ANT-20/ANT-20E
1.3.5

Generation of pointer actions

1.3.5.1

Contiguous concatenation

Stimulation
AU-4 pointer sequences
See "STM-1 mapping" and "STS-1 mapping" specifications.
Pointer jumps
Pointer jump from pointer value A to pointer value B (including setting a new pointer).
Pointer jumps are executed using NDF.
Pointer range A + B:
AU-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 782
1.3.6

OC-48c/STM-16c anomaly insertion

Anomaly insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B1, B2, B3 parity errors
Trigger modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Single
A bit error rate is inserted when Rate is selected.
Anomaly
B1 (OC-48c/STM-16c)
B2 (OC-48c/STM-16c)
REI-L (OC-48c)
MS-REI (STM-16c)
B3 (STS-12c SPE/VC-4-4c)
B3 (STS-48c SPE/VC-4-16c)
REI-P (STS-12c SPE)
HP-REI (VC-4-4c)
REI-P (STS-48c SPE)
HP-REI (VC-4-16c)
1 Mantissa: 1 to 9, Exponent: -3 to -10 (integer values)
Table S-18
Insertion of anomalies and defects is mutually exclusive. The action first selected is active; the
second action is rejected.
Specifications OC-48c/STM-16c
Single
yes
yes
yes
yes
yes
yes
yes
Anomalies (OC-12c/STM-16c) and trigger modes
Concatenation Options
REI-L/MS-REI, REI-P/HP-REI
1
Rate Burst m, n (frame)
2E-5 to 1E-10 m = 1 to 196000
2E-3 to 1E-10 m = 1 to 196000
2E-3 to 1E-10 m = 1 to 196000
2E-4 to 1E-10 m = 1 to 196000
2E-5 to 1E-10 m = 1 to 196000
2E-4 to 1E-10 m = 1 to 196000
2E-5 to 1E-10 m = 1 to 196000
or Rate
S-33
