Summary of Contents for Winmate I370
- Page 1 ® Mini-ITX Fan SBC w/ Intel Socket M CPU, VGA, LCD, Giga Ethernet, Mini-PCI and PCI-E x16 Interface. USER MANUAL Version 1.5...
- Page 2 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at hi m own expense. I370 Motherboard User Manual...
- Page 3 . If the customer discovers a defect, Winmate will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period of one year, with transportation charges prepaid.
- Page 4 We provide service guide for any pro blem as follow steps First, visit the website at http://www.winmate.com to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need addition al assistance. You may have the following...
- Page 5 As a safety precau tion, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static -shielded bag when they are not in the chassis. I370 Motherboard User Manual...
- Page 6 F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. I370 Motherboard User Manual...
- Page 7 Aladin Huang Add new 2007.09.20 Aladin Huang Resolution 2007.10.04 BIOS Check Aladin Huang 2007.10.05 Cancel Audio Jack Aladin Huang 2007.10.23 Revised COM port Chris Tsai Revised 2.4.2 Aladin Huang Add CF issue Revised 2.5.14 Aladin Huang I370 Motherboard User Manual...
- Page 8 Revised 2.5.15 Aladin Huang VIII I370 Motherboard User Manual...
-
Page 9: Table Of Contents
7.4 A BIOS F ..............46 DVANCE EATURE 7.5 A BIOS F .............. 49 DVANCED EATURE 7.6 A ............52 DVANCED HIPSET EATURE 7.7 I .............. 55 NTEGRATED ERIPHERALS 7.8 P ............58 OWER ANAGEMENT ETUP I370 Motherboard User Manual... - Page 10 This chapter includes I370 Motherboard background information. Sections include: Introduction Feature Motherboard Specification Function Block Board Dimensions I370 Motherboard User Manual...
-
Page 11: Chapter 1 General Information
Chapter 1 General Information 1.1 Introduction I370 SBC is equipped with Intel 945GM E North Bridge and Intel ICH7M South Bridge which are designed for use with Intel’s mobile platform, Intel® Centrino® Duo mobile technology. Comparing to previous generation chipset,... -
Page 12: Motherboard Specifications
1 x PCIEx16, 1 x Mini-PCI, 1 x CF Card Type I/II(Option) Form Factor Mini-ITX Dimensions 170mm x 170mm Operating temperature: 0 deg. C to 60 deg. C Mechanical & Operating Humidity: 30 ~ 90% Relative humidity, environmental non-condensing Certification: CE, FCC, RoHS I370 Motherboard User Manual... -
Page 13: Function Block
2GB/s ATA100 1GB/s IDE Host Intel ICH7M 3GB/s 480MB/s SATA II 1, SATAII 2 NH82801GBM CF Card Slot Audio Realtek ALC655 33MHz Mini PCI(Option) Super IO Realtek ALC655 ROM FWH Secondary IO Realtek ALC655 Realtek ALC655 I370 Motherboard User Manual... -
Page 14: Board Dimensions
Board dimensions Note: Audio Jack and CF slot is optional. I370 Motherboard User Manual... - Page 15 This chapter provides information on how to use the jumps and connectors on I370 Motherboard. The Sections include: Memory Module Installation I / O Equipment Installation Setting the Jumpers Connectors on I370 Motherboard I370 Motherboard User Manual...
-
Page 16: Chapter 2 Installations
Installations 2.1 Memory Module DIMM Installation I370 motherboard supports two DDR2 memory socket for a maximum total memory of 4GB in DDR2 memory type. 2.1.1 Installing and Removing Memory Modules To install the DDR2 modules, locate the memory slot on the b oard and perform the... -
Page 17: I/O Equipment Installation
Various adapters may come with USB ports. USB usually connect the external system to the system. The U SB ports support hot plug-in connection. Whatever, you should install the device driver before you use the device. I370 Motherboard User Manual... - Page 18 2.2.7 Audio function (Pin-header) The Audio 5.1 channel capabilities are provided by a Realtek ALC655 chipset supporting digital audio outputs. The audio interface includes Mic-in, line-in and line-out. I370 Motherboard User Manual...
-
Page 19: Jumpers And Connectors
2.3 Jumpers and Connectors J401 ATX12V901 J402 CON905 CON906 USB901 USB902 PCIEX1 SW901 CON903 MINI_PCI901 SATA2 CON908 CPU_FAN901 SATA1 JP902 JP901 CON904 PANEL901 NB_FAN901 IDE901 DIMM1 DIMM2 JP301 Locating Jumpers and Connectors (front side) I370 Motherboard User Manual... - Page 20 BOTTOM CF Card Slot(Optional) Locating Jumpers and Connectors (rear side) I370 Motherboard User Manual...
