Concatenation Options
Pointer jumps
Pointer jump from pointer value A to pointer value B (including setting a new pointer).
Pointer jumps are executed using NDF.
Pointer range A + B:
AU-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 782
1.3.5.2

Virtual concatenation

Only with option BN 3035/90.92
Stimulation of pointer #1
AU-4 pointer sequences
See "STM-1 mapping" and "STS-1 mapping" specifications.
Pointer jumps
Pointer jump from pointer value A to pointer value B (including setting a new pointer).
Pointer jumps are executed using NDF.
Pointer range A + B:
AU-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 782
Stimulation of pointers #2 to #4
Pointer actions in pointer #1 affect pointers #2 to #4 at the same time.
A delta value (deviation) from pointer #1 can be generated for pointers #2 to #4.
Maximum delta of pointers #2 to #4 to pointer #1 . . . . . . . . . . . . . . . . . . . . . . . . . .± 40 pointers
Increment / decrement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pointer
Setting a new delta value is through n x increment or n x decrement.
For n > 1, the spacing between two consecutive increment / decrement actions is 32 frames
(4 ms).
The delta for pointers #2 to #4 is retained for pointer actions in pointer #1.
S-6
or time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .± 6.17 µs
or time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154 ns
