2.3.6 Crosspoint

XPT Video
Assigning video source, and channel setting according to your
preference.
The XPT Video source can be quickly selected in the following way.
XPT Audio
Assigning audio source, and channel setting according to your preference.
The XPT Audio source can be quickly selected in the following way.
1. First press and hold down the XPT AUDIO button. The Program row of input
sources will light.
2. While still holding down the XPT AUDIO button, press the required input on
the Program row.
3. After pressing the required input on the program row, the Preset row of input
sources will light. While still holding down the XPT AUDIO button, press the
required input on the Preset row.
4. The input button will flash to confirm the selected audio source.

2.3.7 OSD MENU Options

button it is stored within the switcher's non-volatile memory.
Version Number xx.xx where xx.xx is the firmware version number.
1080i50Hz
1080i60Hz
1080i59.94Hz
Audio Dynamic Range
1. First press and hold down the XPT VIDEO button. The Program
row of input sources will light.
2. While still holding down the XPT VIDEO button, press the
required input on the Program row.
3. After pressing the required input on the program row, the Preset
row of input sources will light. While still holding down the XPT
VIDEO button, press the required input on the Preset row.
4. The input button will flash to confirm the selected video source.
When the ENTER button is pressed the Main Menu list is
displayed on the HDMI 1 Multi-view output.
This section covers the Menu options in the order that they
appear on the SE-2850 HDMI 1 Multi-view. These settings may
also appear in more detail elsewhere in this instruction manual.
Options may vary depending on the firmware version in use.
Once the chosen setting has been confirmed with the ENTER
Version Number
Base Standard
Tick selection for ON or OFF
Audio Dynamic Range
24
18
Audio Tract
20