-
Page 21: Jumper Setting
User must make sure the power supply to turn off the power supply before setting Clear CMOS. Users remember to setting jumper back to Normal before turning on t he power supply. Default: 2short3. Clear CMOS Normal Pin No. Functions 1 Short 2 Clear CMOS 2 Short 3 Normal I370 Motherboard User Manual... - Page 22 2.4.5 CON908: LCD Panel Voltage Select CON908 can be configured to operate in 3.3Volts / 5Volts / 12Volts mode. 3.3Volts 5Volts 12Volts Pin No. Functions 1 Short 2 3.3Volts Selected 3 Short 4 5Volts Selected 5 Short 6 12Volts Selected I370 Motherboard User Manual...
-
Page 23: Connectors And Pin Assignment
CON905 12V External Power 2x1 header, pitch 2.54mm CON906 5V External Power 2x1 header, pitch 2.54mm 12V External Power header ,pitch 2.54mm CON912 12V DC Jack 4 Pin Jack ATX12V901 12V DC Connector 4 Pin Connecter I370 Motherboard User Manual... - Page 24 SYMBOL Pin No. SYMBOL LCDVDD LVDS_LTX0- LCDVDD LVDS_LTX0+ LCDVDD LVDS_LTX1- LVDS_LTX1+ LVDS_LTX2- LVDS_LTX2+ LVDS_LCLK- LCDS_LCLK LVDS_UTX0- LVDS_UTX0+ LVDS_UTX1- LVDS_UTX1+ LVDS_UTX2- LVDS_UTX2+ LVDS_UCLK- LVDS_UCLK 2.5.2 JP902: Digital Panel Backlight Brightness Control Pin No. SYMBOL Black Light Control I370 Motherboard User Manual...
- Page 25 2.5.3 CON904: Digital Panel Backlight Control Pin No. SYMBOL +12V +12V +12V Black Light Control Black Light EN 5V 2.5.4 PSKBM901: PS2 Keyboard/Mouse Connector PS/2 Keyboard PS/2 Mouse Pin No. SYMBOL Pin No. SYMBOL KDATA MDATA Ground Ground KCLK MCLK I370 Motherboard User Manual...
- Page 26 DTR4/422RX- NDSRA NRTSA NCTSA NRIA DAC_SDAT0 3VHSYNC0 3VVSYNC0 DAC_SCL0 2.5.6 CON909: Serial port COM2 The serial port COM2, which is Winbond I/O support, is RS232 only. SYMBOL SYMBOL NDSR1A NDCD1A NRTS1A NRXD1A NCTS1A NTXD1A NCTS1A NDTR1A I370 Motherboard User Manual...
- Page 27 FK_NDTR1 FK_NDTR2 FK_NDSR1 FK_NDSR2 FK_NRTS1 FK_NRTS2 FK_NCTS1 FK_NCTS2 FK_NRI1 FK_NRI2 2.5.8 AUDIO401: Audio Jack SYMBOL Color Signal Blue Line In Green Line Out Pink Microphone In Pin-Header C0~C4 Line in B1~B4 Line out A1~A4 Mic in I370 Motherboard User Manual...
- Page 28 CBL_ID# DCS#1 DCS#3 DASP# GND8 +5V1 +5V2 2.5.10 USB901/USB902: USB PIN HEADER USB902 SYMBOL SYMBOL USBVCC4 USBVCC4 USB_P6- USB_P7- USB_P6+ USB_P7+ USB901 SYMBOL SYMBOL USBVCC3 USBVCC3 USB_P4- USB_P5- USB_P4+ USB_P5+ 2.5.11 NB_FAN901/CPU_FAN901: FAN CONNECTOR NB_FAN901 CPU_FAN901 I370 Motherboard User Manual...
- Page 29 2.5.12 PANEL901: Front Panel System Function Connector SYMBOL SYMBOL HD_LED+ PW_LED+ HD_LED- PW_LED- RT_BT1 PW_BT1 RT_BT2 PW_BT2 5VSB RSEV 2.5.13 J401/J402: Front Audio J401 J402 I370 Motherboard User Manual...
- Page 30 2.5.14 CON905/CON906/J2: External Power CON905 CON906 2.5.15 CON912: DC Jack 2.5.16 ATX12V901: 12V DC Connector SYMBOL Ground Ground +12V +12V I370 Motherboard User Manual...
- Page 31 This chapter offers information on the chipset software Installation utility Installation of Graphic Driver Panel Resolution Setting I370 Motherboard User Manual...
