LED Annunciators

The 2200 series uses a set of sixteen LED annunciators, in addition to the six digit LED
weight display, to provide information about the status of the scale.
Motion is indicated by the MOT annunciator.
platform weight. The motion sensitivity can be changed in the parameter setup
mode. Some functions like tare, zero and print can only be executed when this
annunciator is lit.
Net mode is indicated by the NET annunciator. When lit, the scale is displaying a
net weight. When not lit, the scale is displaying a gross weight.
Center of zero is indicated by the ZERO annunciator. The ZERO annunciator is
lit when the gross weight is within 0.25 divisions of zero gross weight.
Low battery condition is indicated by the BATT annunciator.
battery when this annunciator is lit. The scale can charge while in operation.
Available weight units are displayed by the lb, oz, kg and g annunciators.
2200, 2200B, 2200CW only, the 8 red led indicators below the main display are
used to indicate: setpoint output status during weighing mode or the current
setpoint, preact or ID being edited.
2200CW only, the OVER, ACCEPT, UNDER indicators above the main display
are used to indicate checkweigh information.
Motion is an instability in the
12
Recharge the
