Analog AC output (AWG70001A with Option AC)

Output connector
Number of analog AC outputs
Type of outputs
Output impedance
Amplitude
Range (for a CW signal at
specified frequencies in each
path)
Accuracy (at calibration
frequency)
Resolution
AWG70000A Series Installation and Safety Instructions
Aeroflex/Weinschel Planar Crown Universal Connector System with SMA female adapter
AWG70001A: 1
single ended
50 Ω
Filter path
No filter
Low pass
Band pass (10 GHz to 14.5 GHz)
Band pass (13 GHz to 18 GHz)
Filter path
No filter
Low pass
Band pass (10 GHz to 14.5 GHz)
Band pass (13 GHz to 18 GHz)
0.01 dB
Description
25 dBm to -70 dBm at 1 GHz
18 dBm to -77 dBm at 13 GHz
25 dBm to -70 dBm at 1 GHz
18 dBm to -77 dBm at 11 GHz
20 dBm to -90 dBm at 14 GHz
18 dBm to -90 dBm at 18 GHz
Description
±0.5 dB at 1 GHz, ambient 16 °C to 26 °C
±1.5 dB at 1 GHz, ambient 0 °C to 50 °C
±0.5 dB at 1 GHz, ambient 16 °C to 26 °C
±1.5 dB at 1 GHz, ambient 0 °C to 50 °C
±1.5 dB at 11 GHz, ambient 16 °C to 26 °C
±3.0 dB at 11 GHz, ambient 0 °C to 50 °C
±1.5 dB at 14 GHz, ambient 16 °C to 26 °C
±3.5 dB at 14 GHz, ambient 0 °C to 50 °C
Specifications
