FMC Technologies AccuLoad II Programming Workbook page 7

Program
Code Function Code
004 A/C Output Relay 2
Terminals 91 & 92
Note: When using three or four products this relay must be programmed "00" (No Assignment).
005 A/C Output Relay 3
Terminals 93 & 94
2
Description
Enter: "00" No Assignment
"01" Additive Relay 1
"02" Additive Relay 2
"03" Additive Relay 3
"04" Additive Relay 4
"05" Additive Relay 5
"06" Additive Relay 6
"07" Additive Relay 7
"08" Additive Relay 8
"09" Additive Pump 1
"10" Additive Pump 2
"11" Additive Pump 3
"12" Additive Pump 4
"13" Additive Pump 5
"14" Additive Pump 6
"15" Additive Pump 7
"16" Additive Pump 8
"17" Alarm Relay
Enter: "00" No Assignment
"01" Additive Relay 1
"02" Additive Relay 2
"03" Additive Relay 3
"04" Additive Relay 4
"05" Additive Relay 5
"06" Additive Relay 6
"07" Additive Relay 7
"08" Additive Relay 8
"09" Additive Pump 1
"10" Additive Pump 2
"11" Additive Pump 3
"12" Additive Pump 4
"13" Additive Pump 5
"14" Additive Pump 6
"15" Additive Pump 7
"16" Additive Pump 8
"17" Alarm Relay
"22" General Relay
Entry
(N/A)
(ADD1)
(ADD2)
(ADD3)
(ADD4)
(ADD5)
(ADD6)
(ADD7)
(ADD8)
(ADP1)
(ADP2)
(ADP3)
(ADP4)
(ADP5)
(ADP6)
(ADP7)
(ADP8)
(ALR) __ __
(N/A)
(ADD1)
(ADD2)
(ADD3)
(ADD4)
(ADD5)
(ADD6)
(ADD7)
(ADD8)
(ADP1)
(ADP2)
(ADP3)
(ADP4)
(ADP5)
(ADP6)
(ADP7)
(ADP8)
(ALR)
(GEN) __ __
Issue/Rev. 03 (8/97)
Program
Code
004
005
