Printing Bluetooth Module Address

Once the Bluetooth devices have been paired, the 12-digit ASCII Bluetooth module
address can be transmitted by using the control character "\j". See Custom Data String
Control Characters in the Data Communication section for more information.

Requesting Bluetooth Module Address

Once the Bluetooth devices have been paired, the 12-digit ASCII Bluetooth module
address can be requested by issuing a RB recall command. See Table 2 in the Data
Communication section for more information.

Display Bluetooth Module Address (Run mode)

To display the Bluetooth module's 12-digit address, press and hold the PRINT button for
3 seconds to access the Communications Menu. Press the UNITS button to scroll
through the menu until "bLUE A" is momentarily displayed. The 12-digit bluetooth
module's address stored in the scale's non-volatile memory is displayed. The higher 6
digits are displayed first, followed by the lower 6 digits. Press the CLEAR button to exit
the menu. No serial communication will occur without a display address. Note: If
"000000" and "000000" are shown, no Bluetooth module address was stored in the
scale's memory. Run the Bluetooth test parameter "bLUE t" to communicate with the
module and store the address in the scale's memory.

Display Bluetooth Module Address (Cal mode)

To display the Bluetooth module's 12-digit address, enter Cal mode. Press the UNITS
button to scroll through the parameters until the Bluetooth menu "blue n" is shown.
Press the ZERO button to scroll through the sub-menu to the Bluetooth address "bLUE
A" option. Press the UNITS button to show the 12-digit bluetooth module's address
stored in the scale's non-volatile memory. The higher 6 digits will be displayed first,
followed by the lower 6 digits. Press the UNITS button to exit the menu. No serial
communication will occur without a display address. Note: if "000000" and "000000" is
shown, no Bluetooth module address was stored in the scale's memory. Run the
Bluetooth test parameter "bLUE t" to communicate with the module and store the
address in the scale's memory.

Detecting Other Bluetooth Addresses (Cal mode)

Cycle the scale's power to disable Bluetooth pairing. Enter Cal mode and press the
UNITS button to scroll through the parameters until Bluetooth menu "blUe n" is shown.
Press the ZERO button to scroll through the sub-menu to the Bluetooth read parameter
"bLUE r". Press the UNITS button to start detecting other Bluetooth devices. Testing
takes several minutes to perform. When done, the display shows the first 12-digit
bluetooth address detected. The higher 6 digits are displayed first, followed by the lower
6 digits. Press the UNITS button to scroll to the next 12-digit address detected. Up to 7
Bluetooth addresses can be displayed. If no address was found, "nonE" is shown.
