System Directories; System Configuration Directory - FMC Technologies AccuLoad II Programming Workbook

Program
Code Function Code
000
001 Number of Products
002 Number of Additive
Injectors
003 A/C Output Relay 1
Terminals 89 & 90
(Position #1)
Terminals 124 & 125
(Position #2)
Note: 1. Option "14" First Trip Indicator of this code applies to SEQ-06 and above firmware.
2. When using a Smart Additive Subsystem, options 02 through 08 (Additive Relays) are not available for selection.
004 A/C Output Relay 2
Terminals 91 & 92
(Position #1)
Terminals 126 & 127
(Position #2)
Note: 1. Option "14" First Trip Indicator of this code applies to SEQ-06 and above firmware.
2. When using a Smart Additive Subsystem, options 02 through 08 (Additive Relays) are not available for selection.
2
Description

System Directories

System Configuration Directory

Enter: "1" One (1) Product
"2" Two (2) Products
"3" Three (3) Products
"4" Four (4) Products
Enter: "0" No Additive Injectors
"1" One (1) Additive Injector
"2" Two (2) Additive Injectors
"3" Three (3) Additive Injectors
"4" Four (4) Additive Injectors
"5" Five (5) Additive Injectors
"6" Six (6) Additive Injectors
"7" Seven (7) Additive Injectors
Enter: "00" No Assignment (NAS)
"01" Alarm Relay (ALR)
"02" Additive Relay 1 (ADD1)
"03" Additive Relay 2 (ADD2)
"04" Additive Relay 3 (ADD3)
"05" Additive Relay 4 (ADD4)
"06" Additive Relay 5 (ADD5)
"07" Additive Relay 6 (ADD6)
"08" Additive Relay 7 (ADD7)
"09" Block Valve Relay 1 (BVR1)
"10" Block Valve Relay 2 (BVR2)
"11" Block Valve Relay 3 (BVR3)
"12" Block Valve Relay 4 (BVR4)
"13" General Relay (GEN)
"14" First Trip Indicator (FTR)
Enter: "00" No Assignment (NAS)
"01" Alarm Relay (ALR)
"02" Additive Relay 1 (ADD1)
"03" Additive Relay 2 (ADD2)
"04" Additive Relay 3 (ADD3)
"05" Additive Relay 4 (ADD4)
"06" Additive Relay 5 (ADD5)
"07" Additive Relay 6 (ADD6)
"08" Additive Relay 7 (ADD7)
"09" Block Valve Relay 1 (BVR1)
"10" Block Valve Relay 2 (BVR2)
"11" Block Valve Relay 3 (BVR3)
"12" Block Valve Relay 4 (BVR4)
"13" General Relay (GEN)
"14" First Trip Indicator (FTR)
Program
Entry Code
__
__
__ __
__ __
AB06030 Rev. 0.6 5/96
