- Page 1 USB 305 HSPA Modem User Guide 2131219 Rev 1.0...
- Page 3 Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE POWERED OFF. When operating, the Sierra Wireless modem can transmit signals that could interfere with various onboard systems. Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open. Sierra Wireless modems may be used at this time. The driver or operator of any vehicle should not operate the Sierra Wireless modem while in control of a vehicle. Doing so will detract from the driver or operatorʹs control and operation of that vehicle. In some states and provinces, operating such ...
- Page 4 USB 305 HSPA Modem User Guide REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY SIERRA WIRELESS PRODUCT, EVEN IF SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY. Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its affiliates aggregate liability arising under or in connection with the Sierra Wireless product, regardless of the number of events, occurrences, or claims giving rise to liability, be in excess of the price paid by the purchaser for the Sierra Wireless product. Patents Portions of this product may be covered by some or all of the following US patents: 5,515,013 5,629,960 5,845,216 5,847,553 5,878,234 5,890,057 5,929,815 6,169,884 6,191,741 6,199,168 6,339,405 6,359,591 6,400,336 6,516,204 6,561,851 6,643,501 6,653,979 6,697,030 6,785,830...
-
Page 5: Contact Information
Preface Contact Information Sales Desk: Phone: 1-604-232-1488 Hours: 8:00 to 5:00 Pacific Time sales@sierrawireless.com E-mail: Post: Sierra Wireless 13811 Wireless Way Richmond, BC Canada V6V 3A4 Fax: 1-604-231-1109 www.sierrawireless.com Web: Consult our website for up‐to‐date product descriptions, documentation, application notes, firmware upgrades, trouble‐ shooting tips, and press releases: www.sierrawireless.com Revision History Revision Release Changes number... - Page 6 USB 305 HSPA Modem User Guide 2131219...
-
Page 7: Table Of Contents
Introducing the USB 305 Modem ........ - Page 8 USB 305 HSPA Modem User Guide Care and Maintenance of Your USB Modem ......23 FAQ and Troubleshooting .
-
Page 9: Introducing The Usb 305 Modem
1: Introducing the USB 305 Modem • Memory stick capability • Services supported • Your account and coverage area • USB 305 modem software • Frequency bands The USB 305 (3G) wireless modem enables you to connect to the Internet, send and receive email, connect to a corporate supported network or virtual private network (VPN), or view streaming video, without the need for a cable. The modem fits into Type A USB ports. The modem has a built‐in antenna. Power LED Data LED microSD card slot... -
Page 10: Accessories
USB 305 HSPA Modem User Guide Accessories Depending on your service provider, your USB 305 modem may come with some or all of the following accessories: • USB extension cable and screen clip • Carrying case • External antenna • microSD memory card Memory stick capability Your USB 305 modem is built to accommodate a microSD external memory card. Depending on your service provider, a microSD card may be included in your package, or you may need to purchase it separately. Services supported Your USB 305 modem supports the latest 3G high‐speed networks and is also compatible with 2G networks. Examples of 3G technology are: HSDPA, HSUPA, HSPA, and UMTS. GPRS and EDGE are 2G technologies. Maximum theoretical data speeds are: • High Speed Download Packet Access (HSDPA)—up to 7.2 Megabits per second (Mbps) • High Speed Upload Packet Access (HSUPA)—up to 2.0 Mbps •... -
Page 11: Your Account And Coverage Area
EDGE service. Once the connection is established, you have access to all Internet services. Your account and coverage area You must have an account with a GSM service provider to use Note: If you purchased the USB the USB 305 modem. To use the modem’s 3G capability, your 305 modem from a GSM service account must be with a service provider that offers HSDPA/ provider, you may already have HSUPA or UMTS service. (The USB 305 modem is backwards an account and a SIM card. compatible with 2G service.) Otherwise, your retailer should be able to give you the names of When you obtain your account, you are given a Subscriber ... -
Page 12: Frequency Bands Supported
USB 305 HSPA Modem User Guide Frequency bands supported Frequency bands supported by the USB 305 modem: Technology Bands Location 850 MHz (cellular band) North America 900 MHz (EGSM band) Europe 1800 MHz (DCS band) Europe and Asia 1900 MHz (PCS band) North America WCDMA 850 (band V) -
Page 13: Getting Started
2: Getting Started Follow the instructions in this chapter to set up and start using your USB 305 modem. To use your USB 305 modem, you’ll need: • An account with a service provider Note: Keep a written record in a secure place of the account • A SIM card (supplied by the service provider) information that your service • A profile, which may be: provider gives you. · Already stored on your modem when you purchase it · Set up automatically · Selected from a drop‐down list · Created manually Overview of installation steps Check the system requirements. -
Page 14: Insert The Sim Card
