Technical Specifications - Omcan MS-IT-0300-A Instruction Manual

Technical Specifications

Model
Blade Size
Power
Cheese Slicing
Slicing Volume*
RPM
Cutting Size
Cut Thickness
Electrical
Weight
Dimensions
Item Number
*Results may vary due to product consistency and temperature
Installation
The slicer must be mounted horizontally on a stable, robust and antiskid base adequate to support its weight.
The suggested height of the working table is of about 800mm. It must be checked that the product holder is not
clamped and the product to be cut can be easily loaded.
WARNING: To prevent the risk of crushing hazard, locate the machine in a manner that allows a clear space
between the moving table and any permanent structure.
PRELIMINARY CLEANING
Before connecting the plug clean off the protective oil from the machine.
WARNING
The working table must always be cleaned.
ELECTRICAL SUPPLY
The machine must be installed in the proximity of a mains socket. Check that the power supply voltage
corresponds to that described on the information label and that it is connected to an adequate earth.
1. Connect the plug.
2. Check that the blade cover fastener handle is tight screwed.
3. Check that the blade sharpener is lowered and the protective cover is closed.
MANUAL FUNCTIONING
1. Press push button blade start.
MS-IT-0300-A
12" / 300mm
0.5 HP / 0.37kW (x2)
8 hours or more
200
8.85" x 8.66" / 225 x 220mm
0" - 0.6" / 0 - 14mm
120V / 60 / 1
90.2 lbs. / 41 kgs.
25.2" x 21.7" x 20.9" / 640 x 550 x 530mm
13654
6
