Issue 06/2016
BRINELL HARDNESS TESTER
MODEL NB-3010
Including Appendix for Retrofit of HB3000 to NB3010
OPERATING INSTRUCTIONS
V 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NB-3010 and is the answer not in the manual?

Questions and answers

Related Manuals for Ametek NB-3010

Summary of Contents for Ametek NB-3010

  • Page 1 Issue 06/2016 BRINELL HARDNESS TESTER MODEL NB-3010 Including Appendix for Retrofit of HB3000 to NB3010 OPERATING INSTRUCTIONS V 1.0...

  • Page 3: Table Of Contents

    Contents 1. APPLICATION INFORMATION 2. GENERAL INFORMATION 2.1 Technical Data 2.2 Items Shipped with Unit 2.3 Accessory/Ship Kit Contents 2.4 Options 3. MECHANICAL DESCRIPTION 3.1 Frame and anvil (See Parts Location Diagram on Page 8) 3.2 Load Lever Mechanism (See Parts Location Diagram on Page 8) 3.3 Rod Assembly (See Parts Location Diagram on Page 8) 3.4 Pneumatic Tube Assembly (See Parts Location Diagram on Page 8) 3.5 Electronic Control System (See Parts Location Diagram on Page 8)

  • Page 5: Application Information

    1. APPLICATION INFORMATION The tester is used for determining the Brinell hardness of un-quenched steel, cast-iron, nonferrous metals and soft bearing alloys. This tester can be used in metallurgical plants, machine manufacturing plants, metal working plants , industrial laboratories, and laboratory environments. The measuring range of hardness is 8-450 HBS when steel ball indenter is used, and 8-650 HBW when a tungsten carbide ball indenter is used.

  • Page 6: Mechanical Description

    3. MECHANICAL DESCRIPTION 3.1 Frame and anvil (See Parts Location Diagram on Page 8) The hardness tester has a cast iron frame (1). An elevating screw seat (18) is set on the stage at the front of the frame. The removable anvil (24) is set on the elevating screw (22), which is fitted precisely into the seat (18).

  • Page 7: Electronic Control System (See Parts Location Diagram

    3.5 Electronic Control System (See Parts Location Diagram on Page 8) The electronic control system consists of a solenoid (23) and printed wiring board (30), etc. Depress the start button (5A) to bring the solenoid into action. The pneumatic cylinder (8) starts to empty, and the indicator light for loading (1A) is lit. The piston rod (6) descends, dropping the fork rocker (5) slowly downward and the roller is separated from the large lever.

  • Page 8: Installation (See Parts Location Diagram On Page 8)

    4. INSTALLATION (See Parts Location Diagram on Page 8) The tester should be installed in a dry, clean room without corrosive gases or large amount of vibration. The base for the tester should be rigid and flat and able to sup- port weight of tester - 570 lbs.
  • Page 9 The weight hanger (3) should be hung on the knife edge of the load lever (4) and the weights added and rotated to different amounts so that the slots on the weights are offset to prevent them from accidentally being knocked off the hanger. (See photo at right) Place the hanger on the knife edge at the end of the large lever.

  • Page 10: Test Setup And Operation

    5. TEST SETUP and OPERATION 5.1 Setting up Indenter and Anvil INDENTER Select the proper indenter according to the desired load in Ball accordance with ASTM E-10. Indenters consist of a ball holder, cap and ball. Clean any oil from the surface of the Holder ball and the ball holder before installing.

  • Page 11: Load A Test Specimen

    5.3 Load a Test Specimen Put a test specimen on the anvil and turn the handwheel (21) of the elevating screw until the piece contacts the indenter. Continue turning the handwheel until the indenter is lifted slightly and the handwheel slips. If the handwheel does not reach a point where it slips, the ball detent (19) may need adjustment.

  • Page 12: Parts Location Diagrams

    1. Frame 16. Air Regulator (set to 60 psi) 2. Limit Switch 17. Cylinder Mounting Bracket MODEL 3. Hanger 18. Elevating Screw Seat NB-3010 4. Load Lever 19. Ball detent 6A, 8A, 10A Load duration time 5. Fork Rocker 20. Nut 6.

