Yale E5400LN Cylindrical Series Programming/Troubleshooting Instructions
Eboss
Hide thumbs
Also See for E5400LN Cylindrical Series:
- Manual (12 pages) ,
- Installation instructions manual (12 pages)
Advertisement
Quick Links
E5400LN Cylindrical Series &
E890 Exit Device Trim Series
Operational Modes
Secure
Normal locked state. Any
assigned user code can gain
access. Lock/relocks
automatically.
An ASSA ABLOY Group brand
Programming/Troubleshooting
Instructions
Lockout
Lockset will not accept any
assigned user codes except
for the Supervisor and
Emergency Codes.
E8850FL Mortise
Series
Passage
Maintains unlocked state.
Relocks by entering passage
code the second time
80-9150-8005-010 (10-12)
Advertisement
Related Manuals for Yale E5400LN Cylindrical Series
Summary of Contents for Yale E5400LN Cylindrical Series
- Page 1 Programming/Troubleshooting Instructions E8850FL Mortise E5400LN Cylindrical Series & Series E890 Exit Device Trim Series Operational Modes Secure Lockout Passage Normal locked state. Any Lockset will not accept any Maintains unlocked state. assigned user code can gain assigned user codes except Relocks by entering passage access.
- Page 2 Operational Check (Lock must be properly installed, refer to Installation Instructions) Insert key into outside cylinder and rotate key The key will retract the latchbolt Inside lever retracts latchbolt Enter factory set Emergency code 4321 [ ] to unlock the outside lever and retract the latchbolt (If emergency code does not work refer to Programming Instructions and reprogram lock with a new master code and emergency code).
- Page 3 Code Descriptions User 1: Master Code – Factory default setting of 1234 must be changed before programming can begin Codes should be 4 to 7 digits and entered followed by [ Assigns Supervisor and Emergency Codes Used for Programming the lock Will not allow the controller to unlock the mechanism User 2: Emergency Code –...
-
Page 4: Programming Instructions
Programming Instructions: ® Code used for entry. The Master Code is always User Number 1 and is used only for programming. The Master Code will not unlock the lock. Use the record log on the last page to assign and log all user codes before proceeding on to programming. -
Page 5: User Programming Commands
3-Change the Master Code when Master Code has been forgotten or lost Remove inside escutcheon # (Hold pound depressed until Yellow LED blinks continuously) Depress the Program (PRGM) button located at the top of the contr oller on the i n s ide Yellow LED Blinks Enter Program Command Code Yellow LED Blinks... - Page 6 Keypad Programming Commands General Format VALUE Audible Keypad Feedback 0=DISABLE, 1=ENABLE (Default =1) (Hold) VAL # These Program Modes Visual Keypad Feedback 0=DISABLE, 1=ENABLE (Default =1) and User Codes can be (Hold) VAL # programmed with the Supervisor Code (SC) or Keypad Attempts (1 thru 255) Default = 3 Attempts (Hold) the Master Code (MC)
-
Page 7: Troubleshooting
Troubleshooting P r o b l em Green light comes on but lever will not retract latchbolt. Solution Check lockbody connection. Check cylinder tail piece length (see Installation Instructions). Check door Prep (refer to door templates). Problem No Lights come on when pushbuttons are depressed. Solution Ensure Visual Keypad Feedback is set to Enable (See page 6). - Page 8 eBOSS® User Log Door Description Installation Date User User Name PIN Number Notes Master Code Emergency Code Su pervisor Lockout Passage 80-9150-8005-010 (10-12) An ASSA ABLOY Group brand...
- Page 9 80-9150-8005-010 (10-12) An ASSA ABLOY Group brand...
- Page 10 Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company. Yale® and eBoss® are registered trademarks of Yale Security Inc., an ASSA ABLOY Group company. Other products' brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only.