-
Page 32: Chapter 3 Graphic Driver Installation
Graphic Driver Installation 3.1 Standard CMOS Feature I370 Motherboard is equipped with Intel 945GME / ICH7M Companion Device. The Intel Graphic Drivers should be installed first , and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation. - Page 33 Step.3. Click on “Next “ to install Driver. Step.4. Click on “Next “ to install Driver. I370 Motherboard User Manual...
- Page 34 Step.5. Click on “Yes “ to agree License. Step.6. Click on “Next “ to install Driver. I370 Motherboard User Manual...
- Page 35 Step.6. Click on “Next “ to install Driver. Step.7. Click on “Yes, I want to restart this com puter now“ to go on. I370 Motherboard User Manual...
-
Page 36: Panel Resolution Setting
3.2 Panel Resolution Setting Step.1. Right-click the desktop, and then click Properties. Step.2. In the Display Properties dialog box, click the Settings tab. Step.3. Click on “Monitor”. I370 Motherboard User Manual... - Page 37 Step.4. Click on “Hide modes that this monitor cannot display” to remove this option. Step.5. Click on “Setting”, then could choose 32bit color qualify. I370 Motherboard User Manual...
- Page 38 This chapter offers information on the chipset software Installation utility Installation of Chipset Driver Further information I370 Motherboard User Manual...
-
Page 39: Chapter 4 Chipset Driver Installation
Chapter 4 Chipset Driver Installation 4.1 Standard CMOS Features Setp.1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”. Setp.2. Click on “infinst_auto.exe“ to install driver. I370 Motherboard User Manual... - Page 40 Setp.3. Click on “Next“ to install driver. Click on “Yes “ to agree License Setp.4. I370 Motherboard User Manual...
- Page 41 Setp.5. Click on “Next“ to install driver. Setp.6. Click on “Next“ to install driver. I370 Motherboard User Manual...
- Page 42 Step.7. Click on “Yes, I want to restart this comput er now“ to go on. I370 Motherboard User Manual...
- Page 43 This chapter offers information on the Ethernet software installation utility. Sections include: Introduction Installation of Ethernet Driver I370 Motherboard User Manual...
-
Page 44: Chapter 5 Ethernet Driver Installation
Chapter 5 Ethernet Driver Installation 5.1 Introduction I370 Motherboard is equipped with the Realtek RTL8111 B Gigabit Ethernet controller combines a triple-speed IEEE 802.3 compliant Media Access Controller (MAC) with a triple-speed Ethernet transceiver, PCI Expr ess bus controller, and embedded memory. -
Page 45: Installation Of Ethernet Driver
Installation of Ethernet Driver The Users must make sure which operating system you are using in the I370 Motherboard before installin g the Ethernet drivers. Follow the steps below to complete the installation of the Realtek LAN drivers. You will quickly RTL8111B complete the installation. - Page 46 Step.3. Click on “Next“ to install driver. Step.3. Click on “Install“ to install driver. I370 Motherboard User Manual...
- Page 47 Setp.3. Click on “Finish“ and go on. I370 Motherboard User Manual...
- Page 48 This chapter offers information on t he Audio software installation utility. Sections include: Introduction Installation of Audio Driver I370 Motherboard User Manual...
-
Page 49: Chapter 6 Audio Driver Installation
Chapter 6 Audio Driver Installation 6.1 Introduction The I370 Motherboard is equipped with the ALC655 is a 16-bit, full-duplex AC'97 Rev. 2.3 compatible six-channel audio CODEC designed for PC multimedia systems, including host/soft audio and AMR/CNR -based designs.. The ALC655 CODEC provides three pairs of stereo outputs with 5 -bit volume control, a mono output, and multiple stereo and mono inputs, along with flexible mixing, gain, and mute functions to provide a complete integrated audio solution for PCs. - Page 50 Step.2. Click on “Next“ to install driver. Step.3. Click on “Yes, I want to restart my computer now ” to finish installation. I370 Motherboard User Manual...
- Page 51 BIOS Setup Standard CMOS Setup Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PC Health Status Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor/User Password Save & Exit Setup Exit Without Saving I370 Motherboard User Manual...
-
Page 52: Chapter 7 Award Bios Installation
”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys. Yo u can also restart by turning the system Off and back On again. The following message will appear on the screen: I370 Motherboard User Manual... -
Page 53: Standard Cmos Setup
+/- keys to set the current time. Time The time format is: Hour 00 to 23 Minute : 00 to 59 Second : 00 to 59 To set the time, highlight the “Time” field and use the <PgUp>/ <PgDn> or +/ - I370 Motherboard User Manual... - Page 54 Whenever the BIOS detects a non -fatal error, the system will stop and you will be prompted. All, But Keyboard The system boot will not be halted for a keyboard error; it will stop for all other errors I370 Motherboard User Manual...
