BDI Sweep Assembly Instructions

BDI Sweep Assembly Instructions

Cabinet

Advertisement

Quick Links

Component List
IL
HL
Designed by Louis A. Lara.
These distinctive product configurations are protected by US and
international patents, trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. ©2015, BDI
Made in China. 8438REV083115v1
sweep
8438
cabinet
B1 - Hex Driver x 1
B2 - Hex Wrench x 1
C - 1/4-20 x 70 mm
Screw x 2
D - 1/4-20 x 15 mm
Screw x 16
E - Cabinet x 1
F - Metal Leg x 2
G - Wood Leg x 1
HL - Adjustable Shelf x 1
HR - Adjustable Shelf x 1
IL - Adjustable Shelf x 1
IR - Adjustable Shelf x 1
J - Back Panel x 2
HR
a s s e m b l y i n s t r u c t i o n s
bdiusa.com
Sweep is engineered for easy assembly. Carefully
follow this procedure to prevent any damage.
Placement and Maintenance
Sweep is designed for indoor use on level floors.
Clean wood veneer with a moist cloth. Clean
glass with glass cleaner.
Step 1
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as clean carpet.
For missing hardware pieces, please contact BDI Customer Service
at customerservice@bdiusa.com. For all other concerns, please
contact your BDI Retailer.
E
F
G
D
1
customerservice@bdiusa.com
J
C
IR
F
D
