User Manual
Ascom d81 DECT Handset
Figure 1. Overview d81 DECT Handset
1
2
3
4
5
6
7
1.Applicable for the d81 Protector only.
2.Applicable for the d81 Protector with the Man-down and No-movement hardware only.
26 April 2010/ Ver. B
19 1
18
17
16
15
14
13
12
11
10
1
Push button
The button is placed on the top side of the handset. The Push button
is used for sending alarms, see
Earpiece speaker
2
Pull cord connector
Is used for connection of the pull cord to the handset, see also
Pull-Cord Alarm on page 37.
Colour display
The full graphic type display is 128 pixels wide and 160 pixels high.
The display has multiple colours and backlighting.
Four-way navigation key
Use this key to step in the menu and when working in text mode.
, , and are used for stepping left/right and up/down in the
menu. The navigation key can be programmed, the
short cut to the Inbox, and
8.6.3 Define Navigation Key
increase/decrease the volume by pressing
On-hook and On/Off key
Combined button; to end a call, to return to idle mode, and to
switch the handset on/off by long press.
Tactile indicators
There are two tactile indicators to indicate the centre of the key pad
2
3
4
5
6
7
8
9
7.1 Push-Button Alarm
is a short cut to Call contact. See also
on page 54. During a call it is possible to
and .