USB 305 HSPA Modem User Guide Insert the SIM card Note: Be sure to insert the SIM card before you insert the modem into the computer’s USB slot. To insert the SIM card: Note: To prevent the SIM card from becoming jammed in its If your SIM card is attached to a larger card, detach the ... -
Page 15: Insert The 305 Usb Modem Directly Into The Usb Slot
Note: Do not forcefully insert the Note: Do not insert the USB 305 modem or the USB extension cable USB 305 modem as you may into a USB hub or, if your keyboard is separate from your notebook damage connector pins. -
Page 16: Connect To The Network
USB 305 HSPA Modem User Guide If it does not: Note: Users of Windows Vista must be logged in with adminis- My Computer Computer Double‐click (Windows XP) or trative privileges. Users of (Windows Vista) on your desktop. Windows XP may require admin- TRU-Install Click the drive (usually E: or F: drive). istrative privileges. Win/ATT Under the TRU‐Install drive, go to ... -
Page 17: Using Your Usb 305 Modem
3: Using your USB 305 Modem • Removing a SIM card • Using the microSD memory card • Using the extension Your HSPA USB 305 modem has a USB connector and slots for a SIM card and a microSD external storage card. LEDs on the cable and notebook front of the modem provide status information. computer clip Power LED Data LED LEDs The USB 305 modem has two LEDs that show the current status of the modem. Rev 1.0 May.09... -
Page 18: Removing A Sim Card
USB 305 HSPA Modem User Guide State Indicates Power Indicates one of the following states: • The modem is not inserted in the computer. • The computer is off or in “suspend and resume” mode. • The modem radio has been turned off using the connection management software. -
Page 19: Using The Microsd Memory Card
Using your USB 305 Modem Remove the SIM card. Note: If the tray comes all the way out, do not discard it. Carefully insert the empty tray back into the modem. Using the microSD memory card The USB 305 modem is built to accommodate a microSD external storage card. To use a memory card: If the modem is inserted into the computer’s USB slot, remove it before inserting the microSD card. Open the flap on the side of the modem. Push the memory card into slot on the left, as shown in the ... -
Page 20: Removing The Microsd Memory Card
USB 305 HSPA Modem User Guide Removing the microSD memory card Tip: To help conserve the computer’s battery life, remove the memory card when you are not using it. To remove the memory card: Open the flap on the side of the USB modem. Push the microSD card in and then release it. Gently pull the microSD card out. Using the extension cable and notebook computer clip Your USB 305 modem comes with an extension cable and clip. ... - Page 21 Using your USB 305 Modem Note: Do not insert the USB 305 modem or the USB extension cable into a USB hub or, if your keyboard is separate from your notebook computer, a USB slot on your keyboard. To use the extension cable and clip: Place the modem into the laptop clip, as shown in the illus‐...
-
Page 22: Connection Management Software
USB 305 HSPA Modem User Guide Connect the larger end of the USB extension cable to the USB connector on your modem. Attach this end to the USB connector on the modem Attach this end to the USB port on your computer Connect the other end of the extension cable to the USB slot on your computer. Connection management software Your USB modem comes with connection management software. The features and options in the connection manager software vary, depending on your service provider, but in general, the connection manager software enables you to: • Initiate data connections •... -
Page 23: Care And Maintenance Of Your Usb Modem
4: Care and Maintenance of Your USB Modem As with any electronic device, the USB 305 modem must be handled with care to ensure reliable operation. Follow these guidelines when you use and store your USB 305 modem: • Do not apply adhesive labels to the SIM card. This may cause it to jam inside the slot, or prevent it from being inserted properly. • When not installed in your computer, store the USB 305 modem and SIM card in a safe place. • The USB 305 modem should fit easily into your computer’s USB port. Forcing the USB 305 modem into the port may damage the connector pins. • Protect the USB 305 modem from liquids, dust, and excessive heat. (See the “Environmental specifications” on page 28 for maximum tolerances.) Rev 1.0 May.09... - Page 24 USB 305 HSPA Modem User Guide 2131219...
-
Page 25: Faq And Troubleshooting
Use the USB extension cable and laptop clip in area with low signal strength or when the position of the USB port on the computer makes it awkward to insert the modem directly into the laptop computer. For more information on using the USB extension cable and laptop clip, see “Using the extension cable and notebook computer clip” on page 20. Is there a limit to the size of microSD card that I can use with the USB 305 modem? The USB 305 modem was designed and tested for 16 GB microSD memory cards (the largest available at the time the modem was developed and tested). However, as memory card technology develops and cards come onto the market that have a larger capacity, the USB 305 modem should support those as well. I inserted the microSD card, but the memory card drive doesn’t appear on my computer? - Page 26 USB 305 HSPA Modem User Guide 2131219...