  • Page 13: The Brinell Test Method

    7. THE BRINELL TEST METHOD 7.1 The ASTM Specification Brinell testing is covered by the ASTM standard E-10. The ASTM specification can be purchased from the ASTM (American Society for Testing and Materials) at 1916 Race Street, Philadelphia, PA 19103. The following test method is not a complete descrip- tion of the standard.
  • Page 14 7.3 Other Conditions for Testing - The angle of test force should be within 90L K2L. - A hardened steel ball (at least 810 Vickers hardness) may only be used on a material of hardness less than 450 and with a tungsten carbide ball on materials under HB 650.

  • Page 15: Maintenance

    Contact this location for general or sales questions as well as self-repair questions, parts, billing etc. 205 Keith Valley Road Horsham PA 19044, USA Tel: 215-355-6900 Fax: 215-354-1803 newage.info@ametek.com www.hardnesstesters.com To schedule a service call anywhere in North America contact Newage Testing Instruments Service 317-329-4300...

  • Page 16: Appendix A: Instructions For Converting Nb3010 From Electric To Air

    Appendix A: Instructions for Converting NB3010 from Electric to Air Coupling Regulator Valve Air Cylinder Air Solenoid P/N 0267 Regulator Valve Air Regulator P/N 0287 Line Filter Assembly Main Board Wire Assembly Assembly P/N 0205 Blank Plate Label Fig 1: UPGRADE PARTS DIAGRAM...
  • Page 17 1. Remove motor and gear box. (Refer to Figure 2) 2. Remove the plate on the top of the tester and the circuit board underneath. Remove the connectors with wiring from the back end of the circuit board. (Refer to Figures 3 & 4.) 3.
  • Page 18 8. Attach the air cylinder to the link on the fork rocker as per Parts Location Diagram and the photo below. Install the air cylinder. Bottom it out, then back it off 4 (four) complete turns. Tighten nut and set screw. Mount the bracket and air cylinder using two bolts from existing motor/gearbox. (Figures 6, 8) Make certain the airline from the solenoid on the bracket is sticking out the bolt hole at the location where the air regulator installs.

  • Page 19: Appendix B: Brinell Conversion Charts

    Appendix B: Brinell Conversion Charts Brinell Conversion: Diameter Measurement to Brinell Value Using 10 mm Ball LOAD (kg) LOAD (kg) LOAD (kg) Diameter (mm) Diameter (mm) Diameter (mm) 1.26 3000 1500 1000 1.26 3000 1500 1000 1.26 3000 1500 1000 4.78 78.5 52.3...
  • Page 20 Brinell Conversion: Diameter Measurement to Brinell Value Using 10 mm Ball LOAD (kg) LOAD (kg) LOAD (kg) Diameter (mm) Diameter (mm) Diameter (mm) 1.26 3000 1500 1000 1.26 3000 1500 1000 1.26 3000 1500 1000 5.33 62.1 41.4 20.7 5.89 49.8 33.2 16.6...
  • Page 21 Brinell Conversion: Diameter Measurement to Brinell Value Using 5 mm Ball LOAD (kg) LOAD (kg) LOAD (kg) Diameter (mm) Diameter (mm) Diameter (mm) 1.26 62.5 1.26 62.5 1.26 62.5 1.00 1.74 101.9 50.9 25.5 2.48 48.3 24.2 12.1 1.01 1.75 2.49 100.7 50.3...

  • Page 22: One Year Limited Warranty

    ONE YEAR LIMITED WARRANTY Should Newage Testing Instruments, Inc. equipment require service, we will repair or replace, at our option, any part or product which upon examination by a Newage ser- vice technician, shows to be defective in material or workmanship. Excluded from this warranty are any parts that are to be replaced as part of normal product operation, such as indenters, test blocks, and indenter shrouds.
  • Page 24 205 Keith Valley Road • Horsham PA 19044, USA Tel: 215-355-6900 • Fax: 215-354-1803 newage.info@ametek.com • www.hardnesstesters.com...
