FMC Technologies AccuLoad II Programming Workbook page 21

Program
Code Function Code
036 4-20 Channel #4
Terminals 71 & 72
037 Additive Injector
#1 Plumbing
Note: If that additive injector output is configured for use and this entry is "0000" the indication is that it is plumbed into the loading arm downstream
of the metering system.
16
Description
Enter: Two digit number indicating
the use of this 4-20 Channel.
First digit:
"0" Channel Not Used
"1" Product 1
"2" Product 2
"3" Product 3
"4" Product 4
Second digit:
"0" Channel Not Used
"1" Temperature
"2" Pressure
"3" Density
(e.g., 11 indicates that this channel
would be used by product 1 for a temperature
input).
Enter: Four digit number indicating
the products that this additive
injector is plumbed into.
1st digit - Product #1
2nd digit - Product #2
3rd digit - Product #3
4th digit - Product #4
A zero in the digit indicates
that the injector is not plumbed
into that product, a one indicates
that the injector is plumbed
into that product. (e.g., 1110
indicates that the injector is
plumbed into products 1, 2,and 3.)
Program
Entry
__ __
__ __ __ __
Issue/Rev. 03 (8/97)
Code
036
037
