Omcan MS-IT-0300-A Instruction Manual page 10

Maintenance
SPARE PARTS
In the event that replacement parts need to be fitted, request only original spare parts.
CLEANING
The machine must be cleaned once a day or more frequently if necessary. Clean all the parts using a cloth
sprinkled with water and washing up liquid (do not use strong detergents) and a brush.
WARNING
Do not use water jet
DANGER
During the cleaning operations take great care: danger of accident.
COMPONENTS REMOVAL
PRODUCT HOLDER
1. Loose the product holder by rotating the product holder clamping handle in a counterclockwise direction.
2. Position to zero the slice thickness control to remove the product holder.
3. Push the product holder towards the operator until it clicks. The click will inform the operator that the
product holder is clamped.
4. Lift the last slice device from the guide bar.
5. Lift the product holder from the carriage.
IMPORTANT
The slice thickness control is clamped on zero.
BLADE COVER
1. Rotate the slice deflector and keep it away from the blade.
2. Loose the blade cover fastener handle by rotating it in a counterclockwise direction.
3. Push on the handle in the direction indicated by the arrow to lift the blade cover from the blade.
4. Lift the blade cover.
ATTENTION
Once removed the blade cover, an interlocking device stops the rotation of the blade.
DANGER
During the cleaning operations of the blade, pay attention to an accidental contact with it.
5. Press a damp cloth on the front side of the blade and move slowly from the center towards the edge in the
direction of the arrow.
6. Follow these instructions to clean the back side of the blade.
7. With a cloth dry both sides of the blade following this procedure.
8. Insert a damp cloth between the blade and the protection ring. Pull it outwards and rotate it to clean the
