3 Technology

3.1 Dimensions

16
Dim
ensi
on
L
Length of boiler
L1
Total length including induced draft fan
B
Width of boiler
B1
Total width inc. side cleaning door
H
Height of boiler
H1
Total height incl. flue gas nozzle
H2
Height of flue pipe connection
H3
Height of flow connection
H4
Height of return connection
H5
Height of safety battery connection
H6
Height of drainage connection
1. Applies for S3 Turbo 18 as well (only available in Italy)
Froeling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.at
Name
Technology
Dimensions
Unit
S3 Turbo
20-30
1)
mm
1160
1260
570
680
1470
1530
1750
1280
140
890
120
S3 Turbo
40-45
1250
1350
670
780
1570
1630
1850
1380
140
970
120
