Summary of Contents for Winmate I330
- Page 1 3.5” Fan/Fanless SBC w/Intel Socket M CPU, VGA, LCD, Giga Ethernet, RAID and Mini-PCI Interface. USER MANUAL Version 1.3...
-
Page 2: Fcc Statement
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at hi m own expense. I330 Motherboard User Manual... -
Page 3: Copyright Notice
. If the customer discovers a defect, Winmate will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period of one year, with transportation charges prepaid. -
Page 4: Packing List
Customer Service We provide service guide for any problem as fo llow steps First, visit the website at http://www.winmate.com to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assista nce. -
Page 5: Safety Precautions
As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static -shielded bag when they are not in the chassis. I330 Motherboard User Manual... - Page 6 F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. I330 Motherboard User Manual...
-
Page 7: Revision History
Initial Draft Aladin Huang 2007.09.13 Add Driver/BIOS Aladin Huang 2007.09.17 Double Check Spec. Aladin Huang 2007.10.01 I330_110 Spec Aladin Huang 2007.10.02 H/W double check Ted Lin 2007.11.07 Add 2.5.13 Aladin Huang 2008.01.14 Revise 2.5 Aladin Huang I330 Motherboard User Manual... -
Page 8: Table Of Contents
STANDARD CMOS SETUP … ……………………………… .43 ADVANCED BIOS FEATURES……………………………… .45 ADVANCED CHIPSET FEATURES………………………… .48 INTEGRATED PERIPHERALS……………………………… ..51 PC HEALTH STATUS………………………………………… .54 FREQUENCY/VOLTAGE CONTROL ………………………..56 LOAD FAIL-SAFE DEFAULTS……………………………… .59 7.10 LOAD OPTIMIZED DEFAULTS…………………………… ... 60 7.11 SET SUPERVISOR/USER PASSWORD……………………… 61 VIII I330 Motherboard User Manual... - Page 9 7.12 LOAD FAIL-SAFE DEFAULTS……………………………… .61 7.13 SET SUPERVISOR/USER PASSWORD…………………… ...61 7.14 EXIT WITHOUT SAVING…………………………………… .61 I330 Motherboard User Manual...
- Page 10 This chapter includes the I330 Motherboard background information. Sections include: Introduction Feature Motherboard Specification Function Block Board Dimensions I330 Motherboard User Manual...
-
Page 11: General Information
Serial ATA connectors, and eight Hi-Speed USB 2.0 connectors. Additionally, I330 SBC build-in a 12V DC-IN power adapter. Thus, the I330 SBC is designed to satisfy most of the applications in the industrial computer market, such as Gaming, POS, KIOSK, Industrial Automation, and Programmable Control System. -
Page 12: Motherboard Specifications
Operating temperature: 0 deg. C to 60 deg. C Operating Humidity: 10 ~ 90% Relative humidity, Mechanical & non-condensing environmental Shock: Operating 15G, 11ms duration Vibration: Operating 5 Hz~500Hz / 1Grms / 3 Axis Certification: CE, FCC, RoHS I330 Motherboard User Manual... -
Page 13: Function Block
18bit/Dual CH DDR2 667/533 Max.2GB 2GB/s ATA100 1GB/s IDE Host Intel ICH7M 3GB/s 480MB/s SATA II 1, SATAII 2 NH82801GBM CF Card Slot Audio Realtek ALC655 33MHz Mini PCI Super IO Realtek ALC655 ROM FWH Realtek ALC655 I330 Motherboard User Manual... -
Page 14: Board Dimensions
Board dimensions I330 Motherboard User Manual... - Page 15 This chapter provides information on how to use the jumps and connectors on the I330 Motherboard. The Sections include: Memory Module Installation I / O Equipment Installation Setting the Jumpers Connectors on I330 Motherboard I330 Motherboard User Manual...
-
Page 16: Installations
Installations 2.1 Memory Module SODIMM Installation The I330 Motherboard provides one 200 -pin SODIMM slot. The socket supports up to 2GB DDR2 400 SDRAM. When installing the Memory device, please follow the steps below Step.1. Firmly insert the SODIMM at an angle into its slot. Align the SODIMM on the slot such that the notch on the SODIMM matches the break on the slot. -
Page 17: I/O Equipment Installation
Various adapters may come with USB po rts. USB usually connect the external system to the system. The USB ports support hot plug -in connection. Whatever, you should install the device driver before you use the device. I330 Motherboard User Manual... - Page 18 2.2.7 Audio function The Audio 5.1 channel capabilities are provided by a Realte k ALC655 chipset supporting digital audio outputs. The audio interface includes two jacks: line-in and line-out. I330 Motherboard User Manual...
