Error Messages:

Error Message
"ovr Ld" Scale overload
"udr Ld" Scale underload
"grS oL" Gross overload
"grS uL" Gross underload
"SU 0 E" Startup zero error
"Er Ad" A/D failure
"Er Sr" SRAM error
"Err 1" Program ROM error
"Ldg 0" Loading zero.
"SPAn E"
Calibration Range Error
"Er neg"
Negative Weight Error
"Er nno"
Motion Error
"rA Err"
Calibration Span Error
"No SAV"
Parameter value not saved.
"Er Cnt"
Count by Error.
"Er dp"
Decimal Point Error.
"CAP rg"
Capacity Range Error.
"CAP Lo"
Capacity weight is too low.
The scale is in overload. The load on the scale exceeds the
capacity by more than 103%. Remove excess weight from
scale.
The scale is in underload. The load on the scale is less then
the minimum scale capacity by more than -20%. Recalibrate
scale or add additional dead load.
The scale is in gross overload. The load exceeds the scale
ratings and might result in damage to the scale. Remove
excess weight immediately. Ignore this message for the first 5
seconds after power up.
The scale is in gross underload. The load exceeds the
minimum scale ratings and might result in damage to the
scale. Load cell connections might be wired in reverse. Ignore
this message for the first five seconds after power up.
The scale was not stable. This error will only occur in Legal for
Trade applications. The scale will zero once it becomes
stable.
The scale has detected a failure in the A/D circuit. Have the
scale serviced by a qualified scale repair technician.
The setup parameters loaded in nonvolatile memory (SRAM)
have become corrupted. The scale requires recalibration by a
qualified scale technician.
The program memory in the scale has become corrupted.
Have scale serviced by a qualified scale repair technician.
The scale is attempting to load power up zero. This message
will remain until scale is stable.
Calibration zero is out of range, refer to A/D Ranging section
for additional information.
Weight is negative range, Load cell signal wires backwards,
refer to A/D Ranging section for additional information.
Weight readings are unstable. Too much vibration occurs
during weight entry. Load cell signal wires are not connected.
Calibration Span is out of range, refer to A/D Ranging section
for additional information.
The scale has not successfully stored or verified the parameter
value in nonvolatile memory.
The weight value entered has a smaller count by step than the
scale's current count by resolution.
Too many digits to the right of the decimal point have been
entered for capacity.
Capacity weight entered has more than three non-zero digits in
a row.
Capacity weight entered is less than 1 lb or kg.
133
What to Do or Check:
