Operating Instruction

for KONVEKTA air conditioning unit
KL47T / KL48T / KL49T
Version:
- 24 Volt DC
- Frischluft / Heizung
ID#: BBA-KL481602A
Version: A02
with control KS600-CAN
Konvekta AG
Am Nordbahnhof 5
34613 Schwalmstadt
Germany
+49 ( 0 ) 66 91 / 76 – 0
+49 ( 0 ) 66 91 / 76 -
200
Info@konvekta.com
www.konvekta.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KL47T and is the answer not in the manual?

Questions and answers

Summary of Contents for KONVEKTA KL47T

  • Page 1: Operating Instruction

    Operating Instruction for KONVEKTA air conditioning unit KL47T / KL48T / KL49T with control KS600-CAN Version: - 24 Volt DC - Frischluft / Heizung Konvekta AG Am Nordbahnhof 5 34613 Schwalmstadt Germany +49 ( 0 ) 66 91 / 76 – 0...
  • Page 2: Table Of Contents

    Contents Page: Introduction ........................3 • Information on the operating instructions ..............4 • Technical data air conditioning unit ................4 1.1. Compressor ........................5 Generally information for a/c unit ................... 5 1.2. Intended use ........................6 1.3. Operating conditions ......................6 Operation ..........................
  • Page 3: Introduction

    In case you need more explanations please contact the next KONVEKTA service sta- tion . On our website www.konvekta.com in category >service< you will find a survey of contact details of all our service partners close to your location BAKL481602A Edition: 01.03.2017...
  • Page 4: Information On The Operating Instructions

    In the course of further developments we reserve the right to technical modifications without preno- tice. Guarantee and liability conditions of KONVEKTA AG’s general business conditions are not enlarged by the above notes. Indications and photos should neither be copied and circulated nor used for competitor’s purposes.
  • Page 5: Compressor

    If you think that the a/c unit is damaged, switch it off immediately. To avoid further dam- age have it check at a KONVEKTA Service Station. Only after that you can take unit into operation.
  • Page 6: Intended Use

    1.2. Intended use The KONVEKTA air conditioner represents an air conditioning system that works with the ozone friendly refrigerant R134a and which creates a pleasant and individually adjustable room tempera- ture by means of forced convection. The determined use includes also the observance of the Op- erating instruction and the proof of regular inspections as well.
  • Page 7 Rotary knob K3 Rotary knob Functional description Turn When the ignition is ON, the desired cockpit channel temperature can be adjusted. ( 12 - 90° C ) Left stopper is OFF. Keypress Functional description Key S1 Short press Switching on the driver's area air conditioning. Its only active when the passenger compartment air conditioner is Long press Double-click...
  • Page 8: Special Functions Of The Ks600

    Key S7 Keypress Functional description Short press Reducing the manual fan settings in 7 steps. Long press Double-click Key combination --- Keypress Functional description Key S8 Short press Reducing the room set temperature for the passenger compart- ment. After reaching the minimum Temperature 6 x press key >> MAX COOL.
  • Page 9: Maintenance

    1 = operating hours unit; 2 = operating hours compressor / Note: h = hours, d = days, Y= year 4. Maintenance Please arrange regular dates for maintenance works and services with a KONVEKTA service sta- tion, as indicated in maintenance schedule bus no.: WP07050618.On our website www.konvekta.com...
  • Page 10: Compressor Type Kvx

    − check a/c unit for leakages compressor slack V-belt − check V-belt at compressor drive On our website www.konvekta.com in category >service< you will find a survey of contact details of all our service partners close to your location By user 5. Warranty Conditions The current „General Warranty Conditions KONVEKTA AG“...
  • Page 11: Waste Disposal In Accordance With Legal Provisions

    7. History of modification Version Date Name Remark File 08.03.2016 B Keßler Source file BAKL481602A 13.07.2016 B. Keßler Added KL47T and KL49T BAKL481602A 01.03.2017 B. Keßler Information on the operating instructions and BAKL481602A technical data expanded with F-gas-regulation BAKL481602A Edition: 01.03.2017 Page: 11/11...