-
Page 19: Jumpers And Connectors
2.3 Jumpers and Connectors JP301 MINI_PCI ATX 12V 901 I330 Motherboard User Manual... - Page 20 BOTTOM CF Card Slot SO-DIMM Locating Jumpers and Connectors (rear side) I330 Motherboard User Manual...
-
Page 21: Jumper Setting
Clear CMOS Normal Pin No. Functions 1 Short 2 Clear CMOS 2 Short 3 Normal 2.4.2 JP602: RS232 / RS422 / RS485 Selector The jumper can be configured to operate COM1 in RS-232/422/485 mode. And the I330 Motherboard User Manual... - Page 22 2.4.4 CON908: LCD Panel Voltage Select CON908 can be configured to operate in 3.3Volts / 5Volts / 12Volts mode. 3.3Volts 5Volts 12Volts Pin No. Functions 1 Short 2 3.3Volts Selected 2 Short 3 5Volts Selected 5 Short 6 12Volts Selected I330 Motherboard User Manual...
-
Page 23: Connectors And Pin Assignment
5V External Power 2x1 header, pitch 2.0mm 12V External Power header ,pitch 2.54mm ATX 12V 901 12V DC Jack 4 Pin Jack 12V DC Connector 4 Pin Connecter CON909 Digital I/O 2x5 Pin header * Not Default Connector I330 Motherboard User Manual... - Page 24 SYMBOL Pin No. SYMBOL LCDVDD LVDS_LTX0- LCDVDD LVDS_LTX0+ LCDVDD LVDS_LTX1- LVDS_LTX1+ LVDS_LTX2- LVDS_LTX2+ LVDS_LCLK- LCDS_LCLK LVDS_UTX0- LVDS_UTX0+ LVDS_UTX1- LVDS_UTX1+ LVDS_UTX2- LVDS_UTX2+ LVDS_UCLK- LVDS_UCLK 2.5.2 JP902: Digital Panel Backlight Brightness Control Pin No. SYMBOL Black Light Control I330 Motherboard User Manual...
- Page 25 +12V +12V Black Light Control Black Light EN 5V 2.5.4 PSKBM1: PS2 K/B Mouse Connector 6-pin Mini Din Signal Name Keyboard Mouse Signal Name Keyboard data Mouse data N.C. N.C. Keyboard clock Mouse clock N.C. N.C. I330 Motherboard User Manual...
- Page 26 SYMBOL Pin No. SYMBOL FK NRI2 FK NDTR2 FK NCTS2 FK NSOUT2 FK NRTS2 FK NSIN2 FK NDSR2 FK NDCD2 FK NRI1 FK NDTR1 FK NCTS1 FK NSOUT1 FK NRTS1 FK NSIN1 FK NDSR1 FK NDCD1 I330 Motherboard User Manual...
- Page 27 DD13 DD14 DD15 GND1 DREQ GND4 DIOW# GND5 DIOR# GND6 IO_RDYD CSEL DACK# GND7 IOCS16# CBL_ID# DCS#1 DCS#3 DASP# GND8 +5V1 +5V2 2.5.7 USB2: USB PIN HEADER USB2 SYMBOL SYMBOL USBVCC USBVCC USB_P6- USB_P7- USB_P6+ USB_P7+ I330 Motherboard User Manual...
- Page 28 2.5.8 NB_FAN901/CPU_FAN901: FAN CONNECTOR NB_FAN901 CPU_FAN901 2.5.9 PANEL901: Front Panel System Function Connector SYMBOL SYMBOL HD_LED+ PW_LED+ HD_LED- PW_LED- RT_BT1 PW_BT1 RT_BT2 PW_BT2 5VSB RSEV I330 Motherboard User Manual...
- Page 29 2.5.12 Digital: Digital I/O Connector SYMBOL SYMBOL Out1 Out3 Out0 Out2 2.5.13 CON3: RS-422 / RS-485 Header Pls note that our I330 the COM1: RS232 transfer RS422/RS485 are using different socket and different cable Pin No. 422 RX2- SYMBOL 422 RX2+...