-
Page 55: Advance Bios Feature
(speed up memory access) or disable the cache function. Quick Power On Self Test When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enabled, BIOS will skip some items. I370 Motherboard User Manual... - Page 56 This option is specifies the MPS (Multiprocessor Specification) version for your operating system. MPS version 1.4 added extended configuration tables to improve support for multiple PCI bus conf igurations and improve future expandability. The default setting is 1.4. I370 Motherboard User Manual...
- Page 57 OS Select for DRAM > 64MB This option allows the system to access greater than 64MB of DRAM memory when used with OS/2 that depends on certain BIOS calls to access memory. The default setting is Non-OS/2. I370 Motherboard User Manual...
-
Page 58: Advanced Bios Feature
(speed up memory access) or disable the cache function. Quick Power On Self Test When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enabled, BIOS will skip some items. I370 Motherboard User Manual... - Page 59 When you select Setup, the system always boots up and prompts for the Supervisor Password only when the Setup utility is called APIC Mode APIC stands for Advanced Programmable Interr upt Controller. The default setting is Enabled. I370 Motherboard User Manual...
- Page 60 OS/2 that depends on certain BIOS calls to access me mory. The default setting is Non -OS/2. Report No FDD For WIN95 The default setting is No. Small Logo (EPA) Show The default setting is Disable. I370 Motherboard User Manual...
-
Page 61: Advanced Chipset Feature
This option sets the number of cycles required for the RAS to accumulate its charge before the SDRAM refreshes. The default setting for the Active to Precharge Delay is 4. Precharge Delay (tRAS) The default setting for the Precharge Delay is 12. I370 Motherboard User Manual... - Page 62 The default setting is Auto On-Chip Frame Buffer Size: The default setting is 8MB DVMT/Fixed Memory Size: The default setting is 128MB Boot Display: You could select Auto/CRT/LVDS1/LVDS1+CRT. The default setting is A uto Panel Scaling: Auto I370 Motherboard User Manual...
- Page 63 SDVO1 Number: (Default: LVDS1 : 1024x768 ; LVDS2: 1280x1024) 1280x1024 24bit DC 1366x768 24bit SC 1440x900 24bit DC 1024x768 24bit DC SDVO 2 Number: (Default: LVDS2: 1400x1050) 1400x1050 24bit SC 1600x1200 24bit DC 1920x1080 24bit SC 1920x1200 24bit DC I370 Motherboard User Manual...
-
Page 64: Integrated Peripherals
These fields allow your system to improve disk I/O throughput to 33Mb/sec with the Ultra DMA/33 feature. The options are Auto and Disabled. Onboard Device/ USB Controller The options for this field are Enab led and Disabled. By default, this field is set to Enabled. I370 Motherboard User Manual... - Page 65 The function is boot from LAN, and the default setting is disable. Onboard Serial Port3 These fields allow you to select the onboard serial ports and their addresses. The default values for these ports are: On Board Serial Port 1 Disable I370 Motherboard User Manual...
- Page 66 These fields allow you to select the onboard serial ports and their addresses. The default values for these ports are: On Board Serial Port 1 Disable Serial Port4 Use IRQ The default values for these ports are: IRQ3/IRQ4/IRQ5/IRQ7/IRQ10/IRQ11. I370 Motherboard User Manual...
-
Page 67: Power Management Setup
Power Management. Min. Saving Minimum power management Max. Saving Maximum power management. User Define Each of the ranges is from 1 min. to 1hr. Except for HDD Power Down which ranges from 1 min. to 15 min. I370 Motherboard User Manual... - Page 68 This field enables or disables the power on of the system through the modem connected to the serial port or LAN. Resume by Alarm This field enables or disables the resumption of the system operation. When enabled, I370 Motherboard User Manual...
- Page 69 Date a nd Time. I370 Motherboard User Manual...
- Page 70 MPEG ISA/VESA VGA cards can work with PCI/VGA. When this field is enabled, a PCI/VGA can work with an MPEG ISA/VESA VGA card. When this field is disabled, a PCI/VGA cannot work with an MPEG ISA/VESA card. I370 Motherboard User Manual...
- Page 71 This function can help prevent damage to the system that is caused by overheating. Smart Fan2 Temperature This field enables or disables the smart fan feature. At a certain temperature, the fan I370 Motherboard User Manual...
- Page 72 Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility. I370 Motherboard User Manual...
- Page 73 4. Master: CF Card ( Transcend 120X -standard ) Slave: IDE CD-ROM ( Plextor PX-760A ) CD-ROM is not founded. 5. Master: IDE CD-ROM ( Plextor PX-760A ) Slave: CF Card ( Transend 120X -standard ) CF Card is not founded. I370 Motherboard User Manual...
