19.4.

Digital outputs

Digital output have PNP open collector output static signal, totem pole for pulse signals.
Digital output current is max. 25 mA continuous and 50 mA for short time, 13 ms.
The output is short circuit protected and protected against voltage transients caused by
inductive loads.
If the digital output is overloaded, it will be turned off after 13 ms and once a second the
output will be activated again.

19.5. LCP cable length

Max. distance between LCP2 and FCD300: 3 m.
20.

Voltage level overview

Voltage level description (DC link voltage)
Inverter Over voltage Disable
Inverter Over voltage Enable
Voltage High Warning with Brake
Brake Start
Voltage High Warning Without Brake
Inverter Under voltage Enable & Inrush Enable
Voltage Low Warning
Inverter Under voltage Disable & Inrush Disable
Voltage trip times
Time in over voltage before trip
Time in under voltage before trip
21.

Current levels

Current level description
Short circuit (and earth short circuit fault)
Time in short circuit before trip (inverter disable)
Over current (hardware)
Time in over current before trip
Earth fault
Time in earth fault before trip (inverter disable)
Software current limit
Time in software current limit before trip
Release 01/2003
Revise 08/01/2003 by DD Service Manager, Steffen Sundbæk
Service Manual FCD 300
820 V
805 V
800 V
770 V
765 V
450 V
440 V
410 V
5 or 15 times within 10ms
2,5 sec
260% Inom
5 – 8 µs
210% Inom
2 – 4 sec
4 –5 A
5 – 8 µs
160% Inom
60 sec
30
