FMC Technologies AccuLoad II Programming Workbook page 8

Program
Code Function Code
006 A/C Output Relay 4
Terminals 95 & 96
007 A/C Output Relay 5
Terminals 87 & 88
Issue/Rev. 0.3 (8/97)
Description
Enter: "00" No Assignment
"01" Additive Relay 1
"02" Additive Relay 2
"03" Additive Relay 3
"04" Additive Relay 4
"05" Additive Relay 5
"06" Additive Relay 6
"07" Additive Relay 7
"08" Additive Relay 8
"09" Additive Pump 1
"10" Additive Pump 2
"11" Additive Pump 3
"12" Additive Pump 4
"13" Additive Pump 5
"14" Additive Pump 6
"15" Additive Pump 7
"16" Additive Pump 8
"17" Alarm Relay
"22" General Relay
Enter: "00" No Assignment
"01" Additive Relay 1
"02" Additive Relay 2
"03" Additive Relay 3
"04" Additive Relay 4
"05" Additive Relay 5
"06" Additive Relay 6
"07" Additive Relay 7
"08" Additive Relay 8
"09" Additive Pump 1
"10" Additive Pump 2
"11" Additive Pump 3
"12" Additive Pump 4
"13" Additive Pump 5
"14" Additive Pump 6
"15" Additive Pump 7
"16" Additive Pump 8
"17" Alarm Relay
"18" Pump-Product 1
"19" Pump-Product 2
"20" Pump-Product 3
"21" Pump-Product 4
Entry
(N/A)
(ADD1)
(ADD2)
(ADD3)
(ADD4)
(ADD5)
(ADD6)
(ADD7)
(ADD8)
(ADP1)
(ADP2)
(ADP3)
(ADP4)
(ADP5)
(ADP6)
(ADP7)
(ADP8)
(ALR)
(GEN)
(N/A)
(ADD1)
(ADD2)
(ADD3)
(ADD4)
(ADD5)
(ADD6)
(ADD7)
(ADD8)
(ADP1)
(ADP2)
(ADP3)
(ADP4)
(ADP5)
(ADP6)
(ADP7)
(ADP8)
(ALR)
(PMP1)
(PMP2)
(PMP3)
(PMP4) __ __
Program
Code
006
007
3
