Operating Instructions
air conditioning units
Version:
- 24 Volt DC
- Recirculated air
ID#: BBA-KL9T0102A
Version: A00
for KONVEKTA
with climate control KS40
Konvekta AG
Am Nordbahnhof 5
34613 Schwalmstadt
Germany
+49 ( 0 ) 66 91 / 76 – 0
+49 ( 0 ) 66 91 / 76 - 200
Info@konvekta.com
www.konvekta.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAURUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KONVEKTA TAURUS

  • Page 1 Operating Instructions for KONVEKTA air conditioning units with climate control KS40 Version: - 24 Volt DC - Recirculated air Konvekta AG Am Nordbahnhof 5 34613 Schwalmstadt Germany +49 ( 0 ) 66 91 / 76 – 0 +49 ( 0 ) 66 91 / 76 - 200 ID#: BBA-KL9T0102A Info@konvekta.com...
  • Page 2: Table Of Contents

    Contents Page: Introduction ........................3 • Information on the operating instructions ..............4 • Technical data ........................4 1.1. Compressor ........................4 Generally information for a/c unit ................... 5 2.1. Intended Use ........................5 2.2. Operating Conditions ......................5 Operation .......................... 5 3.1.
  • Page 3: Introduction

    KONVEKTA or its distributors in case other than original KONVEKTA spare parts or parts bought from KONVEKTA AG have been used for maintenance and repair. These operating instructions contain all necessary information to operate your air conditioning unit.
  • Page 4: Technical Data

    In the course of further developments we reserve the right to technical modifications without notice. Guarantee and liability conditions of KONVEKTA AG’s general business conditions are not en- larged by the above notes. Indications and photos should neither be copied and circulated nor used for competitor’s purposes.
  • Page 5: Generally Information For A/C Unit

    2.2. Operating Conditions NOTE: KONVEKTA uses components made of copper and aluminium, which last a whole unit life- time under normal environmental conditions. Should the units be operated under aggressive envi- ronmental conditions, i.e.
  • Page 6: General Description Ks40

    The control unit can be mounted directly in a cut-out in the instrument panel or via the Konvekta adapter housing B59-AA3-097 and the mounting frame T11-000-108 in a radio DIN shaft. Cut-out size: 90,5/+0,5/-0mm x 43,5/+0,5/-0mm and wall thickness cut-out: 2mm - 4mm.
  • Page 7: Display Function

    3.4. Display function Display Significance Standard display Setpoint temperature Warning / Error display Air conditioner active Economy aktiv / Air conditioner locked Automatic blower and recirculation con- trol active Manual blower control active Recirculation mode active Display blower level 0...4 4.
  • Page 8: Circulating Air

    4.4. Circulating air After switching on the power supply, the recirculation mode is switched on. When the motor is running, the function can be switched over manually via key T6 The flap moves in 15 seconds into the set position. Function when automatic control is switched on (T5 on): Recirculation mode, if:...
  • Page 9: Operations When The Motor Is Switched On/Off (Release D+/Climate)

    The error is also indicated by the symbol L1 ) in the LCD. 6. Maintenance / Service Please arrange regular dates for maintenance works and services with a KONVEKTA service sta- tion, as indicated in maintenance schedule bus no.: WP07050618.
  • Page 10: Troubleshooting

    Before carrying out any maintenance works at your air conditioning unit, carefully read the KONVEKTA safety provisions (TD00052A ) in order to avoid any dangers and accidents! On our website www.konvekta.com in category >service< you will find a survey of contact details of all our service partners close to your location Source of supply: KONVEKTA AG, P.O.
  • Page 11: Waste Disposal In Accordance With Legal Provisions

    8. Waste disposal in accordance with legal provisions After the phase of use the last proprietor is responsible for the adequate waste manage- ment. The environmental regulations in the exporting country must be observed. The following list contains the most important regulating literature, valid for the Federal Rep. of Germany: Resolution for dangerous substances Resolution for used oil...