-
Page 27: Technical Specifications
6: Technical Specifications Radio frequency and electrical specifications Table 6-1: Radio frequency and electrical specifications Compliance 3 GPP Release 6 Transmit GSM 1900 (PCS): 1850 to 1910 MHz GSM 1800 (DCS):1710 to 1785 MHz EGSM 900: 880 to 915 MHz GSM 850: 824 to 849 MHz WCDMA 2100 (Band I): 1920 to 1980 MHz WCDMA 1900 (Band II): 1850 to 1910 MHz... -
Page 28: Environmental Specifications
USB 305 HSPA Modem User Guide Environmental specifications Operating 0°C to +45°C temperature (+32°F to +113°F) Storage -20°C to +85°C temperature (-4°F to +185°F) Humidity 85%, non-condensing Vibration Random vibration, 10 to 1000 Hz, nominal 6G RMS in each of 3 mutually perpendicular axes. -
Page 29: Regulatory And Safety Information
7: Regulatory and Safety Information Notice Because of the nature of wireless communications, trans‐ mission and reception of data can never be guaranteed. Data may be delayed, corrupted (that is, have errors), or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well‐constructed network, the Sierra Wireless modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless and its affiliates accept no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the Sierra Wireless modem, or for failure of the Sierra Wireless modem to transmit or receive such data. Safety and hazards The USB 305 modem MUST BE POWERED OFF in all areas that may be susceptible to radio interference, in particular: • Prohibited areas Obey all signs and notices and follow all rules and regula‐ tions. Power off the USB 305 modem when instructed to do so or when you suspect that it may cause interference or danger. • In areas where blasting is in progress • Where explosive atmospheres may be present Areas with a potentially explosive atmosphere are not always clearly marked. Such areas include gas stations, fuel depots, chemical transfer or storage facilities, areas where blasting is in progress, areas where the air contains chemicals or particles such as grain, dust, or metal pow‐ ders, and any other area where you would normally be ... -
Page 30: Regulatory Information For North America
USB 305 HSPA Modem User Guide • On board aircraft In addition to Federal Aviation Authority (FAA) require‐ ments, many airline regulations state that you must sus‐ pend wireless operations before boarding an aircraft. The USB 305 modem is capable of transmitting signals that could interfere with various onboard systems and controls. Failure to observe this instruction may lead to suspension or denial of cellular telephone services to the offender, legal action, or both. Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open. The USB 305 modem may be used normally at this time. • While operating a vehicle The driver or operator of any vehicle should not use a wireless data device while in control of a vehicle. Doing so detracts from the driver or operatorʹs ability to control and operate the vehicle. In some countries, using such commu‐ nications devices while in control of a vehicle is an offence. Regulatory information for North America CAUTION: Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. The design of the USB 305 modem complies with U.S. Federal Communications Commission (FCC) guidelines respecting safety levels of radio frequency (RF) exposure for portable devices, which in turn are consistent with the following safety standards previously set by Canadian, U.S. and international ... - Page 31 Regulatory and Safety Information Note: The USB 305 modem is approved for normal-size notebook computers only (typically with 12 inches or larger display screens) and must not be used in any unapproved configuration. For details, contact Sierra Wireless. This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause ...
- Page 32 USB 305 HSPA Modem User Guide contracts or any successor regulations. If further government regulations apply, it is your responsibility to ensure compliance with such regulations. 2131219...
-
Page 33: Index
Index microSD, 10, 19 modem, inserting, 15 account, 11 network overview, 11 channel raster, 27 notebook computer clip, 20 channel spacing, 27 clip, 20 connect to the network, 16 coverage area, 11 operating systems supported, 13 electrical specifications, 27 environmental specifications, 28 profile, 13 extension cable, 20 external memory storage, 10, 19 external SD, 10, 19 external storage card, 19 radio frequency specifications, 27 receive frequencies, 27 regulatory information, 29 requirements, software, 14 FAQ, 25 RF specifications, 27 flash drive, 19 roaming, 11 frequencies receive, 27 transmit, 27 frequency stability, 27 safety notice, 29 SIM card inserting, 14 removing, 18 humidity, 28 software requirements, 14 specifications, 27– 28 electrical, 27 environmental, 28 radio frequency, 27 I/O space (input/output space), 13... - Page 34 USB 305 HSPA Modem User Guide USB 305 modem, inserting, 15 Windows 2000 support, 13 USB port requirements, 13 Windows Vista support, 13 Windows XP support, 13 vibration, 28 2131219...
