internal side of the protection ring.
9. After cleaning re-position the blade cover, insert the fastener and screw in a clockwise direction to clamp
the blade cover. Lower the sharpener protective cover.
IMPORTANT
Leave all the parts to soak in warm water and washing-up liquid (do not use strong detergents) and clean them
by using a brush or a cloth. Rinse them in warm water and dry them.
To assemble the machine follow the reverse procedure as described for disassembly.
GUIDES LUBRICATION
This operation must be performed after cleaning the slicer or whenever the sliding is difficult. Use food safe oil
only.
LUBRICATION OF THE GUIDE BAR OF THE LAST SLICE DEVICE
1. Drop a small amount of food grade oil on the bar.
2. Let the last slice device slide on the guide bar.
LUBRICATION OF THE GUIDE BAR OF THE PRODUCT HOLDER CARRIAGE
1. Push the product holder towards the operator.
2. Pour the food grade lubricating oil into the special carriage bar lubricator.
3. Push the product holder to and from and repeat the operation. Re-position it towards the operator.
PROBLEM
The machine vibrates, overheats
and emits a foul smell.
The blade cannot be sharpened
any longer. The sharpening is no
regular.
On pushing the start push button
the machine does not start.
The carriage and the last slice
device run with difficulty.
Stop it immediately and check that the voltage corresponds to that de-
scribed on the rating label.
Clean the grinding wheels of the sharpener and check the wear of the
blade.
Check if power missing. Check the safety devices.
Lubricate the guide bars.
11
Maintenance

Troubleshooting

CORRECTIVE ACTION
