ANT-20/ANT-20E
2.4

Payload

2.4.1

BULK signal receiver

Only with option BN 3035/90.90
2.4.1.1

Bit pattern payloads

See Sec. 1.4.1.1, Page S-10 and Sec. 1.4.1.2, Page S-10
2.4.1.2

Anomaly measurements

The following anomaly can be indicated and evaluated in addition to the anomalies described in
Sec. 2.3.4, Page S-18:
Anomaly
TSE
Table S-12
2.4.1.3

Defect detection

The following defect can be indicated and evaluated in addition to the defects described in
Sec. 2.3.5, Page S-19:
Defect
LSS
Table S-13
2.4.2

ATM receiver section

Only with options BN 3035/90.70 and BN 3035/90.91
2.4.2.1

Descrambling

Descrambling is according to ITU-T Recommendation I.432 (X
The function can be disabled.
Specifications OC-12c/STM-4c
LED
TSE
LED display of additional anomaly
LED
LSS
LED display of additional defect
Concatenation Options
43
+1).
S-21
