FMC Technologies AccuLoad II Programming Workbook page 13

Program
Code Function Code
017 D/C Output Relay 3
Terminals 13 & 12
on Quad OPV
Note: This code is only available for use if the Quad OPV option has been purchased with the AccuLoad II.
018 D/C Output Relay 4
Terminals 17 & 16
on Quad OPV
Note: This code is only available for use if the Quad OPV option has been purchased with the AccuLoad II.
019 A/C Input 1
Terminals 98 & 101
*
Note: Or can be used for Master Reset.
8
Description
Enter: "00" No Assignment
"01" Additive Relay 1
"02" Additive Relay 2
"03" Additive Relay 3
"04" Additive Relay 4
"05" Additive Relay 5
"06" Additive Relay 6
"07" Additive Relay 7
"08" Additive Relay 8
"09" Pulse Output
Enter: "00" No Assignment
"01" Additive Relay 1
"02" Additive Relay 2
"03" Additive Relay 3
"04" Additive Relay 4
"05" Additive Relay 5
"06" Additive Relay 6
"07" Additive Relay 7
"08" Additive Relay 8
"09" Pulse Output
Enter: "00" No Assignment
"01" Additive Feedback 1
"02" Additive Feedback 2
"03" Additive Feedback 3
"04" Additive Feedback 4
"05" Additive Feedback 5
"06" Additive Feedback 6
"07" Additive Feedback 7
"08" Additive Feedback 8
"09" First/Second High Flow (FSC)
"10" Printer Tray Switch
"11" Permissive 1 Contact
"12" Permissive 2 Contact
"13" Valve Power
"14" Valve Stem-Product 1
"15" Valve Stem-Product 2
"16" Valve Stem-Product 3
"17" Valve Stem-Product 4
Entry
(N/A)
(ADD1)
(ADD2)
(ADD3)
(ADD4)
(ADD5)
(ADD6)
(ADD7)
(ADD8)
(POT3) __ __
(N/A)
(ADD1)
(ADD2)
(ADD3)
(ADD4)
(ADD5)
(ADD6)
(ADD7)
(ADD8)
(POT4) __ __
(N/A)
(AFB1)
(AFB2)
(AFB3)
(AFB4)
(AFB5)
(AFB6)
(AFB7)
(AFB8)
(PTS)*
(PRC1)
(PRC2)
(VPW)
(VST1)
(VST2)
(VST3)
(VST4) __ __
Issue/Rev. 03 (8/97)
Program
Code
017
018
019
