19.

Useful Data (supplement to the design guide)

Main electrical data.
Model Input
voltage
[V AC]
303 3x380-480
305 3x380-480
307 3x380-480
311 3x380-480
315 3x380-480
322 3x380-480
330 3x380-480
335 3x380-480
*) Based on 380V line voltage, except FCD335 that is at 460V line.
**) Perhaps a new drive size. Approximate power at 400V line.
Release 01/2003
Revise 08/01/2003 by DD Service Manager, Steffen Sundbæk
Service Manual FCD 300
Full load # Input
input Phase frequency
current
[A] * [Hz]
1.2 3Ø 50/60
1.6 3Ø 50/60
1.9 3Ø 50/60
2.6 3Ø 50/60
3.2 3Ø 50/60
4.7 3Ø 50/60
6.1 3Ø 50/60
6.8 3Ø 50/60
Output Full load
voltage output
current
[V] [A]
0-480 1.4
0-480 1.8
0-480 2.2
0-480 3.0
0-480 3.7
0-480 5.2
0-480 7.0
0-480 7.6
Power Power
[HP] [kW]
0.5 0,37
0.75 0,50
1.0 0,75
1.5 1,1
2.0 1,5
3.0 2,2
4.0 3,0
5.0 3,3**
