System Directories - FMC Technologies AccuLoad II Programming Workbook

Program
Code Function Code
000
001 Number of Products
002 Number of Additive
Injectors
003 A/C Output Relay 1
Terminals 89 & 90
Note: When using three or four products this relay must be programmed "00" (No Assignment).
Issue/Rev. 0.3 (8/97)
Description

System Directories

System Configuration Directory
Enter: "1" One Product
"2" Two Products
"3" Three Products
"4" Four Products
Enter: "0" No Additive Injectors
"1" One Additive Injector
"2" Two Additive Injectors
"3" Three Additive Injectors
"4" Four Additive Injectors
"5" Five Additive Injectors
"6" Six Additive Injectors
"7" Seven Additive Injectors
"8" Eight Additive Injectors
Enter: "00" No Assignment
"01" Additive Relay 1
"02" Additive Relay 2
"03" Additive Relay 3
"04" Additive Relay 4
"05" Additive Relay 5
"06" Additive Relay 6
"07" Additive Relay 7
"08" Additive Relay 8
"09" Additive Pump 1
"10" Additive Pump 2
"11" Additive Pump 3
"12" Additive Pump 4
"13" Additive Pump 5
"14" Additive Pump 6
"15" Additive Pump 7
"16" Additive Pump 8
"17" Alarm Relay
Entry
__
__
(N/A)
(ADD1)
(ADD2)
(ADD3)
(ADD4)
(ADD5)
(ADD6)
(ADD7)
(ADD8)
(ADP1)
(ADP2)
(ADP3)
(ADP4)
(ADP5)
(ADP6)
(ADP7)
(ADP8)
(ALR) __ __
Program
Code
000
001
002
003
1
