backlit display. The display remains lit for 5 seconds. After a certain period of time, in order to minimise battery consumption, the display turns off (sleep mode). It turns on again after pressing the on/oFF key (6). caUtIOn! do not place the handheld in direct or indirect contact with water. -
Page 19: Display
dISplay sCReen wiTh venTilaTiOn nOT enaBled Stby active chrono active Battery flat power 1-5 Hour Water temperature (H2o) detected in the boiler Set H2o temperature set Text display sCReen wiTh venTilaTiOn enaBled Stby active chrono active Battery flat power 1-5 Hour Water temperature (H2o) Temperature detected in... -
Page 20: General Menu
General menU FUnCTiOn FUnCTiOn Scroll parameters Back - exit key modify settings on - off key Access menu key poWer room. Temp. H2o Temp. VenTIlATIon SeT cHrono enABle cHrono eASY SeTUp SeT prg 1 SeT prg 2 SeT prg 3 SeTTIngS dATe/TIme SeT prg 4... -
Page 21: Commissioning Settings
cOmmISSIOnInG SettInGS once the power cable at the back of the generator has been connected, move the switch, also located on the back, to (I). The switch at the back of the generator powers the generator board. The generator remains off and a first screen appears on the panel reading oFF. lIne FreqUency 50/ 60hz If the generator is installed in a country with a frequency of 60Hz, the generator will display "incorrect line frequency". -
Page 22: Operation And Logic
OperatIOn and lOGIc IGnItIOn once the previously listed points have been checked, press the key for three seconds to ignite the stove. 15 minutes are available for the ignition phase. After ignition and after reaching the control temperature, the stove interrupts the ignition phase and switches to prepArATIon. preparatIOn during the preparation phase, the stove stabilises combustion, increasing it progressively, to then start ventilation and switch to WorK. -
Page 23: Set
pOwer The menu allows the generator power to be set. minimum power 1, maximum power 5. To set: oK > Set > Power. rOOm temperatUre The menu allows the room temperature to be reached to be set (front ventilation must be active). range: oFF - 07 - 40°c. -
Page 24: Set Chrono
Set chrOnO This function allows the generator's ignition and switch-off to be automatically programmed. By factory default, the SeT cHrono is disabled. The chrono allows the programming of 4 time slots within a day, which can be used every day of the week. Ignition and switch-off times can be set for each time slot, along with the specific days of application for the programmed time slot and the desired temperature. -
Page 25: Settings
SettInGS date/tIme Š lanGUaGe See cHApTer: commISSIonIng SeTTIngS. Š Set deGreeS Š dISplay The "dISplAY" menu allows: Š Set the timer to turn off the display Š regulation of display contrast backlight. Š Activation/deactivation of backlight. Š Set the timer to turn off the display (sleep Š... -
Page 26: Additional Functions
addItIOnal FUnctIOnS If the producer's conveyed wave accessories are used, the connection must be made by the qualified technician directly in the board. contact the dealer for further details lcd handheld remOte rOOm prOBe calIBratIOn This mode allows calibration of the room temperature detected by the lcd handheld remote (with ventilation active only). For correct calibration, it is recommended to position the lcd handheld remote in a room with constant temperature and wait for at least two hours. -
Page 27: Cleaning And Maintenance
TO FIND OUT WHICH IS YOUR NEAREST AFTER-SALES CENTRE, CONTACT YOUR DEALER OR VISIT THE WEBSITE WWW.LANORDICA-EXTRAFLAME.COM Cleaning and maintenanCe always follow the indiCations in maximum safety! Š Make sure that the power supply cable plug is disconnected, since the generator could be programmed to switch-on. - Page 28 every 7 days burn Pot and Combustion Chamber: The burn pot is cleaned via a mechanical system at pre-fixed intervals automatically by the boiler. It is recommended to remove any residues using a suction device. Š Suck up the ash deposited between separator and fire door.
-
Page 29: Routine Maintenance Performed By Enabled Technicians
Qualified Person, so as to avoid all risks. TO FIND OUT WHICH IS YOUR NEAREST AFTER-SALES CENTRE, CONTACT YOUR DEALER OR VISIT THE WEBSITE WWW.LANORDICA-EXTRAFLAME.COM routine maintenanCe Performed by enabled teChniCians routine maintenance must be performed at least once a year. - Page 30 TO FIND OUT WHICH IS YOUR NEAREST AFTER-SALES CENTRE, CONTACT YOUR DEALER OR VISIT THE WEBSITE WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE ILLUSTRATIONS ONLY. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the points envisioned Gaskets, pellet tank, inspections, ash drawer and door (replace and apply silicone where required) Combustion chamber and heat exchanger (full cleaning) including ignition-plug pipe Hopper (complete emptying and cleaning).
-
Page 31: Displays
Take the stove to OFFconditions using key 1 and repeat the procedure No current during the ignition phase. Black ouT described in the "Ignition" chapter. * on models set-up. TO FIND OUT WHICH IS YOUR NEAREST AFTER-SALES CENTRE, CONTACT YOUR DEALER OR VISIT THE WEBSITE WWW.LANORDICA-EXTRAFLAME.COM ENGLISH... - Page 32 Pump blocked. Electronic module damaged Pump blocked. floW pWM alaRM Liquid with high density. Contact after-sales centre Pipe obstructed. * on models set-up. TO FIND OUT WHICH IS YOUR NEAREST AFTER-SALES CENTRE, CONTACT YOUR DEALER OR VISIT THE WEBSITE WWW.LANORDICA-EXTRAFLAME.COM ENGLISH...
-
Page 33: Guarantee Terms
Extraflame S.p.A. cannot be held liable for injury or damage which may - either directly or indirectly - be caused to persons, animals and property ensuing from failure to observe all the instructions provided in the relevant instruction manual and the warnings regarding installation, use and maintenance of the product, that can also be downloaded on the website. - Page 34 AddITIONAL wARNINGs Š Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator. Š Do not use the product as a ladder or supporting structure. Š Do not place laundry on the product to dry it. Any clothes-horse or similar objects must be kept at due distance from the product. Danger of fire or damage to the coating.
- Page 35 ENGLISH...
- Page 36 Extraflame S.p.A. Via Dell’Artigianato, 12 36030 - MONTECCHIO PRECALCINO (VI) - ITALY +39.0445.865911 - +39.0445.865912 - info@extraflame.it - www.lanordica-extraflame.com MADE ITALY design & production TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM...
