Command
Scale output Response (TXD)
(RXD)
Will respond with current selected data string
transmitted from serial port 1. (No transmission
W or w
will occur if scale is in motion.)
Will respond with Custom Data String
Wx or wx
transmitted from serial port 1.
Will respond with current selected data string
transmitted from serial port 2. (No transmission
P or p
will occur if scale is in motion.)
If this command is sent from serial port 1, a "*"
will be sent out of port 1 to acknowledge the
command was executed.
Will
Px or px
transmitted from serial port 2.
If this command is sent from serial port 1, a "*"
will be sent out of port 1 to acknowledge the
command was executed.
* (acknowledgment, port 1 only)
U or u
* (acknowledgment, port 1 only)
Z
* (acknowledgment, port 1 only)
T or t
* (acknowledgment, port 1 only)
G or g
* (acknowledgment, port 1 only)
N or n
Print Buffer data.
Display shows DUMP message while
d
transmitting.
Print Buffer data & clears buffer.
D Display shows DUMP message while
transmitting.
CB Clears Buffer data.
* (acknowledgment, port 1 only)
ELx
Label buffer string
RLx
Setpoint or Check limit weight value.
RSx
respond with Custom
Description
Transmits data out TXD1 (Port1)
Transmits Custom Data String number
x = 1 to 4 out TXD1 (Port1)
Transmits Data Output Format 1
x = 0 out TXD1 (Port1)
Transmits data out TXD2 (Port2)
Data String Transmits Custom Data String number
x = 1 to 4 out TXD2 (Port2)
Transmits Data Output Format 2
x = 0 out TXD2 (Port2)
Scale changes current units
Zeros scale
Tares Scale and enters Net mode
Scale enters Gross mode
Scale enters Net mode
Dumps serial data that is stored in
Print Buffer. Active when Serial
Handshaking is set for Buffer, 485 or
Bluetooth Buffer mode.
Dumps & clear serial data that is
stored in Print Buffer. Active when
Serial Handshaking is set for Buffer,
485 or Bluetooth Buffer mode.
Clear serial data that is stored in Print
Buffer. Active when Serial
Handshaking is set for Buffer, 485 or
Bluetooth Buffer mode.
Enter data into Custom Data String
number x = 1 to 4
See Custom Data String Configuration
Read data in Custom Data String
number x = 1 to 4
See Custom Data String Configuration
Read weight value in Setpoint number
x = 1 to 8, 0 = current Setpoint number
