MTM400 Configuration Files
3-90
3. Locate and select the configuration file or type in a new name; use the
Browse... button if necessary.
4. Select Start to download the configuration setting from the selected slot.
Uploading to a Slot
Correctly prepared configuration files can be uploaded to a slot.
1. From the Configuration view, select Upload Slot....
2. From the Slot: drop-down list, select the required slot.
3. Locate and select the configuration file to be uploaded or type in the path and
name (*.xml); use the Browse... button if necessary.
4. Select Start to upload the configuration setting into the selected slot.
If the file is incorrectly formatted, the operation will fail and a message will be
displayed in the dialog box.