- Page 30 This chapter offers information on the chipset software Installation utility Installation of Graphic Driver Panel Resolution Setting I330 Motherboard User Manual...
-
Page 31: Graphic Driver Installation
Graphic Driver Installation 3.1 Standard CMOS Feature I330 Motherboard is equipped with Intel 945GME / ICH7M Companion Device. The Intel Graphic Drivers should be installed first, and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation. - Page 32 Step.3. Click on “Next “ to install Driver. Step.4. Click on “Next “ to install Driver. I330 Motherboard User Manual...
- Page 33 Step.5. Click on “Yes “ to agree License. Step.6. Click on “Next “ to install Driver. I330 Motherboard User Manual...
- Page 34 Step.7. Click on “Next “ to install Driver. Step.8. Click on “Yes, I want to restart this computer now “ to go on. I330 Motherboard User Manual...
-
Page 35: Panel Resolution Setting
3.2 Panel Resolution Setting Step.1. Right-click the desktop, and then click Properties. Step.2. In the Display Properties dialog box, click the Settings tab. Step.3. Click on “Monitor”. I330 Motherboard User Manual... - Page 36 Step.4. Click on “Hide modes that this monitor cannot display ” to remove this option. Step.5. Click on “Setting”, then could choose 32bit color qualify. I330 Motherboard User Manual...
- Page 37 This chapter offers information on the chipset software Installation utility Installation of Chipset Driver Further information I330 Motherboard User Manual...
-
Page 38: Chipset Driver Installation
Chapter 4 Chipset Driver Installation 4.1 Standard CMOS Features Setp.1. Insert the CD that comes with the motherboard. Open the file documen t “Chipset Driver”. Setp.2. Click on “infinst_auto.exe“ to install driver. I330 Motherboard User Manual... - Page 39 Setp.3. Click on “Next“ to install driver. Click on “Yes “ to agree License Setp.4. I330 Motherboard User Manual...
- Page 40 Setp.5. Click on “Next“ to install driver. Setp.6. Click on “Next“ to install driver. I330 Motherboard User Manual...
- Page 41 Step.7. Click on “Yes, I want to restart this computer now “ to go on. I330 Motherboard User Manual...
- Page 42 This chapter offers information on the Ethernet software installation utility. Sections include: Introduction Installation of Ethernet Driver I330 Motherboard User Manual...
-
Page 43: Chapter 5 Ethernet Driver Installation
Chapter 5 Ethernet Driver Installation 5.1 Introduction I330 Motherboard is equipped with the Realtek RTL8111 B Gigabit Ethernet controller combines a triple-speed IEEE 802.3 compliant Media Access Contr oller (MAC) with a triple-speed Ethernet transceiver, PCI Express bus controller, and embedded memory. -
Page 44: Installation Of Ethernet Driver
Installation of Ethernet Driver The Users must make sure which operating system you are using in the I330 Motherboard before installing the Ethernet drivers. Follow the steps below to complete the installation of the Realtek LAN drivers. You will quickly RTL8111B complete the installation. - Page 45 Step.4. Click on “Next“ to install driver. Step.5. Click on “Install“ to install driver. I330 Motherboard User Manual...
- Page 46 Setp.6. Click on “Finish“ and go on. I330 Motherboard User Manual...
- Page 47 This chapter offers information on the Audio software installation utility. Sections include: Introduction Installation of Audio Driver I330 Motherboard User Manual...
-
Page 48: Audio Driver Installation
PCs. Installation of Audio Driver The users must make sure which operatin g system you are using in the I330 Motherboard before installing the Audio drivers. Follow the steps below to complete the installation of the Realtek ALC 655 Audio drivers. - Page 49 Step.2. Click on “Next“ to install driver. Step.3. Click on “Yes, I want to restart my computer now ” to finish installation. I330 Motherboard User Manual...
- Page 50 BIOS Setup Standard CMOS Setup Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PC Health Status Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor/User Password Save & Exit Setup Exit Without Saving I330 Motherboard User Manual...
-
Page 51: Award Bios Installation
”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys. You can also restart by turning the system Off and back On again. The following message will appear on the screen: I330 Motherboard User Manual... -
Page 52: Standard Cmos Setup
+/- keys to set the current time. Time The time format is: Hour 00 to 23 Minute : 00 to 59 Second : 00 to 59 To set the time, highlight the “Time” field and use the <PgUp>/ <PgDn> or +/ - I330 Motherboard User Manual... - Page 53 Whenever the BIOS detects a non -fatal error, the system will stop and you will be prompted. All, But Keyboard The system boot will not be halted for a keyboard error; it will stop for all other errors I330 Motherboard User Manual...
- Page 54 (speed up memory access) or disable the cache function. Quick Power On Self Test When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enabled, BIOS will skip some items. I330 Motherboard User Manual...
- Page 55 When you select Setup, the system always boots up and prompts for the Supervisor Password only when the Setup utility is called APIC Mode APIC stands for Advanced Programmable Interrupt Cont roller. The default setting is Enabled. I330 Motherboard User Manual...
- Page 56 OS Select for DRAM > 64MB This option allows the system to access greater than 64MB of DRAM memory when used with OS/2 that depends on certain BIOS calls to access memory. The default setting is Non -OS/2. I330 Motherboard User Manual...
-
Page 57: Advanced Bios Features
(speed up memory access) or disable the cache function. Quick Power On Self Test When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enabled, BIOS will skip some items. I330 Motherboard User Manual... - Page 58 When you select Setup, the system always boots up and prompts for the Supervisor Password only when the Setup utility is called APIC Mode APIC stands for Advanced Programmable Inter rupt Controller. The default setting is Enabled. I330 Motherboard User Manual...
- Page 59 OS Select for DRAM > 64MB This option allows the system to access greater than 64MB of DRAM memory when used with OS/2 that depends on certain BIOS calls to access m emory. The default setting is Non -OS/2. I330 Motherboard User Manual...
-
Page 60: Advanced Chipset Features
SDRAM refreshes. The default setting for the Active to Precharge Delay is 4. Precharge Delay (tRAS) The default setting for the Precharge Delay is 12. System Memory Frequency The default setting is 533MHz. I330 Motherboard User Manual... - Page 61 MB. The choices are Enabled and Disabled. On-Chip VGA Setting The fields under the On-Chip VGA Setting and their default settings are: PEG/On Chip VGA Control: Auto On-Chip Frame Buffer Size: 8MB DVMT/Fixed Memory Size: 128MB Boot Display: Auto Panel Scaling: Auto I330 Motherboard User Manual...
- Page 62 Panel Number These fields allow you to select the LCD Pane l type. The default values for these ports are 640x480 640x480 18bit SC 800x600 18bit SC 1024x768 18bit SC 1280x800 18bit SC 800x480 18bit SC I330 Motherboard User Manual...
-
Page 63: Integrated Peripherals
These fields allow your system to improve disk I/O throughput to 33Mb/sec with the Ultra DMA/33 feature. The options are Auto and Disabled. Onboard Device/ USB Controller The options for this field are Enabled and Disabled. By default, this field is set to Enabled. I330 Motherboard User Manual... - Page 64 The setting configures the system power on status when power is restored to the system after a power failure occurrence. The default setting is Off. GiGA Lan (Lan1) Boot ROM The function is boot from LAN, and the default setting is disable. I330 Motherboard User Manual...
-
Page 65: Power Management Setup
Power Management. Min. Saving Minimum power management Max. Saving Maximum power management. User Define Each of the ranges is from 1 min. to 1hr. Except for HDD Power Down which ranges from 1 min. to 15 min. I330 Motherboard User Manual... - Page 66 This field enables or disables the power on of the system through the modem connected to the serial port or LAN. Resume by Alarm This field enables or disables the resumption of the system operation. When enabled, I330 Motherboard User Manual...
- Page 67 Date and Time. I330 Motherboard User Manual...
- Page 68 MPEG ISA/VESA V GA cards can work with PCI/VGA. When this field is enabled, a PCI/VGA can work with an MPEG ISA/VESA VGA card. When this field is disabled, a PCI/VGA cannot work with an MPEG ISA/VESA card. I330 Motherboard User Manual...
-
Page 69: Pc Health Status
This function can help prevent damage to the system that is caused by overheating. Smart Fan2 Temperature This field enables or disables the smart fan feature. At a certain temperature, the fan I330 Motherboard User Manual... -
Page 70: Load Fail-Safe Defaults
Select this option to exit the Setup utility without savi ng the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Se I330 Motherboard User Manual...
